Vicon V3FCD SERIES User manual

Fixed Position Camera Dome
V3FCD SERIES
INSTALLATION & OPERATION
MANUAL
Vicon Industries Inc. does not warrant that the functions contained in this equipment
will meet your requirements or that the operation will be entirely error free or perform
precisely as described in the documentation. This system has not been designed to be
used in life-critical situations and must not be used for this purpose.
Copyright © 2001 Vicon Industries Inc. All rights reserved. Product specifications subject to
change without notice. Vicon and its logo are registered trademarks of Vicon Industries Inc.
VICON INDUSTRIES INC., 89 ARKAY DRIVE, HAUPPAUGE, NEW YORK 11788
TELEPHONE: 631-952-CCTV (2288) FACSIMILE: 631-951-CCTV (2288)
24-Hour Technical Support: 800-34-VICON (800-348-4266)
TOLL FREE: 800-645-9116 UK: 44/(0) 1489-566300 INFOFAX: 800-287-1207
XX080-00-00
Vicon Part No. 8009-8080-00-00 Section 1 Rev 401

Dear Valued Customer:
Thank you for selecting Vicon systems and products for
your video needs.
Since Vicon’s beginning in 1 67, our only business has
been the desing, engineering, and producion of the
highest quality video systems and equipment for use in
a wide variety of security, safetly, control, surveillance,
and communication appllications.
We stand behind the quality and dependability of every
product with an industry leading Beneficial Use
warranty.
If you are not satisfied with a Vicon product or service,
I would like to know. Your complete satisfaction is the
mission of every Vicon employee.
Sincerely,
Kenneth M. Darby
President
FCC Notice
NOTE: Complies with Federal Communications Commission Rules &
Regulations Part 15, Subpart B for a Class A digital device.
WARNING
This equipment generates and uses radio frequency energy and if not installed and
used properly, that is, in strict accordance with the manufacturer s instruction, may
cause interference to radio and television reception. It has been type tested and
found to comply with the limits for a Class A computing device in accordance with the
specification in subpart B of part 15 of the FCC rules, which are designed to provide
reasonable protection against such interference in a commercial installation.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio and television
reception, which can be determined by turning equipment off and on, the user is
encouraged to try and correct the interference by one or more of the following
measures:
•Reorient the receiving antenna.
•Relocate the equipment with respect to the receiver.
•Relocate the equipment away from the receiver.
•Plug the equipment into a different electrical outlet so that the equipment and
receiver are on different branch circuits.
If necessary, the user should consult the dealer or an experienced radio/television
technician for additional suggestions.
The user may find the following booklet prepared by the Federal Communications
Commission helpful:
"Interference Handbook, Bulletin CIB-2"
This booklet is available from the U.S. Government Printing Office, Superintendent of
Documents, Mailstop SSOP, Washington, D.C. 20402-9328, ISBN 0-16-045542-1.
CAUTION: This unit contains circuit cards with integrated circuit devices that can be
damaged by static discharge. Take all necessary precautions to prevent static
discharge.
EG-1

EG-2
Thank you for your purchase of this product. Before operating the product, please
read this instruction manual carefully to ensure proper use of the product. Please
store this instruction manual in a safe place for future reference.
CONTENTS
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
....................................................................................................
SAFETY PRECAUTIONS
The installation should be made by qualified service personnel or system installers
and should confirm to all local codes.
This symbol indicates that there is a possibility ofdeath ordamage to operator or others.
To prevent fire or electric shock, do not expose this product to rain or moisture.
This symbol indicates that there is a possibility of injury or damage to equipment.
1. Power supply
(1) Use only with a 24V AC power supply marked class 2 or +12V DC regulated power
supply marked class 2.
(2) To prevent fire or electrical shock, UL listed class 2 wiring should be used for the
12VDC or 24VAC input terminal.
(3) Be sure to connect each lead to the appropriate terminal. Wrong connection may cause
malfunction and/or damage to the video camera.
2. Operating and storage locations
(1) Do not attempt to aim the camera at the sun or other extremely bright objects that
cause smear to appear irrespective of whether the camera is operating or not. This can
damage the CCD (Charge Coupled Device).
(2) Do not place the camera in the following locations.
a) Locations subjected to extremely high or low temperatures.
(operating temperature range : 10 °C to +50°C {14°F to 122°F})
(storage temperature range : 20 °C to +60°C { 4 °F to 140°F})
b) Locations subjected to high levels of humidity and dust
(storage humidity range : max 95% {no condensation})
c) Locations where there are large amounts of water vapour and steam
d) Ensure the location selected is sufficiently strong to support the weight of the camera
and is free from vibration.
(3) When this camera is installed near equipment, like a wireless communication device, that
emits a strong electromagnetic field, some irregularity such as noise on the monitor
screen may happen.
(4) Be sure to use screws suitable for the type of material to which the camera is being
mounted.
3. Handling of the unit
Do not allow the camera to be subjected to strong impacts or shocks. The camera could be
damaged by improper handling or storage.
- Never attempt to disassemble or modify the camera.
-
If an abnormality should occur, immediately turn off the power and consult your dealer.
FEATURES
- Integrated varifocal lens w/auto iris allows for versatile utilization and easy installation
- Hi-speed iris provides excellent low light performance
- Latest DSP controls for BLC, white balance, and gain control
- Manual pan/tilt/rotation mechanism
- Can be installed on a wall or a ceiling
- Tamper proof housing design deters tampering
- Video cable with BNC included
-
Additional video out terminal for easy adjustment
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment.
This machine generates, uses, and can radiate radio frequency energy and if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio com-
munications. Operation of this equipment in a residential area is likely to cause interference, in
which case the user will be required to correct the interference at the userÕs own expense.
PRESIDENT'S LETTER EG-1
FCC NOTICE EG-1
FEATURES EG-2
SAFETY PRECAUTIONS EG-2
PARTS DESCRIPTIONS EG-3
INSTALLATION EG-4
ADJUSTMENT EG-5
SPECIFICATIONS EG-8
SHIPPING INSTRUCTIONS EG-9
REFERENCE EG-9

