VETERAN V20L20M0K1 User manual

DANGER:Do not allow any liquid to come into contact with the charger.If the battery pack is
cracked or damaged in any other way,do not insert it in the charging base. There is a danger of
electric shock or electrocution.
The term “power tool” in this manual refers to the V20L2O0K1, Battery and Charger.
Pleasereadthecompleteusermanualbeforeuse.
WARNINGReadallsafetywarningsandinstructions.Failure to follow all warnings
and instructions may result in electric shock, fire and/or serious injury.
SAVETHESEINSTRUCTIONSFORFUTUREREFERENCE.

2
GENERALPOWERTOOLSAFETY,USEANDCARE
Workareasafety
oVisibility is key -- keep work area clean and well lit. Cluttered and dark areas invite accidents.
oProper protective gear (safety goggles/glasses, etc.) is required when using this tool.
oDo not operate in the presence of flammable liquids, gasses, or dust. The operation of power tools creates
sparks which may ignite the dust or fumes, creating a potentially explosive atmosphere.
oAvoid distractions by working at a safe distance from any bystanders, children or pets.
Electricalsafety
oPower tool and battery charger plugs must match the outlet to reduce the risk of electric shock. Never modify
the plug in any way. Unmodified plugs and matching outlets will reduce risk of electric shock.
oAvoid bodily contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators.
There is an increased risk of electric shock if your body is earthed or grounded.
oDo not expose power tools, batteries or charger to rain or wet conditions. Water can irreparably damage the
tool, battery and charger and increases the risk of electric shock.
oDo not abuse the cord. Never use the cord for carrying or pulling/unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
oIf the use of a charger in a damp indoor location is unavoidable, use a ground fault circuit
interrupter/residual current device (GFCI/RCD) protected supply. The use of an GFCI /RCD reduces the risk
of electric shock.
Personalsafety
oUse care and caution when operating any power tool. Do not use a power tool while you are under the
influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in
serious personal injury.
oAlways wear eye protection. The use of personal protective equipment such as a dust mask, non-skid safety
shoes, hard hat, or hearing protection used will reduce the risk of personal injuries.
oDress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewelry or long hair can be caught in moving parts.
oPrevent unintentional starting. Your finger should remain clear of the operating switch whenever you are not
intentionally using the tool. Ensure the switch is in the off position before connecting to the battery pack,
picking up or carrying the tool. Carrying power tools with your finger on the switch or energizing power
tools that have the switch on invites accidents.
oKeep proper footing and balance at all times. This enables better control of the power tool in unexpected
situations. Do not overreach.
oIf devices are provided for the connection of dust extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can reduce dust related hazards.

3
GeneralPowertooluseandcare
oDo not force the power tool. Use the correct power for your application. The correct power tool will do the
job better and safer at the rate for which it was designed.
oDo not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
oDisconnect the plug from the power source and/or the battery pack from the power tool before making any
adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
oStore power tools out of the reach of children and do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
oMaintain power tools. Check for misalignment or binding of moving parts, breakage of parts and any other
condition that may affect the power tools operation. If damaged, have the power tool repaired before use
oKeep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less likely
to bind and are easier to control.
oUse the power tool, accessories, and tool bits etc. in accordance with these instructions,taking into account
the working conditions and the work to be performed. Use of the power tool for operations different from
intended could result in a hazardous situation.
oEnsure the switch is in the “off” position before inserting battery pack. Inserting the battery pack into power tools
that have the switch in the “on” position can result in an unplanned activation and cause serious injury.
oRecharge only with the charger specified by the manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with another battery pack.
oUse power tools only with specifically designated battery packs. Use of any other battery packs may create a
risk of injury and fire.
oWhen battery packs are not in use, keep them away from other metal objects like paper clips, coins, keys,
nails, screws, or other small metal objects that can make a connection from one terminal to another. Shorting
the battery terminals together may cause burns or a fire.
oUnder abusive conditions, liquid may be ejected from the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid ejected from the
battery may cause irritation or burns.
oDo not store or charge batteries in a location subject to extreme temperatures. Recommended temperature
range for charging is 32 to 113 degrees Fahrenheit. Recommended temperature range for discharge/use is -4
to 140 degrees Fahrenheit.
Service
oHave your power tool serviced by qualified repair person using only identical replacement parts. This will
ensure that the safety of the power tool is maintained

