VEVOR SW-2030M User manual

SQUARE WAFFLE MAKER
SW-2030M
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and doses not necessarily mean to
cover all categories of tools offered by us.
You are kindly reminded to verify carefully when you are placing an order with
us if you are actually saving half in comparison with the top major brands.
Support and E-Warranty Certificate
www.vevor.com/support

01
SQUARE WAFFLE MAKER
SW-2030M
Instruction Manual
TOUGH TOOLS, HALF PRICE
NEED HELP? CONTACTUS!
Have product questions? Need technical support? Please feel free to contact us:
[email protected]
This is the original instruction, please read all manual instructions carefully before operating.
VEVOR reserves clear interpretation of our user manual. The appearance of the product shall
be subject to the product you received. Please forgive us that we won't inform you again if
there is any technology or software updates on our product.
MODEL NO.: SW-2030M

02
IMPORTANT SAFEGUARDS
This manual will outline safety warnings and precautions, operating, maintenance and cleaning. The warnings and
instructions reviewed in this manual cannot cover all possible conditions and situations that may occur. Caution and
common sense are not built into this product, since we believe that the uses will comply with these codes.
Please read ALL the instructions before using your machine.
1. Make sure the voltage in your outlet is the same as the voltage indicated on the appliance's rating label.
2. Do not let children and minors get close to or touch the machine.
3. Do not touch the hot surface directly with your hands. Always operate with handle or knob.
4. To prevent electrical shock, do not immerse the cord or plug into water or other liquids.
5. Do not immerse the appliance in water or any other liquid.
6. Unplug the machine from the outlet when not in use and before cleaning. Cool the appliance before installing or
removing parts and before cleaning.
7. Cool down the HOT parts before operation.
8. Do not operate the device with damaged cord or plug, malfunction or with any mechanical damage. Send it to your
nearest authorized service centre for examination and repair (ONLY technicians should open up the unit).
9. Using any accessories or attachments that are not provided or recommended by the manufacturer may cause
injury.
10. If the machine is not to be used for a long period of time, unplug it, clean and cover it and store it in a dry and safe
place.
11. Do not leave the power cord hanging over the edge of table or counter or let it come into contact with any hot
surfaces.
12. Do not place the unit on or near hot air, electric burners or heaters.
13. Always switch off the power before plugging in or unplugging. Hold the plug instead of pulling on the cord.
14. Do not apply this unit to any other purposes than the indicated usage.
15. Do not use it outdoors or for commercial purposes.
16. KEEP IT OUT OF CHILDREN'S REACH.
17. DO NOT CLEAN IT WITH ANY ABRASIVE MATERIAL.
18. Never leave it unattended while in use.
19. Always check that this machine is plugged into a grounded outlet with the appropriate electrical supply. Ensure
that the wall outlet being used is properly grounded. If not, you must install a grounded outlet. Have the work
performed only by a certified electrician who is properly qualified to meet local safety and electrical codes.
20. Ensure that the power outlet, plug and cord being used are in good working condition. Damaged components
should be repaired by a certified electrician who is qualified to meet local safety and electrical codes. Even if your
power cord is functioning properly, keep it away from water and avoid letting it run over carpets or heating devices.
21. Avoid using it in the presence of flammable liquids, gases, dust or other explosive situations.
22. Extreme caution must be taken when moving an appliance containing hot oil or other hot liquids.
23. Do not operate the machine in an appliance garage or under a wall cabinet. Always unplug the unit from the
electrical outlet when storing in an appliance garage. Otherwise, it would cause a risk of fire, especially if the machine
touches the garage wall or the door touches it as it closes.
24. Type X attachment: If the supply cord is damaged, it must be replaced by a special cord or assembly available
from the manufacturer or its service agent.
25. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the
machine alone. Cleaning and user maintenance shall not be made by children without supervision.
Thank you for using this product. In order to make sure that you can operate the machine correctly, read this
instruction carefully before operation and keep it properly for future reference. Please be sure to read the precautions
and safety rules in this page to ensure your safe use.

