Viking Custom Front DFUD142 User manual

M0907F60068E
Professional Performance for the Home™
®
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
[phone]
For product information,
call 1-888-VIKING1 (845-4641),
or visit the Viking Web site at
vikingrange.com
®

No matter what the photo spreads in gourmet magazines
would like you to believe, the delight of cooking always begets the chore of cleaning up.
Even the most spectacular meal leaves a stack of dirty dishes in its wake. But Viking
kitchen cleanup products tackle these mundane tasks with style and ease.
The waste disposer devours any unsightly scraps and the trash compactor makes
quick work of kitchen litter – all while the heavy-duty washer silently scours. And now
the cleanup products are available in both the bold, commercial look of the Professional
Series and the striking curves of the Designer Series. It may be
a dirty job. But it doesn’t have to look that way. ®
3
2

Design flexibility
■ Three design options
• Professional stainless steel door panel
• Designer stainless steel door panel
• “No front” model accepts custom door panel, or
optional Professional or Designer door panels
■ Control panel hidden from view when door is closed
Quiet, efficient operation
■ Sound-absorbing, heat-retaining insulation
• Heavy asphalt insulation on top, sides, rear, and
bottom of tank
• Top and both sides of tank and inside of door are
quieted by an additional layer of felt (DFUD142 only)
■ Two motor/pump assemblies for more efficient circulation
and drainage than single-motor systems
• Anti-jam, auto-reversing pump
Interior design
■ Super-extendible, graphite nylon racks are fully usable for
no lost space
Dishwashers
• Taller upper rack with super-stable rack guides glides
out to nearly full extension
• Two dual-level cup racks in upper rack
• Lower rack extends four extra inches from tank for
easier loading
• Fold-down tines provide space for large items
(DFUD142 only)
• Large silverware/cutlery basket includes special
compartment with lid to hold smaller items in
place during washing
■ Accommodates 16 international place settings of china
in a single load
■ Special basket located above upper rack accommodates
knives and long utensils (DFUD142 only)
■ Extra-tall tank allows taller dishes to be placed in upper
rack
• Eliminates need for top filler strip
• Allows 9" wide plates to be loaded in upper rack
■ Interior light comes on when door is opened, allowing
better visibility (DFUD142 only)
The triple filtration system leaves
dishes spot-free with its removable
large-objects strainer and
self-cleaning small-objects filter.
Professional Door Panel
in Stainless Steel Custom Door Panel with Professional Handle
(may use custom handle)
Designer Door Panel
in Stainless Steel Custom Door Panel with Designer Handle
(may use custom handle)
Fully usable graphite nylon racks
offer convenient random loading
without any lost space.
DFUD142 – shown with
optional Professional
door in Burgundy finish
and Brass Trim Option
No matter how much you romanticize the art of cooking, you still must face one daunting question. Whose turn is it to do the dishes?
There is no getting around the dreaded chore. But Viking dishwashers minimize the task, so you can focus on the important things – like
small talk. And you’ll never have to worry about a Viking dishwasher drowning out pleasant conversation. With ultra-dense asphalt
and felt insulation on all sides, you’ll never hear a peep out of these dishwashers. Separate top and bottom motors and pump deliver
unrivaled cleaning power. And the extra-tall tank with super-extendable racks makes loading a breeze. Now, who’s ready for coffee?
5
4

