F20933 EN (031312)
Viking Range Corporation
111 Front Street
Greenwoo , Mississippi 38930 USA
(662) 455-1200
For pro uct information, call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at vikingrange.com
Freestanding 30” Gas
Self-Clean Sealed Burner Range
Use & Care
Congratulations
Congratulations an welcome to the elite worl of Viking ownership.
We hope you will enjoy an appreciate the care an attention we have
put into every etail of your new, state-of-the-art range.
Your Viking range is esigne to offer years of reliable service. This
Use an Care Manual will provi e you with the information you nee
to become familiar with your range’s care an operation.
Your complete satisfaction is our ultimate goal. If you have any
questions or comments about this pro uct, please contact the ealer
from whom you purchase it, or contact our Consumer Support Center
at 1-888-VIKING1 (845-4641).
We appreciate your choice of a Viking range an hope that you will
again select our pro ucts for your other major range nee s.
For more information about the complete an growing selection
of Viking pro ucts, contact your ealer or visit us online at
vikingrange.com
Getting Starte
Warnings ____________________________________________________4
Before Using Range__________________________________________15
Pro uct Controls
Range Features _____________________________________________16
Oven Functions an Settings _________________________________17
Operation
Surface Operation ___________________________________________18
Lighting Burners___________________________________________18
Surface Burners-Automatic Re-ignition _______________________18
Surface Cooking Tips ______________________________________18
Cooking Vessels ___________________________________________20
Oven Features ______________________________________________21
Rack Positions_____________________________________________21
Using the Oven _____________________________________________22
Conventional an Convection Cooking_______________________22
Baking _____________________________________________________23
BAKE (Natural Airflow Bake) ________________________________23
CONVECTION BAKE ______________________________________23
Broiling_____________________________________________________28
BROIL____________________________________________________28
CONVECTION BROIL______________________________________28
Convection Dehy rate _______________________________________32
Convection Defrost __________________________________________33
Cooking Substitutes Charts ___________________________________34
Pro uct Care
Cleaning an Maintenance ___________________________________35
Self-Clean Cycle_____________________________________________38
Replacing Oven Lights _______________________________________40
Door Removal_______________________________________________41
Door Replacement an A justment____________________________42
Troubleshooting _____________________________________________43
Service Information __________________________________________44
Warranty ___________________________________________________45
Table of Contents
32
Warnings
54
Getting Starte
Getting Starte
Warning an Important Safety Instructions appearing in this manual
are not meant to cover all possible con itions an situations that may
occur. Common sense, caution, an care must be exercise when
installing, maintaining, or operating the appliance.
ALWAYS contact the manufacturer about problems or con itions you o not
un erstan .
Recognize Safety Symbols, Wor s, Labels
Rea an follow all instructions before using this appliance to prevent
the potential risk of fire, electric shock, personal injury or amage to the
appliance as a result of improper usage of the appliance. Use appliance
only for its inten e purpose as escribe in this manual.
To ensure proper an safe operation: Appliance must be properly
installe an groun e by a qualifie technician. DO NOT attempt to
a just, repair, service, or replace any part of your appliance unless it is
specifically recommen e in this manual. All other servicing shoul be
referre to a qualifie servicer. Have the installer show you the location of
the gas shutoff valve an how to shut it off in an emergency. A certifie
technician is require for any a justments or conversions to Natural or LP gas.
KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Hazards or unsafe pra ti es whi h WILL result in
severe personal injury or death
Hazards or unsafe pra ti es whi h COULD result in
death or severe personal injury
DANGER
Hazards or unsafe pra ti es whi h COULD result in
minor personal injury.
All safety messages will identify the hazard, tell you how
to reduce the chance of injury, and tell you what can happen if
the instructions are not followed.
WARNING
CAUTION
Warnings
WARNING
If the information in this manual is not followed exa tly,
a fire or explosion may result ausing property damage,
personal injury or death.
HAT TO DO IF YOU SMELL GAS:
•DO NOT try to light any appliance.
•DO NOT touch any electrical switch.
•DO NOT use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer,
service agency or the gas supplier.