4
SPECIALSAFETYINSTRUCTIONSforLithiumǦIonBatteryPacks
oAlways charge the battery when the temperature is between 18-24°C (32°F to 113°F). Do not charge the
battery pack when the temperature is below 0°C (32°F), or above 40°C (113°F) This is important. Failure to
observe this safety rule could cause serious damage to the battery pack.
oThe battery is to be disposed of safely. Do not dispose of the battery pack by incinerating the battery pack .
The battery pack can explode in a fire.
oNever attempt to open the battery pack for any reason. If the plastic housing of the battery pack breaks
open or cracks, immediately discontinue its use and do not recharge it.
oDo not store or carry a spare battery pack in a pocket or toolbox or any other place where it may come into
contact with metal objects. The battery pack may be short circuited causing damage to the battery pack,
burns or a fire. If storing or disposing the battery pack, cover the terminals with a heavy insulation tape to
ensure short circuit cannot occur.
oBatteries, when stored for a long period of time, will discharge. If the battery pack has been stored for a long
time, you should charge the battery pack first before using it.
oAllow the battery pack to cool down after charging. Do not place it in a hot environment such as near a fire,
in a metal shed or open trailer left in the sun, etc. The best storage place is one that is cool and dry away
from direct sunlight and excess heat or cold.
oOnly charge the battery with the charger supplied.
oDo not splash or immerse in water or other liquids. This may cause premature cell failure.
oA small leakage of liquid from the battery pack may occur under extreme usage or temperature. This does
not necessarily indicate a failure of the battery pack. However, extra care should be taken during cleanup,
including wearing chemical-resistant rubber gloves, eye protection and other protective garb. The fluid can
damage clothing or skin upon contact. After donning appropriate safety wear, wipe battery with a
disposable dry rag to fully remove fluid and then dispose of rag appropriately.
Iftheoutersealisbrokenandthisleakagecomesintocontactwithyourskin:
Wash the affected area quickly with soap and water.
Neutralise the liquid with a mild acid such as lemon juice or vinegar.
Iftheleakagegetsinyoureyes:
Flush your eyes with clean water for a minimum of 10 minutes and seek immediate medical
attention. Inform the medical staff that the liquid is a 25-35% solution of potassium hydroxide.
IFIRRITATIONPERSISTSORFLUIDISINGESTED,SEEKIMMEDIATEMEDICALATTENTION!

The machine is intended for sanding, sawing, scraping and cutting on wood, plasterboard, soft plastics and metals.
WARNING. Contact with or inhalation of harmful / toxic dusts arising from sanding lead-based painted
surfaces, woods and metals can endanger the health of operator and bystanders.
1. All persons entering the work area must wear an approved mask specially designed for protection against
harmful / toxic dusts, in addition to using the dust extraction facility, and keeping work area well ventilated.
2. Children and pregnant women must not enter the work area.
3. Do not eat, drink or smoke in the work area.
4. Any pre 1960 building may have paint containing lead on wood or metal surfaces. If you suspect workpiece
contains lead seek professional advice.
5. Some wood and wood type products especially MDF (Medium Density Fiberboard) can produce dust that can be
hazardous to your health. We recommend the use of an approved face mask with replaceable filters when using
this machine in addition to using the dust extraction facility.
6. This tool is designed for single handed operation. Adopt a stable distance and make sure that the mains cable
is prevented from coming into contact with the machine or getting caught up on other objects preventing
completion of the sanding pass.

PRODUCT SPECIFICATION
Voltage: 20V DC MAX
Speed n0: 11,000-21,000min-1
Vibration: 4.851m/s2, K=1.5m/s2
A weighted sound pressure level: LpA: 79.2dB(A) ; KpA=3dB(A)
A weighted sound power level: LwA: 90.2dB(A) ; KwA=3dB(A)

7. Ensure that you have removed foreign objects such as nails and screws from the workpiece before
commencing sanding.
8. Don’t use it for wet sanding, for dry sanding only.
9. Do not scrape wet or dampened materials (e.g. wallpaper) or on moist surfaces. Penetration of water into the
machine increases the risk of an electric shock.
10. Hold power tools by their insulated gripping surfaces when performing an operation where the cutting tool may
contact hidden wiring or its own cord. Contact with a “live” wire will make exposed metal parts of the tool “live”
and shock the operator.
11. Where possible, secure smaller workpieces to prevent them from moving under the tool.
12. Do not force the tool; let the tool do the work at a reasonable speed. Overloading will occur if too much pressure is
applied and the motor slows resulting in inefficient sanding and possible damage to the motor.
13. Only use application accessories in good condition. Do not use them if they are torn or worn.
14. Do not touch the moving sanding sheet.
15. Do not treat the surface to be worked with solvent-containing fluids. Materials being heated by the scraping can
cause toxic vapors to develop.
16. Exercise extreme caution when handling the scraper accessory. The accessory is very sharp; danger of injury.
17. Keep your hands away from the cutting area. Do not reach under the material being cut. The tool must be used
only for its prescribed purpose. Any use other than those mentioned in this Manual will be considered a case of
misuse. The user and not the manufacturer shall be liable for any damage or injury resulting from such cases
of misuse.
To use this tool properly, you must observe the safety regulations, the assembly instructions and the
operating instructions to be found in this Manual. All persons who use and service the machine have to be
acquainted with this Manual and must be informed about its potential hazards. Children and frail people
must not use this tool. Children should be supervised at all times if they are in the area in which the tool is
being used. It is also imperative that you observe the accident prevention regulations in force in your area.
The same applies for general rules of occupational health and safety. The manufacturer shall not be liable
for any changes made to the tool nor for any damage resulting from such changes. Even when the tool is
used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise
in connection with the tool’s construction and design:
•Damage to the lungs if an effective dust mask is not worn.
•Damage to hearing if effective hearing protection is not worn.
•Hand-arm vibration syndrome if its use is not adequately managed.

