Viessmann VITOLIGNO 300-S User manual

Operating instructions
for the system user
Viesmann
High performance wood gasification boiler
for split logs up to 50 cm long
VITOLIGNO 300-S
5817504 GB 7/2020 Please keep safe.

2
Please follow these safety instruc-
tions closely to prevent accidents
and material losses.
Safety instructions explained
Danger
This symbol warns against the risk
of injury.
!Please note
This symbol warns against the risk
of material losses and environmen-
tal pollution.
Note
Details identified by the word "Note"
contain additional information.
Target group
These operating instructions are
designed for heating system users.
This appliance can also be operated by
children of 8 years and older, as well as
by individuals with reduced physical,
sensory or mental faculties or those
lacking in experience and knowledge,
provided such individuals are being
supervised or have been instructed in
the safe use of this appliance as well as
in any risks arising from it.
!Please note
Supervise children in the proximity
of the appliance.
■Never permit children to play with
the appliance.
■Cleaning and maintenance must
not be carried out by unsuper-
vised children.
Safety instructions for working on the system
Appliance connection
■The appliance may be connected and
commissioned only by authorised con-
tractors.
■Only operate the appliance with suita-
ble fuels.
■Observe the specified electrical con-
nection requirements.
■Modifications to the existing installation
may be carried out only by authorised
contractors.
Danger
Incorrectly executed work on the
heating system can lead to life
threatening accidents.
Work on electrical equipment may
only be carried out by a qualified
electrician.
Safety instructions
For your safety
5817504

3
Work on the appliance
■All settings and work on the appliance
must be carried out as specified in
these operating instructions.
Further work on the appliance may be
carried out only by authorised contrac-
tors.
■Never change or remove attachments
or fitted accessories.
■Never open or tighten pipe connec-
tions.
Danger
Hot surfaces and fluids can lead to
burns or scalding.
■Before maintenance and cleaning
work, switch OFF the system and
let it cool down.
■Never touch hot surfaces on the
boiler, burner, flue system or pipe-
work.
■Wear suitable personal protective
equipment.
Auxiliary components, spare and
wearing parts
!Please note
Components not tested with the
heating system may damage the
system or affect its function.
Have all installation or replacement
work carried out exclusively by
heating contractors.
Safety instructions for operating the system
If you smell flue gas
Danger
Flue gas can lead to life threatening
poisoning.
■Shut down the heating system.
■Ventilate the installation site.
■Close all doors in the living space.
If there is a fire
Danger
Fire presents a risk of burns and
explosion.
■Shut down the heating system.
■Use a tested fire extinguisher,
class ABC.
What to do if water escapes from the
appliance
Danger
If water escapes from the appliance
there is a risk of electric shock.
■Switch off the heating system at
the external isolator (e.g. fuse
box, domestic distribution board).
■Notify your heating contractor.
Safety instructions
For your safety (cont.)
5817504

4
If the heating system develops a fault
Danger
Fault messages indicate faults in
the heating system. If faults are not
rectified, they can have life threat-
ening consequences.
Do not acknowledge fault mes-
sages several times in quick suc-
cession. Inform your heating con-
tractor so the cause can be ana-
lysed and the fault rectified.
Conditions for siting
Danger
Sealed vents result in a lack of
combustion air. This leads to incom-
plete combustion and the formation
of life threatening carbon monoxide.
Never cover or close existing vents.
Do not make any subsequent modi-
fications to the building characteris-
tics that could affect safe operation
(e.g. cable/pipework routing, clad-
ding or partitions).
Danger
Easily flammable liquids and mate-
rials e.g. naphtha/petrol, solvents,
cleaning agents, paints or paper,
can trigger deflagration and fire.
Never store easily flammable sub-
stances in the boiler room or in
direct proximity to the heating sys-
tem.
!Please note
Incorrect ambient conditions can
lead to heating system damage and
can put safe operation at risk.
■Ensure ambient temperatures are
above 0 °C and below 35 °C.
■Prevent air contamination by halo-
genated hydrocarbons (e.g. as
contained in paints, solvents or
cleaning fluids) and excessive
dust (e.g. through grinding/polish-
ing work).
■Avoid continuously high humidity
levels (e.g. through continuous
drying of washing).
Extractors
The operation of appliances that extract
air to the outside (cooker hoods, extrac-
tors, air conditioning units, etc.) can cre-
ate negative pressure. If the boiler is
operated at the same time, this can lead
to a reverse flow of flue gas.
Danger
The simultaneous operation of the
boiler and appliances that extract
air to the outside can result in life
threatening poisoning due to a
reverse flow of flue gas.
Take suitable steps to ensure an
adequate supply of combustion air.
If necessary, contact your heating
contractor.
Safety instructions
For your safety (cont.)
5817504

