Vicks V5100N - Vicks Ultrasonic Humidifier User manual

Use and Care
Manual
Ultrasonic Humidifier
IMPORTANT!
READ AND
SAVE THESE
INSTRUCTIONS

Cool Mist for
Relief of Cold and
Flu Symptoms

Whisper Quiet

20 Hours Operation
Between Fillings
If you have any
questions about
the operation of your
ultrasonic humidifier,
call our toll-free
Consumer Service line
at 800 477-0457
k
Manufacturing Quality Healthcare Products for Over 70 Years

Important Safety Instructions
READ ALL INSTRUCTIONS BEFORE USING HUMIDIFIER,
ESPECIALLY THESE BASIC SAFETY PRECAUTIONS:
1. Always place humidifier on a firm, flat, level surface. Keep cord away from heated
surfaces and out of the way, where it can not be stepped on or tripped over.
2. Before using the humidifier, extend the cord and inspect for any signs of damage. Do
not use product if cord has been damaged.
3. To avoid the risk of fire, shock or personal injury, do not use an extension cord.
4. Humidifier should always be unplugged and emptied when not in operation or while
being cleaned. Shut off and unplug humidifier before moving. Do not move or tilt
humidifier while it is operating. Plug and unplug unit with dry hands.
5. Do not operate without water. Turn off unit when tank is empty.
6. Do not add any medications (e.g., do not add Kaz Inhalant or Vicks VapoSteam) into
the Nozzle, Base, Reservoir or Water Tank. Do not cover, or insert objects into, any
openings on the unit.
7. Do not immerse the Base in water or other liquid. Do not overfill.
8. Do not operate outdoors, this appliance is intended for indoor use.
9. Do not place in direct sunlight, high-temperature areas, or near computers or sensitive
electronic equipment.
10. This product has a polarized plug (one blade is wider than the other) as a safety feature.
This plug will fit into a polarized outlet only one way. If the plug does not fit fully into
the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not
attempt to defeat this safety feature.
11. The humidifier should not be left unattended in a closed room since air could become
saturated and leave condensation on walls or furniture. Leave room door partly open.
Do not aim Mist Nozzle directly at children, walls or furniture.
12. Do not place the humidifier directly on wood furniture or other surfaces which could be
damaged by water. Protect by placing the humidifier on a non-metallic waterproof
surface.
13. Do not touch the Nebulizer while the unit is plugged in as burns could result.

Directional Mist Nozzle
Water Valve
Reservoir
Air Outlet
Water Sensor
Ultrasonic Nebulizer
Power Switch
Power Indicator
Ultrasonic Humidifier
Carrying Handle
Water Tank
Tank Cap
Demineralization Cartridge
(included in certain models)
Base
Mist Intensity
Control

Using Your Ultrasonic Humidifier
First Time Use
Read all instructions before using this appliance.
Unpack and remove all packing material from the Water Tank, Mist Nozzle and Base.
Completely unravel power cord and place unit on a flat, stable surface. If a demineralization
cartridge is included, remove its protective wrapper and replace it into the Base as illustrated
above. Follow the directions below to fill and operate the humidifier.
Filling the Water Tank
Always UNPLUG the humidifier before filling.
1. Remove the Directional Mist Nozzle from the Water Tank. Remove the Water Tank from
the Base and turn it upside down. Turn the Tank Cap counterclockwise to open. Rinse and
wipe clean.
2. Fill the Water Tank with clean, cool, tap water and replace the Tank Cap by firmly turning
clockwise. Turn the Tank upright and check Tank Cap for leaks. If any water drips from
Tank Cap, remove it and re-tighten. Use of very cold water may temporarily
reduce the mist output. Never fill the humidifier with hot or warm water as
this could cause damage and void your warranty.
To avoid white dust we recommend using a Kaz Demineralization Cartridge (Model DC-51)
and replacing it after 30-40 fillings. If you live in an extremely hard water area you may
also wish to use distilled water to further reduce white dust. Refer to About White Dust.
3. Inspect the Base and Nebulizer for cleanliness. Refer to Care and Cleaning section.
4. Replace the Water Tank on the Base and reinstall the Mist Nozzle on the Water Tank.
Operating Instructions
1. Do not operate the humidifier without water in the Water Tank.
2. After filling the humidifier, be sure the Power Switch is in the OFF position, then plug the
power cord into a 120 volt AC wall outlet.
3. Slide the Power Switch to the On position. The Power Indicator will illuminate.
4. Set the Mist Intensity Control to the desired setting. To increase mist, slide Control to the
right; slide Control to the left to decrease mist.
5. Mist will not appear immediately; allow a few minutes for the water to fill the Reservoir. If
you are using a new Demineralization Cartridge, it may take up to fifteen minutes for the
filtering material to become saturated and for mist to appear.
6. Direct Mist Nozzle away from walls and furniture. If condensation forms on walls or
windows, or if indoor relative humidity exceeds 50%, reduce Mist Intensity Control
setting, open door to room where humidifier is operating, or turn unit off.

