ViewSonic PJ1173 - XGA LCD Projector User manual

ViewSonic’s PJ1173 delivers maximum impact for large-venue
presentations. With 5,000 LUMENS and 1000:1 contrast ratio (typ), this
PREMIUM PROJECTOR is ideally suited for conference rooms,
lecture halls, religious sanctuaries and boardrooms. The PJ1173 is
full-featured with native XGA 1024x768 resolution, advanced image
processing, manual lens shift, horizontal and vertical (auto) keystone
correction, and HDMI input to support up to 1080p signals. The image
reversing function offers versatile installation options. Network
connectivity allows you to REMOTELY CONTROL AND MANAGE
YOUR PROJECTOR and the 4x4-watt SRS®WOW STEREO SPEAKERS
give your presentations powerful sound. The security bar and PIN lock
guard against theft and unauthorized use. The PJ1173 is the full-
featured choice for dynamic presentations and smooth video
entertainment in large venues.
Multifunction versatility in
an outstanding projector.
PJ1173
HIGH BRIGHTNESS
MULTIMEDIA PROJECTOR
WITH NETWORK CONTROL
>Ultimate video source flexibility
Connect two computers simultaneously or add a video
source for dynamic meetings
. Add another monitor output
to view the same projected image on another display.
>Network control through RJ-45
Schedule, manage and monitor the projector remotely
and receive e-mail alerts of projector and lamp status
.
>Enhanced security features
PIN lock feature prevents unauthorized use. Kensington
®
security lock and a security bar allow you to secure the
projector to deter theft.
>The perfect image in any setting
Digital horizontal and vertical (auto) keystone correction,
manual lens shift, and optical zoom ensure the perfect
image in any room
.
>Superior 16-watt stereo sound
Four 4-watt speakers with SRS
®
WOW technology for
panoramic 3D sound
.
>Easy maintenance
Easy access to the lamp and filter covers even
when the projector is mounted.
>Optional lenses make installation flexible
Easy-to-install lens options
allow you to project in
rooms of virtually any size.
>3+1+1 warranty
Covered by a three-year
parts and labor limited
warranty, first-year Express
Exchange
®
Service and one-
year limited lamp warranty.
RAISING THE BAR ON
YOUR PRESENTATIONS

PROJECTOR Type 0.8" Poly-Si TFT with micro-lens
Pixel Format 1024x768 XGA
Lens Manual zoom, manual focus, manual lens shift
Zoom Factor 1.2
Keystone Auto-vertical ± 40º, horizontal ± 20º
DISPLAY Size 30"– 350" (diagonally)
Throw Distance 35"– 425"
Throw Ratio 1.5~1.8:1
Lamp 275W, 2,000 hours*
Brightness 5,000 ANSI lumens
Contrast Ratio 1000:1
Aspect Ratio 4:3 (native), 16:9
AUDIO Speakers 4x4-watt with SRS®WOW technology
INPUT SIGNAL Computer and Video RGB analog, NTSC M, NTSC 4.45, PAL, SECAM, HDTV
(480i, 480p, 575i, 720p, 1080i, 1080p)
Frequency Fh: 31–92kHz; Fv: 56–120Hz
COMPATIBILITY PC Analog: from VGA up to UXGA (compressed)
Mac®†Analog: up to SXGA (may require a Mac adapter)
CONNECTOR RGB (input) Analog RGB: DB-15 (x2), Digital RGB:M1-D
RGB (output) DB-15 (x1)
HDMI HDMI 1.3 with audio (x1)
RGB-BNC BNC-5 (x1 set)
Wireless Remote Control IR (x3)
Mouse Control VIA M1-D
Composite Video (input) RCA-3 jack (x1 set)
S-Video (input) Mini-Din 4-pin (x1)
Component Video (input) RCA jack (x1 set)
Audio (input) 3.5mm stereo mini-jack (x2) for RGB, RCA L/R jack (x1 set)
Audio (output) 3.5mm stereo mini-jack (x1)
RS-232 9-pin D-sub (x1)
Network RJ-45 (x1)
POWER Voltage 100–240 VAC, 50/60Hz (universal)
Consumption 460W (typ)
CONTROLS Basic Standby, menu, input, reset, H/V keystone, search, picture mode
OPERATING Temperature 32–95°F (0–35°C)
CONDITIONS Humidity 10–85% (non-condensing)
Altitude 0–12,000 feet
NOISE LEVEL Normal 39 dB (typ)
Whisper Mode 33 dB (typ)
DIMENSIONS Physical (mm) 418mm x 139mm x 319mm
(W x H x D) Physical (in.) 16.5" x 5.5" x 12.6"
WEIGHT Net 15.8 lb. (7.1 kg)
Gross 25.6 lb. (11.6 kg)
REGULATIONS UL 60950, C-UL, FCC-B, TUV/GS, CB, CE, C-TICK, GHOST,
NOM, CCC, PSB, RoHS
OTHER Lens shift, progressive scan, PIN lock, network control, anti-theft
security bar, daylight mode, 16-watt speakers, optional lenses,
active iris, eShot, adjustable fan speed, mouse with laser pointer
PACKAGE CONTENTS Projector, power cords, VGA cable, RCA video cable, wireless
remote control, lens cap, ViewSonic Wizard CD, Quick Start Guide
WARRANTY Three-year limited warranty on parts and labor, first-year
Express Exchange®Service. One-year limited warranty on lamp**
PJ1173
HIGH BRIGHTNESS MULTIMEDIA PROJECTOR WITH NETWORK CONTROL
For more product information, visit us on the web at ViewSonic.com
Sales: [phone] • [email protected] • ViewSonic.com
*Running whisper-mode exclusively can extend lamp life. **Visit ViewSonic.com for full details. †Adapter may be required. Analog adapter available from ViewSonic. Specifications subject to change without notice. Selection,
offers and programs vary by country. See your ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2009 ViewSonic Corporation.
All rights reserved. [14311-00B-02/09] PJ1173-1
Optional Accessories
• Replacement lamp . . . . . . . . . . . . . . .RLC-038
• Extended Express Exchange
®
. . . . .PRJ-EE-10-03
• Universal ceiling mount kit . . . . . . . .WMK-005
• Fixed short throw lens . . . . . . . . . . . .LEN-003
• Short throw zoom lens . . . . . . . . . . . .LEN-004
• Long throw zoom lens . . . . . . . . . . . .LEN-005
• Ultra long throw lens . . . . . . . . . . . . .LEN-006
• Wireless G Presentation Gateway . . .WPG-150
