versa VW-DP Motion User manual

SPECIFICATIONS
Range: 12 meters in sensor-facing direction
12 meters at 45°angle from sensor-facing direction
Sensor Optical View Pattern (side view, in meters)
Optical Fields-of-View:
Long-range Mid-range Short-range
44 36 18
Sensor Optical View Pattern (top view, in meters)
Note: Specifications are subject to change without notice.
VWMSpod-012WPI Motion Sensor
Operation and Specifications SUREN
©2010 SUREN Systems, Ltd.. All rights reserved. SUREN™, PYROFLEX™, HighBar™ are trademarks of SUREN.
www.surensystems.com
IR Sensor:
Dual elements
Power Supply:
CR123A 3V Battery
Power Supply Current:
22uA ( no alarm )
Tamper Switch:
Sealed dome-contact
Housing Material:
High-impact ABS
Dimensions:
73.5 x 60.5x 43.5mm ( H x W x D )
Approvals/qualification:
( Pending )
Pet immunity:10Kg
Events Detection:
HighBar™ false alarm rejection
processor
RF Immunity:
20 V/m, 10-1000 MHz;
10 V/m, 1-2 GHz
White Light Immunity:
6500 lux
Sensitivity:
Selectable: 2-event or 3-event
Operating Temperature
Range:
-40°C to +55° C
Accessories:
Mounting bracket:
MB-100
1.0
2.3
036912
1.0
3.0
0 3 6 9 12
2.0
1.0
2.3
0 3 6 9 12
Short range
Short range Long range
Middle range
0
6
9
3
6
0
12
One FOV ( field of view)
9
3
Long range
Middle range
The VWMSpod-012WPI is a professional state-of-the art motion sensor
engineered with the world's best components and materials.starting with a
TM
SUREN HihgView lens and a top quality infrared detector, Next, a patented
modern DSP ASIC directly converts the infrared detector signal into digital
form, for best reliability and stability. Finally, the signal is evaluated by a
SUREN’s HighBar™ processor, for "best-in-class" false alarm rejection with
excellent intruder detection.
SENSOR INITIALIZATION
Following power-on, a VWMSpod-012WPI sensor is fully operational after a
one-minute warm-up.
WALK TEST
Note: The VWMSpod-012WPI should be tested once per year.
The LED should turn ON (for Alarm) after about two to four normal steps.
Each time the LED turns ON, wait for it to turn OFF. Then, wait 12 seconds
before continuing the walktest.When there is no motion in the monitored area,
the LED should remain OFF. It can be turned off after 5 mins, so it doesn’t
continue to eat up power.
ALARM PROCESSING
Dual-element detector fields-of-view alternate between (+) and (-)polarity.
HighBar™-qualified signal events are counted as "pulses"exclusively when
polarity alternates. Depending on sensitivitysetting, (+,-), (-,+), (+,-,+) or (-
,+,-) will cause an alarm.
PET IMMUNITY
The VWMSpod-012WPI is designed to allow the presence of pets (10kg
or lighter) without signaling an alarm. It includes a special microelement
lens array that produces m uch stronger optical signals for
humans than for pets 10kg or lighter. Furthermore, the optical
sensitivity of each VWMSpod-012WPI is factory-calibrated to ensure
accurate discrimination between humans and pets.
Note: Pets come in many varieties. Some pets (especially larger
ones with very short hair), even if lighter than 10kg, may produce
enough infrared radiation to cause alarms. VWMSpod-012WPI users
are strongly advised to test the sensor with their own pets, in order
to verify that the VWMSpod-012WPI will not signal an alarm when their
pets are moving within its fields of view.
The diagram below shows the VWMSpod-012WPI's zones of greatest
human/pet discrimination. The VWMSpod-012WPI should be mounted so
that pets will occupy onlythe lighter-colored spaces.
SUREN Part no.: 0-ML00-3134-01-1 Rev.3
Limitations of Sensor Products: Sensor products and associated systems do not offer guaranteed anyone for any consequential or incidental damages for breach of this or any other warranty, express or
performance in ordinary situations or in special situations including but not limited to burglary, fire, or other implied, or upon any other basis of liability whatsoever, even if the loss or damage is caused by its own
emergencies. They may fail to function for diverse reasons, including (but not limited to): power failure, negligence or fault.