5
1. Introductory information Symbols ................................................................................................. 8
Terminology ........................................................................................... 8
Intended use .......................................................................................... 8
Commissioning ...................................................................................... 9
Your system is preset ............................................................................ 9
Energy saving tips ................................................................................. 10
Appliance description ............................................................................. 10
2. About the controls Control unit controls and display elements ............................................ 12
3. Start-up/shutdown Boiler operating phases ......................................................................... 13
■Heat up ............................................................................................... 13
■Load operation .................................................................................... 13
■Residual heat utilisation ...................................................................... 13
■Heating water buffer cylinder draw-off ................................................ 13
Heat-up preparations ............................................................................. 14
■Ideal log dimensions ........................................................................... 14
■Opening the hopper cover .................................................................. 15
■Charging with fuel ............................................................................... 15
Heat-up .................................................................................................. 16
■Heating up manually ........................................................................... 17
■Heating up with electric ignition .......................................................... 17
Recharging fuel ...................................................................................... 18
Measures to be carried out in the event of the boiler overheating ......... 19
■Boiler water temperature has reached 100 °C ................................... 19
■High limit safety cut-out (STB) ............................................................ 20
■Thermally activated safety valve ........................................................ 20
Measures for reducing tar deposits ....................................................... 21
4. Control unit operation Navigation in the control unit menu ....................................................... 22
Menu structure of the control unit .......................................................... 22
■Standard menu ................................................................................... 22
■Extended menu .................................................................................. 23
Screensaver ........................................................................................... 24
5. Setting automatic ignition Setting the enable times for ignition ....................................................... 25
■To change the enable times ................................................................ 25
6. Central heating Room temperature ................................................................................. 26
■Required settings ................................................................................ 26
■Selecting a heating circuit ................................................................... 26
■Setting the room temperature ............................................................. 26
Operating program ................................................................................. 27
■Setting the operating program for central heating .............................. 27
Time program ........................................................................................ 27
■Setting the time program for central heating ...................................... 27
■Setting time phases ............................................................................ 28
■Deleting time phases .......................................................................... 28
■Restoring the time phases to the factory settings ............................... 28
Heating curve ......................................................................................... 29
■Adjusting the heating curves .............................................................. 29
Stopping the central heating .................................................................. 30
Comfort function "Party mode" .............................................................. 31
■Selecting "Party mode" ....................................................................... 31
■Terminating "Party mode" ................................................................... 31
Energy saving function "Economy mode" .............................................. 31
■Selecting "Economy mode" ................................................................ 31
■Terminating "Economy mode" ............................................................. 32
Energy saving function "Holiday program" ............................................ 32
■Setting the "Holiday program" ............................................................ 32
Index
Index
5817504

