Viking VGWT241T User manual

PROFESSIONAL SERIES
BUILT-IN GAS OUTDOOR WOK/COOKER
ONE YEAR WARRANTY
Built-in gas woks (VGWT Series) and all of their component parts, except as detailed below*, are warranted to
be free from defects in material or workmanship under normal household use for a period of twelve (12)
months from the date of original retail purchase. Viking Range Corporation, warrantor, agrees to repair or
replace, at its option, any part which fails or is found to be defective during the warranty period.
*Porcelain and decorative items are warranted be free from defective materials or workmanship for a period of
ninety (90) days from the date of original retail purchase. ANY DEFECTS MUST BE REPORTED TO THE
SELLING DEALER WITHIN NINETY (90) DAYS FROM DATE OR ORIGINAL PURCHASE.
FIVE YEAR WARRANTY
Any burner which fails due to defective materials or workmanship in normal household use during the second
through the fifth year from the date of original retail purchase will be repaired or replaced, free of charge for
the part itself, with the owner paying all other costs, including labor.
LIFETIME LIMITED WARRANTY
Any stainless steel part which rusts through due to defective material or workmanship in normal use during
the second year through the useful lifetime of the unit from date of original retail purchase will be repaired or
replaced, free of charge for the part itself, with the owner paying all other costs, including labor.
This warranty extends to the original purchaser of the product warranted hereunder and to each transferee
owner of the product during the term of warranty.
This warranty shall apply to products purchased and located in the United States and Canada. Products must
be purchased in the country where the service is requested. Warranty labor shall be performed by an
authorized Viking Range Corporation service agency or representative. Warranty shall not apply to damage
resulting from abuse, accident, natural disaster, loss of electrical power to the product for any reason,
alteration, outdoor use, improper installation, improper operation or repair or service of the product by
anyone other than an authorized Viking Range Corporation service agency or representative. This warranty
does not apply to commercial usage. Warrantor is not responsible for consequential or incidental damage
whether arising out of breach of warranty, breach of contract, or otherwise. Some jurisdictions do not allow
the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
Owner shall be responsible for proper installation, providing normal care and maintenance, providing proof of
purchase upon request, and making the appliance reasonably accessible for service. If the product or one of
its component parts contains a defect or malfunction during the warranty period, after a reasonable number of
attempts by the warrantor to remedy the defects or malfunctions, the owner is entitled to either a refund or
replacement of the product or its component part or parts. Warrantor’s liability on any claim of any kind, with
respect to the goods or services covered hereunder, shall in no case exceed the price of the goods or service
or part thereof which gives rise to claim.
WWAARRRRAANNTTYYSSEERRVVIICCEE::Under the terms of this warranty, service must be performed by a factory authorized
Viking Range Corporation service agent or representative. Service will be provided during normal business
hours, and labor performed at overtime or premium rates shall not be covered by this warranty. To obtain
warranty service, contact the dealer from whom the product was purchased, an authorized Viking Range
Corporation service agent, or Viking Range Corporation. Provide the model and serial number and date of
original purchase. For the name of your nearest authorized Viking Range Corporation service agency, call the
dealer from whom the product was purchased or Viking Range Corporation. IIMMPPOORRTTAANNTT::Retain proof of
original purchase to establish warranty period.
The return of the Owner Registration Card is not a condition of warranty coverage. You, however, should
return the Owner Registration Card so that Viking Range Corporation can contact you should any question of
safety arise which could affect you.
Any implied warranties of merchantability and fitness applicable to the above described burner are limited in
duration to the period of coverage of the applicable express written limited warranties set forth above. Some
jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also
have other rights which may vary from jurisdiction to jurisdiction.
VIKING RANGE CORPORATION
111 Front Street • Greenwood, Mississippi (MS) 38930 USA • [phone]
Specifications subject to change without notice
For more product information, call 1-888-VIKING1 (845-4641), or visit our web
site at http://www.vikingrange.com
F20093 (PS301VR)
Viking Range Corporation
use & care manual
built-in gas outdoor wok
“T” series

3
-Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
--Do not try to light any appliance.