WARNING
To avoid risk of property damage, personal injury or death;
follow information in this manual exactly to prevent a fire or
explosion. DO NOT store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any appliance.
WARNING
WARNING
DO NOT use commercial oven cleaners inside the oven. Use of these
cleaners can produce hazardous fumes or can damage the porcelain
finishes.
TIPPING HAZARD
To reduce the risk of the appliance tipping, it must
be secured by a properly installed anti-tip bracket(s).
To make sure the bracket has been installed
properly, look behind the range with a flashlight to verify proper
installation engaged in the rear top left corner of the range.
• THIS RANGE CAN TIP
• INJURIES TO PERSONS CAN RESULT
• INSTALL ANTI-TIP DEVICE PACKED ITH RANGE
• SEE INSTALLATION INSTRUCTIONS
7
6
Warnings
Getting Starte
Getting Starte
To Prevent Fire or Smoke Damage
• Be sure all packing materials are remove from the appliance before
operating it.
• Keep area aroun appliance clear an free from combustible materials,
gasoline, an other flammable vapors an materials.
• If appliance is installe near a win ow, proper precautions shoul be taken
to prevent curtains from blowing over burners.
•
NEVER leave any items on the rangetop. The hot air from the vent may ignite
flammable items an may increase pressure in close containers which may
cause them to burst.
• Many aerosol-type spray cans are EXPLOSIVE when expose to heat an
may be highly flammable. Avoi their use or storage near an appliance.
• Many plastics are vulnerable to heat. Keep plastics away from parts of the
appliance that may become warm or hot. DO NOT leave plastic items on
the rangetop as they may melt or soften if left too close to the vent or a
lighte surface burner.
• Combustible items (paper, plastic, etc.) may ignite an metallic items
may become hot an cause burns.
DO NOT
pour spirits over hot foo s.
DO NOT
leave oven unsupervise when rying herbs, brea s, mushrooms,
etc; fire hazar .
In Case of Fire
Turn off appliance an ventilating hoo to avoi sprea ing the flame. Extinguish
flame then turn on hoo to remove smoke an o or.
•Cooktop: Smother fire or flame in a pan with a li or cookie sheet.
• NEVER pick up or move a flaming pan.
• Oven: Smother fire or flame by closing the oven oor. DO NOT use water
on grease fires. Use baking so a, a ry chemical or foam-type extinguisher to
smother fire or flame.
• GREASE–Grease is flammable an shoul be han le carefully.
DO NOT
use water on grease fires. Flaming grease can be extinguishe with
baking so a or, if available, a multipurpose ry chemical or foam type
extinguisher. Let fat cool before attempting to han le it.
DO NOT
allow
grease to collect aroun the oven or in vents. Wipe up spillovers
imme iately.
Chil Safety
• NEVER leave chil ren alone or unsupervise near the appliance when it is in
use or is still hot.
• NEVER allow chil ren to sit or stan on any part of the appliance as they
coul be injure or burne .
•DO NOT store items of interest to chil ren over the unit. Chil ren climbing to
reach items coul be seriously injure .
Chil Safety (cont.)
• Chil ren must be taught that the appliance an utensils in it can be hot.
Let hot utensils cool in a safe place, out of reach of small chil ren.
Chil ren shoul be taught that an appliance is not a toy. Chil ren shoul not
be allowe to play with controls or other parts of the appliance.
Cooking Safety
• To eliminate the hazar of reaching over hot surface burners, cabinet storage
shoul not be provi e irectly above a unit. If storage is provi e , it shoul
be limite to items which are use infrequently an which are safely store
in an area subjecte to heat from an appliance. Temperatures may be unsafe
for some items, such as volatile liqui s, cleaners or
aerosol sprays.
•
ALWAYS
place a pan on a surface burner before turning it on. Be sure
you know which knob controls which surface burner. Make sure the correct
burner is turne on an that the burner has ignite . When cooking is
complete , turn burner off before removing pan to prevent exposure to
burner flame.
•
ALWAYS
a just surface burner flame so that it oes not exten beyon the
bottom e ge of the pan. An excessive flame is hazar ous, wastes energy
an may amage the appliance, pan or cabinets above the appliance.
