VEVOR ADGT01 User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
Cordless Grass Trimmer
MODEL:ADGT01
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

1
ADGT01
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Cordless Grass Trimmer

2
Warning-To reduce the risk of injury, user must read instructions
manual carefully.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:(1)This device may not cause
harmful interference, and (2)this device must accept any interference
received, including interference that may cause undesired operation.
This product is subject to the provision of European Directive
2012/19/EC. The symbol showing a wheelie bin crossed through
indicates that the product requires separate refuse collection in the
European Union. This applies to the product and all accessories
marked with this symbol. Products marked as such may not be
discarded with normal domestic waste, but must be taken to a
collection point for recycling electrical and electronic devices
Safety instructions
---General safety instructions
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded)
power tool or battery pack-operated (cordless) power tool.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.

3
·Only use the product in the manner and for the functions described in these
instructions.
Work area safety
·Keep the work area clean and well-lit. Cluttered or dark areas invite accidents.
·Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
·Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
Electrical safety
·Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodified plugs
and matching outlets will reduce the risk of electric shock.
·Do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
·Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep the cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
·When operating a power tool outdoors, use an extension cord suitable for
outdoor use. The use of a cord suitable for outdoor use reduces the risk of electric
shock.
·If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
·It is recommended that appliances should be supplied via a residual current
device (RCD) with a tripping current of not more than 30mA.

4
Personal safety
·Stay alert, watch what you are doing, and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
·Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust masks, non-skid safety shoes, hard hats, or hearing
protection used for appropriate conditions will reduce personal injuries.
·Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to the power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energizing power tools that
have the switch on invites accidents.
·Remove any adjusting key or wrench before turning the power tool on. A wrench
or a key left attached to a rotating part of the power tool may result in personal
injury.
·Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
·Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
Power tool use and care
· Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and safer at the rate for which it was
designed.
· Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.

5
· Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures reduce the risk of starting
the power tool accidentally.
· Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands of untrained users.
·Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool's
operation. If damaged, have the power tool repaired before use. Many accidents
are caused by poorly maintained power tools.
· Keep cutting parts sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
·Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
CORDLESS HEDGE TRIMMER SAFETY WARNINGS
1. Keep all parts of the body away from the cutter blade. Do not remove cut
material or hold material to be cut when blades are moving. Make sure the
product is switched off when clearing jammed material. A moment of
inattention while operating the product may result in serious personal injury.
2. Carry the product by the handle with the cutter blade stopped. When
transporting or storing the product, always fit the cutting device cover.

6
Proper handling of the product will reduce possible personal injury from the cutter
blades.
3. Hold the product by insulated gripping surfaces only, because the cutter
blade may contact the hidden wiring of its own cord. Cutter blades contacting
a "live" wire may make exposed metal parts of the product "live" and could give the
operator an electric shock.
4. Check the hedge for foreign objects before the operation, e.g. wire fences.
5. Hold the product properly, e.g. with both hands if two handles are provided.
Loss of control can cause personal injury.
ADDITIONAL SAFETY WARNINGS
IMPORTANT
Read carefully before use
Keep for future reference
Training
·Read the instructions carefully. Be familiar with the controls and the proper use
of the appliance.
·Never allow children to use the product.
Never allow people unfamiliar with these instructions to use the appliance. Local
regulations may restrict the age of the operator.
·Never operate the appliance while people, especially children, or pets are
nearby.
·The operator or user is responsible for accidents or hazards occurring to other
people or their property.
Preparation
·Wear safety goggles and ear muffs while operating.

7
·Always wear substantial footwear and long trousers. Do not operate the
equipment when barefoot or wearing open sandals.
·Always wear suitable working clothes during working, which allow freedom of
movement.
·Never operate the appliance which is damaged, incomplete or changed without
the approval of the manufacturer.
Operation
·Disconnect the battery from the product:
whenever you leave the product,
before clearing a blockage,
before checking, cleaning or working on the product,
if the product starts to vibrate abnormally.
·Operate the product only in daylight or in good artificial light.
·Do not overreach and keep your balance at all times.
·Always be sure of your footing on slopes.
·Walk, never run.
·Keep all ventilation openings clear of debris.
·Never blow debris in the direction of bystanders.
Maintenance and storage
1). Keep all nuts, bolts and screws tight to be sure the product is in safe working
condition.
2). Check the collection bag frequently for wear or deterioration.
3). Replace worn or damaged parts.

