VIEQUIPMENT VISLIDE User manual

U S E R ‘ S M A N U A L | V I S L I D E

U S E R ‘ S M A N U A L | V I S L I D E
The beginning
The vislide
Technical characteristics of the Vislide sliding platform
Elements of the equipment
Appropriate use of the Vislide sliding platform
Choosing the location for the instalation
Difficult or complicated maneuvers
Correct use of the equipment and assembly
Safety tips and advice
Connection of the sliding platform to the control tower
Exercises and recommendations
Mobility of the control tower
Maximum weight
Description of the functioning of the control tower
Selection of the vibration frequency
Selection of the start time
Selection of the on/off cycles
Starting the sliding platform
Maintenance
Problem solving
Scrap and elimination of the equipment
Resignation
Guarantee
Customer support
2
3
4
5
6
6
8
8
8
10
12
13
14
14
15
16
17
18
20
20
22
23
24
25
TABLE OF CONTENTS

U S E R ‘ S M A N U A L | V I S L I D E | 2
THE BEGINNING
Viequipment was born in the firm belief that it is possible to evolve exercise using
vibration through the development of innovative vibratory devices. Gerard Moras
and Sergio Rodríguez began to forge the foundations of Viequipment in 2009,
when they developed the first vibratory platform with different levels of distur-
bance, the Vibalance. All of their products were designed painstakingly by the
creators to increase the effectiveness and versatility of training. The positive re-
sults obtained in sport and in the field of rehabilitation motivated them to take on
new challenges to continue growing and share their findings.
We thank you for choosing to purchase a Viequipment product. Its technology,
design and quality will bring long lasting, total satisfaction.
Before starting the MACHINE, carefully read the user’s instructions and save them
for future consultation.
Note: if any type of doubt regarding the operations contained in this manual ari-
se, we advise that it be the official distributor who effects said operations.

U S E R ‘ S M A N U A L | V I S L I D E | 3
THE VISLIDE
Vislide is a vibratory platform with sliding properties which improves upon speci-
fic aspects of neuromuscular performance through exercises with little impact to
the joints. It allows one to carry out sliding exercises with vibration on a platform
of large dimensions.
Vibratory exercise with Vislide can be used at any phase of training.
Among their values, Viequipment stands apart for the idea of promoting a com-
munity which leads a modern and critical vision in the implementation of exercise
with vibration.
A new way of training.
Vibalance, Viroller and Vislide continuously evolve towards the goal of creating
innovative, extremely different but very complementary products that satisfy a
good part of the needs of physical conditioning and rehabilitation professionals.

U S E R ‘ S M A N U A L | V I S L I D E | 4
TECHNICAL CHARACTERISTICS OF THE VISLIDE SLIDING PLATFORM
En la Tabla 1 se especifican las características técnicas de la plataforma Vislide.
TECHNICAL CHARACTERISTICS
Vibratory motors (units)
Feed voltage (vac)
Motor power (kW)
RPM
Vibration frequency (Hz)
Vibration cycles (Hz)
Vibration type
Amplitude (mm peak to peak)
Maximum acceleration range (g)
Time selection (min)
Display
Metronome
Photoelectric START/STOP
Vibratory structure weight (kg)
Control tower weight (kg)
Vibratory structure material
Control tower material
Vibratory structure dimensions (An.x Pr.x Al.) (mm)
Tower dimensions (An.x Pr.x Al) (mm)
Sliding surface (An.x Pr.) (mm)
Contact surface material
Maximum weight (kg)
Resistance limit in each connection (kg)
Noise dB(A)
VISLIDE
1
220-240 (50 Hz)
0.18
3000
20, 25,30
20-30
Rotational
1.7
from 0,3 to 3
Maximum 10
Leds
No
No
100
15
Iron F111
Iron F111
2279x739x240
280x400x997
2000x595
polyethylene
200
50
<70
Table 1. Technical characteristics of the Vislide sliding platform.