7. If mist is not produced, unplug cord and check the Water Sensor in the Reservoir to
ensure it is in contact with the water. The water level in the Base must be high enough to
partially immerse the Water Sensor in order for the humidifier to work.
8. Turn the humidifier off before removing and refilling the Water Tank. When the Tank is
empty the mist will stop although the fan will continue to operate.
About White Dust
Use of high-mineral-content water will cause a white mineral residue to accumulate on room
surfaces near the humidifier. The mineral residue is commonly called “white dust.”. The higher the
mineral content (the harder your water is), the greater the potential for white dust. The white dust is
not caused by a defect in the humidifier, but is due only to minerals suspended in the water.
Kaz Demineralization Cartridge(Model DC-51)
This Humidifier may be supplied with a demineralization cartridge that removes minerals from
the water. This prevents the precipitation of minerals (“white dust”) that can occur in hard water
areas. The demineralization cartridge is designed to last for about a month to two months of
normal use; the effective time will vary depending on the mineral content of the water used. If
you live in a hard water area, we recommend the use of distilled water for better results from
the humidifier.
If you are using distilled water in the humidifier, you may find the demineralization cartridge
unnecessary. And, if you choose, you may operate the humidifier without it.
Replacement Cartridge Model DC-51 should be available where you purchased the humidifier.
For assistance in locating an outlet near you or to purchase directly from Kaz, please call (800)
477-0457.
Care and Cleaning
CAUTION: ALWAYS TURN OFF THE POWER SWITCH AND DISCONNECT THE POWER
CORD FROM THE ELECTRICAL OUTLET BEFORE CLEANING.
Daily Maintenance:
1. Lift the Water Tank from Base and empty all water from the Reservoir. Remove the Tank
Cap and drain any water from the Water Tank. Wipe it clean with a soft, damp cloth. The
Mist Nozzle should be removed during cleaning to prevent damage.
2. Do not immerse the Base in water. Gently wipe the Reservoir with a soft, clean, wet cloth.
Do not attempt to remove or in any other way modify the Water Sensor. Use care when
wiping around the Water Sensor; it is delicate and can be easily damaged. Rinse the
Water Tank with lukewarm water after each use. For storage, wipe dry with a soft, clean
cloth. Keep water away from the Air Outlet.