dead batteries, improper installation, coverage “blind spots”, coverage areas overlooked during Seller does not represent that the products it sells may not be compromised or circumvented; that the
installation, component failure, or inadequate maintenance. Sensors and their associated systems should products will prevent any personal injury or property loss by burglary, robbery, fire or otherwise; or that the
be checked weekly to ensure that all devices are working properly. products will in all cases provide adequate warning or protection. Customer understands that a properly
SUREN LIMITED WARRANTY installed and maintained alarm system may only reduce the risk of a burglary, robbery, or fire without
SUREN Systems, Ltd., of Fo Tan, Shatin, Hong Kong, warrants its products to be in conformance with its warning, but it is not insurance or a guarantee that such will not occur or that there will be no personal injury
own plans and specifications and to be free from defects in materials and workmanship under normal use or property loss as a result.
and service for twelve months from the date of original purchase. Seller's obligation shall be limited to Consequently, seller shall have no liability for any personal injury; property damage or other loss based on a
repairing or replacing, at its option, free of charge for materials or labor, any part which is proved not in claim the product failed to give any warning. However, if seller is held liable, whether directly or indirectly,
compliance with Seller's specifications or proves defective in materials or workmanship under normal use for any loss or damage arising under this limited warranty or otherwise, regardless of cause or origin,
and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product is altered seller's maximum liability shall not in any case exceed the purchase price of the product, which shall be the
or improperly repaired or serviced by anyone other than Seller. For warranty service, return transportation complete and exclusive remedy against seller.
prepaid, to SUREN Systems, Ltd., Unit 15, 12/F, Block B, Wah Sang Industrial Building, 14-18 Wong Chuk
Yeung Street, Fo Tan, Shatin, Hong Kong. Seller has no obligation to attend the buyer's location to retrieve This warranty replaces any previous warranties and is the only warranty made by Seller on this product. No
the goods or make repairs on site. increase or alteration, written or verbal, of the obligations of this Limited Warranty is authorized.
There are no warranties, expressed or implied, of merchantability, or fitness for a particular purpose or
otherwise, which extend beyond the description on the face hereof. In no case shall seller be liable to U.S. Patent NO: 7,042,134 7,141,910 Patents issued and pending worldwide.
SPECIFICATIONS
Range: 12 meters in sensor-facing direction
12 meters at 45°angle from sensor-facing direction
Sensor Optical View Pattern (side view, in meters)
Optical Fields-of-View:
Long-range Mid-range Short-range
44 36 18
Sensor Optical View Pattern (top view, in meters)
Note: Specifications are subject to change without notice.
VWMSpod-012WPI Motion Sensor
Operation and Specifications SUREN
©2010 SUREN Systems, Ltd.. All rights reserved. SUREN™, PYROFLEX™, HighBar™ are trademarks of SUREN.
www.surensystems.com
IR Sensor:
Dual elements
Power Supply:
CR123A 3V Battery
Power Supply Current:
22uA ( no alarm )
Tamper Switch:
Sealed dome-contact
Housing Material:
High-impact ABS
Dimensions:
73.5 x 60.5x 43.5mm ( H x W x D )
Approvals/qualification:
( Pending )
Pet immunity:10Kg
Events Detection:
HighBar™ false alarm rejection
processor
RF Immunity:
20 V/m, 10-1000 MHz;
10 V/m, 1-2 GHz
White Light Immunity:
6500 lux
Sensitivity:
Selectable: 2-event or 3-event
Operating Temperature
Range:
-40°C to +55° C
Accessories:
Mounting bracket:
MB-100
1.0
2.3
036912
1.0
3.0
0 3 6 9 12
2.0
1.0
2.3
0 3 6 9 12
Short range
Short range Long range
Middle range
0
6
9
3
6
012
One FOV ( field of view)
9
3
Long range
Middle range
The VWMSpod-012WPI is a professional state-of-the art motion sensor
engineered with the world's best components and materials.starting with a
TM
SUREN HihgView lens and a top quality infrared detector, Next, a patented
modern DSP ASIC directly converts the infrared detector signal into digital
form, for best reliability and stability. Finally, the signal is evaluated by a
SUREN’s HighBar™ processor, for "best-in-class" false alarm rejection with
excellent intruder detection.
SENSOR INITIALIZATION
Following power-on, a VWMSpod-012WPI sensor is fully operational after a
one-minute warm-up.
WALK TEST
Note: The VWMSpod-012WPI should be tested once per year.
The LED should turn ON (for Alarm) after about two to four normal steps.
Each time the LED turns ON, wait for it to turn OFF. Then, wait 12 seconds
before continuing the walktest.When there is no motion in the monitored area,
the LED should remain OFF. It can be turned off after 5 mins, so it doesn’t
continue to eat up power.
