Victory DVN-16P User manual

www.smartavi.com
Installation
Manual
Control 16 Computers, PC or Mac on one Display
Up To 20 Feet Away with Stereo Audio and USB 2.0
DVN-16P
16-Port Cross-platform DVI-D Switch
with Stereo Audio and USB 2.0

2www.smartavi.com
Introduction
The DVN-16P is a cross-platform switch capable of sharing a DVI-D monitor, stereo speakers and
USB 2.0 devices between sixteen computers. It is RS-232 and Infrared compliant, capable of being
controlled remotely via software (TCP/IP), locally via the front panel, RS-232 or Infrared remote control.
Applications
• Server Collocation
• Digital Signage
• Airports
• Dealer Rooms
• Control Rooms
• Audio/Visual Presentations
• Hotels/Resorts
• KVM Switches
The DVN-16P has a broad range of applications, but its main function is to centralize the access
to several computers into one console. Not only does it function like a KVM, it has USB support.
This allows a user at the console to use USB devices that would otherwise be unavailable with
conventional KVMs. For example, it allows a user to use a ash memory drive without having to
plug it directly into the remote computer. In the medical or industrial eld for example, where
it may not be practical (or safe) to have one or more CPUs in the general vicinity, the DVN-16P is
the perfect solution.
Features
• Supports Mac, PC, Linux and Sun DVI
• Supports High Resolution1920x1200 60Hz WUXGA
• Uses universal DVI Single Link connectors
• Zero pixel loss with TMDS signal correction
• Supports all USB 2.0 Devices (Flash Drives, Printers, Scanners, etc.)
• Supports USB 2.0 keyboard and mouse
• Balanced stereo audio output
• Front panel tactile switch with LCD display
• Full IR and RS-232 control
• Optional TCP/IP control
NOTE: THE USB OPERATION OF THE DVN-16P IS FULLY TRANSPARENT.
TO ATTACH ADDITIONAL USB DEVICES A USB HUB MAY BE USED.

3
www.smartavi.com
Technical Specications
What’s in the Box?
PART NO. QTY DESCRIPTION
DVN-16PS 1 DVNET-16P, 16X1 DVI-D, USB2.0, Audio switch
Power Supply 1 PS5VDC4A
User Manual 1
VIDEO
Format DVI-D Single Line
Maximum Pixel Clock 165 MHz
Input Interface (16) DVI-D 29-pin female
Output Interface (1) DVI-D 29-pin female
Resolution Up to 1920 x 1200 @60Hz
DDC 5 volts p-p(TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
AUDIO
Frequency Response 20 Hz to 20 KHz
Impedance 600 ohm
Nominal Level 0-1.0 V
Common Mode Rejection at 60dB
Input Interface (16) 3.5 mm Stereo Audio
Output Interface (1) 3.5 mm Stereo Audio
USB
Signaling USB 2.0, 1.1 and 1.0 w/ Internal Hub
Input Interface (16) USB Type B
Output Interface (2) USB Type A
CONTROL
Front Panel Tact Switch
RS232 Via Software @ 9600 bps
IR Via Remote Control with IR-EYE Type 3
OTHER
Power External 100-240 VAC/5VDC4A @20W
Dimensions 10.5”W x 1.875”H x 6”D
Weight 8 lbs.
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-131°F (0-55 °C)
Storage Temp. -4-185 °F (-20-85 °C)
Humidity Up to 95%
Emulation NO KEYBOARD OR MOUSE EMULATION

4www.smartavi.com
Product - Installation Diagram
Installation
1. Turn o all computers, speakers and the display.
2. Connect the DVI extension cables, USB cables, and audio cables (not included) to the computers and to
the “IN”ports on the DVN-16P.
3. Connect the display to the“OUT” DVI connector on the DVN-16P.
4. Connect USB devices, including mouse and keyboard, to the “OUT” USB connector on the DVN-16P.
5. Connect speakers to the “OUT” audio connector on the DVN-16P.
6. Connect the power supply to the DVN-16P.
7. Power on the computers, speakers and the display.
8. Use the front panel buttons, an RS-232 connection or infrared remote control to select the desired input port.
RG B
When using the SRC-2A infrared remote control:
• To switch to a specic port, use the keypad to enter the two-digit number of the
desired port and press the ENTER button.
• To cycle through the available ports, press the CH up/down buttons.
Switching Between Ports
There are three ways to switch between inputs on the DVN-16P: via the front panel buttons, IR remote control,
RS-232 connection or TCP/IP (Internet).
Front Panel Control
To switch ports using the front panel, press either the Enter button for up or the Scroll button for down to
select the port you would like to switch to. The selected port number will be indicated on the LED display.
To use the front panel to program the DDC table, see “DDC Learning”.
IR Control (optional)
To switch ports using an infrared remote control (optional accessory), connect
an SM-EYE (optional accessory) to the DVN-16P box and the unit will auto-
detect the infrared connection. Once the connection is made, you may use the
IR remote to cycle through the available ports.