U S E R ‘ S M A N U A L | V I S L I D E | 5
In Figure 1 the components of Vislide are detailed.En la Tabla 1 se especifican las características técnicas de la plataforma Vislide.
ELEMENTS OF THE EQUIPMENT
Figure 1. Details of the components of the Vislide sliding platform.
control potentiometer
LED screen
control tower
connector
spiral cable sliding surface
lateral anchors
sliding vibratory platform

U S E R ‘ S M A N U A L | V I S L I D E | 6
APPROPRIATE USE OF THE VISLIDE SLIDING PLATFORM
CHOOSING THE LOCATION FOR THE INSTALLATION
Vislide is intended for use in professional locales or gymnasiums for exercise with
vibration.
Vislide is not intended for use in outdoor areas.
Vislide should be used in an environment with a temperature between +10°C and
+40°C.
Vislide may be used by children over 8 years of age, persons with reduced mental
or sensorial capacity, or persons without sufficient experience or knowledge if they
have been instructed in the safe use of the vibratory bar and they understand the
risks involved.
The sliding platform and the control tower should be installed on a flat, stable
surface. It is recommended that the surface on which the platform is placed be
sufficiently stable so as to prevent it from moving during exercise.
The free space around the sliding platform should not be less than 1.5 m (Figure
2). The free space should also include emergency space.
IT IS ADVISED TO NOT SURPASS A TOTAL OF 20 MINUTES OF EXPOSITION
TO VIBRATORY STIMULATION AND TO NOT BE EXPOSED TO MORE THAN
10 CONSECUTIVE MINUTES. REST BETWEEN EXERCISES SHOULD BE AT
LEAST 3 MINUTES.

U S E R ‘ S M A N U A L | V I S L I D E | 7
Figure 2. Defining the free space around the Vislide vibration platform.

U S E R ‘ S M A N U A L | V I S L I D E | 8
The Vislide sliding platform does not require difficult or complicated maneuvers,
however it should be used under the supervision of a professional.
DIFFICULT OR COMPLICATED MANEUVERS
CORRECT USE OF THE EQUIPMENT AND ASSEMBLY
SAFETY TIPS AND ADVICE
The Vislide platform should be used as is indicated in this instruction manual,
paying special attention to the importance of safety/ of keeping unsupervised
children away from the equipment. especial atención en la segurida de impor-
tancia de mantener alejados del equipo a los niños sin vigilancia.
To start or stop the equipment, use the START/STOP buttons situated at the top of
the control tower.
The sliding platform should connect to the control tower via the safety connector
and the control tower should be connected to the public electricity network as a
power source.
It is recommended to not separate the control tower more than 2,0 m away from
the sliding platform.

U S E R ‘ S M A N U A L | V I S L I D E | 9
Do not step on the spiral cable.
Never touch the connection cables with wet hands.
Remove connection cables by pulling on the terminations and not the cable, as this
could result in damage.
Do not situate the control tower near sources of heat for prolonged periods of time
(heaters, hot are circuits…) and maintain ventilation displays unobstructed.
Do not place the Vislide in a humid environment. Do not allow liquid to enter the
equipment, especially the control tower. Keep the machine away from heat sources.
Viequipment is not responsible for damage caused by the lack or interruption of
grounding cable (ie. Electrical discharge).
Before beginning any exercise, ensure that the control tower is sufficiently remo-
ved from the sliding platform to avoid any safety risk.
The vibratory platform has sliding properties. Be especially careful when stepping
upon the platform, always ensuring slide board booties are in good repair.
Be sure to use adequate snap rings when using external resistance systems (elastic
straps and/or pulley devices) in conjunction with the platform anchors.

U S E R ‘ S M A N U A L | V I S L I D E | 10
Once finished training, stop the device using the principal switch, situated at the
bottom of the tower. Disconnect the control tower when not in use for prolonged
periods of time.
To store and move the Vislide, use the principal off switch and disconnect the
control tower safety connector.
CONNECTION OF THE SLIDING PLATFORM TO
THE CONTROL TOWER
First use. Once removed from the packaging, place the control tower near the sli-
ding platform so that the spiral cable is positioned near the connector. Connect the
spiral cable safety connector to the electronic control tower as shown in Figure 3.
Plug the power cable in to the power socket and turn on the principal switch.
If the display does not come on, ensure that the L-shaped connector is properly
inserted and that the power plug functions correctly.