-Do not touch any electric switch; do not use any phone in
your building.
-Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
-If you cannot reach your gas supplier, call the fire
department.
-Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
If the information in this manual is not followed exactly, a
fire or explosion may result causing property damage,
personal injury or death.
1. Read all instructions before using the product.
2. Install or locate the product only in accordance with the
provided instructions.
2
Congratulations . . .
Your purchase of this product attests to the importance you
place upon the quality and performance of the major appliances
you use. With minimal care, as outlined in this guide, this product
is designed to provide you with years of dependable service.
Please take the few minutes necessary to learn the proper and
efficient use and care of this quality product.
We appreciate your choosing a Viking Range Corporation
product and hope that you will again select our products for your
other major appliance needs.
Table of Contents
Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Before You Use Your Wok . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using Your Wok . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Service Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Rear Cover
WARNING
WARNING

5
4
Important Safety Instructions
1. TThheesseeuunniittssaarreeffoorroouuttddoooorruusseeoonnllyy!!Do not operate in enclosed
areas. This could result in carbon monoxide build-up which could
result in injury or death.
2. Your appliance should be installed by a qualified technician. The
appliance must be installed according to local codes. Have the
technician show you the location of the gas shutoff valve on the
appliance so you know where and how to turn off the gas if
necessary.
3. Do not attempt to repair or replace any part of this appliance unless
specifically recommended in this manual. All servicing should be
referred to a qualified technician. Warranty service must be
performed by an authorized service agency.
4. The “push-to-turn” knob of this appliance is designed to be child
safe. However, children should not be left alone in the kitchen while
the appliance is in use. Do not store items of interest to children
over the appliance. Children climbing to reach items could be
seriously injured.
5. Do not use water on grease fires. Never pick up a flaming pan.
Smother flaming pan by covering utensil completely with well-fitting
lid, cookie sheet or flat tray. Flaming grease outside of utensil can
be extinguished with baking soda or, if available, a multipurpose dry
chemical or foam-type extinguisher.
6. Never leave surface area unattended at high heat setting. Boilovers
cause smoking and greasy spillovers which may ignite.
7. Wear proper apparel. Loose-fitting or hanging garments should
never be worn while using the appliance.
8. Never use your appliance for warming or heating a room. This is
based on safety considerations.
9. Use proper pan size. Select utensils having flat bottoms large
enough to cover the burner. Using undersized utensils allows the
flame to come up the side of the utensil, scorching the outside of
the utensil and making clean-up more difficult.
10. The flame of the burner should be adjusted to cover the bottom of
the pan. Excessive burner setting may cause scorching of adjacent
countertop surfaces, as well as the outside of the utensil. This is
based on safety considerations.
11. Use only dry pot holders. Damp pot holders on hot surfaces may
result in burns from steam. Do not let pot holder touch hot surface
areas. Do not use a towel or other bulky cloth.
12. To reduce the risk of burns, ignition of flammable materials, and
spillage due to unintentional contact with the utensil, the handle of
provided utensil should be positioned so that it is turned to side of
the unit, away from the front.
13. Surface areas near burners may become hot enough to cause burns.
During and after use, do not touch areas near burners until they
have had sufficient time to cool.
14. Once the unit is installed as outlined in the Installation Instructions, it
is important that the fresh air supply is not obstructed.
15. Storage cabinet areas above the appliance must be a minimum of
36 inches above the appliance and cannot project more than 13
inches outward from rear wall. Beware of potential hazards
associated with retrieving items from such cabinets when the
appliance is in operation.
17. Keep the ventilation openings of the gas cylinder enclosure free and
clear from debris.
18. Spiders and insects can nest in the burners of the unit and block the
gas and air flow to the burner ports. This may cause a fire behind
the manifold cover. Inspect and clean the burners periodically.