6
■Changing the "Holiday program" ........................................................ 33
■Terminating the "Holiday program" ..................................................... 33
7. DHW heating DHW temperature .................................................................................. 34
■Required settings ................................................................................ 34
■Setting the DHW temperature ............................................................ 34
Operating program ................................................................................. 34
■Setting the operating program for DHW heating ................................ 34
Time program ........................................................................................ 34
■Setting the time program for DHW heating ......................................... 34
■Setting time phases ............................................................................ 35
■Deleting a time phase ......................................................................... 35
■Resetting time phases to the factory settings ..................................... 35
Stopping DHW heating .......................................................................... 35
8. Further adjustments Setting the display contrast .................................................................... 37
Setting the brightness of the display ...................................................... 37
Assigning names to heating circuits ...................................................... 37
Setting the time and date ....................................................................... 38
Language selection ................................................................................ 38
Setting the temperature unit (°C/°F) ...................................................... 38
Setting the boiler water temperature ...................................................... 38
Adjusting the set value for residual oxygen ........................................... 39
Setting the minimum system temperature ............................................. 39
Restoring factory settings ...................................................................... 39
9. Information call up Calling up information ............................................................................ 40
■Calling up information in the standard menu ...................................... 40
■Calling up information in the extended menu ..................................... 40
Calling up temperatures ......................................................................... 41
■Calling up temperatures in the standard menu ................................... 41
■Calling up temperatures in the extended menu .................................. 41
■Calling up the heating water temperature in the standard menu ........ 41
Calling up fault messages ...................................................................... 42
■Displaying a fault message ................................................................. 42
■Calling up a fault message ................................................................. 42
■Calling up an acknowledged fault message ....................................... 42
10. Prolonged heating system
shutdown
Prolonged heating system shutdown ..................................................... 43
Shutdown ............................................................................................... 43
11. What to do if... Rooms are too cold ................................................................................ 44
Rooms are too hot ................................................................................. 44
There is no hot water ............................................................................. 45
The DHW is too hot ............................................................................... 45
"Fault" is shown in the display ............................................................... 45
"Warning" is shown on the display ......................................................... 45
is displayed ...................................................................................... 45
12. Maintenance Heating system inspection and maintenance ........................................ 46
■Boiler .................................................................................................. 46
■DHW cylinder (if installed) .................................................................. 46
■Safety valve (DHW cylinder) ............................................................... 46
■Thermally activated safety valve ........................................................ 46
■Drinking water filter (if installed) ......................................................... 46
■Replacing fuses .................................................................................. 46
Overview of maintenance and cleaning work ........................................ 47
Information regarding maintenance and cleaning ................................. 48
Flue gas emissions test by flue gas inspector ....................................... 49
Cleaning the ash chamber ..................................................................... 49
Hopper cleaning (if required) ................................................................. 50
Index
Index
5817504

7
Cleaning the heat exchanger ................................................................. 51
Emptying the heat exchanger ash pan .................................................. 52
Cleaning the sight glass ......................................................................... 52
Cleaning the combustion chamber ........................................................ 53
13. Ordering fuel Wood fuel constituents .......................................................................... 54
■Influence of the moisture content ....................................................... 54
Storage and drying of wood ................................................................... 54
Approved logs ........................................................................................ 55
Approved wood in small pieces ............................................................. 55
Non-approved fuels ............................................................................... 55
14. Appendix Terminology ........................................................................................... 56
Information on disposal .......................................................................... 57
■Disposal of packaging ........................................................................ 57
■Final decommissioning and disposal of the heating system ............... 57
15. Keyword index ................................................................................................................ 58
Index
Index (cont.)
5817504

8
Symbol Meaning
Reference to other document containing
further information
1.
Step in a diagram:
The numbers correspond to the order in
which the steps are carried out.
Warning of material losses and environ-
mental pollution
Live electrical area
Pay particular attention.
■Component must audibly click into place.
or
■Acoustic signal
■Fit new component.
or
■In conjunction with a tool: Clean the sur-
face.
Dispose of component correctly.
Dispose of component at a suitable collec-
tion point. Do not dispose of component in
domestic waste.
Terminology
To provide you with a better understanding of the func-
tions of your Ecotronic control unit, some terminology
is explained. This information can be found in chapter
"Terminology" in the Appendix.
Intended use
The appliance is only intended to be installed and
operated in sealed unvented heating systems that
comply with EN 12828, with due attention paid to the
associated installation, service and operating instruc-
tions. It is only designed for the heating of heating
water that is of potable water quality.
Intended use presupposes that a fixed installation in
conjunction with permissible, system-specific compo-
nents has been carried out.
Commercial or industrial usage for a purpose other
than heating the building or DHW shall be deemed
inappropriate.
Any usage beyond this must be approved by the man-
ufacturer in each individual case.
Introductory information
Symbols
5817504