Washing and drying
■ Superior automatic water-heating system
• 1,200-watt water-heating element guarantees
ample supply of hot water
■ Heating accuracy assured by two separate thermostats
■ Multi-level wash system
• Stainless steel lower and upper wash arms turn in
opposite directions for complete water coverage
• Automatic detergent dispenser
• Automatic rinse agent dispenser with fill indicator
■ Triple filtration and waste-removal system
• Separate motor/pump quietly drains dishwasher
• Removable, self-cleaning fine filter captures
smaller particles
• Removable strainer captures large objects,
protecting pump from damage
■ Electronic controls offer several wash cycles as well as
other options designed to reduce energy costs
• Cycles include Pots/Pans, Heavy, Normal,
Light/China, Quick, and Rinse/Hold
• Cycle options include Temp Selection, Extra Dry,
and 5-Hour Delay
• Top/Bottom Rack Only and Express option
(DFUD142 only)
■ Temperature options range from 85˚F to 170˚F
depending on cycle
■ All cycles are extremely efficient, with Normal wash
using only 4.5 gallons of water and China using only
2.4 gallons of water
■ Convect-Air™ Drying
• Motorized fan extracts moisture from dishes,
utensils, and tank
• Switch-activated vent door opens only during
drying for quieter operation
• Safely vents between door and lower panel –
away from controls and cabinets
Commercial construction and design
■ Extra tall tank and inner door made from rustproof
surgical stainless steel
■ Counterbalanced, heavy-duty door springs for
effortless opening and closing
■ Tough, zinc-coated steel frame and one-piece
galvanized steel base pan
■ Twin fill valve (DFUD142 only) and overflow protection
switch prevents mechanical malfunction overflows
Optional accessories
■ Professional door (PTD24) in any Professional color
finish; must be ordered separately from dishwasher
■ Designer door (DTD24) in any Designer color finish;
must be ordered separately from dishwasher
■ Professional (PHK23) and Designer (DHK20) handle
kits in Stainless Steel (SS) or Brass (BR) for use with
custom door panel
Energy Star
■ All models are Energy Star qualified
The stainless steel tank and inner
door are completely rustproof and
offer unsurpassed durability.
Integrated controls inside dishwasher provide a smooth outside appearance.
The Sani Cycle setting heats the
water to a germ-incinerating 165º F,
ensuring even your dirtiest dishes
come out spotless and sanitized.
DFUD142 – shown
with Designer door in
Stainless Steel finish
7
6

Convenient operation
■ Built-in small litter area (VUC181 only)
• Allows loading of small items without opening large
trash drawer
• May be opened while compactor is operating
■ Large 1.7-cubic-foot trash drawer
• Largest capacity of any residential compactor
• Allows random loading of bulky items
• Easily holds the weekly trash of a family of four
■ Breakaway trash basket
• Easy to empty and clean
• May be used with or without bags
• Basket release handle/plate for easy removal
■ Activated charcoal filter and fan with control panel switch
• Remove odors and eliminate the need for perfumed
deodorizers
• Control panel light indicates fan is operating
■ Built-in storage compartment
• Convenient storage of compactor bags or other
cleanup items
• Largest capacity available
Maximum compacting power
■ 1/2 horsepower, high-torque motor
• Most powerful motor in a residential compactor
■ 3-Point Drive System avoids jamming which can result from
uneven loading
Trash compactors
DUC180
Designer Model
VUC181
Professional Model
The conveniently sized, easy-
to-handle breakaway basket
allows easy removal and
transport of compacted trash.
With the most powerful motor
available in a residential model, the
trash compactor reduces trash to
approximately one-fourth its original
size in less than 35 seconds.
VUC181 – Professional
model in Almond finish
DFC180
Custom Front Model
with Designer Handle
It’s easy to lose yourself in the kitchen. Unfortunately, it’s a little tougher to lose the inevitable mess. But Viking trash compactors make
quick work of whatever you leave in your culinary wake. The largest capacity of any residential compactor handles even the bulkiest
items without cramming or jamming. And the most powerful motor on the market crushes it all with 3,000 pulverizing pounds of
force. An activated charcoal filter and fan keep odors at bay. And the breakaway trash basket makes Viking compactors a snap to empty.
■ Reduces trash to approximately one-fourth its original
size in 35 seconds or less
■ Delivers 3,000 pounds of crushing force at every position
and at every point on the ram head
■ 3-Piece Ram encloses motor and drive system for
quiet operation
Sturdy construction and safety features
■ Durable, heavy-gauge steel frame
■ Double reinforced base withstands heavy loads
■ Key-start operation with safety lock
■ Positive drawer closing ensures compactor will not
operate while drawer is open
Standard accessories
■ Five grip/slip plastic bags with ties
• Outside grips to hold bag in place; inside slips for
easy compacting
• Specifically designed to fit 18" wide compactor
• 3.5 millimeters thick
• Pre-punched holes match bag retainer buttons
■ One activated charcoal air filter
■ One breakaway trash basket
Optional accessories
■ Case of replacement plastic bags and ties (TCBC)
■ Activated charcoal air filter (ACF-VUC) for replacement
every six to nine months
9
8

