VEVOR HS-30R User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
RATCHETING CRIMPER
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

- 1 -
HS-30R HS-D1
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
RATCHETING CRIMPER
HS-30R
HS-D1

- 2 -
1. WARNING!
1 Disconnect wiring power supply before working.
2 Inspect before every use; do not use if damaged.
3 Keep away from children.
2. Product overview
Ratchet crimping pliers are tools used to connect conductors such as
cables and conductors. They are mainly used in electrical,
telecommunication and network industries. This product is characterized
by ratchet design, which makes the crimping process more convenient and
fast, while ensuring the quality of crimping stability and reliability.
3. Product parameter
1) Name: Ratcheting crimper
2) Model: HS-30R+HS-D1
3) Crimping range: AWG22-10
4) Applicable terminal spec：0.5~6mm2
5) Package Size: 305x120x50mm
6) G.W.: 1.06kg
4. Product structure
Crimps Heat Shrink terminals onto 10-22 AWG stranded copper wire
Convenient quick release lever
Built-in ratchet and unique cavity design
Adjustable design
(adds additional crimping force into each squeeze)
Color Markings:
22-16AWG(Red), 16-14AWG(Blue) & 12-10AWG(Yellow)
Quick release lever
Anti-skid handles

- 3 -
5. User Guide
1. Choose the appropriate crimping die: Select the corresponding crimping
die based on the cable and terminal specifications that need to be crimped.
2. Strip the cable to the appropriate length: Use the matching wire
stripping pliers to strip the cable insulation to the recommended length by
the terminal manufacturer.
3. Insert the terminal onto the stripped cable: Ensure good contact
between the cable and terminal, and securely insert the terminal onto the
cable.
4. Insert the cable and terminal into the crimping tool: Place the cable and
terminal into the corresponding slot in the crimping tool.
5. Begin crimping: Grip the handle of the crimping tool and use the
ratchet-style linkage structure to crimp until the handle automatically
tightens and opens. The crimping process is completed at this point.
6. Check the crimping effect: Check whether the crimped terminal is firm
and neat, and ensure the connection is reliable.
7. During the crimping process, you can press the Quick Release Lever to
quickly open the handle.
6. Safety and Maintenance
1.Before using the crimping pliers, make sure to select the correct jaws and

- 4 -
crimping range to avoid damaging the cable and terminals.
2.Do not use the crimping pliers for cables and terminals that are not
applicable, as this may cause equipment damage or unstable connections.
3.When using wire strippers, be careful to avoid cutting your fingers or
damaging the inner core of the cable.
4.Store the crimping pliers and wire strippers in a dry, dust-free
environment to prevent moisture and rust.
5.After using the crimping pliers and wire strippers, clean the surface dirt
with a clean cloth to keep the tools clean.
6.Regularly check the screw tightening of the tools. If there is looseness,
please tighten it in time.
7.Avoid placing the crimping pliers and wire strippers in high-temperature,
high-humidity, or chemically corrosive environments to avoid damaging the
tools.
Address: Baoshanqu Shuangchenglu 803long 11hao 1602A-1609shi Shanghai
Imported to AUS: SIHAO PTY LTD, 1 ROKEVA STREETEASTWOOD NSW
2122 Australia
Imported to USA: Sanven Technology Ltd., Suite 250, 9166 Anaheim Place,
Rancho Cucamonga, CA 91730
Made In China

Technical Support and E-Warranty Certificate
www.vevor.com/support