9
Incorrect usage or operation of the appliance (e.g. the
appliance being operated for longer periods when
open) is prohibited and will result in an exclusion of lia-
bility. Incorrect usage also occurs if the components in
the heating system are modified from their intended
use (e.g. if the flue gas and ventilation air paths are
sealed) or if other fuels than those intended for this
appliance are used.
Commissioning
Commissioning and matching up of the control unit to
local conditions and the structural characteristics of the
building must be carried out by your heating contractor.
Installation and service instructions
As the user, you may be obliged to notify your local
flue gas inspector of the installation of new combustion
equipment [check local regulations]. Your local flue gas
inspector (where applicable) will also provide you with
information on additional tasks concerning your com-
bustion equipment (e.g. regular testing, cleaning, etc.).
Your system is preset
Your boiler's control unit is set at the factory.
■The heating circuits are set to the operating program
"Heating".
■The domestic hot water heating is set to the operat-
ing program "DHW".
Your heating system is therefore ready for use:
Central heating
■From 06:00 to 22:00 h your rooms are heated to
22 °C "Set room temp" (standard heating mode).
■From 22:00 to 06:00 h, your rooms are heated to the
"Set red room temp" (room temperature for
reduced heating mode, night setback).
■Your heating contractor can make further settings for
you during commissioning.
You can individually change any setting at any time
to suit your requirements. See page 26.
DHW heating
■The DHW is heated to 60 °C "Set DHW tempera-
ture" every day from 00:00 to 24:00 h.
■Your heating contractor can make further settings for
you during commissioning.
You can individually change any setting at any time
to suit your requirements. See page 34.
Frost protection
■Your boiler, DHW cylinder and heating water buffer
cylinder are protected against frost.
Wintertime/summertime changeover
■This changeover is automatic.
Time and date
■The day and time were set by your heating contrac-
tor during commissioning.
Power failure
■All data is retained if there is a power failure.
Introductory information
Intended use (cont.)
5817504

10
Use the adjustment options offered by your boiler con-
trol unit:
■For central heating, select the operating program
that meets your current requirements:
–For brief periods of absence (a few hours, for
example when out shopping), select "Economy
mode". See page 31.
The room temperature is reduced for as long as
economy mode is activated.
–If you are going away, select the "Holiday pro-
gram". See page 32.
The operating program for central heating is auto-
matically set to "Standby mode" while the holiday
program is active.
–If you do not want to heat the rooms and you do
not require DHW for an extended period, select the
"Standby mode" operating program for the rele-
vant heating circuits and for DHW.
–See page 30 for the relevant heating circuits
–See page 35 for DHW heating
■Do not set the temperature inside the DHW cylinder
too high. See page 34.
You can further save energy by taking the following
steps:
AC
E
B
D
Fig. 1
■Correct ventilation/airing:
Open windows A wide for a short time. During this
time, close thermostatic valves B.
■Do not overheat the rooms; aim for a room tempera-
ture of 20 °C. Every degree of room temperature
reduction saves up to 6 % on your heating bills.
■Close shutters (where installed) on the windows at
dusk.
■Ensure that thermostatic valves B are properly
adjusted.
■Never cover or obstruct radiators C or thermostatic
valves B.
■Make use of the setting options of control unit D,
e.g. "standard room temperature" alternating with
"reduced room temperature".
■Set the DHW temperature of DHW cylinder E at
control unit D.
■Only enable the DHW circulation pump (via switching
times at the control unit) when DHW is being drawn
off.
■Check your hot water consumption: A shower
requires less energy than a full bath.
Appliance description
The Vitoligno 300-S is suitable for the combustion of
logs with a moisture content of 15 to 20 %, as well as
pieces of residual wood, wood briquettes and residual
wood with shavings. Approved fuels are described in
chapter "Ordering fuel". See page 54.
Note
If the moisture content is greater than 20 %, this can
lead to energy losses and contamination of the boiler
and flue system.
Introductory information
Energy saving tips
5817504

11
Overview of components
Fig. 2
AHeat exchanger cleaning cover
BLifting eye/sight glass
CHopper cover
DHopper
ECombustion chamber maintenance cover
FCombustion chamber
GFlue gas fan
HCleaning door for flue gas collector chamber and
secondary air chamber
KAsh pan
LFlue gas collector chamber
MSecondary air chamber
NIgnition
OAsh pan
PAsh chamber
QPrimary air damper
RAsh door
SLighter basket
TSecondary air damper
Note
Combustion chamber maintenance covers E are
located on the right and left-hand sides of the boiler.
Introductory information
Appliance description (cont.)
5817504