Continuous feed operation
■ Convenient wall switch start
■ Operates with or without cover for easy loading of
food waste
Powerful grind system
■ Solid cast grind wheel
• Two fixed stainless steel impellers
• Continuous cutting from 18 uppercutters
and 16 undercutters
• Precision-balanced for smooth, vibration-free
performance
■ Solid cast shredder ring has 45 double-edged cutters
■ 1,417,500 uppercuttings and 1,260,000 undercuttings
per minute – approximately 15 times that of the nearest
high-end competitor
■ Highly effective for use with septic tanks
Anti-jamming system
■ Capacitor start motor is one of the most powerful available
in a residential model
■ Automatic reversing
• Grind wheel moves in opposite direction with each
start, breaking jams that stop ordinary disposers
■ Power Plus Jam-inator®button (VCFW1000 only)
• Solid-state device causes grind wheel to oscillate
approximately 7,000 times per minute, pulverizing
even the toughest jams
Quiet operation
■ Sound absorbing insulation in grind area
■ Six isolating gaskets in key operating areas absorb sound
■ Quiet and efficient fixed impellers eliminate noise
generated by ordinary swivel blades and will not swing
away from waste
Optional accessories
■ Batch feed accessory kit (BFAK) converts continuous feed
disposer into magnetically activated batch feed unit
■ Counter/sink switch kit (STSK)
• Air activated switch easily mounts to sink or
countertop and is perfect for island installations
• Kit includes chrome and white buttons
■ Sink flanges (SFLG) in brass, white, and biscuit
■ Sink stoppers (SSTP) in brass, white, and biscuit
■ Deep sink flange (SFLGD) in stainless steel
• Accommodates up to 1.75" thick sink
Food waste disposers
VCFW1000VCFW750
The optional counter/sink switch kit
offers an air-activated button control
perfect for island installations.
Flanges available in
brass, white, and
biscuit. Deep sink
flange available
in stainless steel.
No matter how much your guests enjoy the speckled trout, a few bites will surely be left. And speckled trout certainly does not age well.
Luckily, Viking waste disposers are always ready to finish off any and all scraps. The powerful motor devours everything from shrimp
peels to turkey bones. The exclusive anti-jamming system prevents jams in even the heaviest loads – while the precision-balanced grind
system quietly shreds everything into oblivion. It’s almost more fun than cooking.
11
10

