Viconte VC-104 User manual

Steamer
Instruction manual
Отпариватель
Руководство по эксплуатации
VC-104
Благодарим Вас за покупку продукции VICONTE

2
ENG
DESCRIPTION
1. Steam discharge nozzle
2. Steam outputs
3. On/Off button
4. Water level scale
5. Handle
6. Power cord
7. Housing
IMPORTANT SAFETY INSTRUCTIONS
Keep this product out of reach of children. The use of this appliance by persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge can give cause to hazard. Persons responsible for their safety should give
explicit instructions or supervise the use of the appliance. We do not accept
responsibility for damage to the product, persons or other items, caused by misuse,
abuse or non-compliance with these instructions.
Make sure that the voltage indicated on the appliance corresponds with the mains
voltage in your home.
Device is for household use only. Do not use it for commercial or industrial
purposes.

3
Plug your device to a grounded socket. To prevent harming your appliance do not
use extension cords that supply insufficient current. When using extension cords, make
sure to use grounded socket.
Instrument is equipped with automatic release system in the absence of water in
the reservoir, nevertheless it is not recommended to carry off to such state.
After eggs boiling necessarily boil clean water 2-3 times barring from contact of
steam with water in order to prevent spotting.
Use the instrument in vertical position only.
Don’t fill up with water the maximum mark.
Don’t use for heating spiral cleaning rough abrasive materials.
Don’t use the instrument after expiration of its life time.
In the case of outage don’t try to carry out damage control on your own; commit
this job to the specialists of authorized service center (its address and phone number
must be communicated to you on buying).
BEFORE USE
Remove all packing material.
Before connecting the device check that voltage indicated on the rating label
corresponds the mains voltage in your home.
Fill the appliance with cool water up to the “MAX” mark and boil it. Empty the

4
device. The appliance is ready for use.
INSTRUCTION FOR USE
Remove the steam discharge nozzle with rotational movement.
Fill the instrument with water up to maximum mark.
Fix the steam discharge nozzle in a body with reverse rotational movement.
Switch on the instrument; wait till sufficient emission of vapor through steam
outputs.
During eggs or water boiling the steam discharge nozzle doesn’t put on.
CLEANING AND MAINTENANCE
DESCALING
Always remove the plug from the power supply before cleaning and let the
appliance cool down completely.
Clean the outside of the device and the base unit with a soft damp cloth, then wipe
with a dry cloth. Do not use scouring materials.
Make cleaning from the scale regularly. Use special cleaners agent, which can be
obtained from specialist shops and follow the instructions given.
Before switching on the appliance make sure, that the outside surface of the

5
appliance and all electric contacts are absolutely dry.
SPECIFICATION
Power supply
230 V, 50 Hz
Power
1200 W
Net / Gross weight
0.92 kg / 1.12 kg
SERVICE AND WARRANTY
This product has been checked and is free of defects. We warrant this product
against any defects that are due to faulty material or workmanship for the warranty
period from the original date of consumer purchase. If the product should become
defective within the warranty period, we will repair any such defect or elect to replace
the product or any part of it without charge provided there is proof of purchase. This
does not mean an extension of the warranty period. Also warranty does not include
damage to the product by accident or misuse, abuse, alteration to the product or use
inconsistent with the technical and/or safety instructions required. This warranty shall
not apply if the product has been dismantled or repaired by a person not authorized by
us.