8
4). Store the product only in a dry place.
5). Use only spare parts and accessories approved by the manufacturer.
Residual risks
Even if you are operating this product in accordance with the provisions, residual
risks will always still remain. The following dangers can arise in connection with
the structure and design of this product:
1). Health defects resulting from vibration emission if the product is being used
over a longer period of time or not adequately managed and properly maintained.
2). Injuries and damage to property due to broken accessories or hidden objects
that are suddenly dashed.
3). Injuries and damage to property due to thrown and fallen objects.
WARNING! This product produces an electromagnetic field during operation! This
field may, under some circumstances, interfere with active or passive medical
implants! To reduce the risk of serious or fatal injury, we recommend persons with
medical implants consult their physician and the medical implant manufacturer
before operating this product!
Vibration and noise reduction
To reduce the impact of noise and vibration emission, limit the time of operation,
use low-vibration and low-noise operating modes as well as wear personal
protective equipment.
Emergency
Familiarise yourself with the use of this product by means of this instruction
manual. Memorize the safety directions and follow them to the letter. This will help
to prevent risks and hazards.
1). Always be alert when using this product so that you can recognize and handle
risks early. Fast intervention can prevent serious injury and damage to property.

9
2). Stop the motor and disconnect the battery from the product if there is any
malfunction. Have the product checked by a qualified professional and repaired, if
necessary, before you put it into operation again.
Safety Warnings and Instructions: Batteries
■. Do not disassemble or open, drop (mechanical abuse), crush, bend or deform,
puncture, or shred.
■. Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, expose to fire, excessive heat
including soldering irons, or put in a microwave oven.
■. Only use the battery/tool with a charging system specified by the
manufacturer/supplier.
■. Do not short-circuit a battery or allow metallic or conductive objects to contact
both battery terminals simultaneously.
■. Dispose of used batteries promptly according to the manufacturer/supplier's
instructions.
■. Improper battery/tool use may result in a fire, explosion, or other hazards.
■. Battery/tool usage by children should be supervised.
Safety Warnings and Instructions: Charging
1. This manual contains important safety and operating instructions.
2. Before using the battery charger, read all instructions and cautionary warnings
on the battery charger and the product using the battery. CAUTION: To reduce the
risk of injury, use this charger only with this product. Batteries in other products
may burst, causing personal injury or damage.
3. Do not expose the charger to rain or snow.
4. Use of an attachment not recommended may result in a risk of fire, electric
shock, or injury to persons.
5. To reduce the risk of damage to the electric plug and cord, pull by plug rather
than cord when disconnecting the charger.
6. Make sure the cord is located so that it will not be stepped on, tripped over, or
otherwise subjected to damage or stress.
7. An extension cord should not be used unless absolutely necessary. Use of
improper extension cords could result in a risk of fire, electric shock or

10
electrocution.
a. An extension cord must have adequate wire size (AWG or American Wire
Gauge) for safety, and to prevent loss of power and overheating. The smaller the
gauge number of the wire, the greater the capacity of the cable; that is, 16 gauge
has more capacity than 18 gauge. When using more than one extension to make
up the total length, be sure each extension contains at least the minimum wire
size.
CHART FOR MINIMUM WIRE SIZE (AWG) OF EXTENSION CORDS
NAMEPLATE RATING AMPS – 0 – 10.0
Total Extension Cord Length (ft) 0-25 26-50 51-100 101-150
(0-7.6m) (7.6-15.2m) (15.2-30.4m) (30.4-45.7m)
Wire Gauge 18 16 16 14
8. Use only the supplied charger when charging your tool. The use of any other
charger could damage the tool or create a hazardous condition.
9. Use only one charger when charging.
10. Do not attempt to open the charger. There are no customer-serviceable parts
inside. Return to any authorized Black & Decker service center.
11. DO NOT incinerate the tool or batteries, even if they are severely damaged or
completely worn out. The batteries can explode in a fire. Toxic fumes and materials
are created when lithium-ion battery packs are burned.
12. Do not charge or use a battery in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Inserting or removing the battery
from the charger may ignite dust or fumes.
13. If battery contents come into contact with the skin, immediately wash the area
with mild soap and water. If battery liquid gets into the eye, rinse water over the
open eye for three minutes or until irritation ceases. If medical attention is needed,
the battery electrolyte is composed of a mixture of liquid organic carbonates and
lithium salts.
WARNING: Burn hazard. Battery liquid may be flammable if exposed to a spark
or flame.