Dishwashers
■ Professional door panels (PTD24) available in Stainless Steel
(SS), Black (BK), White (WH), Almond (AL), Biscuit (BT), Stone
Gray (SG), Graphite Gray (GG), Burgundy (BU), Lemonade
(LE), Mint Julep (MJ), Forest Green (FG), Viking Blue (VB),
Cobalt Blue (CB), and Eggplant (EP)
• May be ordered with Brass Trim Option (BR) for
nameplate and door handle/brackets
■ Designer door panels (DTD24) available in Stainless Steel
(SS), Black (BK), White (WH), Biscuit (BT), Stone Gray (SG),
and Graphite Gray (GG)
• May be ordered with Brass Trim Option (BR) for door handle
Trash Compactors
■ Professional compactors available in Stainless Steel (SS),
Black (BK), White (WH), Almond (AL), Biscuit (BT), Stone Gray
(SG), Graphite Gray (GG), Burgundy (BU),
Lemonade (LE), Mint Julep (MJ), Forest Green (FG), Viking
Blue (VB), Cobalt Blue (CB), and Eggplant (EP)
• May be ordered with Brass Trim Option (BR) for
nameplate, door handle/brackets, and litter door pull
■ Designer compactors available in Stainless Steel (SS),
Black (BK), White (WH), Biscuit (BT), Stone Gray (SG), and
Graphite Gray (GG)
• May be ordered with Brass Trim Option (BR) for drawer
handle and release lever
■ Custom front compactors accept 3/4" thick door panels
■ All brass components have a durable, protective coating
for maintenance-free normal use
■ Viking uses the most up-to-date processes and best materials
available to produce all color finishes. However, slight color
variation may be noticed because of the inherent differences
in painted parts and porcelain parts, as well as differences
in room lighting, product locations, and other factors.
Design integrity Warranty highlights
Dishwashers
■ One-year full covers complete dishwasher
■ Five-year limited – upper and lower graphite nylon racks,
motor/pump assemblies (2) and water distribution system
■ Twenty-five-year limited – stainless steel tank and
inner door
■ Ninety-day limited – cosmetic parts such as glass,
painted items, and decorative items
Trash Compactors
■ One-year full covers complete compactor
■ Five-year limited – 1/2 horsepower drive system motor
■ Ninety-day limited – cosmetic parts such as painted
items and decorative items
Disposers
■ VCFW750
• Seven-year full covers complete disposer
• Ninety-day limited – cosmetic parts such as
painted items and decorative items
■ VCFW1000
• Ten-year full covers complete disposer
• Ninety-day limited – cosmetic parts such as
painted items and decorative items
stainless steel
black
white
PROFESSIONAL DESIGNER
biscuit
stone gray
graphite gray
stainless steel black
white almond
biscuit
stone gray
graphite gray burgundy
lemonade mint julep
forest green viking blue
cobalt blue eggplant
13
12
Consistency in both performance and design should be a major consideration when building or remodeling a home. With the complete Viking indoor or
outdoor kitchen, every single product works together in form and function with the same level of excellence. It’s something Viking calls Design Integrity™.
Viking is the only company that offers complete ultra-premium kitchens – so Viking is also the only company that can offer truly consistent
design, while delivering the quality and performance that makes Viking the true market leader. Across all product categories, the knobs, handles,
bezels, curves, angles, and lines all match. This enables the designer to create a perfectly harmonious kitchen in one of three Viking product
offerings – Professional Indoor, Designer Indoor, or Professional Outdoor.
You wouldn’t install mismatched cabinets and drawers or countertops. Yet design differences are even more dramatic between multiple
appliance manufacturers. Traditional or contemporary. Stainless steel or color finishes. No matter the look you’re going for, no one can match
the Viking kitchen and Viking Design Integrity.
Exclusive finishes

Total Wash Time – Minutes
AA
BB
A – using the lower water temperature setting
B – using the higher water temperature setting
NOTE: Includes time for dry
■ Express option available for Pots/Pans, Heavy, Normal,
and Light/China cycles on DFUD142 model only.
■ Reduces washing time and lowers temperature (not
available on Quick wash or Rinse/Hold).
Basic specifications – Dishwashers
DFUD042/DFUD142
Description 24" WIDE DISHWASHERS
Overall Width
Overall Height
Overall Depth from Rear
Cutout Width
Cutout Height
Cutout Depth
Electrical Requirements
Water-Heating Element Rating
Maximum Amp Usage
23 7/8" (60.6 cm) with side trim 23 1/2" (59.7 cm) without side trim
34 1/8" (86.7 cm) minimum 36 7/8" (93.7 cm) maximum
To edge of side – 24" (61.0 cm) (includes drain hose and door panel)
With door open – 49" (124.5 cm)
24" (61.0 cm) with side trim 23 5/8" (60.0 cm) without side trim
34 1/4" (87.0 cm) minimum 37" (94.0 cm) maximum
24" (61.0 cm)
120VAC/60Hz; 6' (1.8 m) electrical cord supplied with unit
15.0 amps
Approximate Shipping Weight 104 lb. (47.2 kg)
1,200 watts
Cycle data
Water
Temperature
Description 24" WIDE DISHWASHERS
Pots/Pans
Heavy
Normal
Light/China
Quick
Rinse/Hold
140˚F or 170˚F
(60˚C or 75˚C)
Pre-Wash Main Wash Rinse
130˚F or 160˚F
(55˚C or 70˚C)
130˚F or 150˚F
(55˚C or 65˚C)
105˚F or 120˚F
(40˚C or 50˚C)
85˚F or 120˚F
(30˚C or 50˚C)
2
2
1 or 2
–
–
–
1
1
1
1
1
–
3
2
2
2
2
1
Extra Dry Option
Description
Pots/Pans
Heavy
Normal
Light/China
Quick
Rinse/Hold
Total Water Gal (L) Input Water
60˚F (15˚C)
Input Water
120˚F (49˚C)
yes
yes
yes
yes
no
no
4.5
4.5
4.5
2.4
2.1
0.8
230
210
130
110
25
4
240
220
150
115
–
–
190
175
110
85
15
4
195
185
135
90
–
–
Basic water supply data
■ Inlet water temperature – 120°F (49°C) minimum at
the dishwasher recommended; however, dishwasher
will perform properly with cold water (see 60°F/15°C
columns on cycle data chart)
■ Inlet water pressure operating range – 18 to 176 psi
(125 to 1227 kPa)
■ Unit supplied with 6' (1.8 m) PEX water supply line that
has a 3/8" (1.0 cm) NPT female connection
Basic drain data
■ 6 1/2' (2.0 m), 3/4" (1.9 cm) ID “crimp-proof” rubber
drain hose with clamp attached to dishwasher; can
be extended up to a maximum of 10' (3.1 m) with 3/4"
(1.9 cm) ID copper tubing
■ High loop of drain hose required
■ Minimum height from floor – 24" (61.0 cm)
■ Maximum height from floor – 35" (88.9 cm)
■ Connect drain hose to drain motor/pump (right front
of dishwasher under lower panel)
■ Check local codes for air gap requirement in drain line
Must be 2" (5.1 cm) clearance to side wall if installed in
a corner.
All electrical and plumbing connections must conform
to local codes.
–
15
14