EG-3
PARTS DESCRIPTION
• Camera body interior• Exterior
Body cover (white)
Camera body Inner cover (black)
Opening
Dome cover (transparent)
View angle adjustment lever
DC iris level adjustment volume
Focus adjustment lever
Lens
Video output
connector for BNC
cable(Included)
Line phase
adjustment volume
Video output terminal
for bare coaxial cable
Camera
Dip switch
Synchronization
switch
Power input
terminal
• Accessories
DC iris level adjustment tool Body Cover Opener
Cover Removal and Attachment
• To remove the dome cover, pull lightly.To attach it, insert
and press the cover lightly until it snaps together.
• To remove the body cover, insert the opener in the groove
between the camera body and the body cover and twist
lightly.To attach it,align theedge ofbody cover tothe groove
on the camera body, and press until it snaps together.
Coaxial video cable
Coaxial
video cable

Creating a Hole in the Ceiling or Wall
Make two holes for the screws affixing the camera body, and
one hole for the power and video cables.
* Use the supplied template to mark the appropriate mounting position
on the ceiling or the wall.
Connecting the Cables
Please refer to the diagrams below.
Connect the video cable from monitor to the equipped video
cable.
* When not using the equipped video cable,
connect the video cable from monitor to the
camera as shown.
Connect the power cable.
* When using 12V DC, connect the positive (+) side to the side marked
"DC 12V."
EG-4
INSTALLATION
2
1Mounting the Camera Body
Remove the body cover, and mount
the camera body to the ceiling or
wall.
Align the housing to the holes you
have made, and use two screws to
mount the camera body.
* Choose screws suitable for the type of
ceiling or wall material. Screws with a
diameter of 4 to 5 mm is recom-
mended.
3
Check if the power is off before handling the power cable.
When using DC power, check for proper polarity before connecting
po wer supply.Improper polar ity may cause damage to the camera.
• Running cable on
ceiling or wall surface
Back of camera body
Wall
Press open the perforated
section, and run the cables
through.
• When using 12V DC. • When using 24V AC.
ATTENTION

EG-5
INSTALLATION
Attaching the Service Monitor
When adjusting the camera direction, view angle and focus,
use the included service monitor cable by connecting to the
video output connector
4
ADJUSTMENT
Setting the Dip Switch
Set according to lighting conditions
1
Color V3FCD-24 (NTSC model)
(Factory Settings)
FUNCTIONNAME
AGC OFF
BLC OFF
AT W AW B
Auto Gain
Control
Gain level varies from 0 to 26dB
Gain level fixes at 0dB
AGC
OFF
Back Light
Compensation
set to this position when strong light
comes from behind the target
Normal position
BLC
OFF
No.
3
2
Auto White
Balance
traces and adjusts WB automatically
adjusts WB automatically and fixes it
AT W
AWB
1
POSITION
* BLC function is effective with AGC function
Color V3FCD-24C (PAL model)
(Factory Settings)
FUNCTIONNAME
AGC OFF
BLC OFF
AT W AW B
Auto Gain
Control
Gain level varies from 0 to 26dB
Gain level fixes at 0dB
AGC
OFF
Back Light
Compensation
set to this position when strong light
comes from behind the target
Normal position
BLC
OFF
No.
3
2
Auto White
Balance
traces and adjusts WB automatically
adjusts WB automatically and fixes it
AT W
AWB
1
POSITION
* BLC function is effective with AGC function
•Service monitor is not included.

