Vicon V4300QS User manual

X920
MODEL V4300QS
COLOR QUAD SPLITTER
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788-9633
TELEPHONE: 516-952-CCTV (2288) FACSIMILE: 516-951-CCTV (2288)
TOLL FREE: 1-800-645-9116 UK: 44/(0) 1489-566300 INFOFAX: 1-800-287-1207

V4300QS Instruction Manual
V4300QS Color Quad Splitter
Warning: To reduce a risk of fire or electric shock, do not expose this product to rain or moisture.
Copyright © 1998 Vicon Industries Inc. All rights reserved.
Product specifications subject to change without notice.
Vicon and its logo are registered trademarks of Vicon Industries Inc.
Vicon Part No. 8006-8920-01-00 Section 5 Rev 598

Dear Valued Customer:
Thank you for selecting Vicon systems and products for your
video needs.
Since Vicon’s beginning in 1967, our only business has been the
design, engineering, and production of the highest quality video systems
and equipment for use in a wide variety of security, safety, control,
surveillance, and communication applications.
We stand behind the quality and dependability of every product
with an industry leading Beneficial Use warranty.
If you are not satisfied with a Vicon product or service, I would
like to know. Your complete satisfaction is the mission of every Vicon
employee.
Sincerely,
Kenneth M. Darby
President

FCC Notice
Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a
Class A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in
strict accordance with the manufacturer’s instruction, may cause interference to radio and television
reception. It has been type tested and found to comply with the limits for a Class A computing device in
accordance with the specification in subpart B of part 15 of the FCC rules, which are designed to provide
reasonable protection against such interference in a commercial installation. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause interference to radio
and television reception, which can be determined by turning equipment off and on, the user is encouraged to
try and correct the interference by one or more of the following measures:
•Reorient the receiving antenna.
•Relocate the equipment with respect to the receiver.
•Relocate the equipment away from the receiver.
•Plug the equipment into a different electrical outlet so that the equipment and receiver
are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television technician for additional
suggestions.
The user may find the following booklet prepared by the Federal Communications Commission helpful:
“Interference Handbook, Bulletin CIB-2”
This booklet is available from the U.S. Government Printing Office, Superintendent of Documents, Mailstop
SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
Warning: Power must be removed from this unit before removing circuit modules or ribbon cables.
Caution: This unit contains circuit cards with integrated circuit devices that can be damaged by static
discharge. Take all necessary precautions to prevent static discharge

X920 Rev 598 V4300QS Contents •i
Contents
Introduction .........................................................................................................................1
Installation...........................................................................................................................3
Unpacking and Inspection.............................................................................................................................3
Inspection For Visible Damage.....................................................................................................................3
Inspection For Concealed Damage..............................................................................................................3
Physical Installation.......................................................................................................................................3
Video Connections.........................................................................................................................................4
Camera Connections....................................................................................................................................4
Monitor Connection.......................................................................................................................................4
VCR Connections.........................................................................................................................................5
Alarm Connections ........................................................................................................................................6
Power Connections........................................................................................................................................6
Programming.......................................................................................................................9
Setup Menu...................................................................................................................................................10
Camera ID Menu ...........................................................................................................................................10
Time/Date Menu............................................................................................................................................11
Auto Selector Menu......................................................................................................................................11
Miscellaneous Menu ....................................................................................................................................12
Operation...........................................................................................................................13
Quad ..............................................................................................................................................................13
VCR................................................................................................................................................................13
Sequential Switching...................................................................................................................................13
Camera Displays...........................................................................................................................................13
Maintenance ......................................................................................................................15
Shipping Instructions .......................................................................................................15
Reference...........................................................................................................................17
Technical Information..................................................................................................................................18

ii •List of Figures X920 Rev 598 V4300QS
List of Figures
Figure 1
Front Panel.........................................................................................................................................................1
Figure 2
Rear Panel..........................................................................................................................................................5
Figure 3
Alarm Connections............................................................................................................................................7

