CD4230
42" SLIM BEZEL
COMMERCIAL LCD DISPLAY
ViewSonic’s 42" CD4230 Commercial Display features a super-
slim, 14mm bezel in a robust, all-metal chasis that is ideally
suited for installations in public information applications. The
high brightness and contrast ratio make this display ideal for
messaging in brightly lit rooms or in outdoor installations. The fast
8ms response time delivers blur free scrolling text or video. HDMI
inputs and VGA, DVI and RS-232 inputs/outputs allow you to
daisy chain multiple displays into your network and still control
each display individually.
Sets a New Slim Standard for
Large Format Digital Signage
1080i 8ms panel for vibrant
video and crisp images
High brightness and contrast ratio
RS-232 daisy-chain capable
VGA and DVI inputs/outputs for
flexible connectivity and control
Remote and panel control
lock out
Installation options include
stand or VESA®wall mount and
detachable 2x6-watt speakers
>
>
>
>
>
>
Shown with optional stand.

Complete Your Digital Signage Solution
Add a network media player and digital signage software.
Media Players
• NMP-550 (RISC-based)
• NMP-600 (X-86-based)
• NMP-610 (X-86-based)
Software
• VMS 2.0
• FriendlyWay Composer Software
• Best Wave DisplayIt! Software
• Z Stream Hosted Services
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
Specications subject to change without notice. Selection, offers and programs may vary by country; see your
ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2009 ViewSonic Corporation. All rights reserved. [14278-00B-01/09] CD4230-1
ViewSonic Corporation’s QMS & EMS have been
registered to ISO 9001 & ISO 14001, respectively,
by the British Standards Institution.
CD4230 42" SLIM BEZEL COMMERCIAL LCD DISPLAY
LCD Type 42" color TFT active matrix, wide LCD
Display Area 36.6" horizontal x 20.6" vertical; 42" diagonal
Optimum Resolution 1366x768
Contrast Ratio 2500:1 (typ)
Viewing Angles 178º horizontal, 178º vertical
Response Time 8ms
Light Source Long life, 50,000 hrs. (typ)
Brightness 500 cd/m2 (typ)
Aspect Ratio 16:9
Panel Surface Anti-glare, hard coating (3H)
INPUT Video Input HDMI, DVI, component, VGA
Video Output VGA, component, DVI
Control Input/Output RS-232
AUDIO OUTPUT Speakers 2x6-watt
INPUT SIGNAL TV/Video Comp. 480i, 480p, 720p, 1080i, 1080p
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital HDMI, DVI
Power 3-pin plug
POWER Voltage AC 100–240V (universal), 50–60Hz
Consumption 246W (typ)
CONTROLS Panel Power, Exit, +, –, Menu/Enter
Picture Picture mode, contrast, brightness, color temperature,
temperature adjust, sharpness
VGA Setting Auto adjustment, clock, phase, sharpness,
H. position, V. position
OSD Setting Languages, OSD H. position, OSD V. position, OSD timer
Input VGA, DVI, HDMI, YPbPr
Audio Volume, mute
Special Aspect ratio, over scan, power save, image retention,
auto adjustment, monitor ID, reset
Diagnostic Thermal, back light, ambient, 5V detect, 12 detect
OPERATING Temperature (landscape) 32–104ºF (0–40ºC)
CONDITIONS Temperature (portrait) 41–95ºF (5–35ºC)
Humidity 20–80% (non-condensing)
DIMENSIONS Physical with stand (optional) 37.9" x 23.6" x 6.2" (961mm x 598mm x 152mm)
(W x H x D) Physical without stand 37.9" x 21.8" x 4.3" (961mm x 554mm x 104mm)
WEIGHT Net with stand (optional) 56.7 lb. (25.7 kg)
Net without stand 51.8 lb. (23.5 kg)
Gross without stand 61.7 lb. (28.0 kg)
VESA®MOUNT 400mm x 200mm
REGULATIONS UL/FCC-B
RECYCLE/DISPOSAL The lamp in this product contains mercury. Please
dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS LCD display, power cable, VGA cable, remote control
with batteries, Quick Start Guide
WARRANTY Three-year limited warranty on parts, labor and backlight
