VigilLink VLIP-H5HD-DC User manual

VLIP-H5HD-DC
1G H.265 HDMI 1080p@60HZ over IP w/Videowall
Processing Receiver (Decoder)
VER 1.1

Thank you for purchasing this product
Please read these instructions carefully for optimum performance and safety
before connecting, operating, or adjusting this product. Please keep this manual
for future reference.
A surge protection device is recommended.
This product contains sensitive electrical components that may be damaged
by electrical spikes, surges, electric shocks, lightning strikes, etc. The use of
surgeprotection systems is highly recommended to protect and extend the life
of your equipment.
Table of Contents
1. Introduction......................................................................................... 1
2. Features............................................................................................... 1
3. Package Contents.............................................................................. 1
4. Specifications. .................................................................................... 2
5. Operation Controls and Functions. ................................................... 3
5.1 Encoder Panel............................................................................... 3
5.2 Decoder Panel.............................................................................. 6
6. Rack Mounting Instruction. ................................................................ 8
6.1 4U Rack Mounting......................................................................... 8
6.2 1U Rack Mounting......................................................................... 10
7. Encoder and Decoder Matching Settings. ....................................... 11
8. Web GUI User Guide........................................................................... 12
9. Switch Model ...................................................................................... 18
10. 1080P over IP System Control........................................................... 20
11. Application Example.
....................................................................... 20

1/21
1. Introduction
The AV over IP product distributes multiple HD contents to multiple HD display
devices over a 100M/1G Network Switch. It offers configurable high-quality,
low-bandwidth H.265/H.264 configurable compression video and supports
resolution up to 1920x1200@60Hz 4:4:4. Signal transmission distance can be
extended up to 328ft / 100m via CATE5E/6/6A/7 cable. The product supports
analog audio embedding and extracting. It also supports RS-232 control
(pass-through & Guest mode) and single-machine control (without a Controller
Box, matrix switching can be realized with panel buttons or RS-232 control).
2. Features
☆HDMI 1.3 and HDCP 1.4 compliant
☆Video resolution up to 1920x1200@60Hz 4:4:4
☆Supports 4.95Gbps video bandwidth
☆Signal transmission distance can be extended up to 328ft / 100m via
CATE/6/6A/7 cable
☆Supports point-to-point signal extension
☆Supports signal distribution, multicast mode, distributed matrix, and video
wall (up to 9 x 9) functions over a 1G Network Switch
☆Intelligent video wall management makes it achievable for the novel layout
of wall configurations
☆Supports LPCM 2.0CH (32/44.1/48KHz) audio format
☆Supports audio embedding and extracting
☆Supports RS-232 control (pass-through & Guest mode)
☆Supports mainstream and Substream encoding modes
☆Stream parameters can be configured via Web GUI or Controller Box
☆Controlled via panel buttons, RS-232, TCP/IP, Web GUI, and Controller Box
☆Supports POE function (802.3af Class 3, PD mode)
☆Smart networking design for easy and flexible installation
3. Package Contents
Qty
Item
1
1080P over IP 100M/1GbE
Decoder
2
3-pin Phoenix Connector
(3.81mm, male)
4
Machine Screw (KM3, 4mm)
2
Mounting Ear
1
12V/1A Locking Power Adapter
1
User Manual

2/21
4. Specifications
Technical
HDMI Compliance
HDMI 1.3
HDCP Compliance
HDCP 1.4
Video Bandwidth
4.95Gbps
Video Compression
Standard
H.265/H.264
Transmission
Distance 100m (CAT5E/6/6A/7)
Video Resolution
Up to 1920x1200@60Hz 4:4:4
Color Space
RGB4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
Color Depth
Input: 8-bit, 10-bit, 12-bit (1080p@60Hz);
Output: 8-bit
Audio Formats
LPCM 2.0CH (32/44.1/48KHz)
Connection
Decoder
1x HDMI OUT [Type A, 19-pin female]
1x LAN [RJ45 connector, POE]
1x AUDIO OUT [3-pin phoenix connector]
1x RS-232 [3-pin phoenix connector]
Mechanical
Housing
Metal enclosure
Color
Black
Dimensions
120mm [W] x 95mm [D] x 21.5mm [H]
Weight
74g
Power Supply
Input: AC100 - 240V 50/60Hz,
Output: DC 12V/1A
Power Consumption 2.88W
Operating
Temperature 14 - 113°F / -10 - 45°C
Storage Temperature
-4 - 140°F / -20 - 60°C
Relative Humidity
20 - 90% RH (no condensing)