3. Do not use detergent to clean any water-containing parts of the humidifier. Detergents
and the film they leave behind can affect the output of the humidifier. Do not use
abrasive cleansers or brushes.
4. Do not leave water in the Water Tank or Reservoir when unit is not in use as it may result
in the build up of mineral deposits and bacteria that can inhibit the output efficiency of
the humidifier. Please note that if water remains in the Water Tank for more than a day or
two, bacterial growth is possible.
Weekly Maintenance:
1. Thoroughly clean humidifier every week using a solution of bleach and water (one
teaspoon of bleach in one gallon of water). Fill Tank partially with this solution, let stand
twenty (20) minutes, shaking vigorously every few minutes, drain and rinse with clean
water until the bleach smell is gone.
2. Wipe the Reservoir with a soft cloth dampened in the solution. Rinse area thoroughly
before proceeding.
3. If mineral deposits are evident around the Nebulizer and Water Sensor, clean their
surfaces with a soft, clean cloth and a small amount of undiluted white vinegar. If
necessary for removal of mineral deposits, mix a solution of 50% white vinegar and 50%
water and fill the Base with enough solution to cover the Nebulizer. Allow it to soak for an
hour. Then use a cotton swab to gently loosen buildup on the Nebulizer. Rinse out the
Reservoir and wipe clean. Do not touch Nebulizer with bare fingers as any
fingerprints or other residue can affect mist output. Be careful not to damage the Water
Sensor.
4. All surfaces should be thoroughly cleaned with water prior to reuse.
End of Season Maintenance
1. Follow above weekly cleaning procedure at the end of the humidification season, or when
the humidifier will not be used for several days, being sure to dry all parts, including the
inside of the Water Tank. Do not store with water inside.
2. Leave Tank Cap partially loosened during storage to prevent Tank Cap and gasket from
sticking together. This will prolong the life of the gasket.
3. Clean the Tank and Base after long periods of storage.

Troubleshooting Guide
If your Humidifier is not working properly, refer to the following:
Note: Failure to keep this unit clean from mineral deposits normally contained in any water
supply will affect the efficiency of operation of this unit. Customer failure to follow these
instructions may void the warranty.
Problem
Power Switch is set to “On”
and Power Lamp is off
Little or no mist is produced
Condensation forms around
humidifier or windows
White Dust Accumulation
Possible Cause
•Unit not plugged in
•No power at outlet
•No water in tank
•Unit is not level
•Mineral deposits on
Nebulizer or Water Sensor
•Water Tank was washed
with detergent
•Blower not operating
•Demineralization Cartridge
is clogged
•Nebulizer not functioning
•Mist Intensity is set too
high for room size or
preexisting humidity level.
•Hard water used
•Demineralization Cartridge
needs replacement
Solution
•Plug unit in
•Check circuits, fuses, try a
different outlet.
•Fill Water Tank.
•Place on a level surface.
•Clean Nebulizer and Water
Sensor per instructions.
•Rinse thoroughly with
clean water. Wipe Dry.
•Ensure water in Base is
adequate to immerse
Water Sensor.
•Remove Cartridge and
restart machine. If mist
resumes, replace with a
new Cartridge (#DC-51).
•See Warranty
•Decrease mist output using
the Mist Intensity Control.
•Use distilled water or a
Demineralization Cartridge.
•Replace Demineralization
Cartridge (Model DC-51)

Warranty
This Ultrasonic Humidifier is warranted against defective material or workmanship for a
period of one year from the date of purchase. Any defective part will be repaired or
replaced at no charge if it has not been tampered with and appliance has been used
according to these printed directions. Warranty does not cover the demineralization
cartridge; performance of the demineralization cartridge depends on the mineral content
of the water used in the humidifier. This Warranty gives you specific legal rights as well
as other rights which vary from state to state.
If you experience unsatisfactory operation, first refer to the troubleshooting section
above to ensure that it is not due to care or cleaning. Follow Care and Cleaning
instructions.
If you have any questions or comments, call the Kaz Consumer Service Department at
[phone] or, write to Kaz, Humidifier Service Dept., One Vapor Trail, Hudson, NY
12534, explaining just how the product is operating. Specify model number. Our
Consumer Service Representative will advise you how to correct the problem yourself,
or will ask you to return the product for repair or replacement.
kManufacturing Quality Healthcare Products for Over 70 Years
Kaz, Incorporated
One Vapor Trail
Hudson, NY •USA •12534
The Vicks Ultrasonic Humidifier is
distributed by Kaz, Inc. under license from
The Procter & Gamble Company, Cincinnati, OH 45202.
Vicks and VapoSteam
are registered trademarks of ©1998, Kaz, Incorporated
The Procter & Gamble Company Made and printed in China