EG-6
ADJUSTMENT
Adjusting the Camera Direction
Camera body moves in three ways: Pan,Tilt,and Rotate.
Adjust the direction so that the lens is aiming at the target.
2Adjusting the Synchronization and Phase
If necessary, adjust the line phase to synchronize the image.
Please refer to the drawing below.
qTurn the Synchronization Switch to ON.
wUse a screw driver and adjust the line
phase.
4
Adjusting the View
Angle and Focus
Use the lever to adjust the
view angle and focus.
3
Mark indicates the
top side of
camera.
Focus adjustment lever
View angle adjustment lever
Pan
188゜
Tilt
156゜
Rotate 210゜

EG-7
ADJUSTMENT
Adjusting the DC Iris Level
Set according to lighting conditions.
qTurn the dip switch Auto Gain Control (AGC) to OFF.
wUse the special screw driver provided and adjust the DC iris
level.
eTurn the dip switch Auto Gain Control (AGC) to ON.
5Completing the Adjustment and Installation
qAttach the body cover.
6
wTurn the inner cover
to adjust the lens to
the opening. Attach
the dome cover.
* Attaching procedures are
described in EG-3.
Be aware that the AGC dip switch number is different for color and B/W
cameras.
ATTENTION

EG-8
SPECIFICATIONS: NTSC
Model Name
Focal length
Max. Aperture Ratio
Iris
Angle of view (D)
(H)
(V)
TV System
Scanning System
Image Sensor
Effective Elements
Scanning Frequency (H/V)
Video Outputs
Resolution (horizontal)
Min. Illuminance (50IRE)
AGC
S/N Ratio (AGC off)
characteristic
Sync. System
Iris Control
White Balance
Power Supply
Power Consumption
Ambient Temperature
Ambient Humidity
External Dimensions
Weight
Adjustment Volume
V3FCD-24
3.0 - 6.0 mm
1:1.2
F1.2-360 (Auto)
96.3 - 45.4
71.9 - 36.0
52.0 - 26.8
NTSC
ATW/AWB
24VAC
± 10%, 12VDC ± 10%
Less than 5.8 W
Operation: -10˚C to 50˚C / Storage: - 20˚C to 60˚C
Operation: RH85% max. (keep free from dampness)
128 (ø) mm x 101 (D) mm
400g approx.
DC iris level, line phase
2:1 Interlace
1/4" IT CCD
768 (H) x 494 (V)
15.734 kHz / 59.94 Hz
1.0 V p-p / 75 Ω
INT / L.L.
DC Iris: Shutter speed 1/60 sec. Fixed
480 TV lines
1.5 lux
+ 26 dB max.
More than 48 dB
0.6
SPECIFICATIONS: PAL
Model Name
Focal length
Max. Aperture Ratio
Iris
Angle of view (D)
(H)
(V)
TV System
Scanning System
Image Sensor
Effective Elements
Scanning Frequency (H/V)
Video Outputs
Resolution (horizontal)
Min. Illuminance (50IRE)
AGC
S/N Ratio (AGC off)
characteristic
Sync. System
Iris Control
White Balance
Power Supply
Power Consumption
Ambient Temperature
Ambient Humidity
External Dimensions
Weight
Adjustment Volume
V3FCD-24
3.0 - 6.0 mm
1:1.2
F1.2-360 (Auto)
96.3 - 45.4
71.9 - 36.0
52.0 - 26.8
PAL
ATW/AWB
24VAC
± 10%, 12VDC ± 10%
Less than 5.8 W
Operation: -10˚C to 50˚C / Storage: - 20˚C to 60˚C
Operation: RH85% max. (keep free from dampness)
128 (ø) mm x 101 (D) mm
400g approx.
DC iris level, line phase
2:1 Interlace
1/4" IT CCD
752 (H) x 582 (V)
15.625 kHz / 50.0 Hz
1.0 V p-p / 75 Ω
INT / L.L.
DC Iris: Shutter speed 1/50 sec. Fixed
480 TV lines
1.5 lux
+ 26 dB max.
More than 48 dB
0.6