03
PRODUCT PARAMETERS
CIRCUIT DIAGRAM
NOTE:
1. The voltage used for this device must be the same as the power supply voltage.
2. Users need to install it near the power switch and fuse.
Region
North America AC120V 60Hz
Voltage Input Power
1200W
Plug Type
American PLUG
MODEL NO.: SW-2030M
MODEL NO.: SW-2030M
L
N
Top Heater Element 120V~ 60Hz 600W Top Heater Element 120V~ 60Hz 600W
T / S
LAMP
LAMP
FUSE(240°C)
INPUT:120V~ 60Hz

04
PRODUCT COMPONENTS
1. Handle 2. Non-stick Plate
3. Knob 4. Power Light (Red)
5. Ready Light (Green) 6. Upper Housing
7. Bottom Housing

05
OPERATING INSTRUCTIONS
Before using the appliance for the first time, peel off any promotional materials and packaging materials, and check
that the cooking plates are clean and free of dust. If necessary, wipe them over with a damp cloth. Spread over with
an absorbent kitchen towel and wipe off any excess oil. When your appliance is heated for the first time, it may emit
slight smoke or odor, which is normal for many heating appliances, and will not affect the safety of your appliance.
STEPS TO MAKE WAFFLE
1. Place the machine on a clean, dry, level surface near a plug base outlet.
2. Plug the cord into the wall outlet. And you will notice that red power indicator light starts flashing.
3. Set the temperature level to your desired setting: “Low” for light colored waffles and “High” for darker. At first, try
setting it to the max. You may later adjust it lower or higher according to your preference.
4. Allow your appliance to pre-heat until the
ready light (green) goes on. This indicates that the cooking plates have
reached the appropriate temperature for cooking.
5. Divide the mixture into pan holes as per recipes with a jug & spoon or fabric piping bag.
6. Gently close the lid. Do not slam it down as it may cause the mixture to run off the cooking plates.
7. Cook for approximately 3- 6 minutes or until golden.
8. Always use a plastic or wooden spatula to remove waffles. Never use a sharp object or metal, as this will damage
the non-stick surface of cooking plates.
NOTE:
1. This Wae Maker has been treated with a special nonstick coating. Before each use, we suggest you season the
wae grids by spraying or brushing with cooking spray or avorless vegetable oil to thoroughly coat the grids. Wipe
with a paper towel or past brush.
2. For best results, do not open wae maker indicating that cooking process.
3. Do not use disposable plastic piping bags as these may melt if they come into contact with the hot plates.
TIPS & HINTS
BATTER SUGGESTIONS
1. Packaged waffle mixes found in most supermarkets may be used with this unit.
2. For best results, we recommend filling full waffle grids.
3. For evenly filled waffles, pour the batter into the center of the lower grid and spread out evenly to the edges. The
entire waffle grid should be filled.
4. For best results, lightly spray the cooking plates with cooking oil before using. This will assist in the removal of the
waffles after cooking.
COOKING SUGGESTIONS
1. If waffles tend to stick to waffle grids, slightly add more oil or butter to the batter.
2. Belgian waffles taste best when made to order, but baked Belgian waffles may be kept warm in a 200°F (93.3℃)
oven. Place them in a baking pan or wrap them in foil while in the oven. Waffles wrapped in foil may lose their
crispness.
3. Baked waffles may be frozen. Allow them to cool completely, and then place them in a plastic food storage bag.
Use waxed paper to keep waffles separated. Reheat in an oven, toaster or toaster oven when ready to serve.

06
STORAGE
1. Always unplug the Wae Maker before storage.
2. Always make sure the Wae Maker is cool and d before string.
3. The power cord can be wrapped around the bottom of base for storing.
CLEANING AND MAINTENANCE
1. Once you have finished baking, remove the plug from the electrical outlet.Leave the top lid open and allow the
grids to cool down completely before cleaning.
2. Brush crumbs from grooves, and absorb any excess cooking oil by wiping with a dry cloth or paper towel. You may
clean the grids by wiping with a damp cloth to prevent staining and sticking from batter or oil buildup.
3. Never take your waffle maker apart for cleaning. Be certain that grids have cooled completely before cleaning.
4. If batter adheres to the plates, simply pour a little cooking oil onto the baked batter and let it stand approximately
five minutes, allowing batter to soften for easy removal.
5. To the exterior, wipe with a soft, dry cloth. Never use an abrasive cleanser or harsh pad.
6. Any other servicing should be provided by an Authorized Service Representative.
CAUTION:
1. Never immerse cord, plug or unit in water or other liquids.
2. Be certain that grids have been cooled completely before cleaning.
3. In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this
appliance must not be supplied through an external switching device, such as a timer, or
connected to a circuit that is regularly switched on and off by the utility.
