Viking Professional Custom VGCC530-4B User manual

OVEN CLEAN
GRIDDLEOVEN
Convection fanConvection fan
Removable bottomRemovable bottom
Oven racks (3)Oven racks (3)
Bake BurnerBake Burner
Oven lightsOven lights
Interior Oven
Light Switch
Left Rear Burner
Control Knob
(15,000 BTU)
Left Front Burner
Control Knob
(15,000 BTU)
Grill
Control
Knob
Right Rear Burner
Control Knob
(15,000 BTU)
Right Front Burner
Control Knob
(15,000 BTU)
Griddle
Control
Knob
Griddle
Indicator Light
Right Oven
Function
Selector Knob
(VGSC only)
Right Oven
Temperature
Indicator Light
Self-Clean
Indicator
Light
(VGSC only)
Right Oven
Temperature
Control Knob
Infrared Broil BurnerInfrared Broil Burner
Convection
Fan Switch
(VGCC only)
Automatic
Re-Ignition
Thermal-Convection
Left Oven
Temperature
Indicator Light
Left Oven
Temperature
Control Knob
Range Controls
Surface Heat Settin s*
VariSimmer™
Melting and simmering small
quantities, steaming rice, and sauces
HI
Boiling water quickly, deep-fat frying in
large utensil
MED HI
Maintaining fast boil on large quantities,
high temperature frying, and pan broiling
MED
Maintaining slow boil on large
quantities, sauteing, browning,
braising and pan-frying
MED LOW
Simmering large quantities, low
temperature frying (eggs, etc.),
heating milk, cream sauces, gravies,
and pudding
LOW
Melting large quantities
Griddle/Simmer Plate
Operation/Settin s
• Turn the griddle control knob to
desired temperature setting.
• ALWAYS turn off when not in use,
or lower the heat between cooking
loads.
Grill Operation/Settin s
• Turn on ventilator (separate product).
• Turn control knob to HI.
• Preheat on HI for 5 to 10 minutes.
• Place food on grill, cook as
desired.
*Note: The above information is given as a g ide only. Yo may need to vary the heat settings to s it yo r personal req irements.
BAKE
(Natural
Airflow Bake)
Full power heat is
radiated from the
U-shaped bake
burners in the
bottom of the
oven cavity and is
circulated with natural airflow. This function is
recommended for single rack baking. Many
cookbooks contain recipes to be cooked in the
conventional manner. Conventional baking is suitable
for dishes that require a high temperature. Use this
setting for baking and casseroles.
CONVECTION
BAKE
Heat is radiated
from the U- shaped
bake burners in the
bottom of the oven
cavity. The heated
air is circulated by
one motorized fan
in the rear of the oven providing a more even heat
distribution. Multiple rack use is possible for the
largest baking job. When roasting, cool air is quickly
replaced—searing meats on the outside and retaining
more juices and natural flavor on the inside with less
shrinkage. This even circulation of air equalizes the
temperature throughout the oven cavity and
eliminates the hot and cold spots found in
conventional ovens.
BROIL
(Infrared Broil)
The broil burner at
the top of the oven
heats the metal
screen until it
glows. Heat
radiates from the
GourmetGlo™
infrared broiler located at the top of the oven cavity.
The distance between the foods and the broil
elements determines broiling speed. For “fast”
broiling, food may be as close as 2 inches (5 cm) to
the broil element or on the top rack. “Fast” broiling is
best for meats where rare to medium doneness is
desired. Use this setting for broiling small and
average cuts of meat.
CONVECTION
BROIL
(Infrared
Convection
Broil)
The top burner
operates at full
power. This function
is exactly the same
as regular broiling with the additional benefit of air
circulation by the motorized fan in the rear of the
oven. Smoke is reduced since the airflow also reduces
peak temperatures on the food. Use this setting for
broiling thick cuts of meats.
Convection Dehydration
This oven is designed not only to cook, but also to
dehydrate fruits and vegetables.
1. Prepare the food as recommended.
2. Arrange the food on drying racks (not included with
the oven; contact a local store handling speciality
cooking utensils).
3. VGSC models—Set the temperature control to
200°F (93.3°C) and turn the selector to
“CONVECTION BAKE”.