This is base on safety consi erations.
• NEVER leave a surface cooking operation unatten e especially when using
a high heat setting or when eep fat frying. Boilovers cause smoking an
greasy spillovers may ignite. Clean up greasy spills as soon as possible.
DO NOT use high heat for exten e cooking operations.
• DO NOT heat unopene foo containers, buil up of pressure may cause
the container to explo e an result in injury.
• Use ry, stur y pot-hol ers. Damp pot-hol ers may cause burns from steam.
Dishtowels or other substitutes shoul NEVER be use as pothol ers
because they can trail across hot surface burners an ignite or get caught on
appliance parts.
•
ALWAYS
let quantities of hot fat use for eep fat frying cool before
attempting to move or han le.
•DO NOT let cooking grease or other flammable materials accumulate in or
near the appliance, hoo or vent fan. Clean hoo frequently to prevent
grease from accumulating on hoo or filter. When flaming foo s un er the
hoo , turn the fan off.
•NEVER wear garments ma e of flammable material or loose fitting or
long-sleeve apparel while cooking. Clothing may ignite or catch utensil
han les. DO NOT
rape towels or materials on oven oor han les. These
items coul ignite an cause burns.
Warnings
9
Utensil Safety
(cont.)
• Only certain types of glass, glass/ceramic, ceramic or glaze utensils are
suitable for rangetop surface or oven usage without breaking ue to the
su en change in temperature. Follow manufacturer's instructions when
using glass.
• This appliance has been teste for safe performance using conventional
cookware. DO NOT use any evices or accessories that are not specifically
recommen e in this gui e. DO NOT use eyeli covers for the surface units,
stovetop grills, or a -on oven convection systems. The use of evices or
accessories that are not expressly recommen e in this manual can create
serious safety hazar s, result in performance problems, an re uce the life of
the components of the appliance.
• The flame of the burner shoul be a juste to just cover the bottom of
the pan or pot. Excessive burner setting may cause scorching of a jacent
counter-top surfaces, as well as the outsi e of the utensil. This is base
on safety consi erations.
Heating Elements
• NEVER touch oven bake an broil burner areas or interior surfaces of oven.
• Bake an broil burners may be hot even though they are ark in color. Areas
near burners an interior surfaces of an oven may become hot enough to
cause burns.
•
During an after use, DO NOT touch or let clothing or other flammable
materials contact heating elements, areas near elements, or interior surfaces
of oven until they have ha sufficient time to cool.
Other surfaces of the
oven may become hot enough to cause burns, such as the oven vent
opening, the surface near the vent opening, an the oven oor win ow.
Cleaning Safety
• Turn off all controls an wait for appliance parts to cool before touching or
cleaning them. DO NOT touch the burner grates or surroun ing areas until
they have ha sufficient time to cool.
• Clean appliance with caution. Use care to avoi steam burns if a wet sponge
or cloth is use to wipe spills on a hot surface. Some cleaners can pro uce
noxious fumes if applie to a hot surface.
•
DO NOT
clean oor gasket. It is essential for a goo tight seal. Care
shoul be taken not to rub, amage, or move the gasket.
• No commercial oven cleaner or oven liner protective coating such as
aluminum foil shoul be use in or aroun any part of the oven.
Improper oven liners may result in a risk of electric shock or fire. Keep
oven free from grease buil up.
Getting Starte
Warnings
8
Cooking Safety
(cont.)
•
ALWAYS
place oven racks in the esire positions while oven is cool.
Sli e oven rack out to a or remove foo , using ry, stur y pot-hol ers.
ALWAYS
avoi reaching into the oven to a or remove foo . If a rack
must be move while hot, use a ry pot-hol er.
•ALWAYS turn the oven off at the en of cooking.
• Use care when opening the oven oor. Let hot air or steam escape before
moving or replacing foo .
•NEVER use aluminum foil to cover oven racks or oven bottom. This coul
result in risk of electric shock, fire, or amage to the appliance. Use foil only
as irecte in this gui e.