ALARM PROCESSING
Dual-element detector fields-of-view alternate between (+) and (-)polarity.
HighBar™-qualified signal events are counted as "pulses"exclusively when
polarity alternates. Depending on sensitivitysetting, (+,-), (-,+), (+,-,+) or (-
,+,-) will cause an alarm.
PET IMMUNITY
The VWMSpod-012WPI is designed to allow the presence of pets (10kg
or lighter) without signaling an alarm. It includes a special microelement
lens array that produces m uch stronger optical signals for
humans than for pets 10kg or lighter. Furthermore, the optical
sensitivity of each VWMSpod-012WPI is factory-calibrated to ensure
accurate discrimination between humans and pets.
Note: Pets come in many varieties. Some pets (especially larger
ones with very short hair), even if lighter than 10kg, may produce
enough infrared radiation to cause alarms. VWMSpod-012WPI users
are strongly advised to test the sensor with their own pets, in order
to verify that the VWMSpod-012WPI will not signal an alarm when their
pets are moving within its fields of view.
The diagram below shows the VWMSpod-012WPI's zones of greatest
human/pet discrimination. The VWMSpod-012WPI should be mounted so
that pets will occupy onlythe lighter-colored spaces.
SUREN Part no.: 0-ML00-3134-01-1 Rev.3
Limitations of Sensor Products: Sensor products and associated systems do not offer guaranteed anyone for any consequential or incidental damages for breach of this or any other warranty, express or
performance in ordinary situations or in special situations including but not limited to burglary, fire, or other implied, or upon any other basis of liability whatsoever, even if the loss or damage is caused by its own
emergencies. They may fail to function for diverse reasons, including (but not limited to): power failure, negligence or fault.
dead batteries, improper installation, coverage “blind spots”, coverage areas overlooked during Seller does not represent that the products it sells may not be compromised or circumvented; that the
installation, component failure, or inadequate maintenance. Sensors and their associated systems should products will prevent any personal injury or property loss by burglary, robbery, fire or otherwise; or that the
be checked weekly to ensure that all devices are working properly. products will in all cases provide adequate warning or protection. Customer understands that a properly
SUREN LIMITED WARRANTY installed and maintained alarm system may only reduce the risk of a burglary, robbery, or fire without
SUREN Systems, Ltd., of Fo Tan, Shatin, Hong Kong, warrants its products to be in conformance with its warning, but it is not insurance or a guarantee that such will not occur or that there will be no personal injury
own plans and specifications and to be free from defects in materials and workmanship under normal use or property loss as a result.
and service for twelve months from the date of original purchase. Seller's obligation shall be limited to Consequently, seller shall have no liability for any personal injury; property damage or other loss based on a
repairing or replacing, at its option, free of charge for materials or labor, any part which is proved not in claim the product failed to give any warning. However, if seller is held liable, whether directly or indirectly,
compliance with Seller's specifications or proves defective in materials or workmanship under normal use for any loss or damage arising under this limited warranty or otherwise, regardless of cause or origin,
and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product is altered seller's maximum liability shall not in any case exceed the purchase price of the product, which shall be the
or improperly repaired or serviced by anyone other than Seller. For warranty service, return transportation complete and exclusive remedy against seller.
prepaid, to SUREN Systems, Ltd., Unit 15, 12/F, Block B, Wah Sang Industrial Building, 14-18 Wong Chuk
Yeung Street, Fo Tan, Shatin, Hong Kong. Seller has no obligation to attend the buyer's location to retrieve This warranty replaces any previous warranties and is the only warranty made by Seller on this product. No
the goods or make repairs on site. increase or alteration, written or verbal, of the obligations of this Limited Warranty is authorized.
There are no warranties, expressed or implied, of merchantability, or fitness for a particular purpose or
otherwise, which extend beyond the description on the face hereof. In no case shall seller be liable to U.S. Patent NO: 7,042,134 7,141,910 Patents issued and pending worldwide.
The VW-DP Motion is a professional state-of-the art motion sensor engineered with the world's best components and materials starting with a Versa
HighView™ lens and a top quality infrared detector. Next, a patented modern DSP ASIC directly converts the infrared detector signal into digital form, for
best reliability and stability. Finally, the signal is evaluated by a HighBar™ processor, for "best-in-class" false alarm rejection with excellent intruder detection.
Sensor Initialization
Following power-on, a VW-DP Motion sensor is fully operational after a one-minute warm-up.
