Victa 80102224 Installation and operating instructions

18V LITHIUM-ION
SINGLE BATTERY
CORDLESS LINE TRIMMER
ASSEMBLY & OWNER'S MANUAL
WARNING! Read this manual before operating your product.
Not for
Reproduction

2
IMPORTANT NOTES
Thank you for purchasing your Victa product. Victa prides itself in the quality and performance
of all its products.
This instruction manual will aid in the assembly, safe operation and maintenance of your
product. Please read the following warnings to ensure safety and the long life of your product.
Do not attempt to operate this product until you have read thoroughly and understood
completely all instructions, safety rules, etc, contained in this manual. Failure to comply may
result in accidents involving electric shock, fire, and/or serious personal injury.
INTENDED USE
This product is intended for domestic purposes. This product is not intended for brushcutting
or commercial use. Do not use the product for any task, except for that which it is intended.
Details
General safety
WARNING
1
Warning! Beware of electric shock hazard
when charging.
Read the instruction
manual before use to
reduce risk of injury
Read the directions before
carrying out any adjustment &
maintenance work.
Wear safety goggles and
ear protection that meet
safety standards.
Wait for all components
of the machine to completely
stop & remove the battery.
Wear sturdy, non-slip
footwear.
Do not use rigid cutting disk or
metal blades.
Wear safety gloves.
Do not use machine in
wet conditions, protect
the machine from rain
and damp.
Be careful of objects
being thrown out!
Ensure bystanders are
kept at least 50' (15m)
away & stop the machine
if approached.
Should NOT be disposed of with
house hold items.
Ambient temperature
40˚C Max.
Keep hands away from
cutting area while operating.
Keep bystanders away.
Do not throw into water.
Keep away from heat and/or open
flame.
max.40°C
Li-Ion
Batteries contain Li-ion. Do
not dispose of waste batteries
in domestic waste. Contact
local authority to find out
how to dispose of batteries
appropriately.
Not for
Reproduction

3
Table of Contents
Features & Definitions
Features & supplied items 3
Safety & Handling
General/Electrical/Personal safety 4
Power Tool use and care 5
Battery use and care 6
Product Disposal 7
Assembly Procedures
Unpacking 7
Handle Assembly 8
Guard Assembly 8
Trimmer line Assembly 9
Cutting Head Assembly 11
Operating Instructions
Operating the machine 12
Installing & removing the Battery 12
Start & stopping 12
Speed adjustment 13
Feeding Bump Head Line 15
Maintenance & Care
Cleaning 16
Storing 16
Maintenance chart 17
Service 17
Troubleshooting
Troubleshooting 18
Indication Panel 18
Technical Specification
Product specification 19
2
NOTE: WARRANTY DETAILS ARE NOT WRITTEN WITHIN THIS OPERATOR’S MANUAL.
REFER TO OTHER DOCUMENTS SUPPLIED WITH THIS MACHINE FOR WARRANTY
DETAILS.
THE WARRANTY DOCUMENTS MAY INCLUDE TECHNICAL SPECIFICATIONS THAT
ARE SPECIFIC TO EACH MODEL THAT ARE NOT WRITTEN WITHIN THIS OPERATOR’S
MANUAL.
Not for
Reproduction

4
3
FEATURES DEFINITIONS
1Operating Handle
2On/Off Switch
3Throttle Trigger
4Battery Housing
5Front Handle
6Speed adjustment panel
7 Shaft
8Trimmer Guard
9Bump Head
10 Cut-off Blade
11 Motor Housing
12 Battery (not included with all products)
13 Battery Charger (not included with all products)
- Grass Trimmer Instruction/Safety Manual (not shown)
- Battery & Charger Instruction/Safety Manual (not shown)
Features & Supplied Items - 18V Single Battery Line Trimmer
WARNING
Do not operate the product if any component is missing or damaged. Have any missing or
damaged components repaired or replaced.
NOTE: Refer to figure 1.
Fig 1
1
2
3
4
5
6
7
8
9
10
11
12
13
Not for
Reproduction