•PREPARED FOOD WARNING:
Follow foo manufacturer's instructions. If a
plastic frozen foo container an /or its cover istorts, warps, or is otherwise
amage uring cooking, imme iately iscar the foo an its container. The
foo coul be contaminate
.
• If you are “flaming” liquor or other spirits un er an exhaust, TURN THE
FAN OFF. The raft coul cause the flames to sprea out of control.
• Once the unit has been installe as outline in the Installation
Instructions, it is important that the fresh air supply is not obstructe .
The use of a gas cooking appliance results in the pro uction of heat an
moisture in the room in which it is installe . Ensure that the kitchen is
well-ventilate . Keep natural venting holes open or install a mechanical
ventilation evice. Prolonge or intensive use of the appliance may call
for a itional (such as opening a win ow) or more effective ventilation
(such as increasing the level of a mechanical ventilation if present).
Utensil Safety
• Use pans with flat bottoms an han les that are easily graspe an stay
cool. Avoi using unstable, warpe , easily tippe or loose-han le pans.
Also avoi using pans, especially small pans, with heavy han les as they
coul be unstable an easily tip. Pans that are heavy to move when fille
with foo may also be hazar ous.
• Be sure utensil is large enough to properly contain foo an avoi boilovers.
Pan size is particularly important in eep fat frying. Be sure pan will
accommo ate the volume of foo that is to be a e as well as the bubble
action of fat.
• To minimize burns, ignition of flammable materials an spillage ue to
unintentional contact with the utensil, DO NOT exten han les over
a jacent surface burners. ALWAYS turn pan han les towar the si e or back
of the appliance, not out into the room where they are easily hit or reache
by small chil ren.
•NEVER let a pan boil ry as this coul amage the utensil an the appliance.
• Follow the manufacturer's irections when using oven cooking bags.
Getting Starte
Warnings
11
About Your Appliance
• For proper oven performance an operation, DO NOT block or obstruct the
oven vent uct locate on the right si e of the air grille.
• Avoi touching oven vent area while oven is on an for several minutes after
oven is turne off. When the oven is in use, the vent an surroun ing area
become hot enough to cause burns. After oven is turne off, DO NOT touch
the oven vent or surroun ing areas until they have ha sufficient time to
cool.
• Other potentially hot surfaces inclu e rangetop, areas facing the rangetop,
oven vent, surfaces near the vent opening, oven oor, areas aroun the oven
oor an oven win ow.
• The misuse of oven oors (e.g. stepping, sitting, or leaning on them) can
result in potential hazar s an /or injuries.
Power Failure
If power failure occurs, the electric igniters will not work. No attempt shoul be
ma e to operate the appliance uring a power failure. Make sure the oven
control is in the “OFF” position.
Momentary power failure can occur unnotice . The range is affecte only when
the power is interrupte . When it comes back on, the range will function
properly without any a justments. A “brown-out” may or may not affect range
operation, epen ing on how severe the power loss is.
Warnings
10
Self-Clean Oven
• Clean only parts liste in this gui e. DO NOT clean oor gasket. The
oor gasket is essential for a goo seal. Care shoul be taken not to rub,
amage, or move the gasket. DO NOT use oven cleaners of any kin in
or aroun any part of the self-clean oven.
• Before self-cleaning the oven, remove broiler pan, oven racks an other
utensils an wipe up excessive spillovers to prevent excessive smoke,
flareups or flaming.
• This range features a cooling fan which operates automatically uring a
clean cycle. If the fan oes not turn on, cancel the clean operation an
contact an authorize servicer.
• It is normal for the rangetop cooking surface of the range to become hot
uring a self-clean cycle. Therefore, touching the rangetop cooking
surface uring a clean cycle shoul be avoi e .
Important Safety Notice an Warning
The California Safe Drinking Water an Toxic Enforcement Act of 1986
(Proposition 65) requires the Governor of California to publish a list of
substances known to the State of California to cause cancer or
repro uctive harm, an requires businesses to warn customers of potential
exposures to such substances. Users of this appliance are hereby warne
that when the oven is engage in the self-clean cycle, there may be some
low-level exposure to some of the liste substances, inclu ing carbon
monoxi e. Exposure to these substances can be minimize by properly
venting the oven to the out oors by opening the win ows an /or oor in
the room where the appliance is locate uring the self-clean cycle.
