Dynamic Advertising Made Easy
22" (21.5" viewable)
All-in-One Digital ePoster
EP2203r
Impactful in-store digital signage is easy with
ViewSonic's new EP2203r—an all-in-one 22" digital
ePoster. The EP2203r can be easily configured for
vivid retail messaging via its internal media player, or
via connection to your favorite external media player.
In addition, multimedia JPEG, music, or video content
can be uploaded to the EP2203r using a USB thumb
drive, or over a network using an external media player.
With a 100x100 mounting pattern on the back panel, the
exible EP2203r can be mounted in portrait or landscape
orientation, and features a full edge-to-edge tempered
glass faceplate. This display is ideal in high-visibility
locations such as retail settings, banks and universities.
22" (21.5" viewable)
Full HD 1920x1080 Display Resolution
The EP2203r has everything you expect from a ViewSonic display—
delivering stunning clarity and color performance with full HD resolution.
LED Backlight with 3000:1 Contrast Ratio
LED backlighting enhances display performance and delivers an
outstanding color range, while a brilliant 3000:1 contrast ratio provides for
remarkably detailed images.
Internal Media Player Supports Multimedia Content
With all-in-one functionality, the EP2203r has a built-in media player—
making the sharing of vivid retail messaging a breeze.
Simple Content Loading
Multimedia JPEG, music, or video content can be quickly and easily
uploaded using a USB thumb drive, or over a network using an external
media player, for further versatility.
Connect to an External Media Player or PC
Easily add a third party media player or PC with the integrated HDMI and
VGA inputs.
Integrated Speakers
A pair of 2-watt integrated speakers is ideal for multimedia applications,
videos, and audio-enabled display messaging.
Portrait or Landscape Mountable
The EP2203r ePoster is VESA®wall mountable (100mm x 100mm) in either
portrait or landscape orientation for display exibility in a variety of settings.

Applications
• Retail advertising in high visibility locations
• Informational signs for hotel lobbies
and public locations
• Advertising boards for banks and
university campuses
Specications
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
Specications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete details.Corporate names, trademarks stated herein are
the property of their respective companies. Copyright © 2013 ViewSonic Corporation. All rights reserved. [16555-00B-02/13]
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
LCD PANEL Type 22" (21.5" viewable) color TFT active matrix LCD
w/ WLED backlight
Display Area 18.8" horizontal x 10.6" vertical; 21.5" diagonal
Optimum Resolution 1920x1080
Contrast Ratio 3000:1 (typ)
Viewing Angles 170º horizontal, 160º vertical
Response Time 8ms
Backlight White-light LED
Backlight Life 50,000 hrs. (typ)
Brightness 250 cd/m2(typ)
Aspect Ratio 16:9
Panel Surface Anti-glare, hard coating (3H)
INPUT SIGNAL TV/Video Comp. 480i, 480p, 720p, 1080i, 1080p
CONNECTOR Analog VGA 15-pin mini D-sub (x1)
Digital HDMI (x1)
Audio In 3.5mm mini jack (x1)
USB Type B (x2)
Power 3-pin plug
AUDIO OUTPUT Speakers Internal 2-watt (x2)
POWER Voltage AC 100–240V (universal), 50–60Hz
Consumption 62W (typ)
CONTROLS (OSD) System Settings Language, Clock Display, Scrolling Text, USB Port, Return
to Factory Settings
Playback Control Storage Priority, Playback Mode, Play Time
Date & Time Year, Month, Day, Hour, Minute, Update Date & Time
On / Off Timer Timer Mode, Daily, Sunday~Saturday
Local ID ID, Save
Screen Mode Vertical, Horizontal, Save and Reboot
File Management Information, Format
Source HDMI, VGA, Internal Storage
Image Brightness, Contrast, Saturation, Color Temp.
PC Setting Auto Adjust, H Position, V Position, Phase, Clock
OPERATING Temperature (landscape) 32–122ºF (0–50ºC)
CONDITIONS Humidity 20–90% (non-condensing)
DIMENSIONS Physical 23.1 x 14.9 x 1.3 in. / 586.7 x 378.5 x 33 mm
(W x H x D) Packaging 26.0 x 18.7 x 4.7 in. / 660.4 x 475 x 119.4 mm
WEIGHT Net 17.6 lb. / 8.0 kg
Gross 22.1 lb. / 10.0 kg
WALL MOUNT VESA®100mm x 100mm
REGULATIONS FCC, UL, cUL, RoHS Green BOM List & RoHS DoC
RECYCLE/DISPOSAL Please dispose of in accordance with local, state or
federal laws.
WARRANTY One-year limited warranty
EP2203r
EP2203r ePoster, power cable, remote control with batteries, Quick Start Guide,
ViewSonic Wizard CD (with user guide)
What's in the box?
HDMI VGA Audio
In
USB x2Power
VESA®compatible
100 x 100 mm wall mount
Slim design
only 1.3" thick!
ePoster Manager Express
Content scheduling and management software (MS Windows compatible)
is included for increased control of your corporate branding and
targeted messaging.