4
Read all safety warnings, instructions, illustrations and specifications provided with
this power tool. Failure to follow instructions listed below may result in electric shock, fire
and/or serious injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your battery-operated (cordless) power tool.
• Keep work area clean and well lit. Cluttered or dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
• Keep children and bystanders away while operating the power tool. Distractions
can cause you to lose control.
• Thoroughly inspect the area where the machine is to be used. Remove all
stones, sticks, wire, bones, toys, and other objects that could be tripped over
or thrown by the cutting mechanism. Thrown objects can cause serious personal
injury.
• Avoid body contact with earthed or grounded surfaces such as pipes, radiators
and refrigerators. There is an increased risk of electric shock if your body is earthed
or grounded.
• Do not expose the power tool to rain or wet conditions. Water entering the power
tool will increase the risk of electric shocks.
• Stay alert, watch what you are doing and use common sense when operating
the power tool. Do not use the power tool while you are tired or under the
influence of drugs, alcohol or medication. Reduced concentration while operating
the power tool may result in serious personal injury.
• Use personal protective equipment. Always wear eye protection. Protective
equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection
used for appropriate conditions will reduce personal injuries.
• Prevent unintentional starting. Ensure the switch is in the off-position before
inserting the battery pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch may cause accidental starts.
• Remove any adjusting key or wrench before turning the power tool on. A wrench
or key left attached to a rotating part of the power tool may result in personal injury.
• Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
• Do not wear loose clothing or jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
• Do not operate this machine in bare feet, or while wearing sandals or lightweight
(e.g. canvas shoes) Wear long trousers & heavy shoes.
General Safety
Personal Safety
WARNING
Electrical Safety
Work Area Safety
Not for
Reproduction

5
• The power tool should be operated only with a genuine Briggs & Stratton 18V
Lithium-ion battery. When using battery powered power tool, basic safety
precaution should always be followed to reduce the risk of leaking batteries and
personal injury.
• Do not force the power tool and always use the correct power tool for your
application. The correct power tool will do the job better and safer if it was designed to
do so.
• Do not use the power tool if the switch does not turn it on and off safety. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired before
use.
• Remove the battery pack from the power tool before changing accessories storing
power tools or when not in use.
• Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
• Maintain power tools and accessories. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may affect the power
tool's operation. If damaged, repair the power tool before use.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control.
• Use the power tool and accessories in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power
tool for operations different from what it is intended for may be hazardous.
• Keep handles and grasping surfaces dry, clean and free from oil and grease.
Slippery handles and grasping surfaces do not allow for safe handling and control of the
tool in unexpected situations.
• Become familiar with all controls and their proper operation before using the power
tool. Know how to stop the power tool and how to disengage the power in an
emergency.
• If the power tool starts to vibrate excessively, discontinue use until the machine has
been inspected and assessed. Having a power tool assessed for vibration problems
generally reduces the risk for injury or product failure.
• Do not point the power tool in the direction of people or pets.
• Power tool must be must be completely assembled before attempting to start operation.
• Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
• Never service damaged battery packs. Service of battery packs should only be performed
by the manufacturer or authorized service providers.
Power Tool Use and Care
• Do not let familiarity gained from frequent use of similar power tools allow you to
become complacent and ignore safety principles. A careless action can cause severe
injury.
• Do not use the machine indoors. Only store the machine indoors in a dry & secure
location. Keep the machine out of reach of children.
• Do not use the machine in a rush. Always walk & never run with the machine.
Not for
Reproduction