Important notice regar ing pet bir s:
NEVER keep pet bir s in the kitchen or in rooms where the fumes from the
kitchen coul reach. Bir s have a very sensitive respiratory system. Fumes
release uring an oven self-cleaning cycle may be harmful or fatal to
bir s. Fumes release ue to overheate cooking oil, fat, margarine an
overheate non-stick cookware may be equally harmful.
Getting Starte
Getting Starte
WARNING
NEVER use appliance as a space heater to heat or warm a room to prevent
potential hazard to the user and damage to the appliance. Also, DO NOT
use the rangetop or oven as a storage area for food or cooking utensils.
WARNING
ELECTRICAL SHOCK HAZARD
DO NOT
touch a hot oven light bulb with a damp cloth as the
bulb could break. Should the bulb break, disconnect power
to the appliance before removing bulb to avoid electrical shock.
Warnings
13
Warnings
Getting Starte
Warnings
12
Getting Starte
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect the electric power at the main fuse or circuit
breaker before replacing bulb.
WARNING
CAUTION
To avoid sickness and food waste, DO NOT allow defrosted food to
remain in the oven for more than two hours.
BURN OR ELECTRICAL SHOCK HAZARD
Make sure all controls are OFF and oven is COOL before
cleaning. Failure to do so can result in burns or electrical
shock.
WARNING
NEVER
cover any slots, holes or passages in the oven bottom or cover
an entire rack with materials such as aluminum foil. Doing so blocks
air flow through the oven and may cause carbon monoxide poisoning.
Aluminum foil linings may also trap heat, causing a fire hazard.
NOTICE
DO NOT turn the Temperature Control on during defrosting. Turning
the convection fan on will accelerate the natural defrosting of the food
without the heat.
CAUTION
BURN HAZARD
The oven door, especially the glass, can get hot. Danger of
burning: DO NOT tou h the glass!
CAUTION
DO NOT store items of interest to children over the unit. Children
climbing to reach items could be seriously injured.
CAUTION
You must carefully check the food during the dehydration process to
ensure that it does not catch fire.
WARNING
This range features a self-cleaning cycle. During this cycle, the oven
reaches elevated temperatures in order to burn off soil and deposits.
A powder ash residue is left in the bottom of the oven after completion
of the self-clean cycle.
Note: DO NOT use commercial oven cleaners inside the oven. Use of
these cleaners can produce hazardous fumes or can damage the
porcelain finishes. DO NOT line the oven with aluminum foil or other
materials. These items can melt or burn during a self-clean cycle,
causing permanent damage to the oven.
15
Before Using Range
All pro ucts are wipe clean with solvents at the factory to remove
any visible signs of irt, oil, an grease which may have remaine from
the manufacturing process. Before starting to cook, clean the range
thoroughly with hot, soapy water. There may be some burn off an
o ors on first use of the appliance—this is normal.
Oven
Important! Before first use, wipe interior with soapy water an ry
thoroughly. Then set the oven selector to bake, the thermostat to
450°F, an operate for an hour.
All mo els inclu e:
• Five performance mo es—inclu ing convection baking an
convection broiling—provi ing air circulation for shorter cooking
times with even results.
• Exclusive one-piece toole cooking surface contains spills for easy
cleaning.
• Convection baking with a hi en 30,000 BTU burner provi es a fast,
even baking for all your casserole ishes as well as easy cleanup.
• The close oor, broiler allows intense heat to sear elicate cuts of
meat provi ing that restaurant taste.
• Two lights illuminate the oven cavity with less glare.
• Six rack positions an three full extension gli e racks provi e ample
space for your baking nee s.
• This appliance is certifie by Star-K to meet strict regulations in
conjunction with specific instructions foun on www.star-k.org
Getting Starte
14
Getting Starte
Warnings
CAUTION
You must carefully check the food during the dehydration process to
ensure that it does not catch fire.
WARNING
DO NOT touch the exterior portions of the oven after self-
cleaning cycle has begun, since some parts become
extremely hot to the touch!