Walk Test
Note: The VW-DP Motion should be tested once per year. The LED should turn ON (for Alarm) after about two to four normal steps. Each time the LED
turns ON, wait for it to turn OFF. Then, wait 12 seconds before continuing the walktest. When there is no motion in the monitored area, the LED should
remain OFF. It can be turned o after 5 mins, so it doesn’t continue to eat up power.
Alarm Processing
Dual-element detector fields-of-view alternate between (+) and (-) polarity. HighBar™ - qualified signal events are counted as "pulses" exclusively when
polarity alternates. Depending on sensitivity setting, (+,-), (-,+), (+,-,+) or (-,+,-) will cause an alarm.
Pet Immunity
The VW-DP Motion is designed to allow the presence of pets (60 lbs or lighter) without signaling an alarm. It includes a special microelement lens array
that produces much stronger optical signals for humans than for pets 60 lbs or lighter. Furthermore, the optical sensitivity of each VW-DP Motion is
factory-calibrated to ensure accurate discrimination between humans and pets.
Note: Pets come in many varieties. Some pets (especially larger ones with very
short hair, even if lighter than 60 lbs) may produce enough infrared radiation to
cause alarms. VW-DP Motion users are strongly advised to test the sensor with
their own pets, in order to verify that the VW-DP MotionI will not signal an alarm
when their pets are moving within its fields of view.
This diagram shows the VW-DP Motion's zones of greatest human/pet
discrimination. The VW-DP Motion should be mounted so that pets will occupy
only the lighter-colored spaces.
Specifications
Range: 40 feet in sensor-facing direction , 40 feets at 45° angle from sensor-facing direction
Sensor Optical View Pattern (side view, in feet) Sensor Optical View Pattern: (top view, in feet)
Optical Fields-of-View: Long-range (44) Mid-range (36) Short-range (18)
Operation & Specifications
VW-DP Motion
Motion Sensor
SPECIFICATIONS
Range: 12 meters in sensor-facing direction
12 meters at 45°angle from sensor-facing direction
Sensor Optical View Pattern (side view, in meters)
Optical Fields-of-View:
Long-range Mid-range Short-range
44 36 18
Sensor Optical View Pattern (top view, in meters)
Note: Specifications are subject to change without notice.
VWMSpod-012WPI Motion Sensor
Operation and Specifications SUREN
©2010 SUREN Systems, Ltd.. All rights reserved. SUREN™, PYROFLEX™, HighBar™ are trademarks of SUREN.
www.surensystems.com
IR Sensor:
Dual elements
Power Supply:
CR123A 3V Battery
Power Supply Current:
22uA ( no alarm )
Tamper Switch:
Sealed dome-contact
Housing Material:
High-impact ABS
Dimensions:
73.5 x 60.5x 43.5mm ( H x W x D )
Approvals/qualification:
( Pending )
Pet immunity:10Kg
Events Detection:
HighBar™ false alarm rejection
processor
RF Immunity:
20 V/m, 10-1000 MHz;
10 V/m, 1-2 GHz
White Light Immunity:
6500 lux
Sensitivity:
Selectable: 2-event or 3-event
Operating Temperature
Range:
-40°C to +55° C
Accessories:
Mounting bracket:
MB-100
1.0
2.3
036912
1.0
3.0
0 3 6 9 12
2.0
1.0
2.3
0 3 6 9 12
Short range
Short range Long range
Middle range
0
6
9
3
6
012
One FOV ( field of view)
9
3
Long range
Middle range
The VWMSpod-012WPI is a professional state-of-the art motion sensor
engineered with the world's best components and materials.starting with a
TM
SUREN HihgView lens and a top quality infrared detector, Next, a patented
modern DSP ASIC directly converts the infrared detector signal into digital
form, for best reliability and stability. Finally, the signal is evaluated by a
SUREN’s HighBar™ processor, for "best-in-class" false alarm rejection with
excellent intruder detection.
SENSOR INITIALIZATION
Following power-on, a VWMSpod-012WPI sensor is fully operational after a
one-minute warm-up.
WALK TEST
Note: The VWMSpod-012WPI should be tested once per year.
The LED should turn ON (for Alarm) after about two to four normal steps.
Each time the LED turns ON, wait for it to turn OFF. Then, wait 12 seconds
before continuing the walktest.When there is no motion in the monitored area,
the LED should remain OFF. It can be turned off after 5 mins, so it doesn’t
continue to eat up power.
