VEVOR AF+AF+AR3000- 03 User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
Compressed Air Filter Regulator
User Manual
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and doses not necessarily mean to cover all categories of tools offered by
us. You are kindly reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

1
Have product questions? Need technical support? Please feel free to
contact us:
CustomerService@vevor.com
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Compressed Air
Filter Regulator

2
Technical Specifications
Model
N. W.
G. W.
Carton Size
AF+AF+AR3000-
03
2.4LBS
(1.1Kg)
2.9LBS
(1.3Kg)
8.1*8.1*3.2 inch
(205*205*82 mm)
Port Size
Max Inlet Pressure
Filter Rating
Air Flow
3/8"NPT
145 psi
5μm&5μm
≥70SCFM@90PSI
SAFETY
Note / Remark. Caution / Warning.
Read the instruction manual.
Read this material before using this product. Failure to do so can result
in serious injury. Save This Manual.
Assembly precautions
1.Assemble only according to these instructions. Improper assembly can
create hazards.
2. Wear ANSI-approved safety goggles and heavy-duty work gloves during
assembly.
3.Keep assembly area clean and well lit.
4.Keep bystanders out of the area during assembly.
5.Do not assemble when tired or when under the influence of alcohol, drugs
or medication.
6.Weight capacity and other product capabilities apply to properly and
completely assembled product only.
7.Assemble on a flat, level, hard and smooth surface capable of safely
supporting Compressed Air Combination Filter Regulators

3
Use precautions
TO PREVENT SERIOUS INJURY AND DEATH FROM TIPPING:
1. DO not sit, stand on this Compressed Air Combination Filter Regulators.
2. This product is not a toy. Do not allow children to play with or near this item.
3. Do not exceed weight capacities, evenly distributed from bottom up. Be
aware of dynamic loading! Sudden load movement may briefly create
excess load causing product failure.
4. Use only on a flat, level, hard and smooth surface capable of safely
supporting a Manual pipe bender.
5. Use as intended only.
6. Inspect before every use; do not use if parts are loose or damaged.
WARNING!
DO NOT let comfort or familiarity with product (gained from repeated use)
replace strict adherence to the product safety rules. If you use this product
unsafely or incorrectly, you can suffer serious personal injury.
● When the compressed air is heavily contaminated,the filter cartridges have
to be exchanged in shorter intervals!
● Saturated filter cartridges may cause quality problems during paint
jobs.Furthermore,using a supplied-air respirator could then be harmful,
causing permanent health damaqe and even death!
Preparation
Before beginning assembIy of product. make sure aII parts are present﹒
Compare parts with package contents Iist and hardware contents Iist﹒
If any part is missing or damaged. do not attempt to assembIe the product﹒
The assembly of all calibration shall meet the maximum flow requirement.
Please clean the port and fitting before installation, it will effectively avoid
bring dust to the air path.
Pay attention to direction of air flow and arrow pointing on product body if
correct, minding port and thread size if match.

4
Installation instructions
Notes:Please use a wrench to tighten fittings to avoid leakage.
The first installation may have an excretion reaction ( Not leakage, for the first
time the internal pressure is different from the outside, it is necessary to
discharge the excess air first ) In this case, please patiently wait for a while
and it will work well.
Assembly drawing

5
Name
Qty
Name
Qty
1. Filter valve body
2
2. Vane
2
3. Filter element
2
4. Stud
2
5. Manger
2
6. Discharge valve element
2
7. Spring
2
8. O-ring
2
9. Discharge valve seat
2
10. O-ring
2
11. O-ring
2
12. Cup
2
13. Shield
2
14. Locking plate
2
15. Spacer pin
2
16. Spring
2
17. Hexnut
2
18. Knurled nut
2
19. Hexagon socket
countersunk head screw
4
20. Pressing plate
2
21. O-ring
4
22. Intermediate block
2
23. L-holder
2
24. Pressure regulating
valve seat
1
25. O-ring
1
26. O-ring
1
27. Big check ring
1
28. Spring
1
29. Check ring
1
30. Valve element
1
31. Valve rod
1
32. Relief valve body
1
33. Hex socket plug
1
34. O-ring
1
35. Small retainer
1
36. Feedback catheter
1
37. Diaphragm seat
1
38. Diaphragm
1
39. Diaphragm tray
1
40. SV-Spring
1
41. Pressure regulating nut
1
42. Pressure adjusting
screw
1
43. Bonnet
1
44. Flat pan head screw
combination
4
45. Octagonal hat
1
46. Marking ring
1
47. Pressure regulating
hand wheel
1

6
operation instructions
1.1 Before pressurizing system,make certain the bowl is securely locked in
place by hand tightening the bowl ring until it is snug.
1.2. Unlock the regulator adjusting knobby pulling knob away from the
regulator.
1.3. Tum the regulator adjusting knob counterckockwise until no load is on the
regulating spring.
1.4. Tum on the air pressure supply and turn the adjusting knob clockwise
until the desired outlet pressure is reached. Push the regulator
adjusting knob toward the regulator to lock in desired pressure.
1.5.The first filter stage separates particles>5um as well as condensed water
and oil.The PE fiter is integrated in the filter, fineness 5um.
1.6. PE filter and filter housings have to be cleanedafter 6 months at the latest;
replace PE filter, if necessary!
Pressure Adjustment
Pull up the knob of pressure gauge, rotate:
If you do clockwise rotation, pressure will rise steadily.Pressure will down
when you rotate counterclockwise.