3/21
5. Operation Controls and Functions
5.1 Encoder Panel
No.
Name
Function Description
1POWER LED
(Red)
The LED flashes at 1 Hz during the system startup, and the
LED is always on after the startup is complete.
2
LINK LED
(Green)
Network connection status LED.
▪Light on: Network is connected well, and there is a
compatiblesignal (the resolution is less than 1920*1200,
and the framerate is less than or equal to 60) access.
▪Light flashes at 1Hz: The network is connected well, but
there is
▪No video input.
▪Light flashes at 10Hz: Network is connected well, but the
accessed signal is incompatible (resolution is greater than
1920*1200, or the frame rate is greater than 60).
▪Light off: Network is not connected.
3 LED screen
Displays IP address, ID, etc. information.
Note: When clicking the SHOW ME option of the
corresponding machine on the Controller, the LED screen
of the corresponding device will flash “SHO” so that you
can find the corresponding machine in the system.

4/21
4CH SELECT
Used to set Encoder ID and other settings.
5RESET
System reset button. Press and hold this button for 5
seconds; the system will restart and restore factory Settings.
6RS-232
RS-232 serial port, supporting signal pass-through and local
serial port control.
7 AUDIO IN/OUT
AUDIO IN: Analog stereo audio input port. Connect to an
audio input source device.
AUDIO OUT: Analog stereo audio output port. Connect to an
audio output device.
8LAN (POE)
100M/1G Network port. Connect to a Switch/Router/Hub for
data transmission or POE function.
9
Link Signal
Indicator lamp
(Green)
▪Illuminating: The network cable is typically connected.
▪Dark: The network cable is not connected well.
10
Data Signal
Indicator lamp
(Yellow)
▪Flashing: There is data transmission.
▪Dark: There is no data transmission.
11 HDMI IN
HDMI input port connects to an HDMI signal source device
such as a DVD or Set-top box with an HDMI cable.
12 DC 12V
The device can be powered via two methods:
▪Local DC 12V/1A power supply.
▪POE from Network Switch. The device acts in PD mode.
A DC power supply is unnecessary when the Switch
supports the POE function.
Note:
The encoder can choose HDMI audio input or external audio embedding. It can be set
through the CH SELECT buttons on the front panel of the Encoder. (The default setting
is HDMI audio input.)
If it is set to HDMI audio input, the L/R OUT output of the Encoder is HDMI audio loop
out.Suppose it is set to external audio embedding. In that case, the L/R IN input of the
Encoder is the input of shallow audio embedding, and the L/R OUT output is the
external audio embedding loop out.
Description of the LED screen and CH SELECT buttons (For the Encoder).
1, After the system is powered, the Encoder’s LED screen will show the ENC ID (000by
default if not set).
2, Press and hold the UP button for 5 seconds, the Encoder’s LED screen will show in
sequence “IP:", "xxx", "xxx", "xxx", "xxx", which is the IP address of the Encoder.
3, Press and hold the UP + DOWN buttons simultaneously for 5 seconds, then release
them and enter the “Configuration” mode with “CFN” displayed on the LED screen.

