VEVOR W10 User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
DIGITAL MICROSCOPE
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents
an estimate of savings you might benefit from buying certain tools with us compared to
the major top brands and does not necessarily mean to cover all categories of tools
offered by us. You are kindly reminded to verify carefully when you are placing an order
with us if you are actually saving half in comparison with the top major
MODEL:W10
brands.

W10
Please read this user manual carefully! Reading carefully will enhance your experience.
Please keep this user manual properly!
Have product questions? Need technical support? Please feel free to
contact us: Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
DIGITAL MICROSCOPE

User Manual Model：W10
Thank you for purchasing this device.
Please read this manual carefully before using it.
DIGITAL MICROSCOPE

1. Thank you for purchasing the digital microscope device. Before using it,
please read this user manual carefully.
2. This device complies with Part 15 of the FCC Rules.
（1）This equipment will not cause harmful interference
(2) This equiment must accept any interference received, including inter-
ference that may cause unitended operation.
Product Overview
01
Operation is subject to the following two conditions:
FCC Radiation Exposure Statement:
This equipment complies with the FCC rediation exposure limits estab-
lished for uncontrolled environments.

5. Please protect the lens carefully and make sure to cover the lens with the
cap after use to prevent dust or foreign objects from entering.
6. Please pay attention to the placement of specimens or other objects to
be observed, and try to place them in the center of the lens directly below.
This will avoid unclear observations and ensure a good user experience.
1. Please fully charge the product before first use. Please do not charge
directly through the PC, but choose a 5V-2A adapter.
4. When the battery is low, both the storage mode and camera mode cannot
be used normally. This is not a product failure.
2. This product is not a biological microscope and is not suitable for cell
biology research.
3. This product cannot be accurately read microscope magnification, it is a
combination of digital and optical magnification microscope, the specific
magnification effect is subject to the actual picture taken.
7. Do not disassemble the product or component struture by yourself to
avoid abnormal equipment use.
Important Notes
02

OK
Hex key x1 Screws x 4 Remote control x1 Data cable x1 HDMI cable x1
Fill light x2Column x 1 Base x 1 Screen x1
Accessories and tools
03
Micrometer
Calibration Ruler X1

Microscope components
Column
Card slot
Height adjustment
knob
Fill light
Screen
Lens light adjust-
ment knob
Fill light brightness
adjustment knob
Base
How to assemble
04
Decorative light

How to assemble
1. Connect the both by the connectors as
illustrated.
2. Align the column with the groove and insert it.
3. Insert four screws into the base to fix the
column.
4. Insert the fill light into the USB port.
05
groove

How to assemble
6. Insert the latch at the back of the host into
the dovetail slot on the column.
7. Insert the memory card and remove the
lens cap.
8. Adjust the height of the host to a suitable
level by using the height adjustment knob.
5.The Type-C on the top of the column is
connected to the host as illustrated .
06
SD
(The memory card is installed.)

Function Introduction
Base power
supply
interface
HDMI port
Charging
Camera
Memory
Charging indicator
The red light is on under
charging. The green light is
on when fully charged.
Please refer to page 22 for instructions on how to operate after connect-
ing the device to the computer using Type-C.
07
Interface usage instructions

Function Introduction
1
2
3 4 5 6 7 8
9
14
Button Functions
08
15
10
11
12
13

TF card slot
Adjust the host to the
appropriate height.
Function Introduction
Power button
Press and hold for 3 seconds to
switch on/off the device
Left button
Move up/Zoom in/Page up
Right button
Move down/Zoom out/ Page
down
Photo button
Take a photo
Video button
Start recording/End recording
Menu button
Open the menu/Exit the
menu
OK button
Confirm selection/Play/Pause
Infrared sensor
Receiving infrared remote
control signals
Fill light adjustment
knob
Left for bright
Right for dim
Focus ring
Magnification adjustment
Microscope optical focus
adjustment
Lens light adjustment
knob
Height adjustment
knob
Support expansion 0-64G
TF card
Status indicator light
Steady on after power on
Goes off after power off
1
Reset button
Reset to the original factory
defaults.
2
3
4
5
6
7
8
9
10
11
12
13
09
14
15
Left for dim
Right for bringt

OK
Remote Control
Before use, please remove the transparent
film from the side of the remote control.
Contains a Battery, Battery Model: CR2050
OK button
Confirm selection/Play/Pause
Back button
Photo button
Video button
10
Preview
Mode
page up
page down
Menu
Mode
move up
move down
Observation
Mode
zoom in
zoom out
Take a photo
Start recording/End recording
Move up/Zoom in/Page up
Move down/Zoom out/ Page
down
Menu button

Function Introduction
Supports connection to HDMI display
11
HDMI output for larger view
Connect the microscope to the screen via an HDMI cable, then turn on
the device, and you can watch it simultaneously on the large screen.

Overall Parameters of Microscope
Lens
Lens pixels
Magnification
2 MP
1300X
Focusing mode Manual
Focusing Distance
Video resolution
Photo resolution
0-40 mm
720/1080
2-48M
Video format MP4
Photo format
12
JPG

Screen Screen size
Screen resolution 1024*600P
TF capacity
Support expansion 0-64GB
Only support high-speed
storage cardof class 10 or
above, not including class 10
Battery capacity
Working time
5V/2A
4000mAh lithium battery
2.5hrs
Charging time
2.5hrs
Model
Other
Input voltage&current
13
Overall Parameters of Microscope
10.1” IPS
W10

Material
Operating tempera-
ture
Operating systems
8 high brightness LEDs
Simplified Chinese/Traditional
chinese/English/Français/ Deutsch
Español/Italiano/Português/ Japa-
nese
Languages
Camera temperature
Aluminum Alloy+ABS+PC
Other Light source
Windows 7and above
-10℃ ~55℃
-10℃ ~55℃
14
2个LED fill light
MacOS 11.0 and above
Overall Parameters of Microscope

2022/01/07 17:45:16
1080FHD
SettingVideo File Photo File
Battery Level Date
Time
Video
resolution
System Interface Guide
Startup Screen
15
Sample

Photo Resolution
Video Resolution
Exposure
Date Tags
Auto shutdown
Screen brightness
Language Settings
Date/Time
Line Support
Light source
frequency
Formatting
Default Settings
Versions
Settings Interface Functions
12M
16M
20M
24M
36M
05 29 2023
Month
05
(1)
（3）
(2)
System Interface Guide
Compensation
Date/Time
Line Support
Light source
frequency
Formatting
Default Settings
Versions
Date
Time
1. Setting: After powering on, the device
defaults to the observation mode. Click ,
button and then click the button to
select settings , click button to
enter the settings page, as shown in pictures
(1) and (2):
“ ”
“ ”
“ ” “ ”
2. Date/Time: Click button to
select and then click button to
enter the settings page. Click button
once to switch between year/month/day, and
click button to adjust the digits,
15
as shown in pictures (3):
“ ”
“ ”
Date/Time “ ”
“ ”
“ ”
“ ”
16
