ViewSonic GS815 User manual

21" (20.0 viewable) Short Depth Monitor
ViewSonic does it again with their first 21" (20.0" viewable) Short Depth CRT in
their outstanding line of quality products. The space savings ViewSonic GS815
has arrived. With a footprint only slightly larger than a conventional 17" (various
viewable) CRT, this great display offers a SuperClear screen for vivid color and
maximum clarity, a super fine 0.21mm horizontal dot pitch along with a 300Mhz
video input bandwidth for crisp images and sharp definition. The GS815 touts a
new base design for an optional USB and is capable of achieving a 1,920 x 1,440
resolution refreshing at an easy viewing flicker-free 80Hz. For the demanding
professional who requires more desk space and a large screen and those who
operate applications such as graphic design, CAD/CAM, gaming or Internet,
nothing is better overall than the GS815.
• 0.21mm Horizontal dot pitch
0.25mm Diagonal dot pitch
This super fine dot pitch produces clear, crisp
images with great picture definition, even at the
highest resolutions.
• 1,920 x 1,440 maximum
resolution
Displays a maximum resolution of 1920 x 1440 at
80Hz flicker-free refresh rate for easy viewing.
1920 x 1440 @ 80Hz
1800 x 1440 @ 80Hz
1600 x 1200 @ 95Hz
1280 x 1024 @ 110Hz
• Short Depth design
Space saving short depth design minimizes monitor
footprint and maximizes desktop space, comfort
and productivity.
• SuperClear®screen
SuperClear screen technology incorporates an
enhanced phosphor treatment and optimized glass
to deliver “power color” images that are up to 30%
brighter than conventional CRT monitors with up
to 10% improved color fidelity. This provides vivid,
realistic color and optimized clarity.*
• 300MHz video input bandwidth
Delivers sharp and realistic images at high
resolutions
• USB compatible base
New base design allows easy integration of an
optional ViewSonic USB (Universal Serial Bus) hub**
for convenient USB peripheral connections.
GS815 Monitor
ViewSonic
®
Graphics Series

21" (20" viewable) SHORT DEPTH GRAPHICS COLOR MONITOR WITH SUPERCLEAR®
CRT Type 21" (20.0" diagonal viewable area) 100˚ deflection
Dot Pitch 0.21mm Horizontal, 0.14mm Vertical, 0.25mm Diagonal
Phosphor RGB medium short persistence, P22
Glass Surface Tint (TM=43%), ARAG®screen treatment
INPUT SIGNAL Video RGB Analog (0.71Vp-p, 75 ohms)
Sync H/V separate (TTL) composite, sync on green
Frequency Fh:30-121kHz, Fv:50-180Hz
COMPATIBILITY PC PC compatible (from VGA up to 1,920 x 1440)
Mac®** Power Mac™compatible up to 1600 x 1200
Other Most workstations†
CONNECTOR Signal 15-pin mini D-sub (detached cable)
Power 3-pin plug (IEC320)
POWER Voltage AC 90-264VAC (auto switch) 50-60Hz
Consumption 160W (typ)
USER CONTROLS Basic Power, 1, up, down, key-2
OnView®Contrast, brightness, H/V-position, H/V-size, pincushion,
trapezoid, H/V convergence, pin-balance, parallelogram,
zoom, vertical linearity center, vertical linearity symmetry,
top hooking, bottom hooking, purity, degauss, tilt, moire,
ViewMatch®color, OSD control, ViewMeter®
, language,
data recall
VIDEO INPUT Bandwidth 300MHz (typ)
MISCONVERGENCE 0.25mm (max at center)
0.35mm (max at corner)
DISPLAY AREA Factory Setting 380mm (H) x 285mm (V)
Maximum Scan 400mm (H) x 300mm (V) (Dependent upon signal timing used)
OPERATING Temperature 32˚F to 104˚F (0˚C to 40˚C)
CONDITION Humidity 5 – 95% (no-condensation)
DIMENSIONS Physical 508mm (W) x 500mm (H) x 452mm (D)
20.0" (W) x 19.7" (H) x 17.8" (D)
WEIGHT Net 26.5KG (58.3lb)
OTHER DDC1, DDC2B; GTF
REGULATIONS UL, CSA, FCC-B, DHHS, DOC-B, MPRII, TCO '99, Energy
2000, NEMKO, SEMKO, DEMKO, FEMKO, B-Mark, PCT,
SASO, CCIB, TUV-GS, TUV-Ergo, CE, S-Mark, C-TICK, CB,
NOM, VCCI, ISO9241-3, IRAM, CCEE, EMC, KMI-B
POWER MANAGEMENT Meets Energy Star®
, VESA®DPMS
™
and TCO ’99 and
Energy 2000 standards
WARRANTY Three year limited warranty on CRT, parts and labor.
48 hour Express Exchange®service available.
• ARAG screen treatment
This specially formulated anti-reflection, anti-glare
screen treatment uses a multi layer process to refract
unwanted light away from the user while maintaining
the highest quality of the displayed image.
• OnView controls including ViewMatch®
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows the
user to adjust color temperature and individual
color intensity for screen-to-print matching.
• TCO ’99 and Energy 2000 certified
This monitor complies with the world’s strictest
standards for low radiation, safety ergonomics,
recycling and power management while saving
costs through automatic power saving modes.
•
• PC and Mac compatible
• Three year limited warranty