VGCC models—Set the temperature control to
200°F (93.3°C) and turn on the convection fan
switch.
Convection Defrost
1. Place the frozen food on a baking sheet.
2. Set the temperature control to “OFF”.
3. VGSC models—Turn the selector to
“CONVECTION BAKE” and set the temperature to
“OFF”.
VGCC models—Set the oven temperature control
knob to “OFF” and turn on the convection fan
switch.
Self-Clean Cycle (VGSC Models Only)
This range features a self-cleaning cycle. During this
cycle, the oven reaches elevated temperatures in
order to burn off soil and deposits. A powder ash
residue is left in the bottom of the oven after
completion of the self-clean cycle. See Use and Care
Man al for self-clean cycle instr ctions.
Oven Settings
natural airflow bake
convection bake
infrared broil
convection broil
Note: 48” 4-B rner/Griddle/Grill model shown
Preheat
For best results, it is
extremely important
that you preheat your
oven to the desired
cooking temperature before
placing food items in the oven to
begin cooking. In many cooking
modes, partial power from the broiler
is used to bring the oven to the preheat
temperature. Therefore, placing food items in the oven
during the preheat mode is not recommended.
• BAKE (Natural Airflow Bake)
Use this setting for baking, roasting, and casseroles.
• CONVECTION BAKE
Use this setting to bake and roast foods at the same
time with minimal taste transfer.
• BROIL (Infrared Broil)
Use this setting for broiling dark meats at
1” thickness or less where rare or medium doneness
is desired.
• CONVECTION BROIL (Infrared
Convection Broil)
Use this setting to broil thick cuts of meat.
• Convection Dehydrate
Use this function to dehydrate fruits and vegetables.
• Convection Defrost
Use this function to defrost foods.
OVEN
FUNCTION
OVEN
TEMPERATURE
Oven Functions
plates which are designed to catch drippings and
circulate a smoke flavor back into the food. Beneath the
flavor generator plates is a two piece drip pan which
catches any drippings that might pass beyond the flavor
generator plates. This unique grilling system is designed
to provide outdoor quality grilling indoors.
Griddle/Simmer Plate, Bake Burner,
Infrared Burner
Turning the thermostat counter clockwise to any
“ON” position activates an igniter and opens an
electromechanical valve in the system to start the gas
valve. The griddle has a power “ON” light which glows
when the griddle thermostat is turned on. The light
cycles on and off with the burner. It is not possible to
use both the infrared burner and the bake burners at
the same time. The design of the system will not
permit this, both for control of bake/broiler and for
safety of use.
Li htin the Burners
All burners are ignited by electric
ignition. There are no open-flame,
“standing” pilots.
VariSimmer™
Simmering is a cooking technique in
which foods are cooked in hot liquids kept at or just
barely below the boiling point of water. Simmering
ensures gentler treatment than boiling to prevent food
from toughening and/or breaking up. The size of the
pan and the volume of food can have a significant effect
on how high or low a flame is needed for simmering.
For this reason, Viking range and rangetop burners are
engineered with a VariSimmer setting. The VariSimmer
setting is not just one simmer setting, but provides a
variable range of simmer settings. This variable range of
simmer settings allows you to adjust the flame height to
achieve the best simmer depending on the type and
quantity of food being simmered. It is this ability that
makes the VariSimmer setting the most accurate and
trustworthy simmer on the market.
TruPowerPlus™Burner (where applicable)
Certain model ranges are equipped with a TruPowerPlus
1 ,500 BTU burner in the front right burner position.
This burner is designed to provide extra high heat
output, especially when using large pans, and should be
used for boiling large quantities or if you need to bring
something to a boiled quickly. While the TruPowerPlus
burner has the extra power needed to bring large
quantities of liquid to a boil rapidly, it is also able to be
turned down low enough to provide a very low and
delicate simmer making this burner the most versatile
burner on the market.
