PS775 Monitor
ViewSonic
®
on top!
www.ViewSonic.com
(PC Sold Separately)
Professional Series
• 0.22mm Horizontal Dot Pitch
0.13mm Vertical Dot Pitch
This super fine dot pitch produces clear,
crisp images with great picture definition,
even at the highest resolutions.
• 1,600 x 1,280 maximum resolution
Displays a maximum resolution of 1,600
x 1,280; 1,280 x 1,024 at 88Hz flicker-free
refresh rate for easy viewing.
1,600 x 1,200 @ 76Hz
1,280 x 1,024 @ 88Hz
1,024 x 768 @ 116Hz
800 x 600 @ 146Hz
• SuperClear®screen
SuperClear screen technology incorporates
an enhanced phosphor treatment and
optimized glass to deliver “power color”
images that are up to 30% brighter than
conventional CRT monitors with up to
10% improved color fidelity. This provides
vivid, realistic color and optimized clarity† .
• Short Depth design
Space saving, short depth design minimizes
monitor footprint and maximizes desktop
space, comfort and productivity.
17" (16.0" viewable) Monitor
Users searching for a high performance monitor in a compact environment should
look no further than the 17" (16.0" viewable) ViewSonic PS775. Its 0.26mm dot
pitch and maximum resolution of 1,600 x 1,280 produce super high definition
images, while its SuperClear screen technology delivers high contrast and strong
colors up to 30% brighter than conventional CRT monitors. And all of it is found
in a footprint comparable to most 14" (various viewable) monitors. For a
professional space-saving display, the PS775 is the perfect choice for imaging and
CAD/CAM professionals or anyone looking for high performance suited to a
compact environment.

*Free universal Mac cable adapter available. †Compared to conventional CRT monitors results may vary. Copyright © 1999, ViewSonic Corporation. All rights reserved. Corporate names and trademarks stated herein are the property
of their respective companies. Microsoft, Windows, Windows NT and the Windows logo are the registered trademarks of Microsoft corporation in the United States and other countries. Specifications subject to change without notice.
The EPA only promotes energy efficiency and does not endorse any particular company or product.
VSPS775-2-9/99-20k-rev 2
381 Brea Canyon Road, Walnut, CA 91789
Phone [phone] • [phone]
Fax [phone] • Internet: www.ViewSonic.com
ViewSonic
®
www.ViewSonic.com
Professional Series
PS775 Monitor
17" (16.0" VIEWABLE) SHORT DEPTH COLOR MONITOR WITH SUPERCLEAR
®
SCREEN
CRT Type 17" (16.0" diagonal viewable area), 100˚deflection
0.22mm Horizontal, 0.13mm Vertical Dot Pitch
Phosphor RGB medium-short persistence, SuperClear
Glass Surface Tint (TM=46%) ARAG®screen treatment
INPUT SIGNAL Video RGB analog (0.7V/1.0Vp-p, 75 ohms)
Sync H/V separate (TTL) composite, sync-on-green
Frequency Fh:30-95kHz, Fv:50-180Hz
COMPATIBILITY PC IBM®XT, AT, 386, 486, Pentium®
, PS/2 and compatibles
(VGA up to 1,600 x 1,280 non-interlaced)
Mac®*Power Mac™(up to 1152 x 870)
CONNECTOR Signal 15-pin mini D-sub (attached cable)
Power 3-pin plug (IEC320)
POWER Voltage 90-132/198-264VAC 50/60 (+/-3)Hz auto switch
Consumption 120W (typ)
USER CONTROLS Basic Power on/off, Key-1, up, down, Key-2
OnView®Contrast, brightness, H/V-position, H/V-size, pincushion,
pin-balance, top hook, top hook balance, bottom hook,
bottom hook balance, degauss, trapezoid, ViewMatch®color,
parallelogram, tilt, ViewMeter®
, language, OSD position,
moiré reduction, recall
VIDEO INPUT Bandwidth 150MHz (typ)
MISCONVERGENCE 0.3mm (max) at center
0.4mm (max) at corner
DISPLAY AREA
Factory Setting 300mm(H) x 225mm(V) (Dependent upon
Maximum Scan 326mm(H) x 243mm(V) signal timing used)
OPERATING Temperature 32˚F to 104˚F (0˚C to 40˚C)
CONDITION Humidity 5% to 95% (no condensation)
DIMENSIONS Physical 420mm (W) x 436mm (H) x 385mm (D)
(16.5" x 17.2" x 15.2")
WEIGHT Net 16.0Kg (35.2 lbs.)
OTHER DDC1 & DDC2B, GTF
REGULATIONS UL, CSA, DHHS, FCC, DOC-B, VCCI, TUV/GS, TCO ’99, CE,
MPR-II, C-TICK, S-Mark, ISO9241-3, NORDIC, Energy 2000
POWER MANAGEMENT Meets Energy Star, VESA®DPMS™, TCO ’99 and Energy 2000
standards
WARRANTY Three year limited warranty on CRT, parts and labor
48 hour Express Exchange®service option available
• OnView controls including ViewMatch
All screen adjustments are made via an on-screen
menu using simple controls. ViewMatch allows
the user to adjust color temperature and individual
color intensity for screen-to-print matching.
• ARAG screen treatment
This specially formulated anti-reflection, anti-glare
screen treatment uses a multi-layer process to
refract unwanted light away from the user while
maintaining the highest quality of the displayed
image.
• TCO ’99 and Energy 2000 certified
This monitor complies with the world’s strictest
standards of low radiation, safety, ergonomics,
recycling and power management while saving
costs through an automatic power savings mode.
•
Fully supports the Microsoft
®
Windows
®
auto
installation standard for easy, trouble-free
configuration and set-up.
• PC and Mac compatible
• Three year limited warranty