12
The programming unit
You can adjust all control unit settings centrally at the
programming unit.
Cylinder
Heating
DHW
Boiler
Accum. extraction
Select with (
Fig. 3
Takes you to the previous step in the menu or can-
cels a setting that has been started.
Cursor keys
Scrolls through the menu or adjusts values.
dConfirms your selection or saves the setting
made.
Calls up the help text relevant to the selected
menu point.
Calls up the extended menu.
For guidance on operating the control unit, see
page 22.
About the controls
Control unit controls and display elements
5817504

13
The operating phases are shown on the programming
unit display. After heat up, the boiler runs through the
following operating phases in sequence:
■Heat up
■Load operation
■Residual heat utilisation
■Buffer drawing
■Additional heat generator (if installed)
Heat up
After charging and igniting the fuel, the boiler starts up.
Initially, the boiler air dampers are adjusted.
Load operation
From a flue gas temperature above 120 °C or a resid-
ual oxygen content below 15 % (for 2 minutes), the
boiler enters control mode. For this, the residual oxy-
gen content is monitored and the air dampers are con-
tinuously regulated to achieve the set value.
The fuel in the boiler is completely combusted.
Note
Operating noise or vibrations can occur due to thermo-
acoustic effects with optimum combustion, but do not
impair the combustion process.
Residual heat utilisation
After combustion of the fuel, the boiler is still warm.
During this phase, the residual heat of the boiler water
is used to supply the heating circuits and DHW heat-
ing. When the temperature of the boiler water is no
longer sufficient for this, the required heat is drawn
from the heating water buffer cylinder. This is achieved
by using the buffer cylinder control valve and provides
up to 9 % increased heat energy yield for the boiler.
Heating water buffer cylinder draw-off
The temperature of the boiler water is too low to supply
the heating circuits and DHW heating with heat. They
are now supplied exclusively from the heating water
buffer cylinder.
Start-up/shutdown
Boiler operating phases
5817504

14
Fig. 4
1. Check the pressure of the heating system at pres-
sure gauge A:
The system pressure is too low if the indicator
points to the area below the red field. Top up with
water or notify your local heating contractor.
Minimum system pressure: 1.0 bar (0.1 MPa)
2. Check that the vent in the installation room is unre-
stricted.
Note
The combustion air is drawn from the installation
room during operation.
3. Check that the heating system or the heating water
buffer cylinder can draw off heat. Where neces-
sary, open the thermostatic valves.
4. Check that the heating system has been vented.
5. Ensure that all shut-off gate valves to the heating
flow and return are open.
6. Check that all doors and covers on the boiler are
closed.
7. Ensure that all ball valves for the return tempera-
ture raising facility are open.
8. Ensure that power is supplied to the boiler.
Ideal log dimensions
≤ 5 cm
≤ 10 cm
10-12 cm
≤ 20 cm
≤ 7 cm
8-10 cm
Fig. 5
■Split log length 45 to 50 cm.
■Shorter logs must be layered without air gaps in the
boiler hopper.
■25 cm long logs can be inserted crosswise next to
one another.
Note
Differing log dimensions can only be layered with
gaps. Gaps reduce the boiler output and increase the
risk of ineffective gasification.
Start-up/shutdown
Heat-up preparations
5817504

15
Opening the hopper cover
Danger
Deflagration and poisonous flue gases can
cause serious injuries.
Never open the hopper cover in any operating
phase until the flue gas temperature has fallen
below 120 °C.
Danger
Poking around in the firebed leads to oxygena-
tion, which can produce a flash.
Never poke around in the firebed.
A
B
Fig. 6
1. Initially open the hopper cover to lock A.
2. Turn mushroom handle B to unlock the hopper
cover and fully open the cover.
Charging with fuel
Important information
■Charge with fuel according to the heat demand.
■Fill the hopper completely if the outside temperature
is low and the heating water buffer cylinder is cold. In
spring and autumn, only recharge the boiler with as
much fuel as is required for the actual heat demand
and buffer volume.
■Before starting up the boiler, ensure that the amount
of heat generated can be drawn off and stored by the
heating system. If the amount of heat produced can-
not be drawn, the boiler will overheat and the high
limit safety cut-out will respond. The boiler is then
cooled with cold tap water via the safety heat
exchanger and heating energy is lost.
Danger
The wrong kind of fuel facilitates the discharge
of low temperature carbonisation gases into the
hopper during heat-up and can result in defla-
gration.
Never place pieces of residual wood, shavings,
sawdust, woodchips, wood briquettes or residual
wood with shavings directly onto the grate.
!Please note
If the boiler is charged incorrectly with pieces of
residual wood, wood briquettes and residual
wood with shavings it may be damaged.
1. Fill the hopper with logs up to at least one
third of its capacity.
This is achieved when the fireclay bricks in
the combustion chamber are no longer visible
and the grate is fully covered with logs.
2. Do not charge with other fuels before this is
achieved.
Start-up/shutdown
Heat-up preparations (cont.)
5817504