6
• Only use machine with Briggs & Stratton 18V Batteries and Chargers.
• Recharge only with the charger specified by the manufacturer. A charger that is
suitable for one type of battery pack may create a risk of fire when used with another
battery pack.
• Use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
• When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws, or other small metal objects that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery. If this
happens, avoid contact. If contact accidentally occurs, flush with water and if
it comes in contact with eyes, seek medical help. Liquid ejected from the battery
may cause irritation or burns.
• Do not use a battery pack or tool that is damaged or modified. Damaged or
modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or
risk of injury.
• Do not expose a battery pack or tool to fire or excessive temperature.
Exposure to fire or temperature above 130°C may cause explosion.
• Follow all charging instructions and do not charge the battery pack or tool
outside the temperature range specified in the instructions. Charging improperly
or at temperatures outside the specified range may damage the battery and increase
the risk of fire.
Battery Use and Care
Not for
Reproduction

7
3.
Product Disposal
CORRECT DISPOSAL OF THE PRODUCT
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your local authority or retailer
for recycling advice.
The battery contains material which is hazardous to you and the environment. It must
be removed and disposed of separately at a facility that accepts lithium-ion batteries.
Refer to Briggs & Stratton 18V Battery & Charger manual for further information
relating to battery and charger disposal.
In the rare case a battery is damaged & any of the contents leaks or comes into contact
with a persons skin, eyes, or is ingested, follow the first aid instructions inside the battery &
charger manual. Seek further medical attention immediately.
Emergency Contact
ASSEMBLY PROCEDURES
This product requires assembly.
• Carefully remove the product and any accessories from the box. Make sure that all items
listed in the packing list are included. Refer to pages 3.
• Do not discard the packing material until you have carefully inspected and ensured
product is in correct operating condition.
WARNING: Do not attempt to modify this product
or create accessories not recommended for use with
this product. Any such alteration or modification is misuse and could result in a hazardous
condition leading to possible serious personal injury.
Do not operate the machine unless assembly is complete including guards, handles &
harness.
Do not install the battery in the product before finishing the complete assembly.
Unpacking
CORRECT DISPOSAL OF THE PACKAGING
The packaging consists of cardboard and correspondingly marked plastics that
can be recycled. Make these materials available for recycling.
Not for
Reproduction

8
Fitting the handle
1. Remove all the screws from the handle. (Fig.2)
2. Position brackets on Shaft and tighten the screws.(Fig.3)
Handle Assembly
ASSEMBLY PROCEDURES
CAUTION! Not too loose or too tight. Over tightening may damage the unit.
Fig. 2 Fig. 3
Guard Assembly
Fitting the bent shaft guard
1. Remove screws and bracket from guard. (Fig 4).
2. Place the guard as shown below, using the centre screw to align the location. (Fig 5).
3. Now, fasten the 2 other screws firmly. (Fig 6).
Fig. 4 Fig. 5 Fig. 6
Not for
Reproduction

9
ASSEMBLY PROCEDURES
Trimmer Line Assembly - Bump Head
Cover
Spool
Housing Upper spool
Middle
plate
Top of Spool
Notches in top of
spool
1. Press two cover clips inwards on the housing & remove the cover slowly.
2. Remove the remains of worn line from the spool (if any remains).
Note: Remaining line may be sufficient to rewind and reuse if it has been tangled or has
retracted back into the housing.
Note: Ensure inside of housing and spool are clean and free of grass & soil before
refilling.
3. Fold the full length of line in the centre and insert the centre fold into one of the slots in
the spool middle plate.
4. Wind the upper half of the line tightly 'ANTI-CLOCKWISE' onto the upper spool.
Note: 'ANTI-CLOCKWISE' direction when looking at the top of the spool as shown by
the arrow in Fig.4.
5. Continue winding until approximately 10cm remains at the end of the line and hold line
end by locking into one of the four notches on the top of the spool. Refer Fig. 4.
6. Repeat process with other half of the line winding in the SAME DIRECTION on the
lower spool and hold the line end in an opposite notch.
7. Put the spool back into the cover. Remove one end of the line from the spool notch &
push it into an Eyelet slot. Repeat for the other end of the line into the opposing Eyelet
slot. Pull both ends of line tightly through the eyelets to remove any excess slack in
spool winding.
8. Push the spool and cover back into the housing so that the housing clips align with the
cover and clicks back into place.
* The bump head can be fitted with line diameters from 2.0mm to 3.0mm. The
maximum length of the line that can fit the head varies according to the line diameter.
Do not overfill the head spool with excessive lengths of line as it will result in
ineffective spool feeding of line.
Not for
Reproduction