5
www.smartavi.com
RS-232 Control
To switch ports using an RS-232 connection, use a male-to-female serial cable to connect a computer to
the DVN-16P’s RS-232 port. Use Hyperterminal to connect to the DVN-16P, making sure to use the standard
communication mode of 9600bps, 8, N, 1.
(NOTE: all commands must be uppercase)
• To switch ports, use the standard“//M” command prompt.
• To switch to the “IN 1” port, send “//M01 [ENTER]”
• To switch to the “IN 2” port, send “//M02 [ENTER]” etc.
• To switch to the “IN 1” port and toggle the hotplug pin, send “//H01 [ENTER]”
• To switch to the “IN 2” port and toggle the hotplug pin, send “//H02 [ENTER]” etc.
(the hotplug pin is used to wake the display from standby)
• To begin“Learn Screen” Mode, send “//E [ENTER]”
• To reset the DVN-16P to factory defaults, send“//R [ENTER]”
DDC Learning
The DVN-16P is fully capable of“learning”and remembering what type of display monitor is connected to the
unit. Programming the DDC (Display Data Channel) is accomplished using the two buttons located on the
front panel.
To enter Learning Mode, simply press both the Scroll and Enter buttons at the same time until the display
reads “Menu”. By then pressing the Scroll button, you may cycle through the following DDC learning modes:
(to select a mode, press the Enter button)
“Learn PC” indicates Personal Computer Mode and automatically selects the standard display characteristics
of a PC display, which typically works for any PC/Display combination.
“Learn Mac” indicates Mac Mode and selects the best display mode to accommodate a Mac.
“Learn Screen” indicates Screen Mode, which learns the type of display connected to the “OUT” port.
“Exit” allows the user to exit the menu.
DDC provides plug-and-play capability to your displays. When you plug a display into your computer, the
DDC table in the display tells the computer the optimal resolution to use. In order to preserve this plug-
and-play capability, we have integrated DDC learning into all of our DVI Solutions.
ABOUT DDC
TCP/IP Control (optional)
To control the DVN-16P remotely via the internet, connect an SMTCP controller (optional accessory) to the
RS-232 port of the DVN-16P. For more information about the SMTCP controller, please visit our website at
www.smartavi.com.

6www.smartavi.com
Supported Resolutions (built in DDC table)
DVN-16P Front
DVN-16P Rear
Resolution Refresh Rate
640 x 480 85 Hz
800 x 600 85 Hz
1024 x 768 85 Hz
1152 x 870 75 Hz
1280 x 768 75 Hz
1280 x 960 60 Hz
1280 x 1024 60 Hz
1600 x 1200 60 Hz
1920 x 1200 60 Hz
NOTE: The DVN-16 is capable of DDC learning and is not limited to
the above resolutions. (See DDC learning on page 5)

7
www.smartavi.com
Technical Specifications
Input/Output Signal
#niPlangiS#niPlangiS
1-2ataDS.D.M.6T1tceteDgulPtoH
2+2ataDS.D.M.7T1-0ataDS.D.M.T
d3leihS4/2ataDS.D.M.8T1+0ataDS.D.M.T
4-4ataDS.D.M. 9Td1leihS5/0ataDS.D.M.T
5+4ataDS.D.M.0T2-5ataDS.D.M.T
6kcolCCD1D2+5ataDS.D.M.T
7ataDCD2Dd2leihSkcolCS.D.M.T
8cnyS.treVgolan 3A 2+kcolCS.D.M.T
9-1ataDS.D.M.4T2-kcolCS.D.M.T
01+1ataDS.D.M.T
1d1leihS3/1ataDS.D.M.1TCdeRgolanA
21-3ataDS.D.M.2TCneerGgolanA
31+3ataDS.D.M.3TCeulBgolanA
41rewoPV54+CcnySzroHgolanA
51DN 5GCdnuorGgolanA
PIN 17
PIN 1
PIN 24
PIN 8
C 4
C 1
C 2
C 5
C 3
esolutions
Suppote  the intenal I configuation
zH 58084 x 046
zH 58006 x 008
zH 58867 x 4201
zH 57078 x 2511
zH 57867 x 0821
zH 06069 x 0821
zH 064201 x 0821
zH 060021 x 0061
Resolution Refresh Rate
5C 16
Technical Specifications
Input/Output Signal
#niPlangiS#ni
Pl
angiS
1-2ataDS.D.M
.6
T1tceteDgulPtoH
2+2ataDS.D.M
.7
T1-0ataDS.D.M.T
d3leihS4/2ataDS.D.M
.8
T1+0ataDS.D.M.T
4-4ataDS.D.M. 9
Td1l
eihS5/0ataDS.D.M.T
5+4ataDS.D.M.0T2-5ataDS.D.M.T
6kcolCCD1D2+5ataDS.D.M.T
7ataDCD2
Dd2l
eihSkcolCS.D.M.T
8cnyS.treVgolan 3A
2+
kcolCS.D.M.T
9-1ataDS.D.M.4T2-kcolCS.D.M.T
01+1ataDS.D.M.T
1d1leihS3/1ataDS.D.M
.1
TCdeRgolanA
21-3ataDS.D.M.2T
Cn
eerGgolanA
31+3ataDS.D.M.3TCeulBgolanA
41rewoPV54+CcnySzroHgolanA
51DN 5GCdnuorGgolanA
PIN 17
PIN 1
PIN 24
PIN 8
C 4
C 1
C 2
C 5
C 3
esolutions
Suppote  the intenal I configuation
zH 58084 x 046
zH 58006 x 008
zH 58867 x 4201
zH 57078 x 2511
zH 57867 x 0821
zH 06069 x 0821
zH 064201 x 0821
zH 060021 x 0061
Resolution Refresh Rate
5C 16
DVI-D Conguration
NOTE: The DVN-16 uses a DVI-I connector, but supports DVI-D.
DVI-I Connector