16
E
D
C
B
A
Fig. 7
ACharcoal remains
BCrumpled paper, cardboard
CSmall, easily combustible kindling
DLogs
EHopper cover
1. Remove fine ash from the hopper. Use a scraper to
push the fine ash into the ash pan.
2. !Please note
If the logs are too big, they will impair the
function of the boiler and may result in
poorer combustion.
Take the depth of the hopper and size of the
hopper cover into account when selecting
logs. Never exceed the maximum log length.
See page 55.
Place crumpled paper, cardboard B and small,
easily combustible kindling C on charcoal remains
A.
Note
■The layer of crumpled paper must cover the
entire grate.
■The overall layer should be roughly 25 cm thick
and should also cover the entire grate.
3. Place logs D in the hopper so they are horizontal
and densely packed across the entire width of the
boiler.
4. Remove any dirt that may be present on the seat-
ing faces of hopper cover E.
5. Close hopper cover E.
Note
Ensure that the safety latch engages and that the
hopper cover is securely closed.
Heat-up
Note
Operating noise or vibrations can occur due to thermo-
acoustic effects with optimum combustion, but do not
impair the combustion process.
Start-up/shutdown
Heat-up preparations (cont.)
5817504

17
Heating up manually
3.
1.
Fig. 8
1. Open the ash door.
2. Danger
Risk of severe injuries due to highly-flamma-
ble materials when igniting the fuel.
Never use highly-flammable substances
such as petrol, oil, alcohol or solvents to
ignite the fuel.
Ignite the paper across the entire width of the hop-
per.
Note
This allows the flames to spread quickly across the
entire grate area. Perfect combustion is ensured if
the combustion chamber heats up quickly.
3. Switch the boiler on at the control unit. Press
"START/STOP".
4. Use |/~ to select "Manual".
5. Press d to confirm.
6. Do not completely close the ash door; leave it
approx. 10 cm ajar.
7. Supervise the heating system during the heat-up
phase until a flue gas temperature of 80 °C is dis-
played.
Note
To display the flue gas temperature, call up the
"Boiler" menu point in the standard menu.
8. Close the ash door as soon as the flue gas temper-
ature has reached 80 °C.
Note
Ensure that all covers and doors are tightly shut
during operation. This safeguards optimum com-
bustion.
Heating up with electric ignition
Before beginning heat-up: Check that all conditions are
met. See chapter "Heat-up preparations" from
page 14.
Start-up/shutdown
Heat-up (cont.)
5817504

18
3.
1.
4.
2.
Fig. 9
1. Open the ash door.
2. Fill the lighter basket with primary ignition material
(paper).
3. Close the ash door.
4. Press "START/STOP" on the programming unit.
5. Use |/~ to select "Immediately", "Automatic"
or "Holiday program".
6. Press d to confirm.
Note
If you make no selection after pressing "START",
"Automatic" is set on the display.
The boiler is ignited by the ignition system in accord-
ance with the setting on the programming unit:
■Immediately
■When there is a heat demand
■Within the selected enable times. See "Setting the
enable times" on page 25.
■On the selected return date in the holiday program.
See "Setting the holiday program" on page 32.
Note
Keep all doors closed securely during burnout to
ensure optimum burnout.
The electric ignition will not start if the door is open.
Recharging fuel
Note
■When charging with pieces of residual wood, wood
briquettes and residual wood with shavings, logs
should be regularly added. This ensures better com-
bustion.
A full hopper charge will provide a combustion period
of 3 - 5 hours, depending on the amount of heat
being drawn off and the quality of the fuel.
■Check the heating water buffer cylinder temperature:
Do not recharge the boiler with fuel until the heating
water buffer cylinder has sufficient capacity availa-
ble.
Flue gas temperature > 120 °C < 120 °C to > 60 °C < 60 °C
Steps to take Do not recharge with fuel. Recharge with fuel. Repeat the heat-up proc-
ess. See page 15.
Danger
Flue gas escaping via the hopper cover poses a
risk to health and the environment.
Wait until the temperature of the flue gas has
dropped below 120 °C before opening the hop-
per cover briefly to recharge with fuel.
Start-up/shutdown
Heat-up (cont.)
5817504

