Viega Prevista Pure 8367 User manual

Instructions for Use
Prevista Pure bidet block
for wall-hung bidet, wet construction installation
Model Year built (from)
8367 01/2020
INT

Table of contents
1About these instructions for use 3
1.1 Target groups 3
1.2 Labelling of notes 3
1.3 About this translated version 4
2Product information 5
2.1 Intended use 5
2.1.1 Areas of use 5
2.2 Product description 5
2.2.1 Overview 5
2.2.2 Technical data 6
3Handling 7
3.1 Assembly information 7
3.1.1 Installation dimensions 7
3.2 Assembly 8
3.2.1 Mounting a pre-wall block 8
3.3 Disposal 11
Table of contents
Prevista Pure bidet block 2

1 About these instructions for use
Trade mark rights exist for this document; for further information, go to
viega.com/legal.
1.1 Target groups
The information in this instruction manual is directed at the following
groups of people:
nHeating and sanitary professionals and trained personnel
Individuals without the abovementioned training or qualification are not
permitted to mount, install and, if required, maintain this product. This
restriction does not extend to possible operating instructions.
The installation of Viega products must take place in accordance with
the general rules of engineering and the Viega instructions for use.
1.2 Labelling of notes
Warning and advisory texts are set aside from the remainder of the text
and are labelled with the relevant pictographs.
DANGER!
This symbol warns of possible life-threatening injury.
WARNING!
This symbol warns of possible serious injury.
CAUTION!
This symbol warns of possible injury.
NOTICE!
This symbol warns of possible damage to property.
This symbol gives additional information and hints.
About these instructions for use
Prevista Pure bidet block 3

1.3 About this translated version
This instruction for use contains important information about the choice
of product or system, assembly and commissioning as well as intended
use and, if required, maintenance measures. The information about the
products, their properties and application technology are based on the
current standards in Europe (e.g. EN) and/or in Germany
(e.g. DIN/DVGW).
Some passages in the text may refer to technical codes in Europe/
Germany. These should serve as recommendations in the absence of
corresponding national regulations. The relevant national laws, stand‐
ards, regulations, directives and other technical provisions take priority
over the German/European directives specified in this manual: The
information herein is not binding for other countries and regions; as said
above, they should be understood as a recommendation.
About these instructions for use
Prevista Pure bidet block 4

2 Product information
2.1 Intended use
2.1.1 Areas of use
The Prevista Pure bidet block is suitable for mounting wall-mounted
bidets and for walling in or around. This model 8367 has height-adjust‐
able and width-adjustable wall plates.
2.2 Product description
2.2.1 Overview

Fig. 1: Components
1 Prevista Pure bidet block
2 Holder for drain elbow
3 Drain elbow
4 Fixing material for bidet ceramic
5 threaded rods for fixing sanitary objects
6 Fixing material: dowels and screws
7 Wall plates
Product information
Prevista Pure bidet block 5

2.2.2 Technical data
The product has the following technical data:
frame Galvanised steel
Wall plates Gunmetal ½ inch
Drain elbow DN 40
Product information
Prevista Pure bidet block 6

3 Handling
3.1 Assembly information
3.1.1 Installation dimensions

9

Fig. 2: Dimensional drawing
Handling
Prevista Pure bidet block 7

3.2 Assembly
3.2.1 Mounting a pre-wall block
▶Bend open the four fixing lugs on the side by 90°.
▶Determine the fixing height.
▶Align the block horizontally.
▶Drill the holes and attach the dowels.
Mounting on a solid wall
Y
Handling
Prevista Pure bidet block 8

▶Attach the block to the wall with the screws supplied.
▶Open the pipe clamp.
▶Insert the drain elbow.
▶Close the pipe clamp.
▶Set the height of the drain elbow.
Handling
Prevista Pure bidet block 9

▶Set the height and width of the wall plates.
▶Turn in the threaded rods by hand.
▶Brick the block in and up completely.
▶Tile the pre-wall.

Handling
Prevista Pure bidet block 10

▶Align the block horizontally and fix in the wall using mortar.
▶Brick the block in and up completely.
▶Plaster the block completely.
3.3 Disposal
Separate the product and packaging materials (e. g. paper, metal,
plastic or non-ferrous metals) and dispose of in accordance with valid
national legal requirements.
Mounting in a solid wall
Handling
Prevista Pure bidet block 11
