Viessmann VITOLIGNO 300-P User manual

Operating instructions
for the system user
VIESMANN
Heating system with weather-compensated, digital boiler and
heating circuit control unit Vitotronic 300 type FW1
VITOLIGNO 300-P
5592 598 GB 10/2008 Please keep safe.

2
Please follow these safety instructions closely to prevent accidents and
material losses.
Safety instructions explained
Danger
This symbol warns against the
risk of injury.
!Please note
This symbol warns against the
risk of material losses and
environmental pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These operating instructions are for the
heating system user.
This unit is not designed to be used by
persons (including children) with limited
bodily, sensory or mental capacities, or
lacking experience and/or lacking
knowledge, unless they are supervised
by a person responsible for their safety,
or have received instructions from such
a person as to how to use the unit.
!Please note
Children should be supervised.
Ensure that children do not play
with the unit.
Danger
Incorrectly executed work on the
heating system can lead to life-
threatening accidents.
■ Work on gas appliances must
only be carried out by a
registered gas fitter.
■ Work on electrical equipment
must only be carried out by a
qualified electrician.
If you smell gas
Danger
Escaping gas can lead to
explosions which may result in
serious injury.
■ Do not smoke. Prevent naked
flames and sparks. Never
switch lights or electrical
appliances ON or OFF.
■ Close the gas shut-off valve.
■ Open windows and doors.
■ Remove all people from the
danger zone.
■ Notify your gas or electricity
supplier and your heating
contractor from outside the
building.
■ Shut off the electricity supply to
the building from a safe place
(outside the building).
Safety instructions
For your safety
5592 598 GB

3
If you smell flue gas
Danger
Flue gas can lead to life-
threatening poisoning.
■ Shut down the heating system.
■ Ventilate the boiler room.
■ Close all doors in the living
space.
In case of fire
Danger
Fire creates the risk of burning
and explosions.
■ Shut down the heating system.
■ Close the shut-off valves of the
fuel lines.
■ Use a tested fire extinguisher,
class ABC.
Boiler room requirements
!Please note
Incorrect ambient conditions can
lead to damage to the heating
system and put the safe
operation at risk.
■ Ensure ambient temperatures
above 0 ºC and below 35 ºC.
■ Prevent air contamination by
halogenated hydrocarbons
(e.g. as contained in paints,
solvents or cleaning fluids) and
excessive dust (e.g. through
grinding/polishing work).
■ Avoid continuously high
humidity levels (e.g. through
frequent drying of washing).
■ Never close existing ventilation
apertures.
Ancillary components, spare and
wearing parts
!Please note
Components that are not tested
with the heating system may lead
to damage to the heating system,
or may affect their various
functions.
Installation or replacement work
must only be carried out by
qualified personnel.
Safety instructions
For your safety (cont.)
5592 598 GB

4
Introductory information
Commissioning..................................................................................................... 6
Your system is preset at the factory..................................................................... 6
Where to find the controls
Summary of controls and indicators..................................................................... 7
■Opening the control unit.................................................................................... 7
■Functions.......................................................................................................... 8
■Symbols in the display...................................................................................... 10
■ Heating circuit selection – before any adjustment and scanning...................... 10
■ Possible standard displays............................................................................... 10
Start-up/shutdown
Starting the heating system.................................................................................. 11
Shutting down the heating system....................................................................... 11
Starting one heating circuit and DHW heating..................................................... 12
Stopping one heating circuit and DHW heating.................................................... 13
Starting DHW heating only................................................................................... 14
Stopping DHW heating......................................................................................... 15
Adjusting the room temperature
Setting a permanent room temperature............................................................... 17
■ Setting the standard room temperature............................................................ 18
■ Setting the reduced room temperature............................................................. 19
■ Switching times................................................................................................. 19
Changing the room temperature for a few days only........................................... 22
■ Setting a holiday program................................................................................. 22
Changing the room temperature for a few hours only.......................................... 23
■ Setting economy mode..................................................................................... 24
■ Setting party mode............................................................................................ 25
Selecting DHW heating
Selecting constant DHW heating.......................................................................... 27
■ Setting the DHW temperature........................................................................... 28
■ Switching times................................................................................................. 29
Selecting DHW heating for a few hours only........................................................ 33
Selecting DHW heating only once........................................................................ 34
Further adjustments
Setting delivery times for fuel supply.................................................................... 35
Heating circuit designation................................................................................... 37
Setting the time and date..................................................................................... 38
Language selection.............................................................................................. 38
Index
Index
5592 598 GB