7
Stop turning after reaching the required index and lock down the knob,forget
this step you may face leakage problem.
Dial Reading
Make sure that the pressure gauge is tightly installed on the main body, and
pay attention to whether the reading rises and falls smoothly while adjusting
pressure.
Drainage
1. Manual drain
a. When water exceeds the level, please drain off the water, press up the
bottom of brass drain body, then it will start to drain.
b.When the water level exceeds the maximum limit,please drain off the water
to keep optimal dehumidification.
2. Auto drain
The auto drain only works properly when the filter is vertically mounted. If a
certain condensate fillinglevel is reached inside the filter housing the
condensate drain valve opens automatically draining the condensate through

8
the condensate drain hose into the collection container (not included in
delivery) until just a small residual quantity remains
Pneumatic schematic diagram
MAINTENANCE/ Service
Have your tool serviced by a qualified repair person using only identical
replacement parts.This will ensure that the safety of the tool is maintained.
PE filter and filter housings have to be cleanedafter 6 months at the latest;
replace PE filter, if necessary!
Disposal
This product should be disposed of in accordance with local regulations. If you
are unsure how to proceed, contact your local authority.
Only qualified technicians are authorized to undertake the repair of Manual
pipe bender.
For your safety , please observe all safety notes, precautions, and details in
this manual.

9
Warranty
1.This warranty shall only cover claims for damage due to a fault in the
product's manufacture
2.If a warranty claim is made, the party entitled to warranty cover must
present the proof of purchase, including the purchase date.
3.Customers’ satisfaction is always the motivation of our brand growth. We
promise to help you solve any issues . Please just let us know if you need
help.
OUR SERVICE TEAM PROMISES TO REPLY TO YOUR MESSAGE WITHIN
24H.
Scope of Warranty
1.We guarantee that VEVOR products are produced in accordance with
iso9001 Quality Management procedures and are free of manufacturing
defects for the period of warranty.
2.This warranty covers faults in the products due to manufacturing defects
within 1 year from date of purchase.After inspection by sales representative,
defective products will be replaced or repaired with equivalent goods free of
charge.
3.Any warranty claim made during warranty period shall not extend the overall
period of warranty coverage.
4.Warranty periods:Warranty claim date
WHAT IS NOT COVERED UNDER THIS WARRANTY:
A. Implied warranties, including those of merchantability and fitness for a
particular purpose are limited from the date of original purchase as stated in
the duration. If this product is used for commercial,industrial or rental
purposes,the warranty will apply for ninety(90)days from the date of purchase.
Some States do not allow limitation on how long an implied warranty lasts,so
the above limitations may not apply to you.
B. Any incidental, indirect, or consequential loss, damage or expense that
may result from any defect,failure,or malfunction of the product.
Some States do not allow the exclusion or limitation of incidental or
consequential damages,so the above limitation or exclusion may not apply to
you.

10
C. Any failure that results from an accident, purchaser's abuse.neglect or
failure to operate products in accordance with instructions provided in the
owner's manual(s) supplied with product. Accident,purchaser's abuse,neglect
or failure to operate products in accordance with instructions shall also include
the removal or alteration of any safety devices, if such safety devices are
removed or altered,this warranty is void.
D. Normal adjustments which are explained in the owner's manual(s) provided
with the product.
E. Items or service that are normally required to matntain the product,
i.e. O-rings,springs, bumpers, debris shields, driver blades,fuses,batteries,
gaskets,packing or seals,fluid nozzles,needles,sandblast nozzles,lubricants,
material hoses,filter elements, motor vanes,abrasives,blades,cut-off wheels,
chisels,chisel retainers,cutters, collets,chucks,rivet jaws,screw driver bits,
sanding pads,back-up pads,impact mechanism,or any other expendable part
not specifically listed. These items will only be covered for ninety(90)days
from date of original purchase. Underlined items are warranted for dafects in
material and workmanship only.
RESPONSIBILITIES OF WARRANTOR UNDER THIS WARRANTY:
Repair of replace, at warrantor's option, products or components which are
defective, have malfunctioned and/er failed to conform within duration of the
warranty period.
RESPONSIBILITIES OF PURCHASER UNDER THIS WARRANTY:
A. Provide dated proof of purchase and maintenance records.
B. Deliver or ship the product.Freight costs,if any,must be borne by the
purchaser.
C. Use reasonable care in the operation and maintenance of the products as
described in the owner's manual(s).
Table of contents
Other VEVOR Controllers manuals
Popular Controllers manuals by other brands

DitoGear
DitoGear DMC-16 manual

Skov
Skov DOL 534 Circuit Diagrams and Cable Plans

YASKAWA
YASKAWA J1000 CIMR-JC series CHEAT SHEET

PAW
PAW Domestic Installation and operation instructions for

Auber Instruments
Auber Instruments KIT-Cube5E Assembling Guide

Trane
Trane Tracer UC210 Installation, operation, and programming

Shenzhen USER Special DispllayTechnollogies Co.
Shenzhen USER Special DispllayTechnollogies Co. P817W Operation manual

NI
NI 500 Series Getting started

StudioComm
StudioComm 77 user guide

Ricoh
Ricoh AFICIO 1055 operating instructions

Endress+Hauser
Endress+Hauser Liquiline CM44P operating instructions

Johnson Controls
Johnson Controls CK721-A Installation and operation manual