Griddle/Simmer Plate (where applicable)
The optional 15,000 BTU griddle is constructed of
machined steel with a blanchard finish and is uniquely
designed to offer excellent cooking performance as well
as easy clean up. The griddle is equipped with an
electronic thermostat to maintain an even temperature
across the griddle once the desired temperature has
been set. The griddle has a power “ON” indicator light
which glows when the griddle thermostat has been
turned on. This will cycle on and off as needed to
indicate the thermostat is maintaining the selected
temperature. Before the griddle is used, it is important
to season the griddle. See instructions in the Use &
Care Manual for steps on seasoning the griddle.
Char-Grill (where applicable)
The optional 1 ,000 BTU char-grill is equipped with a
single piece, heavy-duty porcelainized cast-iron grill
grate for easy movement of grilling items. Beneath the
grill grate are two slotted porcelainized flavor generator
Surface Operation

F20544B EN (0 1009J)
VIKING RANGE CORPORATION
111 Front Street • Greenwood, Mississippi
3 930 USA • [phone]
Warnings (cont.)Warnings (cont.)
Warnings
Warnin and Important Safety Instructions appearin
in this manual are not meant to cover all possible
conditions and situations that may occur. Common
sense, caution, and care must be exercised when
installin , maintainin , or operatin the appliance.
ALWAYS contact the manufacturer about problems or
conditions you do not understand.
Reco nize Safety Symbols,
Words, Labels
Read and follow all instructions before usin this
appliance to prevent the potential risk of fire, electric
shock, personal injury or damage to the appliance as
a result of improper usage of the appliance. Use
appliance only for its intended purpose as described
in this manual.
To ensure proper and safe operation:
Appliance must be properly installed and grounded
by a qualified technician. DO NOT attempt to adjust,
repair, service, or replace any part of your appliance
unless it is specifically recommended in this manual.
All other servicing should be referred to a qualified
servicer. Have the installer show you the location
of the gas shutoff valve and how to shut it off
in an emergency.
Important Safety Notice and Warnin
The California Safe Drinking Water and Toxic
Enforcement Act of 19 6 (Proposition 65) requires the
Governor of California to publish a list of substances
known to the State of California to cause cancer or
reproductive harm, and requires businesses to warn
customers of potential exposures to such substances.
Users of this appliance are hereby warned that when
the oven is engaged in the self-clean cycle, there may
be some low-level exposure to some of the listed
substances, including carbon monoxide. Exposure to
these substances can be minimized by properly
venting the oven to the outdoors by opening the
windows and/or door in the room where the appliance
is located during the self-clean cycle.
Important notice re ardin pet birds:
NEVER keep pet birds in the kitchen or in rooms
where the fumes from the kitchen could reach. Birds
have a very sensitive respiratory system. Fumes
released during an oven self-cleaning cycle may be
harmful or fatal to birds. Fumes released due to
overheated cooking oil, fat, margarine and overheated
non-stick cookware may be equally harmful.
Viking Quick Reference Guide
Professional Freestanding Gas
& Gas Self-Clean Sealed Burner Ranges
DANGER
Hazards or unsafe practices which WILL result in
severe personal injury or death
WARNING
Hazards or unsafe practices which COULD result
in death severe personal injury or death
CAUTION
Hazards or unsaf practic s which COULD
r sult in minor p rsonal injury.
All safety messages will identify the hazard, tell you
how to reduce the chance of injury, and tell you what
can happen if the instructions are not followed.
WARNING
TIPPING HAZARD
To reduce the risk of the
appliance tipping, it must be
secured by a properly installed
anti-tip bracket(s). To make sure the bracket has
been installed properly, look behind the range with
a flashlight to verify proper installation engaged in
the rear top left corner of the range.
• THIS RANGE CAN TIP
• INJ RIES TO PERSONS CAN RES LT
• INSTALL ANTI-TIP DEVICE PACKED WITH
RANGE
• SEE INSTALLATION INSTR CTIONS
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect the electric power at the
main fuse or circuit breaker before
replacing bulb.
WARNING
BURN OR ELECTRICAL
SHOCK HAZARD
Make sure all controls are OFF and oven
is COOL before cleaning. Failure to do
so can result in burns or electrical shock.
CAUTION
To avoid sickness and food waste, DO NOT allow
defrosted food to remain in the oven for more than
two hours.