ADDITIONAL SAFETY INSTRUCTIONS
FOR BATTERIES AND CHARGERS
Use only batteries and chargers applicable for this machine.
BATTERIES
• Never attempt to open for any reason.
• Do not store in locations where the temperature may exceed 105 °F.
• Charge only at ambient temperatures between 40 °Fand 105 °F.
• When disposing of batteries, follow the instructions given in the section “Protecting the environment”.
•Do not cause short circuits. If connection is made between the positive (+) and negative (-) terminal directly or via
accidental contact with metallic objects, the battery is short circuited and an intense current will flow causing heat
generation which may lead to casing rupture or fire.
•Do not heat. If batteries are heated to above 212 °F, sealing and insulating separators and other polymer
components may be damaged resulting in electrolyte leakage and/or internal short circuiting leading to heat
generation causing rupture or file. Moreover do not dispose of the batteries in fire, explosion and/or intense
burning may result.
•Under extreme conditions, battery leakage may occur. When you notice liquid on the battery, proceed as follows:
• Carefully wipe the liquid off using a cloth. Avoid skin contact.
• In case of skin or eye contact, follow the instructions below:
1. Immediately rinse with water. Neutralize with a mild acid such as lemon juice or vinegar.
2. In case of eye contact, rinse abundantly with clean water for at least 10 minutes.
3. Consult a physician.
Fire hazard! Avoid short-circuiting the contacts of a detached battery. Do not incinerate the battery.
CHARGERS
• Never attempt to charge non-rechargeable batteries.
•Have defective cords replaced immediately.
•Do not expose to water.
•Do not open the charger.
•Do not probe the charger.
•The charger is intended for indoor use only.



SYMBOLS
In this manual and/or on the machine the following symbols are used:
Denotes risk of personal injury or damage to the tool.
Read manual before use
Wear eye protection
Wear ear protection
Wear safety gloves
In accordance with essential requirements of the European directive(s)
Class II - The machine is double insulated; Earthing wire is therefore not necessary (only for
charger)
Ambient temperature 40°C max. (only for battery)
Do not expose charger and battery pack to water
Use battery and charger only in closed rooms
Do not incinerate battery pack or charger
Protect from the rain.

OPERATION
BATTERY CHARGER
The lithium-ion battery can be charged at any time and will not develop a “memory” when charged after
only a partial discharge. It is not necessary to run down the battery pack charge before recharging. Remove the
battery pack from the tool when convenient for you and your job. You can “top-off” your battery pack’s charge
before starting a big job or long period of use.
Due to lithium-ion’s fade-free properties, the only time it is necessary to charge the lithium-ion battery
pack is when the pack has reached the end of its charge. To signal the end of charge, power to the tool will
drop quickly. Charge the battery pack as needed.
CHARGING THE BATTERY
This lithium-ion battery pack is shipped partially charged. Before using it the first time, fully charge the
battery pack. A fully discharged 2.0Ah battery pack with a temperature between 40°Fand 105°Fwill charge in
about 1 hour.
Plug the charger adapter into power source. The green light on the charger stand will illuminate, indicating the
charger is powered.
Slide the battery all the way into the charger stand. The red light on the charger stand will illuminate,
indicating that the battery is charging.
The red light will go off after charging is complete and a green light will appear.
NOTE: Batteries may become warm while charging. This is normal. If the battery is hot after continuous
use in the tool, allow it to cool down to room temperature before charging. This will extend the life of
your batteries.
WARNING: Always disconnect the battery pack from the tool before any assembly, adjustments or
changing accessories.
INSERTION AND REMOVAL OF RECHARGEABLE BATTERY
Depress the battery-release button located on the front of the battery pack to release battery pack.
Pull the battery pack out and remove it from the tool.
WARNING: Always remove the battery pack before making adjustments to the equipment.
Be sure to read the following information before you put the cordless equipment into operation:
Charge the battery pack with the charger. An empty 2.0Ah battery pack requires a charging period of
approximately 0.5 to 1 hour.