10
ASSEMBLY PROCEDURES
Trimmer Line Assembly - Bump Head
Nylon line will deteriorate over time and may require replacement if line
breakages and cut performance is not satisfactory
Do not operate the bump head with parts missing such as the spring or
eyelets
Do not operate the bump head if the cover is not secured by the Cover
Clips.
Do not operate the bump head if components are damaged or
excessively worn.
Bump Head Assembly
1. Housing
2. Arbor
3. Spring
4. Spool
5. Eyelet (2)
6. Cover
Cover Cli ps
Eyelet Slot
Slots in
middle plate
Upper Spool
Notches in top
of spool
Middle Plate
Upper Spool
Lower Spool
Eyelet Slot
1. 2.
3.
4.
5.
6.
Not for
Reproduction

11
ASSEMBLY PROCEDURES
Cutting Head Assembly
Always ensure the line cutting blade on the guard is covered when
fitting, changing or removing the trimmer head.
Never operate the machine without a cutting head fitted.
Never fit an alternative cutting head that has not been
recommended by the manufacturer.
BENT SHAFT CUTTING HEAD
1. Cover the cutting blade with protector.
2. Align hole in Gearbox Mounting & slot on the
shaft.
3. Insert Allen Key into hole & firmly support to
lock shaft rotation.
4. Grip the head & rotate anti-clockwise to
remove.
5. Refit preferred head in reverse order & firmly
tighten.
Mounting
Hole
Shaft
Gearbox Mounting
CUTTING HEAD REMOVAL & REPLACEMENT
Text
Before Starting
Check the position & operation of controls to ensure you are comfortable
before you start using the machine. Triggers, starter cord and grip position
should provide smooth operation, balance and comfort before starting the
machine. Check that all screws are securely fastened and also check all
the safety devices.
Always use the shoulder strap when using the machine. Switch off the
powerhead unit before you take off the shoulder strap.
Check the machine for the following each time before use:
• That the cutting unit and all safety devices are in perfect condition
• That all screws are securely fastened
11
Not for
Reproduction

12
Starting & Stopping
Operating The Machine
Hold the machine with your right hand on the rear handle and your left hand on the front
handle. Keep a firm grip with both hands while in operation. The machine should be held at
a comfortable position with the rear handle about hip height. Always operate the machine
at full throttle. If debris becomes wrapped around the cutting head, release the trigger,
remove battery and then remove the debris.
• Position the unit on the operator’s right side & never operate unit with the bottom of the
motor above waist level.
• Reverse hand orientation if left hand use is desired.
WARNING
WARNING
NOTE: Refer to figure 7
• Align the guide ribs on battery with grooves in the machine's battery port.
• Push the battery in the line trimmer battery housing.
• Make sure the latch on bottom of the battery snaps in place and that the battery is fully
seated (will "click" into place) and secure in the machine before beginning operation.
• If the machine is not going to be used immediately, remove the battery.
• To remove the battery, press the release trigger on the battery and pull it out from
machine. Refer battery manual to locate the release trigger.
Installing & Removing the Battery
Fig 7
PRESENCE SWITCH (Fig. 9)
The presence switch reduces the possibility of accidental starting. The presence switch is
located on the handle above the trigger. The presence switch must be pushed in before you
pull the trigger. The lock resets each time the trigger is released.
Remove batteries from machine when not in use.
ASSEMBLY PROCEDURES
Not for
Reproduction