X920 Rev 598 V4300QS Important Safeguards •iii
Important
Safeguards
GRAPHIC SYMBOL EXPLANATION
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the unit.
1. Read Instructions - All the safety and operating
instructions should be read before the video product is
operated.
2. Retain Instructions - All the safety and operating
instructions should be retained for future reference.
3. Heed Warnings - All warnings on the video product
and in the operating instructions should be adhered to.
4. Follow Instructions - All operating and use
instructions should be followed.
5. Cleaning - Step aapplies to equipment that can be
disconnected from the CCTV system without seriously
jeopardizing security. Step b applies to equipment that
must operate continuously such as video switching
equipment at military installations.
a. Disconnect this video product from its power source
before cleaning. Do not use caustic, abrasive, or
aerosol cleaners. Use a damp cloth for cleaning.
b. Use a damp cloth to clean the equipment. Do not
allow moisture or liquids to enter any vents. Do not
use caustic, abrasive, or aerosol cleaners.
6. Attachments - Do not use attachments not
recommended by Vicon as they may cause hazards.
7. Water and Moisture - Do not use this video product
in any location where it may be exposed to water or
moisture. This does not apply to outdoor camera
housings, outdoor pan-and-tilt drives, and other
equipment designed for direct exposure to outdoor
environments.
8. Accessories - Do not place this video product on any
unstable surface or table. The video product may fall,
causing serious injury to a person and serious damage
to the video product. Use only with a mounting accessory
recommended by Vicon, or sold with the video product.
Any mounting of the video product should follow Vicon’s
instructions, and a mounting accessory recommended
by Vicon should be used.
9. Ventilation - Slots and openings in the cabinet are
provided for ventilation and to ensure reliable operation
of the video product and to protect it from overheating,
and these openings must not be blocked or covered.
The openings should never be blocked by placing the
video product on a rug or other similar surface. This
video product should never be placed near or over a
radiator or heat register. This video product should not
be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or Vicon’s
instructions have been adhered to.
10. Power Sources - This video product should be
operated only from the type of power source indicated
on the marking label. If you are not sure of the type of
power supplied to your installation site, consult your
Vicon dealer or local power company. For video

iv •Important Safeguards X920 Rev 598 V4300QS
products intended to operate from battery power, or
other sources, refer to the operating instructions.
11. Grounding - This applies to video products
equipped with a 3-wire grounding-type plug, a plug
having a third (grounding) pin. This plug only fits into a
grounding-type power outlet. This is a safety feature. If
you are unable to insert the plug into the outlet, contact
your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
12. Power-Cord Protection - Power supply cords
should be routed so that they are not likely to be walked
on or pinched by items placed upon or against them,
paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the video product.
13. Outdoor Cable Grounding - If an outside cable
system is connected to the video product, be sure the
cable system is grounded so as to provide some
protection against voltage surges and built-up static
charges. Section 810 of the National Electrical Code,
ANSI/NFPA 70-1984, provides information with respect
to proper grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding
electrode.
14. Lightning - For added protection for this video
product when it is not used for long periods of time,
disconnect it from its power source and from the cable
system. This prevents damage to the video product due
to lightning and power-line surges.
15. Power Lines - An outside cable system should not
be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside cable system, extreme care should be taken to
keep from touching such power lines or circuits as
contact with them might be fatal.
16. Overloading - Do not overload wall outlets and
extension cords as this can result in a risk of fire or
electric shock.
17. Object and Liquid Entry - Never push objects of
any kind into this video product through openings as
they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never
spill liquid of any kind on the video product.
18. Servicing - Do not attempt to service this video
product yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
19. Damage Requiring Service - Disconnect this video
product from its power source and refer servicing to
qualified service personnel under the following
conditions. Note that step cdoes not apply to outdoor
camera housings, outdoor pan-and-tilt drives and other
equipment specifically designed for direct exposure to
outdoor environments.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into
the video product.
c. If the video product has been exposed to rain or
water.
d. If the video product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as an improper adjustment of other
controls may result in damage and will often require
extensive work by a qualified technician to restore
the video product to its normal operation.
e. If the video product has been dropped or the cabinet
has been damaged.
f. When the video product exhibits a distinct change in
performance - this indicates a need for service.
20. Replacement Parts - When replacement parts are
required, be sure the service technician has used
replacement parts specified by Vicon or that have the
same characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
21. Safety Check - Upon completion of any service or
repairs to this video product, ask the service technician
to perform safety checks to determine that the video
product is in proper operating condition.