120V/60Hz; hard wire direct with 2-wire ground
1 HP-10.0 amps, 3/4 HP - 8.0 amps
23 lb. (10.4 kg)
Basic specifications – Trash compactors
VUC181
Description 18" WIDE TRASH COMPACTORS
Overall Width
Overall Height from Bottom
Overall Depth from Rear
Cutout Width
Cutout Height
Cutout Depth
Electrical Requirements
Maximum Amp Usage
17 13/16" (45.2 cm)
34 3/16" (86.8 cm)
minimum
35 11/16" (90.6 cm)
maximum
To edge of side –
23 5/8" (60.0 cm)
To end of handlebracket–
26 1/16" (66.2 cm)
With door open –
48 1/8" (122.2 cm)
18" (45.7 cm) minimum
34 1/4" (87.0 cm)
minimum
35 3/4" (90.8 cm)
maximum
24" (61.0 cm) minimum
115VAC/60Hz; 72" (128.9 cm)
2-wire cord with grounded 3-prong plug attached to product
9.0 amps
Approximate Shipping Weight 210 lb. (94.5 kg)
Disposers
A
Description DISPOSERS
VCFW750/1000
Sink Flange
Drain
Dishwasher Connection
BDE
13 11/16"
(34.8 cm)
Electrical Requirements
Maximum Amp Usage
Approximate Shipping Weight
C
6 13/16"
(17.3 cm) 4" (10.2 cm) 10 1/16" (25.6 cm) 5 3/4" (14.6 cm)
Fits all types of sinks with standard 3 1/2" (8.9 cm) to 4" (10.2 cm) openings;
flange comes with two rubber sealing gaskets.
1 1/2" (3.8 cm) OD waste line spout with rubber sealing gasket packed with disposer
7/8" (2.2 cm) OD tube
217 lb. (97.7 kg)
DUC180
34 1/8" (86.7 cm) minimum
35 1/2" (90.2 cm) maximum
To edge of side –
23 7/8" (60.6 cm)
To front edge of handle–
25 7/8" (65.7 cm)
With door open –
47" (119.42 cm)
34 1/4" (87.0 cm) minimum
35 5/8" (90.5 cm) maximum
All electrical and plumbing connections must conform to local codes.
DFC180
To edge of side –
23 7/8" (60.6 cm)
With door open –
47" (119.42 cm)
17
16

NotesNotes
To receive the most current specification sheets, call Dimension Express from your fax
machine at [phone], or visit their Web site at www.dexpress.com. Enter the
code #8051 for Viking products. This will send you information on how to use the system
and the corresponding model code numbers. Dimension Express customer service
number is [phone].
All models with standard equipment are design-certified for residential installation.
© 2007, Viking Range Corporation
Specifications subject to change without notice.
All kitchen
cleanup products All kitchen cleanup products
C
19
18