13
STARTING the machine:
• Push and hold the ON/OFF Button on the Indication Panel (Fig. 8) until the Green LED
appears.
• Push the presence switch and hold it in place (Fig. 9).
• While the presence switch is held, squeeze the throttle trigger to start the machine
(Fig. 9)
• Release the presence switch while keeping the throttle trigger squeezed.
• Allow few seconds for the cutting head to reach max RPM.
STOPPING the machine:
• Release the throttle trigger.
• Allow cutting head to come to a complete stop.
• Remove battery from the machine.
Fig 9
Presence switch
Trigger
ON/OFF
Button
Speed control
Button
Speed
Indication LED
Power
Indication LED
Fig 8
Speed Adjustment
Speed settings can be adjusted by pressing the speed control button (Fig. 10) when
the machine is turned on.
Note: When the highest speed setting is activated, pressing the speed control button
again willl revert the speed setting back to the lowest speed.
OPERATING INSTRUCTIONS
13
Not for
Reproduction

14
OPERATING INSTRUCTIONS
Trimming Procedures
Trimming / Mowing
• Swing trimmer with a sickle-like motion from side to side.
Do not tilt the cutting head during the procedure. Test
area to be trimmed for proper cutting height. Keep string
head at same level for even depth of cut.
Fence / Foundation Trimming
• Approach trimming around chain link fences, picket
fences, rock walls and foundations slowly to cut close
without whipping string against the barrier. If the string
comes in contact with rock, brick walls, or foundations,
it will break or fray. If string snags fencing, it will snap off.
Trimming Around Trees
• Trim around tree trunks with a slow approach so string
does not contact bark. Walk around the tree trimming
from left to right. Approach grass or weeds with the tip of
the string and tilt cutting head slightly forward.
Scalping
• Scalping refers to removal of all vegetation down to the ground. To do this, tilt the cutting
head to about 30 degree angle to the left. By adjusting the handle you will have better control
during this operation. Do not attempt this procedure if there is any chance flying debris could
injure operator, other people or cause damage to property.
Use extreme caution when SCALPING. Keep a distance of 100 feet
(30 metres) between operator, other people and animals during these
operations.
Not for
Reproduction

15
Text
Practical Tips
• Practice all operating techniques with the powerhead unit switched off before you start
to use the machine.
DO NOT use steel wire or plastic-coated steel wire of any kind with your
string head. Serious operator injury can result.
Periodically remove weed wrap to prevent overheating the drive shaft.
Weed wrap occurs when strands of weed become entangled around the
shaft beneath the debris shield. This condition prevents the shaft from
being properly cooled.
• Remove weed/grass wrapped around head/shaft.
• When properly equipped with a guard and cutting head, your unit will trim unsightly
weeds and tall grass in those hard-to-reach areas – along fences, walls, foundations
and around trees. It can also be used for scalping to remove vegetation down to the
ground for easier preparation of a garden or to clean out a particular area.
Trimming around foundations, brick or stone walls, curves, etc. will result
in above normal string wear.
To increase the length of nylon trimming line when using the Bump Head;
1. Run the trimmer at maximum RPM while firmly bumping the spool on the ground.
2. The line will come out incrementally each time head is bumped.
3. Check the length after each bumping and repeat till the required length is achieved.
4. Bump and feed the line before it becomes too short and fall back into the bump head. If
this happens refer to the section of “Trimmer Line Assembly – bump head” on page 6.
Note: refer to “Troubleshooting - Bump head” if the line is not coming out when bumping.
DO NOT touch the bump head while the powerhead unit is running.
DO NOT Bump feed excessive lengths of line longer than the limits of the
guards.
Feeding Bump Head Line
OPERATING INSTRUCTIONS
Not for
Reproduction