X920 Rev 598 V4300QS Introduction •1
Introduction
The information in this manual covers the installation, programming, operation, and maintenance procedures
for the V4300QS Digital Color Quad Splitter. This equipment should only be installed by a qualified technician
using approved materials in accordance with national, state, and local electrical codes. Read these
instructions through completely before attempting installation.
The V4300QS Digital Color Quad Splitter accepts four camera inputs, processes them digitally, and displays
all four on a single monitor screen. The complete video from each camera is displayed. All operating and
programming functions are performed with the front panel keys. Refer to Figure 1. Refer to Table 1 in
Programming for a complete description of front panel functions. The V4300QS is available in two versions.
Model V4300QS is the NTSC version; model V4300QS-P is the PAL version. The term V4300QS is used to
refer to both models unless specifically stated otherwise.
Figure 1
Front Panel
The V4300QS features real time image processing and 2X digital zoom in VCR playback. It has a high
resolution of more than 700 TV lines in single screen mode. In quadrant mode, the image in each channel
can be put in a FREEZE mode. The splitter also features adjustable dwell time and on/off selectable on-
screen title, time, date display and border display.
Sequential Switching
In addition to the quad screen display, the V4300QS offers a manually selected full-screen display of
individual cameras and a sequencing program that displays each camera full screen. In this program, after
camera 4 has been displayed, the quad image is displayed as part of the sequence. A dwell period is menu-
selectable. Dwell can be set from 1 to 99 seconds and a camera can be programmed to be skipped in the
sequence.
Individual Camera Titles
Each camera can have a title of up to eight characters, from a character set including the upper and lower
case alphabet, numbers 0 through 9 and a blank.

2 •Introduction X920 Rev 598 V4300QS
Alarm Operation
The V4300QS includes alarm response capabilities. A separate hardwired alarm input (which can be normally
open or normally closed, menu-selectable) is provided for each camera channel, and an alarm relay output is
provided for connection to an external device, such as a VCR. This output is normally open (N.O.).
When an alarm is activated, the associated camera video displays full screen, the word ALARM displays on
screen, a buzzer, if programmed ON, generates a continuous audible alarm for 60 seconds and the alarm
output relay activates. If multiple alarms are activated, the screen switches the full screen video for each
channel in turn and displays the ALARM message for each screen. The buzzer generates an audible sound
for 60 seconds. If one of the alarm activated channel buttons is depressed while the video is switching, the
switching stops temporarily while the button is depressed and continues when the button is released.
Pressing the ALARM RESET button resets the alarm condition. On the output to the VCR quadrant display,
an ALM message blinks on the related channel.
Video Loss
A built-in video loss detection system generates a visual alarm if video is lost from any of the four camera
inputs. If video is lost from a camera, the screen goes black and VLD appears on the screen. Unaffected
cameras continue to display video.
Time/Date
The unit has an onscreen menu to set the time and date. Time is in the 24-hour mode and is displayed at the
top of the screen. The real time clock has a battery backup that can store data for two weeks without power.
VCR Interface
The V4300QS has a VCR interface. The VCR input BNC accepts the video signal from the VCR and
connects to the video output connector of the VCR. It allows the recorded tape to be played back. The VCR
output BNC outputs the video signal to the VCR. This output is a quadrant display of video at all times. It is
connected to the video input connector of the VCR.
The V4300QS complies with FCC requirements for a Class A device and with European Community EMC
Directive 89/336 EEC. The product was subjected to the testing outlined in European Normalization Standard
EN 55022:1994 + A1:1995 (Class A) (Electromagnetic Compatibility - General Emissions Standard Part 1)
and EN 50082-1 (Electromagnetic Compatibility - Generic Immunity Standard Part 1: Residential, Commercial
and Light Industry).