Shipping Instructions
Use the following procedure when returning a unit to the factory:
1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations
listed below. Record the name of the Vicon employee who issued the R.A.
Vicon Industries Inc.
89 Arkay Drive
Hauppauge, NY 11788
Phone: 516-952-CCTV (2288); Toll-Free: 1-800-645-9116; Fax: 516-951-
CCTV (2288)
For service or returns from countries in Europe, contact:
Vicon Europe Ltd
Brunel Way
Fareham, PO15 5TX
United Kingdom
Phone: [phone]; Fax: [phone]
2. Attach a sheet of paper to the unit with the following information:
a. Name and address of the company returning the unit
b. Name of the Vicon employee who issued the R.A.
c. R. A. number
d. Brief description of the installation
e. Complete description of the problem and circumstances under which it
occurs
f. Unit’s original date of purchase, if still under warranty
3. Pack the unit carefully. Use the original shipping carton or its equivalent for
maximum protection.
4. Mark the R.A. number on the outside of the carton on the shipping label.
Reference
CAUTION: Careful selection of the proper cable is essential to obtain the best performance from this
equipment. Vicon assumes no responsibility for poor performance when cables other than those
recommended are installed. In all cases, coaxial cable impedance should be 75 ohms.
Materials
Use only cable with a pure copper center conductor. Do not use cable with either a copper-plated
steel or an aluminum center conductor because these do not transfer signals effectively in the
frequency range used in CCTV networks. A center conductor with low DC resistance is required for
effective CCTV operation. Solid-core bare copper conductor is best suited to video applications,
except where flexing occurs. If the coaxial cable will be subjected to flexing during normal use, select
a cable with a stranded center conductor. The preferred dielectric material is cellular (foam)
polyethylene. It has better electrical characteristics than solid polyethylene, but is more vulnerable to
moisture. Therefore, use only solid polyethylene dielectric cable with a heavy exterior insulation in
applications subject to moisture.
Cable Types
The most commonly used cable types are RG-59/U and RG-11/U. Each is actually a family of cables
with widely varying electrical characteristics, some of which are not suitable for CCTV applications.
Choose a cable type by referring to the characteristics and maximum distances listed below. The
maximum distance for best picture refers to the distance between the Receiver and the Transmitter.
The characteristics of the cables in this table should be used as a guideline when cables other then
Belden are used. Materials and construction must follow the guidelines above. Note that "BC" refers
to bare copper and "TC" refers to tinned copper.
Table A
Recommended Coaxial Cable Types
Cable Belden Alpha Type West Penn Type Center Type Shield & DCR/ Distance
Type Type No. No. Type No. Conductor % Coverage 1000ft (km) (max) ft (m)
RG-11/U 8213 9847 811,4811 14 Solid BC BC braid (95%) 2.6 (8.5) 820 (250)
RG-6/U 9248 9804C 806,4806 18 Solid BC Foil + 61% 7.5 (24.6) 530 (160)
TC braid (100%)
RG-59/U 8281 9803 815 20 Solid BC 2 TC braids (96%) 9.9 (32.5) 400 (120)
RG-59/U 9259 ---- 816 22 Strand BC BC braid (95%) 15.0 (49) 400 (120)
RG-59/U 9659 ---- ---- 22 Strand BC BC braid (95%) 15.0 (49) 400 (120)
Table B
Picture Quality vs. Cable Length
Picture Quality -- Cable Length (max) ft (m) ---
-- RG-59/U RG-6/U RG-11/U
*Dim, faint picture. Greater than 1100 (350) Greater than 1500 (450) Greater than 2400 (750)
Usable picture 1100 (350) 1500 (450) 2400 (750)
Clean picture 820 (250) 1000 (300) 1600 (500)
Best picture 400 (120) 530 (160) 820 (250)
*Cable amplification required.
EG-9

Vicon Industries Inc.
Corporate Headquarters
89 Arkay Drive
Hauppauge, New York 11788
516-952-CCTV (2288) 800-645-9116
Fax: 516-951-CCTV (2288)
&Infofax: 800-287-1207
Atlanta Office Vicon Europe Headquarters
3070AA Business Park Drive Brunel Way
Norcross, Georgia 30071 Fareham, PO15 5TX
770-449-0499 800-824-8479 United Kingdom
Fax: [phone]
Fax: [phone]
Brussels Office Vicon China
Planet II - Unit Unit 5, 17/F, Metropole Square
Leuvensesteenweg 542 8 On Yiu Street, Shatin
B-1930 Zaventem New Territories,
Belgium Hong Kong
322 712 8780 (852) 2145-7118
Fax: [phone] Fax: [phone]
Internet Address: www.vicon-cctv.com