ALARM PROCESSING
Dual-element detector fields-of-view alternate between (+) and (-)polarity.
HighBar™-qualified signal events are counted as "pulses"exclusively when
polarity alternates. Depending on sensitivitysetting, (+,-), (-,+), (+,-,+) or (-
,+,-) will cause an alarm.
PET IMMUNITY
The VWMSpod-012WPI is designed to allow the presence of pets (10kg
or lighter) without signaling an alarm. It includes a special microelement
lens array that produces m uch stronger optical signals for
humans than for pets 10kg or lighter. Furthermore, the optical
sensitivity of each VWMSpod-012WPI is factory-calibrated to ensure
accurate discrimination between humans and pets.
Note: Pets come in many varieties. Some pets (especially larger
ones with very short hair), even if lighter than 10kg, may produce
enough infrared radiation to cause alarms. VWMSpod-012WPI users
are strongly advised to test the sensor with their own pets, in order
to verify that the VWMSpod-012WPI will not signal an alarm when their
pets are moving within its fields of view.
The diagram below shows the VWMSpod-012WPI's zones of greatest
human/pet discrimination. The VWMSpod-012WPI should be mounted so
that pets will occupy onlythe lighter-colored spaces.
SUREN Part no.: 0-ML00-3134-01-1 Rev.3
Limitations of Sensor Products: Sensor products and associated systems do not offer guaranteed anyone for any consequential or incidental damages for breach of this or any other warranty, express or
performance in ordinary situations or in special situations including but not limited to burglary, fire, or other implied, or upon any other basis of liability whatsoever, even if the loss or damage is caused by its own
emergencies. They may fail to function for diverse reasons, including (but not limited to): power failure, negligence or fault.
dead batteries, improper installation, coverage “blind spots”, coverage areas overlooked during Seller does not represent that the products it sells may not be compromised or circumvented; that the
installation, component failure, or inadequate maintenance. Sensors and their associated systems should products will prevent any personal injury or property loss by burglary, robbery, fire or otherwise; or that the
be checked weekly to ensure that all devices are working properly. products will in all cases provide adequate warning or protection. Customer understands that a properly
SUREN LIMITED WARRANTY installed and maintained alarm system may only reduce the risk of a burglary, robbery, or fire without
SUREN Systems, Ltd., of Fo Tan, Shatin, Hong Kong, warrants its products to be in conformance with its warning, but it is not insurance or a guarantee that such will not occur or that there will be no personal injury
own plans and specifications and to be free from defects in materials and workmanship under normal use or property loss as a result.
and service for twelve months from the date of original purchase. Seller's obligation shall be limited to Consequently, seller shall have no liability for any personal injury; property damage or other loss based on a
repairing or replacing, at its option, free of charge for materials or labor, any part which is proved not in claim the product failed to give any warning. However, if seller is held liable, whether directly or indirectly,
compliance with Seller's specifications or proves defective in materials or workmanship under normal use for any loss or damage arising under this limited warranty or otherwise, regardless of cause or origin,
and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product is altered seller's maximum liability shall not in any case exceed the purchase price of the product, which shall be the
or improperly repaired or serviced by anyone other than Seller. For warranty service, return transportation complete and exclusive remedy against seller.
prepaid, to SUREN Systems, Ltd., Unit 15, 12/F, Block B, Wah Sang Industrial Building, 14-18 Wong Chuk
Yeung Street, Fo Tan, Shatin, Hong Kong. Seller has no obligation to attend the buyer's location to retrieve This warranty replaces any previous warranties and is the only warranty made by Seller on this product. No
the goods or make repairs on site. increase or alteration, written or verbal, of the obligations of this Limited Warranty is authorized.
There are no warranties, expressed or implied, of merchantability, or fitness for a particular purpose or
otherwise, which extend beyond the description on the face hereof. In no case shall seller be liable to U.S. Patent NO: 7,042,134 7,141,910 Patents issued and pending worldwide.