X920 Rev 598 V4300QS Installation •3
Installation
Unpacking and Inspection
All Vicon equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to
deliver the equipment in the same condition as it left the factory.
Inspection For Visible Damage
Immediately inspect the cartons upon delivery. Make a note of any visible damage on all copies of the
carrier’s freight bill.
Make sure the carrier’s agent (the person making the delivery) signs the note on all copies of the bill. If the
agent does not have claim forms, contact the carrier’s office.
Inspection For Concealed Damage
As soon as possible after delivery, unpack the unit and inspect it for concealed damage. Do not discard the
carton or packing materials. If the unit is damaged, contact the carrier immediately and request forms for filing
a damage claim. Make arrangements for a representative of the carrier to inspect the damaged equipment. If
the equipment must be returned for repair, follow the Shipping Instructions at the end of this manual.
Physical Installation
Installation of the V4300QS is simple and involves making video connections, alarm connections and power
connections. Power connections should be made after all other connections are complete.
The V4300QS may be either rack mounted or desk-top mounted. The accessory kit includes the items
necessary for both configurations. For rack mounting, remove the two screws on the side of the unit that align
with the holes in the bracket. Attach the rack mount brackets to the unit in the holes on the side of the unit
with the screws previously removed. Install the unit into the rack according to the instructions provided with
the rack. If desk-top installation is preferred, 4 adhesive-backed rubber feet are provided. Remove the
backing from each foot and insert into the recesses on the bottom of the unit.

4 •Installation X920 Rev 598 V4300QS
Video Connections
The V4300QS provides four inputs for camera video and a looping output for each camera input. An output is
provided for the basic system monitor, and two connections are provided for a VCR, one for output to the
VCR and one to allow the VCR to be played back through the V4300QS. Playing back through the V4300QS
allows recorded tapes to be viewed on the same monitor on which the live video is normally displayed,
eliminating the need for an extra monitor dedicated to the VCR. All video connections are made with BNC
connectors on the rear panel. See Figure 2.
Caution: Read the COAXIAL CABLE RECOMMENDATIONS carefully before selecting coaxial cable for
this video system.
Camera Connections
The VIDEO INPUT BNC connector accepts the video signal from the camera. Connect a coaxial cable
terminated with a male BNC connector from Camera 1 to the CH1 IN connector on the rear panel. Repeat for
all four video inputs.
Note: If the cameras connected to the V4300QS are equipped with autoiris lenses, adjust the lenses for
optimum picture quality with the V4300QS in the quad display mode.
Each camera input channel also features a VIDEO OUTPUT BNC connector that allows each video output to
be looped out to other equipment, such as a dedicated VCR or dedicated monitor. If the looping output is not
used, it must be terminated with the 75 ohm/high impedance selector on the rear panel. Set this selector to
the 75 position if there is no looping output; set the selector to HI when the looping output is connected to
external equipment. If the video is to be looped out to other equipment, make sure that the final item of video
equipment on each line is terminated with 75 ohms. (Monitors usually have a termination slide switch; VCRs
automatically select the correct termination.)
Monitor Connection
The MONITOR OUTPUT BNC connector outputs the video signal selected on the front panel to the video
monitor. Connect a coaxial cable from the MONITOR OUT connector on the rear panel of the V4300QS to
the VIDEO IN connector on the monitor that is to serve as the basic system monitor. Most monitors allow the
video to be looped out to other equipment; if the video line ends at the basic system monitor, set the monitor’s
termination switch to 75 OHMS. If the video is looped through the monitor to some other item of equipment,
set the monitor termination switch to HIGH Z or HIGH IMPEDANCE. The last video device in the line must be
terminated with 75 ohms.
Note: If the V4300QS is not to be connected to a VCR, the output from the VCR OUT connector may be
connected to a second monitor. This output displays the quad screen continuously.

X920 Rev 598 V4300QS Installation •5
Connector Function
c75Ω/High Impedance Selector Used for setting the termination. Set to 75Ω(75) when
there is no looping out; set to high impedance (Hi)
when video will be looped out to another device.
dVideo Input BNC Connector Accepts video signal from the camera.
eOutput BNC Connector Loops video out to another device; internally connected
with the video input BNC connector.
fVCR Input BNC Connector Accepts the video signal from the VCR. Connects to
the video output connector of the VCR.
gVCR Output BNC Connector Outputs the video signal to the VCR. This output is a
quadrant display at all times. Connects to the video
input connector of the VCR.
hMonitor Output BNC Connector Outputs the video signal to the video monitor. This
output is selected on the front panel.
iAlarm In/Out Connector Four channel alarm inputs and one output. Inputs are
activated by an external contact open or closure
(menu-selectable); output is a simple relay contact
(N.O.).
jDC Power Input Jack Accepts 12 VDC power. DC supply requires12 VDC,
1.2 A minimum.
Figure 2
Rear Panel
VCR Connections
The VCR INPUT BNC connector accepts the video signal from the VCR. It is connected to the video output
connector of the VCR. The VCR OUTPUT BNC connector outputs the video signal to the VCR. This output is
a quadrant display of video at all times. It is connected to the video input connector of the VCR.

