ViewSonic VG2236wm-LED User manual

The VG2236wm-LED is one of two new members of ViewSonic’s
new VG36-LED family. Its 22" (21.5" viewable) display with a native
1920x1080 resolution is big enough to replace dual-monitor setups.
What makes it even more appealing is the LED backlight for up
to 50% energy savings. Monitor is also fully ergonomic with 90º
pivot, height adjust, swivel and tilt. The slim bezel design coupled
with hidden stereo speakers make VG2236wm-LED a space saver.
You can put it on your desk or mount on your wall or on any
VESA compliant monitor stand. With Viewsonic’s strongest pixel
performance guarantee and 3-year limited warranty, you will have
peace of mind in your investment.
Planet-friendly. Picture perfect.
AMAZING GAMES AND HD CONTENT
Up to 50% energy saving with LED backlight>
Without compromising your viewing quality and has
eco-friendly mercury free LED backlight.
Multi-functional base design (360º swivel and height adjust)>
VESA compliant wall-mount interface and detachable
base for ergonomic flexibility with pivot, 5.3 height, tilt
and 360° swivel adjustments.
OptiSync>®digital/analog inputs expand your connectivity
Multi-mode input technology supports both digital (DVI)
and analog (VGA) signals for ultimate compatibility and
configuration flexibility.
Multimedia enhanced>
Stereo speakers provide clear and rich sound.
MEGA dynamic contrast ratio at 20,000,000:1>
For true-to-life picture depth and clarity in any room.
Widescreen aspect ratio with 1920x1080 resolution>
The widescreen aspect ratio allows you to view Full HD
content in its native format with no stretching or distortion.
Wall mountable design>
100mm x 100mm VESA compliant
VG2236wm-LED
22" (21.5" VIEWABLE)
WIDESCREEN LED MONITOR
WITH HEIGHT ADJUST, SPEAKERS
AND ENERGY STAR®5.0

VG2236wm-LED
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection,
offers and programs may vary by country; see your ViewSonic representative for complete details. Windows is a trademark of
Microsoft Corporation registered in the U.S. and other countries. Corporate names, trademarks stated herein are the property of their
respective companies. Copyright © 2010 ViewSonic Corporation. All rights reserved. [15137-01B-10/10] VG2236wm-LED
LCD Type 22" (21.5" viewable) Wide Color TFT Active Matrix LCD
Display Area 18.8" horizontal x 10.6" vertical; 21.5" diagonal
Optimum Resolution 1920x1080
Contrast Ratio 1000:1 (typ); 20,000,000:1 (dynamic)
Viewing Angles 170º horizontal, 160º vertical @ contrast ratio > 10:1
Response Time 5ms (typ)
Light Source Long life, 30,000 hrs. (typ)
Brightness 250 cd/m2(typ)
Panel Surface Anti-glare, hard-coating (3H)
VIDEO INPUT Analog RGB analog (75 ohms, 0.7/1.0 Vp-p)
Digital DVI-D (TMDS, 100 ohms)
Frequency Fh: 24~83kHz, Fv: 50~75Hz
Sync H/V separated (TTL), composite sync-on-green
COMPATIBILITY PC VGA up to 1920x1080 non-interlaced
Mac®* Power Mac™up to 1920x1080
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital DVI-D
Audio 3.5 mm audio in
Power 3-pin plug (CEE22)
AUDIO Speakers 2x2W
POWER Voltage AC 100–240V (universal), 50/60Hz
Consumption 22W (typ)
CONTROLS Basic Power, 1, down, up, 2
OSD Auto Image Adjust, Contrast/Brightness, Input Select (D-SUB,
DVI), Audio adjust (Volume mute), Color Adjust (sRGB, 9300K,
7500K, 6500K, 5000K, User Color [R, G, B]), Information,
Manual Image Adjust (H/V Position, Horizontal Size, Fine
Tune, Sharpness, Dynamic Contrast, Response Time, Aspect
Ratio, Eco-mode), Setup Menu (Language, Resolution Notice,
OSD Position, OSD Timeout, OSD Background, Auto Power
Off), Memory Recall
ERGONOMICS Tilt Down 5º, Up 20º
Swivel 360º
Height Adjust 0-135mm
Pivot 0-90º
OPERATING Temperature 32–104º F (0–40º C)
CONDITIONS Humidity 20–90% (non-condensing)
DIMENSIONS Physical with stand 20.52" x 16.48" x 9.42" (521.21mm x 418.63mm x 239.2mm)
(W x H x D) Physical without stand 20.52" x 12.66" x 2.02" (521.21mm x 321.71mm x 51.5mm)
Packaging 23.46" x 19.01" x 6.81" (596mm x 483mm x 173mm)
WEIGHT Net with stand 9.7 lb. (4.4 kg)
Net without stand 7.5 lb. (3.4 kg)
Gross 15.4 lb. (7.0 kg)
WALL MOUNT VESA®100mm x 100mm
REGULATIONS UL, CUL, FCC-B (ICES), CB, CE, CES-003B, ISO13406-2, TUV/GS,
ERGO, TUV-S, NOM, GOST-R, HYGIENIC (20 copies), CCC, BSMI,
PSB, C-TICK, MIC(KCC), SASO, WEEE, RoHS, SASO, Ukraine,
TCO, EPEAT Gold
POWER MANAGEMENT ENERGY STAR®standards
PACKAGE CONTENTS LCD display, power cable, VGA cable, DVI cable, audio cable,
Quick Start Guide ViewSonic Wizard CD (User Guide and drivers)
WARRANTY Three-year limited warranty on parts, labor and backlight.
ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by TUV NORD.
22" (21.5" VIEWABLE) WIDESCREEN LED MONITOR WITH
HEIGHT ADJUST, SPEAKERS AND ENERGY STAR®5.0
