Vestfrost CNF 201 X User manual
EN NO FROST
COMBI REFRIGERATOR
Freezer - Fridge
User manual
CNF 201 X
CNF 201 DX
CNF 201 WB
UA КОМБІ-ХОЛОДИЛЬНИК
NO FROST
Інструкція користувача
EN
2
Index
BEFORE USING THE APPLIANCE................................. 4
General warnings...................................................................... 4
Old and out-of-order fridges...................................................... 8
Safety warnings ........................................................................ 8
Installing and operating your fridge........................................... 9
Before Using your Fridge......................................................... 10
Information about New Generation Cooling Technology ..........11
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 12
THE VARIOUS FUNCTION AND POSSIBILITIES ......... 14
Display and control panel ........................................................ 14
Operating your fridge............................................................... 14
Cooler temperature settings ............................................... 14
Super cool mode ................................................................. 15
Economy mode ................................................................... 15
Warnings about Temperature Adjustments.............................. 15
Accessories ............................................................................. 16
Freezer box.......................................................................... 16
Chiller Shelf ......................................................................... 17
Humidity Controler ............................................................... 17
Adjustable Door Shelf .......................................................... 18
Adjustable Glass Shelf......................................................... 18
Natural Ion Tech / Ionisier .................................................... 19
CLEANING AND MAINTENANCE.................................. 20
Defrosting ................................................................................ 21
ARRANGING FOOD IN THE APPLIANCE..................... 22
Refrigerator compartment........................................................ 22
Freezer compartment .............................................................. 23
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION........................................................................ 28
Repositioning the door............................................................. 28
EN
3
BEFORE CALLING YOUR AFTER SALES SERVICE... 29
TIPS FOR SAVING ENERGY.......................................... 32
EN
4BEFORE USING THE APPLIANCE
General warnings
WARNING: Keep ventilation openings, in
the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use mechanical devices
or other means to accelerate the defrosting
process, other than those recommended by the
manufacturer.
WARNING: Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type
recommended by the manufacturer.
WARNING: Do not damage the refrigerant
circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or
damaged.
WARNING: Do not locate multiple portable
socket-outlets or portable power supplies at the
rear of the appliance.
WARNING: In order to avoid any hazards
resulting from the instability of the appliance, it
PXVWEH¿[HGLQDFFRUGDQFHZLWKWKHIROORZLQJ
instructions:
FIRE
Warning;5LVNRI¿UHÀDPPDEOHPDWHULDOV
If your appliance uses R600a as a refrigerant
(this information will be provided on the label of
EN
5
BEFORE USING THE APPLIANCE
the cooler) you should take care during
transportation and installation to prevent the
cooler elements from being damaged. R600a is
an environmentally friendly and natural gas, but
it is explosive. In the event of a leak due to
damage of the cooler elements, move your
IULGJHDZD\IURPRSHQÀDPHVRUKHDWVRXUFHV
and ventilate the room where the appliance is
located for a few minutes.
While carrying and positioning the fridge, do
not damage the cooler gas circuit.
Do not store explosive substances such as
DHURVROFDQVZLWKDÀDPPDEOHSURSHOODQWLQ
this appliance.
This appliance is intended to be used in
household and domestic applications such
as:
- VWDII NLWFKHQ DUHDV LQ VKRSV RI¿FHV DQG
other working environments.
- farm houses and by clients in hotels, motels
and other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
If the socket does not match the refrigerator
plug, it must be replaced by the manufacturer,
DVHUYLFHDJHQWRUVLPLODUO\TXDOL¿HGSHUVRQV
in order to avoid a hazard.
A specially grounded plug has been
connected to the power cable of your
refrigerator. This plug should be used with a
EN
6
specially grounded socket of 16 amperes.
If there is no such socket in your house,
please have one installed by an authorised
electrician.
This appliance can be used by children
aged from 8 years and above and
persons with reduced physical, sensory or
mental capabilities or lack of experience
and knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and user
maintenance shall not be made by children
without supervision.