FUNCTIONS
ATTACHING THE APPLICATION TOOL
CAUTION: For all work or when changing application tools,
disconnect the battery pack from power tool and always wear
protective gloves. The sharp edges of the application tools
will cause personal injury. Application tools can be very hot
while working.
WARNING: Check that the application tools are correctly
attached. Incorrect or insecurely fastened application tools can
come loose during operation and cause a hazard.
1. Switch off & disconnect the tool from the power source.
2. Turn over the quick-release lever until to be horizontal
3. Put the accessory onto the attachment plate.
4. Turn the quick-release lever back to lock the drive shaft.
NOTE: Attach the application tool at the desired orientation for the
task at hand. The shaft is configured so that the application tool can be
attached every 30°around the shaft, from 0°to 330°
MOUNTING/CHANGING THE SAND PAPER
1. Follow the directions for attaching the application tool to attach the
sanding base to the multi tool.
2. Align the sand paper with the sanding base and use your hand to
press it firmly on the sanding base.
3. Press the sand paper firmly against a smooth surface for a short



period, and then switch on the tool. The burr will form a non-slip bond with the outer edge of the sand
paper felt. This will avoid premature wear. If one point has become worn, pull off the sandpaper, turn it
120° and place it on again.
VARIABLE SPEED CONTROL
The variable speed feature of this tool enables the speed to be adjusted
according to the accessory being used and material being cut, scrapped or
sanded. The speed dial is numbered “1” through “6”, with position “1” being
the lowest speed and position “6” being the highest speed.
SWITCH ON AND OFF
To turn the tool ON, push the on/off switch forward. To turn it OFF, push the
switch backward.
OPERATION FOR WORKING
Do not touch the gear box after prolonged use; it could be very hot.
The removal rate and the sanding pattern are determined by the choice of
sanding sheet and the work surface. Apply uniform sanding pressure to
extend the life of the sanding sheets.
• Intensifying the sanding pressure does not lead to an increase of the sanding capacity, but instead it increases wear
on the machine and the sanding sheet.
•Use only the tip or an edge of the sanding sheet for precise sanding of edges, corners and hard to reach areas.
•When selectively sanding on one spot, the sanding sheet can heat up considerably. Remove the tool from the
surface periodically to permit the sanding sheet to cool down.
•A sanding sheet that has been used for metal should not be used for other materials.
•Use only original sanding accessories. For sanding, always connect dust extraction.
B. SCRAPING
The tool is suitable for scrapping and removing surface coverings. For scraping, select a high speed setting.
• To remove surface covers, place the scraping blade vertically on the work piece.
•Switch the tool on and cut down through the covering.
•Place the tool at a flat angle (not over 20°) and apply alight forward pressure to remove the covering.
C. CUTTING
Saw blades are ideal for making precise cuts in tight areas, close to edges or flush to a surface.
• Select the lowest speed for making initial plunge, start off at lowest speed for increased control. After making your
initial cut, you can increase speed for faster cutting ability.


• Flush cutting blades are intended to make precise cuts to allow for installation of flooring or wall material. When
flush cutting, it is important not to force the tool during the plunge cut. If you experience a strong vibration in your
hand during the plunge cut, this indicates that you are applying too much pressure. Back the tool out and let the
speed of the tool do the work. While keeping the teeth of the blade in the work surface, move the back of the tool in
a slow sideways motion. This motion will help expedite the cut.
•The flat saw blade is ideal for making precise cuts in wood, plaster, drywall material.
•Applications include cutting openings in flooring for venting, repairing damaged flooring, cutting openings for
electrical boxes. The blade works best on softer woods such as pine. For harder woods, the blade life will be limited.
•The flat saw blade can also be used for window restoration making glazing easy to remove. The saw blade can be
placed directly against the edge of the window frame, guiding the blade through the glazing.
CLEANING AND MAINTENANCE
DANGER! Always pull out the mains power plug before startingany cleaning work.
CLEANING
Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the
equipment with a clean cloth or blow it with compressed air at low pressure.
We recommend that you clean the device immediately each time you have finished using it.
Clean the equipment regularly with a moist cloth and some soft soap. Do not use cleaning agents or
solvents; these could attack the plastic parts of the equipment. Ensure that no water can seep into the
device. The ingress of water into an electric tool increases the risk of an electric shock.
MAINTENANCE
There are no parts inside the equipment which require additional maintenance.
STORING
Store the machine, operating instructions and where necessary the accessories in the original packaging.
In this way you will always have all the information and parts ready to hand.
Pack the device well or use the original packaging in order to avoid transit damage.
Always keep the machine in dry place.


1. Quick-release lever
2. On/off switch
3. Release button(battery pack)
4. Battery pack
5. Sanding base
6. Sanding paper
7. Scraper
8. Plunge cut blade
5
7
6
8
1
2
3
4
