VigilLink VL-DA2PD-1 User manual

VL-DA2PD-1
Dante 2CH Analog AudioDecoder with POE
VER 1.0

Thank you for purchasing this product
For optimum performance and safety, please read
these instructions carefully before connecting, operating,
or adjusting this product. Please keep this manual for
future reference.
Surge protection device recommended
This product contains sensitive electrical components
that may be damaged by electrical spikes, surges,
electric shock, lightning strikes, etc. The use of
surge protection systems is highly recommended
to protect and extend the life of your equipment.
Table of Contents
1. Introduction. ...........................................................
1
2. Features. .................................................................
1
3. Package Contents.................................................
1
4. Specifications.........................................................
2
5. Operation Controls and Functions. ......................
3
6. Application Example.............................................
4

1/4
1. Introduction
This Dante 2CH Analog Audio Decoder is an audio
receiver based on the Dante Ultimo solution. It
supports balanced/unbalanced audio output and 3-
level gain adjustment. It receives audio signals from
the transmitting end through a network (Dante),
then decodes and outputs the audio as analog
audio. It supports POE function.
2. Features
☆ Analog audio output supports balanced/unbalanced
audio output (unbalanced access to "+" and "GND")
☆ Audio sampling rate supports 44.1kHz, 48kHz,
and96kHz (24bit)
☆ Dante solution supports AES67 RTP audio
transmission
☆ Audio output supports 3-level gain adjustment：
+18dBu, 0dBu (default) and -10dBV
☆ Support DC 12V power supply and POE function
(IEEE802.3af Class 0)
3. Package Contents
① 1× Dante 2CH Analog Audio Decoder
② 1× 6pin-3.81mm Phoenix Connector (male)
③ 1× 2pin-3.81mm Phoenix Connector (male)
④ 1× User Manual

2/4
4. Specifications
Technical
Video Network
Bandwidth 100M
Audio Formats
PCM 2.0 44.1kHz/48kHz/96kHz
up to 24bit
Transmission
Distance
100m (CAT6/6A)
Control Method
Dante Controller
Connection
Inputs
1x DANTE [RJ45 connector, POE]
1x PWR [2-pin phoenix, 3.81mm]
Output
1x AUD [6-pin phoenix, 3.81mm]
Mechanical
Housing
Metal Enclosure
Color
Black
Dimensions
120mm[W] x 47mm[D] x 26mm[H]
Weight
186g
Power Supply
DC input: 12V
POE input: IEEE802.3af Class 0
Power Consumption
1.32W
Operation
Temperature
32 - 104°F / 0 - 40°C
Storage temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensation)

3/4
5. Operation Controls and Functions
No.
Name
Function Description
1
DC IN
DC 12V power input port.
2
AUDIO
OUTPUT
(CH1/CH2)
2 channel analog audio output
ports, supporting balanced and
unbalanced audio.
3
DANTE
(POE)
Dante digital audio input port.
Connect to the Network Switch
through the RJ45 line, supporting
PDpower supply.
The green LINK LED is always on
after a normal connection.
The yellow DATA LED is flashing
when there is data transmission.
4 GAIN switch
Used for audio output gain
adjustment, respectively +18dBu,
0dBu (default), -10dBV.
1
2
3
4

4/4
6. Application Example
Trademarks
Dante® is a registered trademark of Audinate Pty Ltd. All
other trademarks are the property of their respective
owners.