NOTICE
DO NOT turn the Temperature Control on during
defrosting. Turning the convection fan on will
accelerate the natural defrosting of the food
without the heat.
WARNING
BURN HAZARD
The oven door, especially the glass, can
get hot. Dang r of burning: DO NOT
touch th glass!
CAUTION
You must carefully check the food during the
dehydration process to ensure that it does not
catch fire.
CAUTION
BURN HAZARD
When self-cleaning, surfaces may get
hotter than usual. Therefore, children
should be kept away.
CAUTION
DO NOT store items of interest to children over
the unit. Children climbing to reach items could
be seriously injured.
NOTICE
Avoid any damage to oven vents. The vents need
to be unobstructed and open to provide proper
airflow for optimal oven performance.
NOTICE
The Cooling Fan should be operating when the
unit is in operation. If you notice the cooling fan is
not operating or you observe unusual or excessive
noise coming from the cooling fan, contact a
Viking Authorized Service Center before continuing
operation. Failure to do so can result in damage to
the oven or surrounding cabinets.
WARNING
If th information in this manual is not
follow d xactly, a fir or xplosion may
r sult causing prop rty damag , p rsonal
injury or d ath.
WHAT TO DO IF YO SMELL GAS:
• DO NOT try to light any appliance.
• DO NOT touch any electrical switch.
• DO NOT use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
WARNING
DO NOT use commercial oven cleaners inside the
oven. se of these cleaners can produce hazardous
fumes or can damage the porcelain finishes.
WARNING
To avoid risk of property damage,
personal injury or death; follow
information in this manual exactly to
prevent a fire or explosion. DO NOT
store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any appliance.
WARNING
ELECTRICAL SHOCK HAZARD
DO NOT touch a hot oven light bulb with
a damp cloth as the bulb could break.
Should the bulb break, disconnect power
to the appliance before removing bulb to avoid
electrical shock.
WARNING
This range features a self-cleaning cycle. During
this cycle, the oven reaches elevated temperatures
in order to burn off soil and deposits. A powder ash
residue is left in the bottom of the oven after
completion of the self-clean cycle.
Note: DO NOT use commercial oven cleaners
inside the oven. Use of these cleaners can
produce hazardous fumes or can damage the
porcelain finishes. DO NOT line the oven with
aluminum foil or other materials. These items can
melt or burn during a self-clean cycle, causing
permanent damage to the oven.
CAUTION
DO NOT touch the exterior portions of
the oven after self-cleaning cycle has
begun, since some parts become
extremely hot to the touch!
During the first few times the self-cleaning feature
is used, there may be some odor and smoking
from the “curing” of the binder in the high-density
insulation used in the oven. When the insulation is
thoroughly cured, this odor will disappear. During
subsequent self-cleaning cycles, you may sense
an odor characteristic of high temperatures.
KEEP THE KITCHEN WELL-VENTED DURING
THE SELF-CLEAN CYCLE.
About Your Appliance
• For proper oven performance and operation,
DO NOT block or obstruct the oven vent duct
located on the right side of the air grille.
• Avoid touching oven vent area while oven is on
and for several minutes after oven is turned off.
When the oven is in use, the vent and surrounding
area become hot enough to cause burns. After
oven is turned off, DO NOT touch the oven vent or
surrounding areas until they have had sufficient
time to cool.
• Other potentially hot surfaces include rangetop,
areas facing the rangetop, oven vent, surfaces near
the vent opening, oven door, areas around the
oven door and oven window.
• The misuse of oven doors (e.g. stepping, sitting,
or leaning on them) can result in potential hazards
and/or injuries.
WARNING
NEVER use appliance as a space heater to heat or
warm a room to prevent potential hazard to the user
and damage to the appliance. Also, DO NOT use the
rangetop or oven as a storage area for food or
cooking utensils.
C A U T I O N
To prevent possible damage to cabinets and
cabinet finishes, use only materials and finishes
that will not discolor or delaminate and will
withstand temperatures up to 194° F (90° C). Heat
and moisture resistant adhesive must be used if the
product is to be installed in laminated cabinetry.
Check with your builder or cabinet supplier to make
sure that the materials meet these requirements.