Children aged from 3 to 8 years are allowed
to load and unload refrigerating appliances.
Children are not expected to perform
cleaning or user maintenance of the
appliance, very young children (0-3 years
old) are not expected to use appliances,
young children (3-8 years old) are not
expected to use appliances safely unless
continuous supervision is given, older
children (8-14 years old) and vulnerable
people can use appliances safely after they
have been given appropriate supervision or
instruction concerning use of the appliance.
Very vulnerable people are not expected to
use appliances safely unless continuous
supervision is given.
BEFORE USING THE APPLIANCE
EN
7
BEFORE USING THE APPLIANCE
If the supply cord is damaged, it must be
replaced by the manufacturer, an authorised
VHUYLFHDJHQWRUVLPLODUTXDOL¿HGSHUVRQVLQ
order to avoid a hazard.
This appliance is not intended for use at
altitudes exceeding 2000 m.
To avoid contamination of food, please
respect the following instructions:
Opening the door for long periods can cause
DVLJQL¿FDQWLQFUHDVHRIWKHWHPSHUDWXUHLQ
the compartments of the appliance.
Clean regularly surfaces that can come in
contact with food and accessible drainage
systems
6WRUHUDZPHDWDQG¿VKLQVXLWDEOHFRQWDLQHUV
in the refrigerator, so that it is not in contact
with or drip onto other food.
Two-star frozen-food compartments are
suitable for storing pre-frozen food, storing
or making ice cream and making ice cubes.
One-, two- and three-star compartments are
not suitable for the freezing of fresh food.
If the refrigerating appliance is left empty for
long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould
developing within the appliance.
EN
8BEFORE USING THE APPLIANCE
Old and out-of-order fridges
If your old fridge has a lock, break or remove the lock
before discarding it, because children may get trapped
inside it and may cause an accident.
Old fridges and freezers may contain isolation material
and refrigerant with CFC or HFC. Therefore, take care
not to harm environment when you are discarding your
old fridges..
Please ask your municipal authority about the disposal of the
WEEE reuse, recycle and recovery purposes.
Notes:
Please read the instruction manual carefully before
installing and using your appliance. :H DUH QRW
UHVSRQVLEOHIRUWKHGDPDJHRFFXUUHGGXHWRPLVXVH
Follow all instructions on your appliance and instruction
manual, and keep this manual in a safe place to resolve
the problems that may occur in the future.
This appliance is produced to be used in homes and it
can only be used in domestic environments and for the
VSHFL¿HG SXUSRVHV ,W LV QRW VXLWDEOH IRU FRPPHUFLDO RU
common use. Such use will cause the guarantee of the
appliance to be cancelled and our company will not be
responsible for losses incurred.
This appliance is produced to be used in houses and it is
only suitable for cooling / storing food. It is not suitable for
commercial or common use and/or for storing substances
except for food. Our company is not responsible for
losses to be incurred in the contrary case.
Safety warnings
Do not connect your Fridge Freezer to the mains
electricity supply using an extension lead.
Do not plug in damaged, torn or old plugs.
Do not pull, bend or damage the cord.
EN
9
BEFORE USING THE APPLIANCE
This appliance is designed for use by adults, do not allow
children to play with the appliance or let them hang off the
door.
Never touch the power cord/plug with wet hands as this
could cause a short circuit or electric shock.
Do not place glass bottles or beverage cans in the ice-
making compartment as they can burst as the contents
freeze.
'R QRW SODFH H[SORVLYH RU ÀDPPDEOH PDWHULDO LQ \RXU
fridge. Place drinks with high alcohol content vertically in
the fridge compartment and make sure that their tops are
tightly closed.
When removing ice from the ice-making compartment, do
not touch it. Ice may cause frost burns and/or cuts.
Do not touch frozen goods with wet hands. Do not eat ice-
cream or ice cubes immediately after you have taken them
out of the ice-making compartment.
Do not re-freeze frozen goods after they have melted. This
may cause health issues such as food poisoning.