19. If the outdoor cooking appliance is not in use, the gas must be
turned off at the supply cylinder.
20. Gas cylinders must be stored outdoors out of the reach of children
and must not be stored in a building, garage, or other enclosed
areas.
21. Before lighting the burners, inspect the gas supply hose. If there is
evidence of cuts, wear, or abrasions, it must be replaced prior to
use.
22. If the following instructions are not followed exactly, a fire causing
death or serious injury may occur:
-Do not store a spare LP gas cylinder under or near this appliance.
-Never fill the cylinder beyond 80 percent full.
SAVE THESE INSTRUCTIONS

76
Before You Use Your Wok
All products are wiped clean with solvents at the factory to
remove any visible signs of dirt, oil and grease which may have remained
from the manufacturing process. Before starting to cook, clean the wok
thoroughly with hot, soapy water.
Wok Pan w/Lid
Remove all packaging materials and temporary labels from the
wok. Clean thoroughly with hot soapy water and dry thoroughly. Apply
a light coat of vegetable oil (do not use corn oil) to the entire inside
surface with a paper towel. Heat the wok on a medium setting until the
cooking surface turns golden brown. Repeat this procedure several
times. This seasoning seals the pores of the metal, keeps food from
sticking, and prevents the wok from rusting. Wipe off excess oil before
using or storing.
For LP units, check the connection with a soap and water
solution after attaching the hose. Make sure there is gas in the tank and
tank is upright. Keep a spray bottle of soapy water near the gas
supply valve and check the connections for gas leaks before each
use.
Using Your Wok
Lighting the Burner
CAUTION: Before lighting the burners, remove the outdoor
cover!
Push and turn the control knob until the “OFF” position on the
knob aligns with the “LIGHT” position on the control panel.
IImmmmeeddiiaatteellyypprreesssstthheeeelleeccttrroonniicciiggnniittiioonnbbuuttttoonn..You will hear a
clicking sound. At the same time a spark will be provided at the grill
burner. If the burner does not light in 4 seconds, turn the knob to
“off” and wait 5 minutes before trying again..This will allow
accumulated gas to dissipate. After several failed attempts the burner
can be lit with a paper book match and the lighting rod located in the
drip tray.
For proper lighting and efficient performance of the burner, it is
necessary to keep the igniter and burner ports clean. If the flame is
uneven, flutters, makes excessive noise or lifts, check to see if the burner
ports are clogged. If the ports are clogged, use a wire, straightened
paper clip, or needle to clear the ports. Do not use a toothpick; it
could break off in the port. If the condition persists, contact an
authorized service agency for adjustments.
To light with a Match
If you have just attempted to light the burner with the ignitor,
allow 5 minutes for any accumulated gas to dissipate. Keep your face
as far away from the burner as possible. Place the lit match and the
lighting rod (supplied in the drip tray) next to the burner. Push and
turn the control knob. If the burner does not light in 4 seconds,
turn the knob “off”, wait 5 minutes and try again.
Control
knob
Electronic
ignition
button

9
Wok Pan w/Lid
Wash the wok after each use in hot, soapy water. Do not use
harsh abrasives or scouring pad as they can harm the protective
seasoning. Dry thoroughly. Apply a light coat of cooking oil to the
inside surface with a paper towel. Place over medium heat for 15 - 30
seconds. Remove from heat and allow to cool. Wipe off excess oil
before storing in an inside cabinet. Do not store the wok pan and lid
outdoors.
Stainless Steel Parts
All stainless steel body parts should be wiped with hot, soapy
water at the end of each cooling period or with a liquid cleaner
designed for stainless steel when soapy water will not do the job. DO
NOT USE steel wool, abrasive cleansers, cloths, or powders. If it is
necessary to scrape the stainless to remove encrusted materials, soak the
area with hot towels to loosen the material, then use a nylon spatula or
scraper. DO NOT USE a metal knife, spatula, or any other metal tool to
scrape stainless steel. Do not permit citrus or tomato juice to remain on
the stainless steel surface, as citric acid will permanently discolor stainless
steel.