IR Sensor:
Dual elements
Sensitivity:
Selectable: 2-event
or 3-event
Events Detection:
HighBar™ false alarm
rejection processor
Housing Material:
High-impact ABS
Power Supply :
CR123A 3V Battery
Dimensions:
2.9” x 2.4” x 1.7”
( H x W x D )
RF Immunity:
20 V/m, 10-1000 MHz;
10 V/m, 1-2
Operating
Temperature Range:
-40°C to +55° C
Power Supply
Current:
22uA (no alarm) GHz
Approvals/
qualification:
(Pending)
White Light
Immunity:
6500 lux
Mounting bracket:
MB-100
Tamper Switch:
Sealed dome-contact
Pet immunity:
60 lbs
©2020 Versa Wireless Inc. All rights reserved. PYROFLEX™, HighBar™ are trademarks used by permission. Versa Part No: VW-DP Motion. Rev. 1
www.versawireless.com
7.5’
3’
0 10’ 20’ 30’ 40’
7.5’
3’
0 10’ 20’ 30’ 40’
9’
6’
3’
0 10’ 20’ 30’ 40’
0
10’
20’
30’
40’
0
10’
20’
30’

SPECIFICATIONS
Range: 12 meters in sensor-facing direction
12 meters at 45°angle from sensor-facing direction
Sensor Optical View Pattern (side view, in meters)
Optical Fields-of-View:
Long-range Mid-range Short-range
44 36 18
Sensor Optical View Pattern (top view, in meters)
Note: Specifications are subject to change without notice.
VWMSpod-012WPI Motion Sensor
Operation and Specifications SUREN
©2010 SUREN Systems, Ltd.. All rights reserved. SUREN™, PYROFLEX™, HighBar™ are trademarks of SUREN.
www.surensystems.com
IR Sensor:
Dual elements
Power Supply:
CR123A 3V Battery
Power Supply Current:
22uA ( no alarm )
Tamper Switch:
Sealed dome-contact
Housing Material:
High-impact ABS
Dimensions:
73.5 x 60.5x 43.5mm ( H x W x D )
Approvals/qualification:
( Pending )
Pet immunity:10Kg
Events Detection:
HighBar™ false alarm rejection
processor
RF Immunity:
20 V/m, 10-1000 MHz;
10 V/m, 1-2 GHz
White Light Immunity:
6500 lux
Sensitivity:
Selectable: 2-event or 3-event
Operating Temperature
Range:
-40°C to +55° C
Accessories:
Mounting bracket:
MB-100
1.0
2.3
036912
1.0
3.0
0 3 6 9 12
2.0
1.0
2.3
0 3 6 9 12
Short range
Short range Long range
Middle range
0
6
9
3
6
012
One FOV ( field of view)
9
3
Long range
Middle range
The VWMSpod-012WPI is a professional state-of-the art motion sensor
engineered with the world's best components and materials.starting with a
TM
SUREN HihgView lens and a top quality infrared detector, Next, a patented
modern DSP ASIC directly converts the infrared detector signal into digital
form, for best reliability and stability. Finally, the signal is evaluated by a
SUREN’s HighBar™ processor, for "best-in-class" false alarm rejection with
excellent intruder detection.
SENSOR INITIALIZATION
Following power-on, a VWMSpod-012WPI sensor is fully operational after a
one-minute warm-up.
WALK TEST
Note: The VWMSpod-012WPI should be tested once per year.
The LED should turn ON (for Alarm) after about two to four normal steps.
Each time the LED turns ON, wait for it to turn OFF. Then, wait 12 seconds
before continuing the walktest.When there is no motion in the monitored area,
the LED should remain OFF. It can be turned off after 5 mins, so it doesn’t
continue to eat up power.
ALARM PROCESSING
Dual-element detector fields-of-view alternate between (+) and (-)polarity.
HighBar™-qualified signal events are counted as "pulses"exclusively when
polarity alternates. Depending on sensitivitysetting, (+,-), (-,+), (+,-,+) or (-
,+,-) will cause an alarm.
PET IMMUNITY
The VWMSpod-012WPI is designed to allow the presence of pets (10kg
or lighter) without signaling an alarm. It includes a special microelement
lens array that produces m uch stronger optical signals for
humans than for pets 10kg or lighter. Furthermore, the optical
sensitivity of each VWMSpod-012WPI is factory-calibrated to ensure
accurate discrimination between humans and pets.
Note: Pets come in many varieties. Some pets (especially larger
ones with very short hair), even if lighter than 10kg, may produce
enough infrared radiation to cause alarms. VWMSpod-012WPI users
are strongly advised to test the sensor with their own pets, in order
to verify that the VWMSpod-012WPI will not signal an alarm when their
pets are moving within its fields of view.
The diagram below shows the VWMSpod-012WPI's zones of greatest
human/pet discrimination. The VWMSpod-012WPI should be mounted so
that pets will occupy onlythe lighter-colored spaces.