U S E R ‘ S M A N U A L | V I S L I D E | 11
CONNECTION OF THE SLIDING PLATFORM TO
THE CONTROL TOWER
Figure 3. Connection of the sliding platform to the control tower

U S E R ‘ S M A N U A L | V I S L I D E | 12
The position of the L-shaped connector is fixed and must be maintained so. For
correct maintenance of the connector, do not force or rotate the L-shaped body,
ensuring that it not be subjected to excessively elevated tension.
Your Vislide sliding platform is ready to use.
EXERCISES AND RECOMMENDATIONS
ADVISORY: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR DOCTOR.
Read all of the instructions before using the product. Improper training or excessi-
ve exercise can cause health damage. Always use under the supervision of a profes-
sional.
If you experience pain or vertigo while doing exercise, stop immediately and cool
down. This is especially important for anyone who has had previous health pro-
blems.
Viequipment assumes no responsibility for personal injury or property damage due
to or caused by the use of this product.

U S E R ‘ S M A N U A L | V I S L I D E | 13
As well as common vibration platform exercises, Vislide is designed for sliding
movements or exercises with vibration.
The total time of exposure to vibratory stimulation in one single session should
not exceed 20 mins, regardless of the amplitude and frequency selected. Excee-
ding this time limit could be damaging to one’s health.
If so desired, the control tower may be moved, separating it from the sliding
platform, thanks to the extendable spiral cable. To do so, slide or slightly lift the
tower, do not place it upon the safety aerial connector. To avoid elevated tension
in the aerial connector, avoid extending the spiral cable to its full limit.
To transport Vislide with maximum safety, disconnect the aerial connector, first
unscrewing the safety connector, so that it then may be removed.
MOBILITY OF THE CONTROL TOWER

U S E R ‘ S M A N U A L | V I S L I D E | 14
MAXIMUM WEIGHT
DESCRIPTION OF THE FUNCTIONING OF THE CONTROL TOWER
The maximum load for the sliding platform should not exceed 200 kg. Do not
submit the lateral couplings of the sliding platform to loads superior to 50kg.
The Vislide control tower allows one to select the frequency of vibration, the on/
off cycles and the ignition timing.
When one has ensured that both the sliding platform connector and the power
cable are correctly connected, engage the principle on switch situated at the top
left of the control tower. One can confirm that the display lights up, showing the
version of the plate, followed thereafter by the visual of the three programmable
variables.
The parameters offered by the Vislide display are, on the left, the frequency of
vibration; in the center, the on/off cycles; and on the right, the vibration time
interval.

U S E R ‘ S M A N U A L | V I S L I D E | 15
SELECTION OF THE VIBRATION ACCELERATION LEVEL
The vibration acceleration level can be modified with the potentiometer on the
lower left part of the control tower.
A vibration frequency of 20, 25 or 30 Hz can be selected, turning this dial from the
left towards the right. (Figure 4).
Figure 4. Selection of the vibration acceleration level.

U S E R ‘ S M A N U A L | V I S L I D E | 16
SELECTION OF THE START TIME
The vibration time interval can be modified using the potentiometer on the lower
right side of the control tower.
Vibration time intervals of 3, 6, 8 or 10 min can be selected, turning this dial from
left to right (Figure 5).
Figure 5. Selection of the start time.

U S E R ‘ S M A N U A L | V I S L I D E | 17
On/off cycles can be modified by using the central potentiometer located at the
bottom of the control tower.
On/off cycles of 20-10, 20-20, 40-20, 40-40, 60-30 or 60-60 Hz can be selected
turning this dial from the left toward the right (Figure 6).
SELECTION OF ON/OFF CYCLES
Figure 6. Selection of on/off cycles.