Cleaning
WARNING
To prevent serious personal injury remove the battery from the machine before servicing,
cleaning, or removing debris.
• Clean the unit using a damp cloth with a mild detergent.
• Do not immerse the machine or any part of it in water.
• Moisture can cause a shock hazard. Wipe off any moisture with a soft dry cloth & ensure
the machine is dry before replacing the battery.
• Use a small brush or vacuum cleaner to clean the air vents on the product.
• Keep the air vents free of obstructions.
Do not use solvents, strong detergents, certain aromatic oils such as pine and lemon when
cleaning plastic parts. Chemicals can damage, weaken or destroy plastic component which
may result in serious personal injury.
The following steps should be taken in order to prepare the machine for storage.
• Clean the machine as described in the previous section.
• Store the machine in a dry, clean location. Do not store it next to corrosive materials,
such as fertilizer or fuel.
• Store the machine indoors, in a cool, dry place, out of the reach of children.
• Ensure batteries are removed before storage.
Storing
16
Not for
Reproduction

17
Maintenance Chart
Features Requirements Before use After use Recharging Monthly Yearly If damaged As required
Throttle trigger Check operation •
Trimmer Visual inspection • •
Cutting Head Check & clean • •
Bump Head Clean
Replacement
•
• •
Presence trigger Check •
Battery locking latch Check • •
Ventilation Grills Clean • •
All accessible fasteners Retighten • •
Refer to the following table for routine maintenance.
Service
Servicing requires extreme care and knowledge and should be performed only by a
qualified service technician. For service we suggest you return the product to your nearest
authorized service centre for repair. When servicing, use only genuine replacement parts.
• Keep the machine dry, clean, and free of oil and grease.
• In order to reduce the risk of fire, keep the motor free of grass, leaves, and debris build-
up.
• Keep all nuts, bolts, and screws tight in order to be sure that the equipment is in safe
working condition.
• Never tamper with safety devices. Check them regularly for proper operation.
• Improper repairs may result in product malfunction. This endangers you and your
environment.
Never service damaged battery packs. Service of battery packs should only be performed
by the manufacturer or authorized service providers.
NOTE: Refer to warranty card supplied with this product for service contact details.
WARNING
Not for
Reproduction

18
Troubleshooting
TROUBLESHOOTING
Indication Panel
(Refer to figure 5.1 for further details on indication panel)
LED Indication User action
Solid Green LED Trimmer is ON Active and ready for use.
Blue LED
"Flashing"
Temperature
protection has
been activated
- Allow batteries to cool down before continuing operation.
- Change a different set of batteries to continue operation.
* LOAD PROTECTION
The grass trimmer has built in load sensing. When the load is high, the trimmer will shut
the motor down immediately and emit beeping sound informing the user that the load
protection has been activated to protect the product and user.
Problem Cause Solution
Motor fails to run
when trigger is
depressed
Flat battery
Battery
disengaged
Faulty battery
Recharge battery
Refit battery
Replace battery
Excessive
vibration
Cut off blade worn
Bumphead not
fitted correctly
Broken drive shaft
Replace cut off blade
Refit bumphead
Replace drive shaft
Not for
Reproduction

19
Product Specifications
Note:
• That the declared vibration total value has been measured in accordance with a
standard test method and may be used for comparing one tool with another;
• That the declared vibration total value may also be used in a preliminary assessment of
exposure.
• That the vibration emission during actual use of the power tool can differ from the
declared total value depending on the ways in which the tool is used; and
• Of the need to identify safety measures to protect the operator that are based on an
estimation of exposure in the actual conditions of use (taking account of all parts of the
operating cycle such as the times when the tool is switched off and when it is running
idle in addition to the trigger time).
TECHNICAL SPECIFICATIONS
Model number 80102224
Description 18V Line Trimmer
Cut Diameter 330 mm
Head Type Bump head
Nylon Line Diameter 2.0 mm
Motor Type Brushless
Motor Specification 18V DC
Motor Speed (rpm) 12,500
Cutting Speed (rpm) 3,500 @low
6,000 @high
Product Weight (No battery) 3.5 kg
Sound Power Level (Guaranteed) 96 dBA
Vibration Total Value (Max) 2.86 m/s2(Rear handle)
4.94 m/s2(Front handle)
Not for
Reproduction