Do not cover the body or top of fridge with lace. This affects
the performance of your fridge.
Secure any accessories in the fridge during transportation
to prevent damage to the accessories.
Do not use plug adapter.
Installing and operating your fridge
%HIRUH XVLQJ \RXU IULGJH \RX VKRXOG SD\ DWWHQWLRQ WR WKH
IROORZLQJSRLQWV
The operating voltage for your fridge is 220-240 V at 50Hz.
We do not accept responsibility for any damages that
occur due to ungrounded usage.
Place your fridge where it will not be exposed to direct
sunlight.
Your appliance should be at least 50 cm away from stoves,
gas ovens and heater cores, and at least 5 cm away from
electrical ovens.
Your fridge should never be used outdoors or exposed to
rain.
EN
10 BEFORE USING THE APPLIANCE
When your fridge is placed next to a deep freezer, there
should be at least 2 cm between them to prevent humidity
forming on the outer surface.
Do not place anything on your fridge, and install your fridge
in a suitable place so that at least 15 cm of free space is
available above it.
Use the adjustable front legs to make sure your appliance
is level and stable. You can adjust the legs by turning them
in either direction. This should be done before placing food
in the fridge.
Before using your fridge, wipe all parts with a solution of
warm water and a teaspoon of sodium bicarbonate, then
rinse with clean water and dry. Place all parts in the fridge
after cleaning.
Install the plastic distance guide (the part with black vanes
DWWKH UHDU E\WXUQLQJ LW DV VKRZQLQ WKH¿JXUH WR
prevent the condenser from touching the wall.
The refrigerator should be placed against a wall with a free
space not exceeding 75 mm.
Before Using your Fridge
:KHQ XVLQJ \RXU IULGJH IRU WKH ¿UVW WLPH RU DIWHU
transportation, keep it in an upright position for at least 3
KRXUVEHIRUHSOXJJLQJLQWRWKHPDLQV7KLVDOORZVHI¿FLHQW
operation and prevents damage to the compressor.
Your fridge may have a smell when it is operated for the
¿UVWWLPH7KLVLVQRUPDODQGWKHVPHOOZLOOIDGHDZD\ZKHQ
your fridge starts to cool.
EN
11
BEFORE USING THE APPLIANCE
Information about New Generation Cooling
Technology
Fridges with new generation cooling technology have a
different working system than static fridges. In normal fridges,
humid air that enters into fridge and the water vapor that comes
out from the foods, accumulates frost formation in freezer
compartment. In order to melt this frost, in other words defrost,
the fridge has to be stopped. During the stopping period, to
keep the foods cold, user has to extract the food to outside of
fridge and user has to clear the ice during this period.
In the fridges with new generation cooling technology, situation
in the freezer compartment is completely different. With the
aid of fan, cold and dry air is blown out through many points
into the freezer compartment. As a result of the homogenously
blown cold air, even in the spaces between shelves, foods are
frozen equally and correctly. On the other hand there will be
no frost formation.
In the refrigerator compartment, there will be nearly same
FRQ¿JXUDWLRQ ZLWK IUHH]HU FRPSDUWPHQW $LU WKDW LV HPLWWHG
with the fan, located at the top of refrigerator compartment,
is cooled while passing through the gap behind the air duct.
At the same time, air is blown out through the holes on the air
duct so that cooling process is successfully completed in the
refrigerator compartment. Holes on the air duct are designed
such that the air distribution becomes homogenous in this
compartment.
As there is no air passage between freezer and refrigerator
compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling
technology, gives you, ease of use beside the huge volume
and esthetic appearance.
EN
12
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
1
2
4
5
6
7
8
9
10
A
B
12
13
14
15
3
11
16
EN
13
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
A) Fridge compartment
B) Freezer compartment
1) Fridge shelves
2) Wine rack *
3) Interior display / In room control
4) Chiller *
5) Crisper cover
6) Crisper
7) Freezer top basket
8) Freezer middle basket
9) Freezer bottom basket
10) Leveling feet
11) Ice trays
12) Freezer glass shelves
13) Bottle shelf
14) Adjustable door shelf * / Door shelf
15) Door shelf
16) Egg holder
* In some models
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.