6 •Installation X920 Rev 598 V4300QS
Connect a coaxial cable from the VCR OUT connector on the V4300QS to the VIDEO IN connector on the
VCR. If the basic system monitor is to be used to display playback video from the VCR, connect a second
coaxial cable from the VIDEO OUT connector on the VCR to the VCR IN connector on the V4300QS.
If the playback video from the VCR is to be displayed on some other monitor, connect a coaxial cable from
the VIDEO OUT connector on the VCR to the VIDEO IN connector on the other monitor and terminate the line
with 75 ohms.
The VCR can be connected to the V4300QS to allow it to respond to alarm inputs to the V4300QS. These
alarm connections are discussed in the following section, Alarm Connections.
Alarm Connections
Alarm input and output connections are made through a 10-pin screw terminal labelled ALARM on the rear
panel of the V4300QS. Refer to Figures 2 and 3 for connections.
Note: To comply with FCC requirements, alarm input cables must be shielded, and the shield must be
grounded.
The alarm input channels (CH1, CH2, CH3, CH4) can be wired normally open (N.O.) or normally closed
(N.C.). Each input channel has two terminals of +5V supply and the return and are activated by an external
contact open or closure. The alarm output (RL) is a simple relay contact wired normally open (N.O.). When
the alarm condition occurs, this contact is closed. Nominal contact capacity (resistive load) is 1A/30V DC or
0.5A/125V AC.
Power Connections
Vicon systems and components, like most electronic equipment, require a clean, stable power source.
Voltage irregularities such as surges, drops, and interruptions can affect the operation of your equipment and,
in severe cases, damage certain components. Vicon strongly recommends the use of line conditioners,
voltage regulators, and uninterruptible power supply (UPS) systems.
The V4300QS operates on 12 VDC/0.9 A power supplied from an external power supply provided with the
unit. The power supply is designed to be plugged into a standard wall outlet and has a 6-foot (1.8 meter)
cable with a connector for attachment to the V4300QS. The power supply feels warm during normal
operation.
Plug the concentric connector on the power supply cable into the connector labelled DC 12V on the V4300QS
rear panel. Plug the power supply into a conventional outlet. The POWER LED on the power switch on the
front panel illuminates when power is supplied to the unit.

X920 Rev 598 V4300QS Installation •7
Figure 3
Alarm Connections

8 •Installation X920 Rev 598 V4300QS

X920 Rev 598 V4300QS Programming •9
Programming
Programming the V4300QS includes writing titles for the video inputs, assigning dwell times for sequencing
operation, setting time and date, turning the buzzer and border on or off, and selecting the frame or field reset
mode.
All programming is done with the front panel keys. Each key has two functions, one when it is simply
depressed and one when it is depressed in conjunction with SHIFT in the operation mode or used in
programming. Refer to Figure 1 and Table 1 for front panel key functions.
Table 1
Front Panel Key Functions
Key Label Operation Function Programming Function
cPOWER Turns V4300QS ON and OFF None
dALARM RESET - SHIFT Resets alarm condition, stops
beep, removes visible “ALARM”
message; functions with other
keys to allow second function
None
eFREEZE - VCR Freezes each quadrant image
selected by channel keys; with
SHIFT, switches V4300QS to
VCR input mode and displays
VCR playback (each quadrant is
displayed on full screen with 2X
digital zoom)
None
fAUTO - SETUP Initiates sequential display With SHIFT, displays main
setup menu
gQUAD - OSD Enables quadrant display on
screen; with SHIFT, onscreen
titles, time, and date are
enabled and disabled
Returns to Main Setup Menu
hCH1 - UP (S) Enables camera 1 to be
displayed in full screen Moves cursor up on setup menu
iCH2 - DOWN (T) Enables camera 2 to be
displayed in full screen Moves cursor down on setup menu
jCH3 - LEFT (W) Enables camera 3 to be
displayed in full screen Moves cursor left on setup menu
kCH4 - RIGHT (X) Enables camera 4 to be
displayed in full screen Moves cursor right on setup menu