8
Cleaning and Maintenance
Any piece of equipment works better and lasts longer when
maintained properly and kept clean. Cooking equipment is no
exception. Your appliance must be kept clean and maintained properly.
Porcelain Parts (Grate)
Allow the grate and grate support to cool to a safe temperature
level. Wipe up spillovers as soon as possible after they occur and before
they get a chance to burn in and cook solid. The grate and grate
support are coated with a porcelain enamel finish for durability. Wash in
hot, soapy water and rinse clean. For stubborn stains, use a mild
abrasive cleanser or non-abrasive soap-filled pad. Abrasive cleansers
used vigorously or too often can eventually scratch and harm the enamel.
Cast Iron Burner
For proper lighting and performance of the burner, keep the
electric igniter and burner ports clean. It is necessary to clean these only
when the flame does not burn blue completely around all rings of the
burner, when there is a severe spillover or when the burner does not
light, even though the electric spark igniter sparks.
Burner
ports
Venturi tube
Orifice
Clean the burner by scraping off burned on food soil. Use a wire, a
straightened paper clip, or needle to clean the ports. Do not use a
toothpick; it could break off in the port. Be sure the venturi tube
remains dry.
Using the Trivet Grate (Center Grate)
The trivet
grate converts the
large burner grate
to a grate suitable
for use with large
stock pots. To use
the trivet grate,
place the small
grate in the center
of the large grate.
Turn the trivet
grate until the feet
on the trivet grate
sits inside the
notches located on
the center ring of
the large grate.
Trivet grate feet
Notches

1110
Service Information
If your appliance should fail to operate:
1. Is the electrical cord securely inserted into the electrical outlet?
2. Is the circuit breaker open, or is fuse blown?
3. Is there gas supply to the appliance?
If service is required:
1. Call your dealer or authorized service agency. The name of the
authorized service agency can be obtained from the dealer or
distributor in your area.
2. Have the following information readily available:
a. Model number
b. Serial number
c. Date purchased
d. Name of dealer from whom purchased.
3. Clearly describe the problem that you are having.
If you are unable to obtain the name of an authorized service agency, or
if you continue to have service problems, contact Viking Range
Corporation at [phone] or write to:
VIKING RANGE CORPORATION
PREFERRED SERVICE
111 Front Street
Greenwood, Mississippi (MS) 38930 USA
Record the information indicated below. You will need it if service
is ever required. The serial number for your built-in wok is located on
the left hand side under the grate support.
Model number: Serial number:
Date of purchase: Date installed:
Dealer’s name:
Address:
If service requires installation of parts, use only authorized parts to
ensure protection under the warranty.
THIS MANUAL SHOULD REMAIN WITH THE APPLIANCE FOR
FUTURE REFERENCE.
Spider and Insect Warning!!
Spiders and insects can nest in the burners of this or any other
unit located outdoors and cause the gas to flow from the front of the
burner. This is a very dangerous condition which can cause a fire to
occur behind the valve panel, thereby damaging the grill and making it
unsafe to operate.
When to look for spiders:
You should inspect the burners at least once a year or
immdiately if any of the following conditions occur:
1. The smell of gas along with the burner flames appearing yellow.
2. The gas wok does not reach the proper temperatures.
3. The gas wok heats unevenly.
4. The burner makes a popping noise.
Brass Parts
All brass special ordered parts are coated with an epoxy coating.
DDooNNoottUUsseeBBrraassssoorrAAbbrraassiivveeCClleeaanneerrssoonntthheeBBrraassssOOppttiioonnPPaarrttss..They
should be wiped regularly with hot, soapy water. When hot soapy water
will not do the job, use every day household cleaners that are not
abrasive.