EN
14 THE VARIOUS FUNCTION AND POSSIBILITIES
Display and control panel
Operating your fridge
Cooler temperature settings
Initial temperature value for Cooler Setting Indicator is 6 oC.
Press set button once, the set value will start to blink.
If you keep pressing set button, lower temperatures will be selected.
(8, 6, 5, 4, 2, super and eco)
If no button is pressed for 1 second, your choice will be set, it will blink
3 times. Buzzer will sound beep beep.
The temperature value selected before Super Cool Mode or Economy
Mode is activated will remain the same when the mode is over or
cancelled. The appliance continues to operate with this temperature
value.
C
o
8 6 5 4 2
It is Economy mode
indicator.
It is Super cool mode
indicator.
Set button
Thermostat set level
indicator
Button LED
EN
15
THE VARIOUS FUNCTION AND POSSIBILITIES
Super cool mode
How would it be used?
Press set button until super cool symbol will be seen on the screen.
Buzzer will sound beep beep. Mode will be set.
During this mode:
Economy mode can not be selected.
Super cool mode can be cancelled by the same operation of
selecting.
Economy mode
How would it be used?
Press set button until eco symbol will be seen on the screen. Buzzer
will sound beep beep. Mode will be set.
During this mode:
Super cool can be selected. Economy mode is automatically
cancelled and the selected mode is activated.
Eco mode can be cancelled by the same operation of selecting.
Warnings about Temperature Adjustments
Temperature adjustments should be made according to the frequency
of door openings and the quantity of food kept inside the fridge.
Do not pass to another adjustment before completing an adjustment.
Your fridge should be operated up to 24 hours according to the
ambient temperature without interruption after being plugged in to be
completely cooled. Do not open doors of your fridge frequently and do
not place much food inside it in this period.
A 5 minute delaying function is applied to prevent damage to the
compressor of your fridge, when you take the plug off and then plug
it on again to operate it or when an energy breakdown occurs. Your
fridge will start to operate normally after 5 minutes.
Your fridge is designed to operate in the ambient temperature intervals
stated in the standards, according to the climate class stated in the
information label. We do not recommend operating your fridge out
of stated temperatures value limits in terms of cooling effectiveness.
EN
16 THE VARIOUS FUNCTION AND POSSIBILITIES
This appliance is designed
for use at an ambient
temperature within the
10°C - 43°C range.
Important installation instructions
7KLVDSSOLDQFHLVGHVLJQHGWRZRUNLQGLI¿FXOWFOLPDWHFRQGLWLRQVXSWRGHJUHHV
C or 110 degrees F) and is powered with ‘Freezer Shield’ technology which
ensures that the frozen food in the freezer will not defrost even if the ambient
temperature falls as low as -15 °C. So you may then install your appliance in an
unheated room without having to worry about frozen food in the freezer being
spoilt. When the ambient temperature returns to normal, you may continue using
the appliance as usual.
Accessories
Freezer box
The freezer box allows foods are maintained more regularly.
Removing The freezer box;
Pull the box out as far as possible
Pull the front of box up and out.
! Make the inverse of the same operation for the resetting the sliding
compartment.
Note: Always Keep the handle of box while removing the box.
Climate Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Freezer boxes
EN
17
THE VARIOUS FUNCTION AND POSSIBILITIES
Chiller Shelf
Keeping food in the Chiller compartment instead
of the freezer or refrigerator compartment allows
IRRG UHWDLQ IUHVKQHVV DQG ÀDYRXU ORQJHU ZKLOH
preserving its fresh appearance. When chiller tray
becomes dirty, remove it and wash it with water.
(Water freezes at 0°C, but foods containing salt or
sugar freeze at temperature lower than that)
Normally people use the chiller compartment for
UDZ¿VKOLJKWO\SLFNOHGULFHHWF
'RQRWSXWIRRGV\RXZDQWWRIUHH]HRULFHWUD\VLQRUGHUWRPDNHLFH
Removing the Chiller shelf
Pull the chiller shelf out toward you by sliding on rails.
