Satel INDIGO User manual

®DIGITAL GLASS BREAK DETECTOR
INDIGO
indigo_e 06/04
The INDIGO digital glass breaking detector can be used for detection of shattering of
ordinary, armored and/or laminated glass. The detector sounds an alarm upon recording
the occurrence of a low-frequency signal (impact sound) or a high-frequency signal
(sound of broken glass). The low-frequency sound wave caused by the impact makes
the detector analyze the high-frequency channel. The shock wave sound registered by
the microphone is signaled by blinking of the LED. The analysis of high-frequency chan-
nel lasts 4 seconds. If a high-
frequency sound, i.e. the glass
breaking sound, occurs during
that time, the detector will trip an
alarm.
TERMINALS:
COM - ground (0V)
12V - supply input (9-16V
DC)
NC - alarm relay (NC)
TMP - tamper contact (NC)
Two pairs of pins are provided
for setting performance pa-
rameters of the glass breaking
detector (see Table). The test mode is used for the functional check of
the detector. In this mode the detector will only
signal an alarm when a high-frequency sound is
recorded by the microphone.
The LED lights red when the detector is actu-
ated, which enables the installer to check the
detector for correct functioning.
The detector monitors the supply voltage. If the
voltage drops below 9V (±5%) for more than
2 seconds, the detector will signalize a violation
state until a voltage of minimum 9V (±5%) is restored.
INSTALLATION
The detector is designed for indoor installation. It should be mounted directly on the wall
so that the protected glass surfaces are kept within the detector coverage area. It should
be borne in mind that all shades, curtains, furniture upholstery, soundproof tiles etc. will
reduce the detector range.
To install the detector, open the housing, remove the printed circuit board and make
suitable openings for cable entry and screws in the rear wall of the housing.
J3 J4
Normal mode
Test mode
LED indicator ON
LED indicator OFF
- pins open - pins shorted
Figure 1. View of INDIGO detector board
LED
jumpers for setting
operating parameters
tamper contact
alarm relay
micro
p
hon
NC NC TMPTMPCOM+12V
J3
J4
LED ON / OFF
TEST
-SENS. +
high-frequency
channel
sensitivity control

Figure 2 shows typical examples of
connecting the detectors in EOL
(parameter) configuration and 2EOL
(two-parameter) configuration.
Resistors should be mounted inside
the detector housing.
TECHNICAL DATA
Nominal supply voltage.......................................................................................... 12V DC
Mean power consumption (±10%) ...........................................................................12.5mA
Violation signaling time ....................................................................................................2s
Detection range..................................................................................................... up to 6m
Operating temperature range............................................................................-10...+50°C
Housing dimensions.......................................................................................48x78x23mm
Latest EC declaration of conformity and product approval certificates can
be downloaded from our Web site www.satel.pl
SATEL sp. z o.o.
ul. Schuberta 79
80-172 Gdańsk
POLAND
tel. + 48 58 320 94 00
[email protected]
www.satel.pl
Figure 2. Examples of detector connection
2R
NC NC TMP TMP COM 12V
INDIGO detector
Z2 - programmed as „24h TAMPER” – type NC
+12V COM Z1 Z2 COM Z3 Z4 COM Z5 Z6 COM Z7 Z8 COM
R R
NC NC TMP TMP COM 12V
INDIGO detector
