ViewSonic VG2437mc-LED User manual

“All-In-One” Video Conferencing Solution
Whether hosting business meetings, participating in virtual lectures
and seminars or just keeping in touch with family and friends, the
VG2437mc-LED includes everything needed for video conferencing.
With an integrated 2MP webcam, microphone and a pair of 2-watt
speakers built-in, customers can count on outstanding video and audio
performance. Support for external
headphones and a MIC offers the
option to enjoy added privacy.
Compatible with leading video
conferencing applications, the
VG2437mc-LED is a complete
one-stop solution for any web
conferencing needs.
VG2437mc-LED
Full HD Resolution with DisplayPort™Connectivity
24" (23.6" Viewable)
Ergonomic Webcam LED Monitor
The ViewSonic®VG2437mc-LED Full HD ergonomic
display is the ideal video conferencing solution with
integrated 2 megapixel webcam, MIC and speakers.
The 1080p LED panel provides an incredibly sharp
picture and stunning video playback in full HD with
a 20,000,000:1 MEGA Dynamic Contrast Ratio.
Easy and flexible connectivity with DisplayPort, DVI,
VGA, and 2-port USB hub for transferring files and
attaching peripherals. The VG2437mc-LED is perfect
for any workplace or classroom environment, with
a highly ergonomic design engineered to maximize
comfort and productivity. Backed by ViewSonic’s
3-year limited warranty and industry leading pixel
policy, the VG2437mc-LED is a great investment for
any video conferencing use.
Versatile Connectivity with DisplayPort
The latest standard for rapid transmission of data, DisplayPort
delivers the best refresh rate, highest resolution and incredibly rich
colors. The VG2437mc-LED also offers VGA and DVI connections
to support even more exibility for both digital and analog media
sources. It’s easy and convenient to connect additional peripherals
or accessories with the integrated 2-port USB hub.

Specications
Sales: [phone] or [email protected] • More product information: www.ViewSonic.com
*Energy savings may vary based on cost, actual usage and other factors. Specications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic
representative for complete details.Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2012 ViewSonic Corporation. All rights reserved. [16388-00B-09/12] VG2437mc-LED
ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
LCD PANEL Type 24" (23.6" Viewable) Wide Color TFT Active Matrix LED
Display Area 20.5" horizontal x 11.5" vertical; 23.6" diagonal
Optimum Resolution 1920x1080
Brightness 300 cd/m2(typ)
Contrast Ratio 1000:1 (typ)
Dynamic Contrast Ratio 20,000,000:1
Viewing Angles 170º horizontal, 160º vertical
Response Time 5ms (typ.)
Backlight White-light LED
Backlight Life 50,000 hours (min)
Aspect Ratio 16:9
Panel Surface Anti-glare, hard-coating (3H)
INPUT Analog RGB analog (75 ohms, 0.7 / 1.0 Vp-p)
Digital DVI-D (TMDS, 100 ohms), DisplayPort (PCI-B)
Sync H/V separated (TTL)
Frequency Fh = 24 ~ 82 kHz ; Fv = 50 ~ 75 Hz
AUDIO OUTPUT Speakers 2-watt (x2)
COMPATIBILITY PC VGA up to 1920x1080 @ 60Hz (preferred)
Mac®Power Mac (up to 1920x1080)
CONNECTOR Analog 15-pin mini D-sub (VGA)
Digital DVI-D (with HDCP), DisplayPort
Audio 3.5mm Audio In
3.5mm Headphones
3.5mm Mic In
3.5mm Mic Out
USB Hub USB 2.0 (x2), USB Upstream
Power Internal Power Board, 3-pin plug (CEE22)
WEBCAM Hardware 2.0MP
OS Support Windows®8 / Windows®7 / Windows®Vista / Mac OSx
Interface Support USB 2.0
Program Support Skype / Windows Live Messenger
POWER Voltage AC 100–240V (universal), +/-10% Wide Range
Consumption 24.5W (typ)
Optimize: 19W (typ)
Conserve: 15.5W (typ)
CONTROLS Basic Power, 1, down, up, 2
OSD Auto Image Adjust, Contrast/Brightness, Input Select
(D-SUB, DVI), DisplayPort, Audio adjust (Volume Mute),
Audio Input, Color Adjust (sRGB, 9300K, 7500K, 6500K,
5000K, User Color [R, G, B]), Information, Manual Image
Adjust (H/V Position, Horizontal Size, Fine Tune,
Sharpness, Dynamic Contrast, Response Time, Aspect
Ratio, Eco-mode), Setup Menu (Language, Resolution
Notice, OSD Position, OSD Timeout, OSD, Background,
Auto Power Off), Memory Recall
ERGONOMICS Tilt -5º down, 20º up
Swivel 360º
Height Adjust 5.3" (0-135mm)
Pivot 0-90º
OPERATING Temperature 32–104ºF (0–40ºC)
CONDITIONS Humidity 10–90% (non-condensing)
DIMENSIONS Physical with stand 21.9 x 17.8 x 9.4 in. / 556.8 x 450.9 x 239.6 mm
(W x H x D) Physical without stand 21.9 x 13.4 x 2.4 in. / 556.8 x 340.3 x 60.5 mm
Packaging 24.8 x 20.8 x 7.6 in. / 631 x 527 x 192 mm
WEIGHT Net with stand 11.5 lb. / 5.2 kg
Net without stand 8.3 lb. / 3.7 kg
Gross 15.5 lb. / 7.1 kg
WALL MOUNT VESA®100 x 100 mm
REGULATIONS UL/cUL, FCC-B, ENERGY STAR®, EPEAT Silver,
Mexico Energy, WEEE, RoHS
RECYCLE/DISPOSAL Please dispose of in accordance with local,
state or federal laws.
WARRANTY Three-year limited warranty on parts, labor and backlight
24" (23.6" Viewable)
Ergonomic Webcam LED Monitor
VG2437mc-LED Monitor, power cable, VGA video cable, DVI cable, audio cable, USB cable,
mic cable, ViewSonic Wizard CD-ROM, Quick Start Guide
What's in the box?
Planet-Friendly LED Backlighting and Eco-Mode
Energy-saving LED technology enhances display performance with
an outstanding color range, contrast ratio and brightness output
for remarkably well defined images. Embedded mercury-free LED
backlighting is good for the environment and can help reduce electricity
costs. Customers can save more with Eco-mode, the included three-phase
self-adjusting power saving feature.
Headphone
VGA
DisplayPort DVI-D
Full HD 1080p for Superlative Pixel Performance
Experience the most amazing clarity and detail whether working, gaming or
enjoying the latest multimedia entertainment. The VG2437mc-LED features full
HD 1920x1080 resolution to ensure excellent pixel-by-pixel image performance.
A 20,000,000:1 MEGA Dynamic Contrast Ratio guarantees accurate image
reproduction with rich, vibrant visual effects.
Full HD 1080pNormal
Full Ergonomics for Maximum Comfort and Productivity
Users can reduce eyestrain and physical fatigue by adjusting the monitor to
create their own most comfortable work environment. The VG2437mc-LED
is designed to maximize comfort and productivity with advanced ergonomic
technology. This fully ergonomic design offers over 5" of height adjustment,
360˚ swivel, 90˚ pivot and a tilt angle from -5˚ to 20˚.
Height Swivel Tilt Pivot
Mic In/Out
AC In
USB x2
USB Uplink
Audio In
Kensington®
Lock Slot
VESA Wall Mount
Internal Speaker Internal Speaker
Controls
Webcam
VG2437mc-LED
