Vigitron MaxiiCopper Vi2404A User manual

Application Drawing
Vi2404A Coax Ethernet Extender Installation Manual
DO NOT OPEN
RISK OF ELECTRIC SHOCK
CAUTION
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER. NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
IP Camera-end Installation
The Smart Choice for Transmission Solutions www.vigitron.com
The MaxiiCopper Model Vi2404Ais a revolutionary data transmission device
that extend full-duplex High-Speed Ethernet over existing coaxial
infrastructures. it transmits Ethernet 10BaseT signal up to 5,000 ft. (1,524m)
and 100BaseT up to 1,800 ft. (546m). When using Pass Through PoE (PTP
™), It extend 10BaseT up to 3,000 ft. (914m) and 100BaseT up to 1,800 ft.
(546m). It employs MaxiiCopper, an innovative and unique Ethernet
extension technology, that is designed to take full advantage of
high-bandwidth coaxcial cables and maintain a full-duplex 10 or 100 Mb/s
Ethernet connection up to the maximum range with minimum transmission
error and latency. Multiple remote network devices such as Mega-pixel IP
cameras or VoIP can be connected to a central LAN switching fabric with
ease. Its dual-rate capability provides an easy way to balance the best
possible network throughput and long-reach distance design.
These hubs need to be deployed along with Vi2401A on the remote end of
each coaxial cable. They are equipped with LEDs to provide link status and
configured data rate for each port. They are completely transparent to the
corporate IP network and higher layer protocols and require no IP
programming or other configurations.
The Vi2404A is ideal for medium to large scale IT networking or digital
CCTV projects.
Important Safety Warning - Use a Vi2401A single port extender for the camera side transmission.
- Set the Master/Slave dip switch to “Master” mode.
- Connect the external 12VDC power supply to the power connector of the
Vi2401A. An optional power adapter connector can be provided to simplify
connection. If no local power supply is present the Vi2401A will use POE.
- Connect the IP camera’s RJ45 connector to the 10/100BaseT Ethernet
port of Vi2401A using a standard Cat5/6 patch cable of maximum 330 feet
(100 m) in length.
- Connect one end of the long coax cable to the BNC connector of Vi2401A.
The link LED on the 10/100 connector should be “ON” to indicate proper
connection between the camera and Vi2401A.
Ethernet Switch/NVR-end Installation
- Connect the chassis ground screw to a solid earth ground.
- Connect the RJ45 connector of the Ethernet switch to the 10/100BaseT
Ethernet port of Vi2404A using a standard Cat5/6 cable of maximum
328 feet (100m) in length.
- Connect long coax cables to the BNC connectors of Vi2404A.
- Connect the 12VDC power supply to the power connector of Vi2404A.
The link LED on the 10/100 Ethernet connectors should be “ON” to indicate
proper connection between the switch and Ethernet ports of Vi2404A. While
the Link LED, Orange for 100BaseT and Green for 10BaseT, on the coax
side, in a steady state will indicate confirmed connection between extenders.
- Read and keep these instructions.
- Heed all warnings.
- Follow all instructions.
- Do not use this apparatus near water.
- Clean only with a dry cloth.
- Install in accordance with the manufacturer’s instructions.
- This installation should be made by a qualified service person and should conform to all local
codes.
- DO NOT bundle UTP or Coax signals in the same conduit as high-voltage wiring.
- To reduce the risk of fire or electrical shock, do not expose these products to rain, moisture,
dripping or splashing.
- No objects filled with liquids, such as vases, shall be placed on Vigitron equipment.
- DO NOT install the unit in a place where the operating ambient temperature exceeds 75°C.
- Make sure that the external power supply output voltage is in the recommended range.
- Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including DVRs) that produce heat.
- Protect the power cord from being walked on or pinched particularly at power source,
convenience receptacles, and the point where they exit from the apparatus.
- Only use attachments/accessories specified by the manufacturer.
- Unplug this apparatus during lightning storms or when unused for long periods of time.
- Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as when a power supply cord or plug is damaged, liquid
has been spilled, objects have fallen inside the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has been dropped.
- The main plug is used as the disconnect device and shall remain readily operable.
WARNING! - To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture. This apparatus shall not be exposed to
dripping or splashing and no objects filled with liquids, such as vases shall
be placed on the apparatus.
WARNING! - This apparatus is a Class I product. This product must
be connected to a mains socket outlet thru an AC to DC Power supply.