5/21
4, Press the UP or DOWN button for Channel ID settings to display the current ID
number (e.g., 001) on the LED screen. Press and hold the UP + DOWN buttons for
5 seconds, then release them to enter the “ID Settings” mode. The ID number (e.g.,
001) onthe LED screen will flash at 1Hz; press the UP or DOWN button to select
the Channel ID you desire, then press and hold the UP + DOWN buttons for 5
seconds toconfirm the setting and stop flashing.
5, For EDID ID settings, press the UP or DOWN button until the LED screen shows
“E00” (in which “E” refers to EDID, “00” to EDID ID). Press and hold the UP + DOWN
buttons for 5 seconds, then release them to enter the “EDID Settings” mode. The
EDID IDnumber (e.g., E01) on the LED screen will flash at 1Hz, then press the UP
or DOWNbutton to select the EDID ID you desire, then press and hold the UP +
DOWN buttons for 5 seconds to confirm the setting and stop flashing.
The corresponding EDID ID is as follows:
EDID ID
EDID Description
00
H1080P60_2CH
01 H720P60_2CH
02
D1024P60
03
D1080P60
04 D1200P60
05
H1200P60_2CH
06
COPY
07 USER1
08 USER2
Notes:
(1) H refers to HDMI; D refers to DVI. (The default EDID of 1080p60 will be used if you
have not previously copied the EDID to ID 06 or downloaded EDID to ID 07/08 on
the controller box web page.)
(2) EDID ID 06/07/08 is not available without Controller Box.
6, For audio options settings, press the UP or DOWN button until the LED screen shows
“AHE” (in which “A” refers to Audio and “HE” to HDMI EMB). Press and hold the UP +
DOWN buttons for 5 seconds, then release them to enter the “AUDIO Settings” mode.
The audio option (AHE or AEI) on the LED screen will flash at 1Hz, then press the UP
or DOWN button to select the AUDIO option, then press and hold the UP + DOWN
buttons for 5 seconds to confirm the setting and stop flashing.
The corresponding audio options are as follows:
AHE: Use HDMI Audio
A: Use external Audio In

6/21
5.2 Decoder Panel
No.
Name
Function Description
1POWER LED
(Red)
The LED flashes at 1 Hz during the system startup, and the
LED is always on after the startup is complete.
2
LINK LED
(Green)
Network connection status LED.
▪Light on: Network is connected well, and there is video data.
▪Light flashes: Network is connected well, but there is no video
data.
▪Light off: Network is not connected.
3 LED screen
Displays IP address, ID, etc. information.
Note: When clicking the SHOW ME option of the
corresponding machine on the Controller, the LED screen of
the corresponding device will flash “SHO” so that you can
find the corresponding machine in the system.
4
CH SELECT
Used to set Decoder ID and other settings.
5RESET
System reset button. Press and hold this button for 5
seconds; the system will restart and restore factory Settings.
6RS-232
RS-232 serial port, supporting signal pass-through and local
serial port control.
7 AUDIO OUT
Analog stereo audio output port. Connect to an amplifier or
loudspeaker through a 3-pin phoenix connector. It follows
the audio output of the Encoder.

7/21
8LAN (POE)
100M/1G Network port. Connect to a Switch/Router/Hub for
data transmission or POE function.
9
Link Signal
Indicator lamp
(Green)
▪Illuminating: The network cable is typically connected.
▪Dark: The network cable is not connected well.
10
Data Signal
Indicator lamp
(Yellow)
▪Flashing: There is data transmission.
▪Dark: There is no data transmission.
11 HDMI OUT
The HDMI output port connects to an HDMI display device
such asaTV or monitor.
12 DC 12V
The device can be powered via two methods:
▪Local DC 12V/1A power supply;
▪POE from Network Switch. The device acts in PD mode.
A DC power supply is not needed when the Switch
supports the POE function.
Description of the LED screen and CH SELECT buttons (For the Decoder).
1, After the system is powered on, the Decoder’s LED screen will show the ID of the
connected Encoder (000 by default if not set).
2, Press and hold the UP button for 5 seconds, the Decoder’s LED screen will show in
sequence “IP:", "xxx", "xxx", "xxx", "xxx", which is the IP address of the Decoder.
3, Press and hold the UP + DOWN buttons simultaneously for 5 seconds, then release
them and enter the “Configuration” mode with “CFN” displayed on the LED screen.
4, Press the UP or DOWN button for Channel ID settings to display the current ID
number (e.g., 001) on the LED screen. Press and hold the UP + DOWN buttons for
5 seconds, then release them to enter the “ID Settings” mode. The ID number (e.g.,
001) onthe LED screen will flash at 1Hz; press the UP or DOWN button to select
the Channel ID you desired, then press and hold the UP + DOWN buttons for 5
seconds toconfirm the setting and stop flashing.
5, For output resolution settings, press the UP or DOWN button until the LED screen
shows “S00” (in which “S” refers to Scaler and “00” to resolution ID), then press and
hold the UP + DOWN buttons for 5 seconds, then release to enter the “Output
ResolutionSettings” mode. The Resolution ID number (e.g., S01) on the LED screen
will flash at 1Hz, then press the UP or DOWN button to select the Resolution ID you
desire, thenpress and hold the UP + DOWN buttons for 5 seconds to confirm the
setting and stop flashing.

