Via Seating Linate User manual

Linate
user guide
205 Vista Boulevard, Sparks, Nevada 89434 lPhone: 800-443-6614 lviaseating.com
table of contents
67C control mechanism
12LUM adjustable lumbar support
pg. 3
pg. 1
pg. 2
pg. 4
pg. 5
pg. 6
pg. 7
51A/53A adjustable height arm with 4-ways adjustable cap option
9C/9CH control mechanism
10C/10CH control mechanism
11C control mechanism
67CSS with optional FT control mechanism

775 331 6001
[e-mail]
www.viaseating.com
1
Linate
user guide
Additional Width Adjust-
ment(Only applies to 19AB):
Pull back on the “levers” under
the arms to unlock and extend
the arms outwards. Push forward
on the levers to lock.
To put them back to normal
simply just do the opposite.
Unlock (pull back on the lever)
and push the arms back in to
place, and lock the arms by
pushing the lever forward.
Arm height adjustment:
While lifting up on the
small “switch”, use your
hand grasping the arm
cap to raise and lower the
arm height.
51A/53A adjustable height arm with 4-ways adjustable cap option
Switch
(Lever)
Switch
(Lever)
Switch
(Lever)
Arm cap slide: Grasp
and slide “arm cap”
forward or backward,
sliding forward a max
of 2.5”.
Arm cap rotation: Grasp
and lift “arm cap” to turn
left or right, rotating a max
of 15° each way.

775 331 6001
[e-mail]
www.viaseating.com
2
Linate
user guide
9C/9CH control mechanism
Right
knob
Left
knob
Seat height adjustment:
Adjust the seat height by
lifting your weight out of the
chair and pulling up on the
“paddle”. Proper seat height
is realized when the top
of your legs are somewhat
parallel to the oor.
Back/recline tension adjustment:
Pull “knob” out and turn right to
tighten or left to loosen the back
tension.
Pull up
on paddle
Pull up
on paddle
Note: 9CH variation uses a heavy duty spring tension.
Single rotation back tilt lock
adjustment (5 position): Tilt the
seat back to desired angle and
twist the “knob” a quarter turn.
To unlock, twist the other way,
leaning back to unlock.

Linate
user guide
775 331 6001
[e-mail]
www.viaseating.com
3
10C/10CH control mechanism
Right
knob
Left
knob
Seat height adjustment:
Adjust the seat height by
lifting your weight out of the
chair and pulling up on the
“paddle”. Proper seat height
is realized when the top
of your legs are somewhat
parallel to the oor.
Seat slider: Pull up on “paddle”
while shifting your weight forward
to move your seat forward or
backward to move your seat
back.
Single rotation back tilt lock
adjustment (5 position): Tilt the
seat back to desired angle and
twist the “knob” a quarter turn.
To unlock, twist the other way,
leaning back to unlock.
Back/recline tension adjustment:
Pull “paddle” out and turn right to
tighten or left to loosen the back
tension.
Pull up
on paddle Pull up
on paddle
Note: 10CH variation uses a heavy duty spring tension.
Pull up
on paddle

Linate
user guide
775 331 6001
[e-mail]
www.viaseating.com
4
11C control mechanism
Right
lever
Knob
Seat height adjustment:
Adjust the seat height by
lifting your weight out of the
chair and pulling up on the
“paddle”. Proper seat height
is realized when the top
of your legs are somewhat
parallel to the oor.
Back lock adjustment (Single
position): Use the same “paddle”
as you use for the seat height
adjustment. To lock the chair in
an upright position, shift your
weight forward until the chair is
in an upright position. Then push
lever in. To rock (free oat) shift
your weight forward and pull the
lever out.
Back/recline tension adjustment:
Rotate “knob” clockwise to
increase tilt tension. Rotate knob
counter clockwise to decrease tilt
tension.
Pull up
on paddle
Push the lever in to
lock the position
To rock (free oat)
shift your weight
forward and pull the
lever out

Linate
user guide
Right
knob
Left
knob
Seat height adjustment:
Adjust the seat height by
lifting your weight out of the
chair and pulling up on the
“paddle”. Proper seat height
is realized when the top
of your legs are somewhat
parallel to the oor.
Single rotation back tilt lock
adjustment (5 position): Tilt the
seat back to desired angle and
twist the “right knob” slightly.
To unlock, twist the other way,
leaning back to unlock. The turn
is smooth. All tilt lock angles
can be reached within a single
turn of the handle.
Back/recline tension adjustment:
Rotate knob right to increase tilt
tension. Rotate “left knob” left to
decrease tilt tension. Rotate within
a single rotation of the knob to
achieve any of the 7 distinct back
tension levels.
Pull up
on paddle
67C control mechanism
Pull up
on paddle
775 331 6001
[e-mail]
www.viaseating.com
5

Linate
user guide
775 331 6001
[e-mail]
www.viaseating.com
6
67CSS with optional FT control mechanism
Right
knob
Left
knob
Seat height adjustment:
Adjust the seat height by
lifting your weight out of the
chair and pulling up on the
“paddle”. Proper seat height
is realized when the top
of your legs are somewhat
parallel to the oor.
Seat slider: Pull up on “paddle”
while shifting your weight forward
to move your seat forward or
backward to move your seat back.
Single rotation back tilt lock
adjustment (5 position): Tilt the
seat back to desired angle and
twist the “right knob” slightly.
To unlock, twist the other way,
leaning back to unlock. The turn
is smooth. All tilt lock angles
can be reached within a single
turn of the handle.
Back/recline tension adjustment:
Rotate knob right to increase tilt
tension. Rotate “left knob” left to
decrease tilt tension. Rotate within
a single rotation of the knob to
achieve any of the 7 distinct back
tension levels.
Pull up
on paddle
Pull up
on paddle
Pull up
on paddle
Pull up
on paddle
Forward tilt adjustment (FT): Push the “paddle” in
the down position and lean back in the chair. You
will hear a click when the forward tilt mechanism
has turned on. Sit in your normal position to use
the forward tilt feature. To turn off the forward tilt
feature, lift the paddle in the up position and lean
back in the chair. You will hear a click when the
forward tilt mechanism has turned off.
Pull up
on paddle Pull up
on paddle

775 331 6001
[e-mail]
www.viaseating.com
7
Linate
user guide
12LUM mechanical lumbar
Lumbar position adjustment: Turn the “knob”
clockwise (forward toward front of chair) to
increase lumbar support, pushing the lumbar
cushion forward into the back. Turn the knob
counter-clockwise (backward toward back of
chair) to decrease lumbar support, moving
the lumbar cushion away from the back. This
adjustment is made from a seated position.
Clockwise = more lumbar support
Counter-clockwise = less lumbar support
Adjustment
knob
View is back
of chair
Adjustment
knob