11
PRODUCT SPECIFICATIONS
Model
ADGT01
Rated Voltage
20V DC
No Load Speed
7600rpm
Cutting Device
Auto Feed
Cutting Swath
Diameter
300mm
Guaranteed
Sound Power
Level
92 dB(A)
Battery Charger
HY-1287U1
Battery Pack
VV-SP2020 (20V 2AH)
VV-EX2040 (20V 4AH)
These instructions should be read in conjunction with the instruction
manual for the battery pack and charger.
SYMBOLS
Warning, safety alert.
Read and follow all safety precautions in the owner's manual.
Protective goggles/visor, protective helmet & hearing
protection.
Do not expose to rain.
Beware of throwing or flying objects at bystanders. Keep
bystanders at a safe distance away from the machine.
Thrown objects can ricochet and result in personal injury or
property damage. Wear protective clothing and boots.
Beware of falling objects. Keep bystanders away.

12
CHARGING PROCEDURE
IMPORTANT: The battery pack is not fully charged at the factory. Before
attempting to charge them, thoroughly read all of the safety instructions.
(1) To ensure that the charger you use is applicable to the battery pack.
(2) Plug the charger plug into the charging hole of the battery pack.
(3) Plug the charger into any suitable standard outlet.
(4) Let the battery pack charge initially, for the green light is twinkled. If the power
lights are all lighting, the battery pack is fully charged.
Recharge discharged batteries as soon as possible after use or battery life
may be greatly diminished. For the longest battery life, do not discharge
batteries fully.
It is recommended that the batteries be recharged after each use.
WARNING: Fire Hazard. When unplugging the output plug from the charging hole,
be sure to unplug the charger from the outlet first, then disconnect the charger
output plug from the charging hole.
Important Charging Notes
1. Your tool was sent from the factory in an uncharged condition. Before attempting
to use it, it must be charged.
2. CAUTION: To reduce the risk of damage to the batteries, NEVER charge them
in an air temperature below 40°F (4.5°C) or above 105°F (40.5°C). Also, NEVER
charge them if the battery temperature is below 40°F (4.5°C) or above 105°F
(40.5°C). The longest life and the best performance occur when batteries are
charged with an air temperature of approximately 75°F (24°C). NOTE: The tool will
not charge if the tool temperature is below approximately 32°F (0°C) or above

13
113°F (45°C).
3. While charging, the charger may hum and become warm to the touch. This is a
normal phenomenon and does not indicate a problem.
4. If the batteries do not charge properly—(1) Check the current at the receptacle
by plugging in a lamp or other appliance. (2) Check to see if the receptacle is
connected to a light switch that turns the power off when you turn out the lights. (3)
Move the charger and tool to a surrounding air temperature of 40°F (4.5°C) to
105°F (+40.5°C). (4) If the receptacle and temperature are OK, and you do not get
proper charging, take or send the tool and charger to your local service center.
See Tools Electric in the yellow pages.
5. The tool should be recharged when it fails to produce sufficient power on jobs
that were easily done previously. Battery life may be greatly diminished if batteries
are discharged deeply. DO NOT CONTINUE using the product with its batteries in
a depleted condition. Recharge discharged batteries promptly.
6. To maximize battery life:
a. Do not fully discharge batteries.
b. Fully recharge batteries after each use.
c. Store the tool in a location where the surrounding air temperature is
approximately 40°F-75°F (4.5°C - 24°C).
d. Disconnect the charger from the tool after the charge is complete.
WARNING: Fire Hazard. When disconnecting the charger from the tool, be sure to
unplug the charger from the outlet first, then disconnect the charger cord from the
tool.