8/21
The corresponding output resolution ID is as follows:
Resolution ID
Resolution Description
00
Pass-Through (default)
01
1080P60
02
1080P50
03
1080P30
04
1080P25
05
1080P24
06
720P60
07
720P50
08 576P50
09
480P60
10
640X480P60
11
800X600P60
12
1024X768P60
13
1280X800P60
14
1280X1024P60
15
1366X768P60
16
1440X900P60
17
1600X1200P60
18
1680X1050P60
19
1920X1200P60
6. Rack Mounting Instruction
6.1 4U Rack Mounting
This product can be mounted in a standard 4U rack (Please contact your
supplier for a 4U rack sale). The mounting steps are as follows:

9/21
Step 1: Use included screws to fix two mounting ears on the product, as
shown in the figure below:
Step 2: Insert the product with mounting ears into a 4U rack (up to 12 units
can be installed vertically), as shown in the figure below:
Step 3: Use screws to fix mounting ears on the rack to complete the mounting,
as shown in the figure below:

10/21
6.2 1U Rack Mounting
This product also can be mounted in a standard 1U rack (up to 8 units can be
installed horizontally). The mounting steps are as follows:
Step 1: Stack two products on top of each other, then use included screws
to fix two 1U rack panels on the products, as shown in the figure below:
Step 2: Fix two 1U rack panels on another two stacked products in the same
way, then use screws to fix two 1U rack panels together, as shown in
The figure below:
Step 3: Fasten screws between two 1U rack panels so that eight products
are mounted in a 1U rack, as shown in the figure below:

11/21
7. Encoder and Decoder Matching Settings
When multiple Encoders and Decoders are in the system without a Controller
Box, it is necessary to match them well first. You can match all Encoders and
Decoders in the following two methods.
Method 1: Use the CH SELECT buttons on the front panel of the Encoder/
Decoder.
According to the methods mentioned in Chapter 5, set the ID of Encoder, then
the ID of Decoder, and finally the Encoder ID from which to subscribe the
stream. Match all Encoders and Decoders in the same way.
Method 2: Use the RS-232 serial port command control.
Connect the RS-232 port of the Encoder/Decoder to a PC or control
system, asshown in the figure below. Then use a Serial Command tool on a
PC to send the RS-232 command code: “!OUT xxx FR yyy\r\n”. The
function of this command is to connect the Decoder (ID: xxx) to the Encoder
(ID:yyy). Matchall Encoders and Decoders in the same way.
TX
Ground
RX
3-pin Phoenix Connector
RS-232
RS-232 to USB cable
PC

12/21
8. Web GUI User Guide
The built-in Web GUI can configure all products through a Switch.The
operation method is shown below.
Step 1: Match all Encoders and Decoders as described in Chapter 7.
Step 2: Connect the PC and IP products you need to configure to a Switch.
The connection diagram is shown below.

