VA520 LCD Display
ViewSonic®
Bright, ultra-thin 15" LCD display sets your desktop style.
ViewSonic’s super-bright VA520 15" LCD display saves desk space,
while the 2.4" thin silver-on-black look states your style. The full 15"
viewable screen has an outstanding 250 nits of brightness (typ) for
rich, vivid color, and an incredible 300:1 contrast ratio (typ) for
detailed, true-to-life images. With optional TV-ready performance
with add-ons like ViewSonic’s video processors, the VA520 LCD
display is the state-of-the-art LCD choice for gamers, advanced-home
and small or home office users.
• Full 15.0" viewable screen
Displays a full, flat 15" viewable area with
crisp detail and fully saturated color.
•1024x768 native resolution
Displays a native resolution of 1024x768 for
outstanding image detail. Automatically scales
lower resolutions to fill the screen using an
advanced processor with variable sharpness
control.
•High brightness and contrast
With a high brightness of 250 nits (typ) and a
high contrast ratio of 300:1 (typ), this display
brings vivid, true-to-life color to your desktop.
•OSD/Power lock function
When activated, the user-controlled OSD/Power
lock function prevents changes to monitor
settings, maintaining an optimized image.
•Optimum 90°backward tilt
Wall mount easily without removing the base.
•ViewSonic Wizard
This software provides user-friendly installation.
The included CD-ROM automates the set-up
process to deliver optimized screen performance.

•VESA®wall mountable
The VA520 mounts on most walls with
ViewSonic’s optional wall mount kit (WM-U1).
•TCO’99 and ENERGY certified
This monitor complies with the world’s strictest
standards of low radiation, safety, ergonomics,
recycling and power management.
•PC and Mac compatible
•One-year limited warranty
FREE 24/7 technical and customer support.*
U.S. only, three (3) years outside of U.S.
•Turn your LCD into a high-resolution TV
Hook up favorite extras like a DVD, gaming
console, VCR or digital camera with a ViewSonic
video processor.
ViewSonic®
VA520 LCD Display
*Excluding major U.S. holidays. **Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for complete
details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2003 ViewSonic Corporation. All rights reserved. [11698-00B-02/04] VA520-2/3
15" TFT LCD DISPLAY
LCD Type TFT active matrix
Display Area 12.0" (horizontal), 9.0" (vertical); 15.0" diagonal
Brightness 250 cd/m2(typ)
Contrast Ratio 300:1 (typ)
Viewing Angles 120° horizontal, 110° vertical (typ)
Light Source Long life, 50,000 hrs. (typ)
Panel Surface Anti-glare
VIDEO INPUT Analog RGB Analog (75 ohms, 0.7/1.0 Vp-p)
Frequency Fh: 30~62kHz; Fv: 50~75Hz
Sync H/V separated (TTL)
COMPATIBILITY PC VGA up to 1024x768 non-interlaced
Mac®** Power Mac™up to 1024X768
CONNECTOR Analog 15-pin mini D-sub
Power AC in, AC to head
POWER Voltage AC 100–240V (universal) via external DC converter brick
Consumption 30W (max)
CONTROLS Basic Power (soft), 1, down, up, 2
OnView®Contrast, brightness, auto image adjust, H. position,
V. position, H. size, color adjust (9300K, 6500K/default,
user), sharpness, fine tune, information, OSD position,
OSD timeout, resolution notice, OSD background
(on/off), language, recall
OPERATING Temperature 32–104°F (0–40°C)
CONDITIONS Humidity 10–90% (non-condensing)
DIMENSIONS Physical 356mm (W) x 344mm (H) x 200mm (D)
(WxHxD) 14.0" x 13.5" x 7.9"
WEIGHT Net 8.1 lbs. (3.7 kgs)
REGULATIONS UL, c-UL, FCC-B, CB, CE, IC-B, (covers ISO13406-2 and
MPR II), TUV/GS, TCO’99, EPA, E2000, VCCI, BSMI,
NEMKO, SEMKO, DEMKO, FIMKO, TUV-S, PSB, C-Tick,
SASO, GOST-R (PCT-BZ02), EMI/B
POWER MANAGEMENT Meets VESA®DPMS, TCO’99 and ENERGY standards
WARRANTY One-year limited warranty on parts, labor and backlight.
U.S. only, three (3) years outside of U.S.