19
A
B
Fig. 10
1. Press the "START/STOP" button.
The flue gas fan starts up and the primary air
damper closes.
2. Initially open the hopper cover to lock A.
3. Wait a short while to allow the low temperature car-
bonisation gas to be drawn out of the hopper.
4. Turn mushroom handle B clockwise to unlock the
hopper cover. Fully open the cover.
5. Check the fuel level and the height of the glowing
embers.
If there are only glowing embers present, continue.
6. Danger
Recharging the fuel too slowly, recharging
large amounts of logs or recharging with
pieces of residual wood encourages the for-
mation of low temperature carbonisation
gases in the hopper and can result in defla-
gration.
■Quickly recharge with wood according to
the current heat demand.
■Never place pieces of residual wood,
shavings, sawdust, woodchips, wood bri-
quettes or residual wood with shavings
directly onto the glowing embers.
!Please note
If the logs are too big, they will impair the
function of the boiler and may damage it.
Take the depth of the hopper and size of the
hopper cover into account when selecting
logs. Never exceed the maximum log length.
See page 55.
7. Close the hopper cover.
8. Open the ash door if necessary.
This supports the combustion process. We recom-
mend this procedure only with flue gas tempera-
tures up to 100 °C.
Measures to be carried out in the event of the boiler overheating
Your boiler is protected from overheating by safety
equipment.
Components:
■High limit safety cut-out
■Thermally activated safety valve
Note
Never make adjustments at the high limit safety cut-out
or thermally activated safety valve, which would result
in an exclusion of liability.
Replace faulty components only with genuine spare
parts from Viessmann.
Note
Notify your heating contractor if the boiler overheats
again after a short time or overheats regularly.
Boiler water temperature has reached 100 °C
Start-up/shutdown
Recharging fuel (cont.)
5817504

20
High limit safety cut-out (STB)
The high limit safety cut-out is part of the boiler. It is
located behind the programming unit under the front
top panel.
Note
If the high limit safety cut-out responds, it must be
manually reset.
When the function responds:
The high limit safety cut-out responds if the boiler
water temperature exceeds 95 °C.
The fan in the boiler is stopped down and the air
dampers are closed. This reduces the boiler output
and lowers the flow temperature. Boiler overheating is
prevented.
Resetting the function:
Note
The high limit safety cut-out can only be reset
(unlocked) once the boiler water temperature has
reached approx. 70 °C.
!Please note
If it is not reset (unlocked), it inhibits the safety
equipment function and can result in system
damage.
Always carry out the following steps.
A
1.
Fig. 11
1. Slide the cover on the programming unit to the
right.
2. Press green button A of the high limit safety cut-
out. A quiet "click" will be audible. The high limit
safety cut-out has been reset.
3. Close the programming unit cover.
4. Acknowledge the excess temperature on the pro-
gramming unit of the control unit with d.
Note
If the high limit safety cut-out responds several times
within a short period, check the cause. Check whether
the system can absorb any more heat. Notify your
heating contractor.
Thermally activated safety valve
The thermally activated safety valve is installed by
your heating contractor. It is connected to the safety
heat exchanger integrated in the boiler. The safety
heat exchanger is at the back of the boiler.
Note
Observe the instructions in the manufacturer's docu-
mentation of the thermally activated safety valve.
The boiler must be equipped with a thermally activated
safety valve.
Start-up/shutdown
Measures to be carried out in the event of the… (cont.)