13/21
Step 3: Press and hold the (CH SELECT) UP button on the front panel of the
Encoder/Decoder for 5 seconds to check the IP address. (Please refer to
Chapter 5 for details.)
Step 4: Set the PC’s IP address in the same network segment as the
Encoder/Decoder; for instance, set the IP address to 169.254.3.150 and the
Subnet mask to 255.255.0.0.
Step 5: Input the IP address of the Encoder/Decoder into the browser on the PC to
enter the Web GUI login interface.
Step 6: Input the default User “admin” and the default Password “admin,”
and then click “Log In” to enter the Web GUI interface.

14/21
The Web GUI function pages are shown below:
■Device Information Page
The Status page provides basic information about the Encoder/Decoder, such
as Firmware Version, IP Address, Subnet Mask, Gateway, and MAC Address.
■Video Configuration Page
On this page, you can configure the video properties as required.

15/21
Encoder Video Configuration
Encoder video configuration page includes Main Stream, Sub Stream, ID
Setting, Audio Selection, and EDID Setting.
Main Stream: You can configure Video Encoding Format, Audio Encoding
Format, and Bitrate. Video Encoding Format supports H.264 and H.265
(H.265 by default). Audio Encoding Format supports PCM and AAC (PCM
by default). Encoding Resolution cannot be set; it follows the input resolution.
The default Bitrate is 8Mb/s.
Sub Stream: You can configure Video Encoding Format, Resolution, and
Bitrate. Video Encoding Format supports H.264 and H.265 (H.265 by default).
The default Encoding Resolution is 640*360. The default Bitrate is 1Mb/s.
ID Setting: You can configure the ID of the Encoder. (After setting the ID,
the IP will change. You need to press and hold the (CH SELECT) UP button
on the front panel of the Encoder for 5 seconds to check the IP address, and
then re-enter the new IP address on the web page to continue setting).
Audio Selection: You can configure the Audio Input (HDMI/Analog). EDID
Setting: You can choose an EDID option from the drop-down list, asshown
in the below figure.

16/21
User EDID 1 and User EDID 2 can be uploaded in the Select User EDID1
File and Select User EDID2 File, and the content of the uploaded binary file
is EDID. (This file can be downloaded from the Download EDID of the
DecoderVideo page.)
Decoder Video Configuration
The decoder video configuration page includes Transmission Protocol,
ScaleSetting, Download EDID, Video Timeout Setting, ID Setting, and
PictureSetting.

17/21
Transmission Protocol: You can select “udp unicast” or “udp multicast”
(udp multicast by default).
Scaler Setting: You can set the output resolution (Pass Through by default).
Download EDID: You can download the EDID binary file of the display device
connected to the Decoder. The EDID file can be used as the User EDID file to
be uploaded to the Encoder.
Video Timeout Setting: You can set the timeout to turn off the video output
when no input video signal is detected. 0 means never close.
ID Setting:
Local ID: You can set the ID of the Decoder. (After setting the ID, the IP will
change. You need to press and hold the (CH SELECT) UP button on the front
panel of the Decoder for 5 seconds to check the IP address, and then re-enter
the new IP address on the web page to continue setting).
Max Channel ID: You can set the maximum range of Source Selection ID that
can be set. When it is set to 0, there is no limit to the Source Selection ID setting
range.
Source Selection ID: You can select the Encoder ID as the inputsource.
Picture Setting: You can configure the picture parameters (Brightness,
Contrast, Hue, and Saturation).
■Settings Page
You can set Network settings on this page, configure Security Module, and
modifyyourusername and Login Password as required.

18/21
Notes:
(1) The Network Settings can be set only when the Mode button is set to Static.
(2) All changes will take effect by clicking “Save” below.
(3) After any changes to the Network Settings, username, or Login Password,
it will redirect to the Web browser home page or the Web GUI login interface.
You must log in to the Web GUI again with the new settings.
■Update Page
Click “Browse..” to import the upgrade file and click “Update” to start the
upgrade.There will be a progress bar prompt during the upgrade process.
When the progress bar reaches 100%, it indicates the promotion is booming,
and the device will be restarted automatically.
Clicking “Reset” can reset the device to factory default settings.
Clicking “Reboot” can reboot the machine.