WARNING! - The mains plug is used as the disconnect device and
shall remain readily operable.
Connecting Multiple PoE Cameras over Extended Coax Cables
Network Switch
Vi2404A
Data + PoE
328 ft. (100m)
Data + PoE
328 ft. (100m)
Data + PoE
328 ft. (100m)
Data + PoE
328 ft. (100m)
PoE Cameras
Data + PoE
328 ft. (100m)
Vi2401A
Vi2401A
Vi2400WP
Data + PoE
Extended Coax
Data + PoE
Extended Coax
Data + PoE
Extended Coax
Data + PoE
Extended Coax
Vi2400A
Maxii Copper
TM

Limited Lifetime Warranty
Vigitron, Inc. warrants that all Vigitron products (“Product”), if used in accordance
with these instructions, will be free of defects in material and workmanship for
lifetime defined as the duration period of time until product end of life is announce-
ment. After which Vigitron will continue to provide warranty services for a period of 3
years. Period covering valid warranty will be determined by proof of purchase in the
form of an invoice from an authorized Vigitron dealer.
Warranty will only be provided for as long as the original end user purchaser owns
the product. Warranty is not transferrable. At Vigitron's option, defective product will
be repaired, replaced or substituted with a product of equal value. This warranty
does not apply if, in the judgment of Vigitron, Inc., the Product fails due to damage
from shipment, handling, storage, accident, abuse or misuse, or if it has been used
or maintained not conforming to Product manual instructions, has been modified, or
serial number removed or defaced. Repair by anyone other than Vigitron, Inc. or an
approved agent will void this warranty. Vigitron, Inc. shall not under any circum-
stances be liable to any person for any incidental, indirect or consequential
damages, including damages resulting from use or malfunction of the product, loss
of profits or revenues or costs of replacement goods. The maximum liability of
Vigitron, Inc. under this warranty is limited to the original purchase price of the
Product only.
Technical Specifications*
Drawings
Status LEDs
© Copyright 2021 Vigitron, Inc.
TEL (+1) 858 - 484 - 5209 • FAX (+1) 858 - 484 - 1205
7810 Trade Street, Suite 100, San Diego, CA 92121, USA • [email protected] • www.vigitron.com
Electrical
Ethernet Interface Standard 10/100BaseT
Ethernet Rate Auto select 10/100 Mb/s
Full speed / full duplex at maximum rated distance
Coax (data only)** 75 Ohm, 5000 ft (1,524 m) at 10BaseT
1,800 ft (548 m) at 100BaseT
Coax (with PTP™)**3,000 ft (914m) at 10 BaseT
1,800 ft (546m) at 100 BaseT
Power Supply 12 VDC, 3A maximum
Status LEDs Extended Ethernet:Green/OrangeLED, 10/100BaseT
Standard Ethernet:Green LED, Activity
Yellow LED, Link
Power On: Red LED
Connectors Ethernet Interface: 4 x RJ-45 Connector
Extended Interface: 4 x RFemale BNC
Power: IEC380-8 inlet
Jumbo Frame Up to 9,600 bytes
Support
Environmental
Humidity 0 to 95%, non-condensing
Temperature Operating: -40°C to +75°C
Storage: -40°C to +80°C
Mechanical
Dimensions 1.15x3.6x3.3 in., 4.2x9.2x8.4 cm (HxWxL)
Weight 0.584 lb, 265 g
Material Aluminum
Accessories
Rack mount brackets
*Specifications subject to change without notice.
**Distance figures are obtained using in house testing mirroring installations. Factors such as cabling, connections,
use of power and environmental conditions may affect actual distances and should be taken into consideration.
Vi2416A_UM
LED Name Color Status Function
OFF P ower is OFF
ON Power is ON
OFF No connection
FLASHING Connection is OK with Traffic
OFF No connection
ON Connection is OK
Traffic
(Standard Side)
GREEN
Link
(Standard Side) YELLOW
Power RED
LinkTraffic
10BaseT
100BaseT
1 2 3 4
10BaseT
100BaseT
Standard Ethernet
Extended Ethernet
RoHS
3.6"
9.2cm
3.3"
8.4cm
Front ViewSide View
Rear View
12VDC
+ -
1.6"
4.1cm
Vi2404A 4-Port Ethernet Extender
1234
Extended Ports
Ethernet Ports
10
100