SUREN Part no.: 0-ML00-3134-01-1 Rev.3
Limitations of Sensor Products: Sensor products and associated systems do not offer guaranteed anyone for any consequential or incidental damages for breach of this or any other warranty, express or
performance in ordinary situations or in special situations including but not limited to burglary, fire, or other implied, or upon any other basis of liability whatsoever, even if the loss or damage is caused by its own
emergencies. They may fail to function for diverse reasons, including (but not limited to): power failure, negligence or fault.
dead batteries, improper installation, coverage “blind spots”, coverage areas overlooked during Seller does not represent that the products it sells may not be compromised or circumvented; that the
installation, component failure, or inadequate maintenance. Sensors and their associated systems should products will prevent any personal injury or property loss by burglary, robbery, fire or otherwise; or that the
be checked weekly to ensure that all devices are working properly. products will in all cases provide adequate warning or protection. Customer understands that a properly
SUREN LIMITED WARRANTY installed and maintained alarm system may only reduce the risk of a burglary, robbery, or fire without
SUREN Systems, Ltd., of Fo Tan, Shatin, Hong Kong, warrants its products to be in conformance with its warning, but it is not insurance or a guarantee that such will not occur or that there will be no personal injury
own plans and specifications and to be free from defects in materials and workmanship under normal use or property loss as a result.
and service for twelve months from the date of original purchase. Seller's obligation shall be limited to Consequently, seller shall have no liability for any personal injury; property damage or other loss based on a
repairing or replacing, at its option, free of charge for materials or labor, any part which is proved not in claim the product failed to give any warning. However, if seller is held liable, whether directly or indirectly,
compliance with Seller's specifications or proves defective in materials or workmanship under normal use for any loss or damage arising under this limited warranty or otherwise, regardless of cause or origin,
and service. Seller shall have no obligation under this Limited Warranty or otherwise if the product is altered seller's maximum liability shall not in any case exceed the purchase price of the product, which shall be the
or improperly repaired or serviced by anyone other than Seller. For warranty service, return transportation complete and exclusive remedy against seller.
prepaid, to SUREN Systems, Ltd., Unit 15, 12/F, Block B, Wah Sang Industrial Building, 14-18 Wong Chuk
Yeung Street, Fo Tan, Shatin, Hong Kong. Seller has no obligation to attend the buyer's location to retrieve This warranty replaces any previous warranties and is the only warranty made by Seller on this product. No
the goods or make repairs on site. increase or alteration, written or verbal, of the obligations of this Limited Warranty is authorized.
There are no warranties, expressed or implied, of merchantability, or fitness for a particular purpose or
otherwise, which extend beyond the description on the face hereof. In no case shall seller be liable to U.S. Patent NO: 7,042,134 7,141,910 Patents issued and pending worldwide.
2. Sensor Disassembly
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch. (2.)
Remove cover. (3.) Push outward on circuit board
latch at sensor base right side. Using circuit
board battery holder as handle, gently lift circuit
board right side and remove.
VW-DP Motion Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor or bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 7.5’ or 10‘ above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views)
3. Base Hole Preparation
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
4. Wall Mounting
Use screws to mount on wall or in corner.
5. Bracket Mounting
Use screws to mount brackets in desired
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board
alignment post.
6. Strips Installation
Press on with three adhesive strips (3M).
7. Circuit Board & Battery Installation
To replace circuit board, (1.) place circuit board
right edge into two left-hand mounting slots in
sensor base. (2.) On right-hand side, gently press
circuit board into place until latch snaps over
circuit board.
Place a CR123 battery in the battery holder. Be
sure that the (+) is in the correct position.
8. Operation Programming
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if
aggressive detection is required, then use high
sensitivity. Otherwise, normal sensitivity is fine
for ordinary applications. Factory-set positions
are shown below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
9. Motion Distance Sensitivity
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2
to 4 steps.
10 LED Indicator Operation
The chart below shows possible LED indications.
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
10: LED Indicator Operation
2: Sensor Disassembly 3: Base Hole Preparation 4: Wall Mounting
Use screws to mount on wall or in corner.
5: Bracket Mounting 6: Strips lnstallation 7: Battery lnstallationCircuit Board lnstallation&
8: Operation Programming
VWMSpod-012WPI
Sensor State
Warm-up
Alarm
Normal
LED Display
OFF
ON (2 Seconds)
OFF
VWMSpod-012WPI Installation Instructions
1: Mounting Location
A. Wall mounting:
1. Sensor base fastened flat on vertical wall (± 2 degrees)
B. Bracket mounting:
1. Bracket fastened to semi-vertical surface (± 15 degrees)
2. Sensor on bracket in vertical position (± 2 degrees)
C. All mounting:
1. Height = 2.3 m or 3m above floor of monitored area
2. Clear line-of-sight from sensor to monitored area
Note: glass will block sensor’s view.