14
MAJOR PARTS OF THE GRASS TRIMMER
1 unlock knob 2 switch handle
3 main handle 4 battery pack
5 Auxiliary handle 6 handle lock nut
7 handle support 8 locking sleeve(length adjustment)
9 telescopic pole 10 lock sleeve and edging function button
11 trimmer head 12 edging function wheel
13 flower guard 14 head rotary button
15 safety guard 16 spool

15
Scope of delivery
---Grass trimmer
---Battery pack
---Charger
---Safety guard
ASSEMBLY
Warning! Remove the battery pack before cleaning or maintaining the
tool, fitting the plant guard before making any adjustments to the tool, especially
around the string head. Remove the battery pack before transporting or storing the
tool.
Replacing the spool
WARNING: Remove the battery pack before attempting to replace the string spool.
(Fig.1—Fig4)
-This trimmer uses 0.065 in. (1.6mm) diameter round nylon line. During use, the
tips of the lines will become frayed and worn. Restarting the machine will feed and
trim a fresh length of the line.
-When no line is fed, remove the battery pack and turn the machine upside-down
so that you are looking down at the spool cap.
-Press the tabs and remove the spool cap from the spool housing in the trimmer
head.
-Grasp the empty spool retainer with one hand and pull it out.
-Unfasten the line end of the new string spool and guide the line into the eyelet,
then push the spool onto the head and rotate the spool slightly until it's fully
inserted.
-Align the tabs on the spool cap with the slots in the housing.
-Push the cap onto the housing until it snaps securely into place.

16
Fitting the guard
WARNING: Remove the battery pack before attempting to attach the guard. Never
operate the tool without the guard firmly in place. The guard must always be on the
tool to protect the user.
-Push the Head Rotation Pedal to rotate the cutting head to a vertical position,
then rotate the flower Guard (13) forward to the working position.
-Insert the Safety Guard (15) to fix. When you hear the click sound, this means it is
already fixed.
Fig.5

17
Fitting and Removing the battery (Fig6—Fig7)
Fig.6 Fig.7
The battery should always be removed whenever you are not using
the tool and especially when you are adjusting or transporting the tool to
avoid accidental operation.
To insert the battery, slide it into the grass trimmer until it latches into place. Check
that the battery is securely locked into place ( Fig.6-7)
To remove the battery, press and hold the button on the two sides of the battery
pack and slide the battery away from the trimmer.
OPERATION
BEFORE OPERATING THIS TOOL, ENSURE THAT THE GUARD IS
FITTED TO THE HEAD OF THE MACHINE. NEVER USE THE MACHINE
WITHOUT THE GUARD.
Starting/Stopping the trimmer:
To switch the trimmer on, first press the unlock knob(1), then press the switch
handle(2), and the trimmer is running. You can release the unlock knob.
To switch the trimmer off, release the switch handle. Be aware that the blade will
continue to rotate for a short period.

18
Trimming tips:
-Keep the trimmer tilted toward the area being cut. This is the most efficient cutting
area.
-The string trimmer cuts when moving the unit from left to right. This will avoid
throwing debris at the operator.
-Use the tip of the string to do the cutting, do not force the string head into uncut
grass.
-Wire and picket fences cause extra string wear, and breakage. Stone and brick
walls, curbs, and wood may wear string rapidly.
-Avoid trees and shrubs. Tree bark, wood moldings, siding, and fence posts can
easily be damaged by the strings.
2. Converting to edging mode (Fig. 8 & 9)
-Hold the Main Handle, pull the button on the tube end backward, and rotate the
tube by 90°.
-Release the button to fix the edging mode and position the trimmer with flower
Guard to operate as a maintenance edger
-Restart the machine after a complete stop. It will feed the spool line automatically.
-Return to the trimming position by reverse rotation after pulling the button
backward.

19
NOTE: The cutting line will wear faster and require more feeding if the cutting or
edging is done along sidewalks or other abrasive surfaces or if heavier weeds are
being cut.
Setting the handle length
Turn the lock sleeve towards the 'unlock' symbol about half a turn. Slide the lower
part of the trimmer up or down to the desired length. Lock it in position by turning
the lock sleeve towards the 'lock' symbol.
unlock
Fig.10
3. Adjusting the cutting head (Fig. 11)
-Push the Head Rotation Pedal to rotate the cutting head to cut the grass under a
bush or tree.
-Push the Head Rotation Pedal to rotate the cutting head back to the trimming
position.