Pull the chiller shelf up from rail to remove.
Humidity Controler
When the humidity controler in the closed position, it allows fresh fruit and
vegetables to be stored longer.
In case of the crisper is totally full, the fresh
dial is located in front of crisper, should
be opened. By means of this the air in the
crisper and humidity rate will be controlled
and endurance life will be increased.
If you see any condensation on glass shelf,
humidity control should be taken into the
open positions.
(In some models)
(In some models)
EN
18 THE VARIOUS FUNCTION AND POSSIBILITIES
Adjustable Door Shelf
Six different height adjustments can be made to provide
storage areas that you need by adjustable door shelf.
To change the position of adjustable door shelf ;
Hold the bottom of the shelf and pull the buttons on the side of
the door shelf direction of arrow (Fig.1).
Position door shelf the height you need by moving up and
down. After you get the position that you want the door shelf,
release the buttons on the side of the door shelf (Fig.2) Before
releasing the door shelf, move up down and make sure the
GRRUVKHOILV¿[HG
Note: Before moving door shelf is loaded, you must hold the
shelf by supporting the bottom. Otherwise, door shelf could fall
off the rails due to the weight. So damage may occur on the
door shelf or rails.
Adjustable Glass Shelf
Adjustable glass shelf mechanism provides higher storage
spaces with a simple movement. To cover the glass shelf,
push it.
You can load your food as you want in the resulting extra
space. To bring the shelf in its original position, pull it toward
you.
(In some models)
(In some models)
Figure -1
Figure -2
Figure -1
Figure -2
EN
19
THE VARIOUS FUNCTION AND POSSIBILITIES
Natural Ion Tech / Ionisier
Natural Ion Tech spreads negative ions which neutralize particles of
unpleasant smell and dust in the air.
By removing these particles from the air in the refrigerator, Natural Ion
Tech improves air quality and eliminates odours.
This feature is optional. It may not exist on your product.
The location of your ioniser device may vary from product to product.
Ionisier
(In some models)
Visual and text descriptions on the accessories section may
vary according to the model of your appliance.
This manual suits for next models
2
Table of contents
Other Vestfrost Refrigerator manuals
Vestfrost
Vestfrost VCF 10180 NoFrost User manual
Vestfrost
Vestfrost CVKS 611-670-671 User manual
Vestfrost
Vestfrost AKG 337 User manual
Vestfrost
Vestfrost VCF 10186-L User manual
Vestfrost
Vestfrost AKG 377 User manual
Vestfrost
Vestfrost VIC 10177 S User manual
Vestfrost
Vestfrost CW 286 WB User manual
Vestfrost
Vestfrost VICF 10177 S User manual
Vestfrost
Vestfrost VR-FW916-1E0I User manual
Vestfrost
Vestfrost CW 397 R User manual
Vestfrost
Vestfrost VCF 10122 TF User manual
Vestfrost
Vestfrost R-90 User manual
Vestfrost
Vestfrost BBR150 User manual
Vestfrost
Vestfrost FZ 277R User manual
Vestfrost
Vestfrost R-138 User manual
Vestfrost
Vestfrost VLS200 Installation and user guide
Vestfrost
Vestfrost VC 10146 User manual
Vestfrost
Vestfrost VLS 204A User manual
Vestfrost
Vestfrost VFC 312 User manual
Vestfrost
Vestfrost VICF 105177 S User manual
Popular Refrigerator manuals by other brands
LG
LG LFXS28596M owner's manual
Essentials
Essentials C99CF13 Service manual
Danby
Danby Silhouette DBC056D1BSSPR Owner's use and care guide
Master Bilt
Master Bilt J - Version GT-50 s Installation & operation manual
Siemens
Siemens KI81RAD30 user manual
Mainstreet Equipment
Mainstreet Equipment 829BMR23R user manual