5
Modifying the boiler heating characteristics......................................................... 39
■ Changing the slope and level............................................................................ 39
■ For technically-minded system users................................................................ 40
Adjusting the display contrast............................................................................... 41
Adjusting the key tone.......................................................................................... 42
Restoring the standard settings............................................................................ 42
Scanning options
Scanning temperatures........................................................................................ 44
■ Boiler information.............................................................................................. 44
■ System circuit information (weather-compensated), heating circuit 1 and
heating circuit 2................................................................................................. 45
■ System circuit information (with constant boiler water temperature)................ 45
■ DHW information (subject to a DHW cylinder being installed).......................... 46
■ Solar information............................................................................................... 46
■ Resetting the system data................................................................................ 47
Scanning the fault display.................................................................................... 47
What to do if...
Rooms are too cold.............................................................................................. 49
Rooms are too hot................................................................................................ 50
There is no hot water............................................................................................ 50
The DHW is too hot.............................................................................................. 51
"Fault" is shown on the display............................................................................. 51
"Service" is displayed........................................................................................... 51
"Remote control" is shown on the display............................................................ 51
"Close ash door" is shown on the display............................................................ 52
"Cleaning during operation" is shown on the display........................................... 52
"Cleaning when stopped" is shown on the display............................................... 52
"Refill store" is shown on the display.................................................................... 52
"Grate cleaning" is shown on the display............................................................. 52
"Empty ash box" is shown on the display............................................................. 52
Ordering fuel....................................................................................................... 53
Maintenance
Emptying the ash box........................................................................................... 54
Cleaning............................................................................................................... 55
Inspection and maintenance................................................................................ 55
Energy saving tips............................................................................................. 57
Keyword index.................................................................................................... 58
Index
Index (cont.)
5592 598 GB

6
The commissioning and matching of the
control unit to local conditions and the
structural characteristics of the building
must be carried out by your heating
contractor.
As the user of new combustion
equipment, you may be obliged to notify
your local flue gas inspector of the
installation [check local regulations].
Your local flue gas inspector will also
inform you [where appropriate] about
work he may be required to perform on
your combustion equipment (e.g. regular
checks, cleaning).
Your system is preset at the factory
The control unit has been preset at the
factory to "Heating and DHW", i.e. the
system delivers central heating and
DHW heating (if a DHW cylinder is
installed).
Your heating system is therefore ready
for use:
■ Between 06:00 and 22.00 h the
system delivers central heating with
standard room temperature.
■ Between 05:30 and 22:00 h the DHW
is boosted to the selected set
temperature (if a DHW cylinder is
installed). The DHW circulation pump
is switched ON (if connected to the
control unit).
■ Between 22:00 and 06:00 h the
system delivers central heating with
reduced room temperature (set to
3 ºC, frost protection).
■ Between 22:00 and 05:30 h the DHW
cylinder will not be boosted.
■ The system automatically changes
over between summer and wintertime.
Day and time are entered by your
heating contractor during
commissioning.
You may change the standard settings
preset at the factory in accordance with
personal requirements.
Note
All data will be retained in case of power
failure.
Introductory information
Commissioning
5592 598 GB

7
You can change all settings of your heating system, centrally, at the programming
unit.
You may also make such changes at any remote control units.
Remote control operating instructions
Opening the control unit
C
AB
AON indicator (green)
BFault indicator (red)
1. Lift up the top part of the control
unit.
This latches in a specific position.
2. You can change this position by
pushing C on the side.
Where to find the controls
Summary of controls and indicators
5592 598 GB

8
Functions
Idle state
Boiler
Outside temperature
DHW temp.
8°C
50°C
55°C
G A B C
E
D
F
ADisplay
BBack key
This key always takes you back to
the previous menu choice.
CCursor key (moving up and down in
the menu) and adjusting values.
DConfirmation
ESettings menu
FEmissions test key (only for
service)
GStandby (see page 12)
Display layout
At any one time, the display shows four
lines of the selected menu. Select further
menu points with keys | / ~.
If you choose a menu point where a
value can be changed, e.g. "Standard
room temperature" you change it with
keys |/~ and confirm the new value by
pressing d.
Where to find the controls
Summary of controls and indicators (cont.)
5592 598 GB

9
Summary of menu structure
Boiler System circuit
or Heating circ. 1 or Heating circ. 1 Heating circ. 2
i Information
Boiler temp. set Supply times
Standard room temp. Reduc. Room temp. DHW temp. Heating program Party mode Econ. mode Switching times Holidays prog. Heating curve Standard setting
Heating + DHW DHW only Standby mode
Settings
Central heating DHW DHW circulation pump
i Boiler i System circuit i Htg. circuit 1 HK1 i Htg. circuit 2 HK2 i DHW i Solar
Time / date Language Contrast Key tone Htg. circuit designation
*1
*1
*1
*1
*1
*1
*1 *1
*1
*1 Not for system circuit with a constant boiler water temperature.
Where to find the controls
Summary of controls and indicators (cont.)
5592 598 GB

10
Symbols in the display
These symbols are not permanently displayed, but appear subject to the system
version and the operating state.
eRisk of frost
SEmissions test function activated
QRadio clock reception (only with
radio clock module, accessory)
ÑPlease wait
HK1 Heating circ. 1
HC2 Heating circ. 2
Heating circuit selection – before any adjustment and scanning
Your building may be heated by several
independent heating circuits (e.g.
underfloor heating circuits or radiator
circuits).
You need to select these before any
adjustment or scanning. The heating
circuits can be individually designated
(see chapter "Heating circuit
designation").
Possible standard displays
Subject to the operational status of the boiler the following standard displays can
appear in the display:
Control mode
Boiler
Central heating
DHW Off
68°C
On
Heat up
Boiler
Central heating
DHW Off
25°C
On
Burnout phase
Boiler 52°C
Idle state
Boiler
Central heating
DHW Off
50°C
On
Where to find the controls
Summary of controls and indicators (cont.)
5592 598 GB