3. Wall temperature similar to walls/floor of monitored area
4. Sensor aimed away from windows and reflected sunlight
5. Sensor aimed away from heaters or heater/cooler outlets
6. Sensor aimed so that likely intruder paths cross three views
1.
2. 3.
+
-
VWMSpod-012WPI
Sensitivity
NORMAL HIGH
1-3
2-1
9: Motion Distance Sensitivity
+=
+=
2-4
3-5
3
3
2
2
1
1
1.
2.
Press on with three adhesive strips(3M).
1
3
2
In slot at sensor bottom, use screwdriver or
thumbnail to push inward (1.) on cover latch.
( 2 . ) R e m o v e c o v e r . ( 3 . ) P u s h o u t w a r d o n
circuit board latch at sensor base right side.
Using circuit board battery holder as handle,
gently lift circuit board right side and remove.
Identify necessary holes on diagram;
1. For wall mounting,knock out hole covers.
2. For corner or 45 degree wall mounting, use
drill to open at least two holes at base side
depressions.
3. For bracket mounting, use drill to open a 3
mm hole in the center of the square recess at
the rear of the base. See 5 for more.
U s e s c r e w s t o m o u n t b r a c k e t i n d e s i r e d
location. Use screw to mount sensor base onto
bracket. Refer to 7 for setting circuit board alignment
post.
To replace circuit board, (1.) place circuit
board right edge into two left-hand mounting
slots in sensor base. (2.) On right-hand side,
gently press circuit board into place until latch
snaps over circuit board.
Place a CR123 battery in the battery holder.
Be sure that the (+) is in the correct position.
Set J4 (Sensitivity setting) according to need.
With normal sensitivity, detection occurs in 3 to 5
steps. With high sensitivity, detection occurs in 2 to
4 steps.
The chart below shows possible LED indications.
If there is a way for intruders to pass only a very
short distance in the sensor's view, or if aggressive
detection is required, then use high sensitivity.
Otherwise, normal sensitivity is fine for ordinary
applications. Factory-set positions are shown
below in gray.
NOTE: LED turn on is for test only, as continual
LED use shortens battery life.
OFF
J4
ON
345MHz
S3
Frequency
319MHz
S3
VW-DP Motion
VW-DP Motion
QOLSYS/ITI
319MHz
Honeywell/2GIG
345MHz

VW-DP Motion Detector Quick User Overview
On power up:
Flash LED
Send RF power up message
While tamper switch open and for 5 minutes after tamper switch closed:
PIR is in “Walk Test Mode”
If PIR triggers: flash alarm LED on for 2 seconds, send reed switch / loop alarm message
After PIR alarm clears, send reed switch / loop alarm clear message
Approximately 12 second hold-o between subsequent reed switch / loop alarm message transmissions and LED flash. This hold-o is partially
determined by the A&R PIR module ALARM signal operation.
From 5 minutes after tamper switch closed:
PIR is in “Normal Operation Mode”
LED alarm indicator disabled
If PIR trigger: send reed switch / loop alarm message
After PIR alarm clears, send reed switch / loop alarm clear message
180 second (3 minute) hold-o between subsequent reed switch / loop alarm message transmissions.
Protocol Selection with Switch:
When the Switch is ON -> transmits using QOLSYS, INTERLOGIX (319.5 Mhz).
When the Switch is OFF -> transmits using Honeywell 5800, 2GIG (345MHz).
Quick
Start Guide

Caution:

ThisdevicecomplieswithPart15oftheFCCrulesandIndustryCanadalicense‐exemptRSS
standard(s).Operationissubjecttothefollowingtwoconditions:(1)thisdevicemaynotcause
harmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,including
interferencethatmaycauseundesiredoperation.

ThemanufacturerisnotresponsibleforanyradioorTVinterferencecausedbyunauthorized
modificationsorchangetothisequipment.Suchmodificationsorchangecouldvoidtheuser’s
authoritytooperatetheequipment.

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,
maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmful
interferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipment
offandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthe
followingmeasures:
‐‐Reorientorrelocatethereceivingantenna.
‐‐Increasetheseparationbetweentheequipmentandreceiver.
‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

ThedevicehasbeenevaluatedtomeetgeneralRFexposurerequirement.