10 •Programming X920 Rev 598 V4300QS
Setup Menu
To enter the Main Setup menu, press SHIFT + SETUP keys. The Main Setup menu displays as follows:
Move the cursor with the UP (S) and DOWN (T) keys, then press the QUAD key to select the menu.
Camera ID Menu
When the Camera ID menu is selected from the Main Setup menu, the following screen displays:
Note: The titles are automatically centered. See Figure below for title position.
To move the cursor, use the LEFT (W) and RIGHT (X) keys. To enter the characters, press UP (S) or
DOWN (T) keys repeatedly until the character to be entered appears on the cursor. When the UP (S) key is
pressed, sequential character strings are displayed in the following order:
BLANK, 0, 1, 2…9, A, B, C…Z, BLANK, a, b, c…z
When the DOWN (T) key is pressed, the character string appear in the reverse order. If the cursor is located
on the character, pressing the UP (S) or DOWN (T) key increases or decreases the character location just
after or before the original in the string, respectively. To return to the Main Setup menu, press the QUAD key.
** MAIN SETUP MENU **
1. CAMERA ID
2. TIME/DATE
3. AUTO SELECTOR
4. MISCELLANEOUS
USE UP/DN, QUAD keys
SHIFT+SETUP keys to Exit
** CAMERA ID **
1. CH-1 ID :CH1
2. CH-2 ID :CH2
3. CH-3 ID :CH3
4. CH-4 ID :CH4
opto move, UP/DN to input
To return to MAIN &QUAD
CH1 CH2
CH3 CH4

X920 Rev 598 V4300QS Programming •11
Time/Date Menu
If Time/Date is selected from the Main Setup menu, the following menu displays:
To move the cursor, use the LEFT (W) and RIGHT (X) keys. To update time and date, use UP (S) or DOWN
(T) keys. The real time clock has a battery backup and retains the data about two weeks without power
supply. To return to Main Setup menu, press the QUAD key.
Auto Selector Menu
When the Auto Selector menu is selected from the Main Setup menu, the following screen displays:
To move the cursor, use the LEFT (W) and RIGHT (X) keys. To set the dwell time or skip a channel, use UP
(S) or DOWN (T) keys. Dwell time can be set from 1 to 99 seconds. ON enables the channel and OFF
disables (skips) the channel. If all channels are set to OFF, only the quadrant configuration displays when the
AUTO key is pressed. To return to the Main Setup menu, press the QUAD key.
** TIME/DATE SET **
1. TIME : 12:20:30
hh:mm:ss
2. DATE : 97/01/01
yy/mm/dd
opto move, UP/DN to input
To return to MAIN &QUAD
** AUTO SELECTOR **
1. DWELL TIME : 01sec
2. CHANNEL SKIP
CH1 - CH2 - CH3 - CH4 - QUAD
ON ON ON ON ON
opto move, UP/DN to input
To return to MAIN &QUAD

12 •Programming X920 Rev 598 V4300QS
Miscellaneous Menu
If the Miscellany Menu is selected from the Main Setup menu, the following menu will display:
To move the cursor, use the UP (S) or DOWN (T) keys. To toggle the setting, use the LEFT (W) and RIGHT
(X) keys. Alarm Buzzer ON enables the beep alarm when the alarm condition occurs, while OFF disables it.
Alarm Contact N.O. accepts all wired normally open (N.O.) sensors and the alarm is activated by an external
contact closure; Alarm Contact N.C. accepts all wired normally closed (N.C.) sensors and the alarm is
activated by an external contact opening. Factory setting is N.O. Border ON enables the border on the
quadrant display mode and OFF disables it. If the V RESET MODE is set to FRAME, the image is processed
in 30 frames/second and displays full real time video on the quadrant video. In this mode, the horizontal edge
flicker is easily seen and the video captured by FREEZE may be shaky. If the V RESET MODE is set to
FIELD, the image is processed in 30 double fields/second or 15 frames/second. In this mode, the horizontal
edge flicker is not seen and the video captured by FREEZE is very stable, but the resolution is less than that
of the FRAME mode and the reality of a moving scene is less.
** MISCELLANEOUS **
1. ALARM BUZZER : ON
2. ALARM CONTACT : N.O.
3. BORDER MODE : ON
4. V RESET MODE :FRAME
UP/DN to sel, opto toggle
To return to MAIN &QUAD