During the first few times the self-cleaning feature is used, there may
be some odor and smoking from the “curing” of the binder in the high-
density insulation used in the oven. hen the insulation is thoroughly
cured, this odor will disappear. During subsequent self-cleaning cycles,
you may sense an odor characteristic of high temperatures.
KEEP THE KITCHEN WELL-VENTED DURING THE
SELF-CLEAN CYCLE.
WARNING
BURN HAZARD
hen self-cleaning, surfaces may get hotter than usual.
Therefore, children should be kept away.
CAUTION
DO NOT store items of interest to children over the unit. Children
climbing to reach items could be seriously injured.
Pro uct Controls
17
16
Range Features
Pro uct Controls
Oven Functions an Settings
BAKE (Natural Airflow Bake)
Use this setting for baking, roasting, an casseroles.
CONVECTION BAKE
Use this setting to bake an roast foo s at the same time with minimal
taste transfer.
BROIL
Use this setting for broiling ark meats at 1” thickness or less where
rare or me ium oneness is esire .
CONVECTION BROIL
Use this setting to broil thick cuts of meat.
Convection Dehy rate (CONVECTION BAKE)
Use this function to ehy rate fruits an vegetables.
Convection Defrost (CONVECTION BAKE)
Use this function to efrost foo s.
Note: For more information on oven functions, see Operation”
section.
11
1 2 3 4 5 6 7 8 9 10
19
17
18
16 12
15
13
14
1. Interior oven light switch
2. Left rear burner control knob
3. Left front burner control knob
4. Center burner control knob
5. Oven function selector knob
6. Self-Clean in icator light
7. Oven temperature control knob
8. Oven temperature in icator light
9. Right rear burner control knob
10. Right front burner control knob
11. Backguar
12. One 9,000 BTU burner
13. One 12,000 BTU burner
14. One 18,000 ual stacke BTU burner
15. One 17,000 BTU burner
16. One 8,000 BTU burner
17. I entification plate
18. Three full extension gli e racks/Six rack positions
19. Broiler pan (locate insi e oven)
19
18
Surface Operation
Operation
Lighting Burners
All burners are ignite by electric ignition. There
are no open-flame, “stan ing” pilots.
Surface Burners-Automatic Re-ignition
To light the surface burners, push an turn the
appropriate control knob counter clockwise to any
position. This control is both a gas valve an an electric switch. Burners
will ignite at any “ON” position with the automatic re-ignition system.
If the flame goes out for any reason, the burners will automatically
reignite if the gas is still flowing. When gas is permitte to flow to the
burners, the electric igniters start sparking. On all surface igniters you
shoul hear a “clicking” soun . If you o not, turn off the control an
check that the unit is plugge in an that the fuse or circuit breaker is
not blown or trippe .
Within a few moments, enough gas will have travele to the burner to
light. When the burner lights, turn the burner control to any position to
a just the flame size. Setting the proper flame height for the esire
cooking process an selecting the correct cooking vessel will result in
superior cooking performance, while also saving time an energy.
Surface Cooking Tips
Your range is equippe with a variety of ifferent size surface burners.
Below is a gui e for which burners work best for certain cooking
applications:
Surface Cooking Tips (cont.)
• Use low or me ium flame heights when cooking in vessels that are
poor con uctors of heat, such as glass, ceramic, an cast-iron.
Re uce the flame height until it covers approximately 1/3 of the
cooking vessel iameter. This will ensure more even heating within
the cooking vessel an re uce the likelihoo of burning or scorching
the foo .
• Re uce the flame if it is exten ing beyon the bottom of the
cooking vessel. A flame that exten s along the si es of the vessel is
potentially angerous, heats the utensil han le an kitchen instea
of the foo , an wastes energy.
• Re uce the flame height to the minimum level necessary to perform
the esire cooking process. Remember that foo cooks just as
quickly at a gentle boil as it oes at a rolling boil. Maintaining a
higher boil than is necessary wastes energy, cooks away moisture,
an causes a loss in foo flavor an nutrient level.
• The minimum pot or pan (vessel) iameter recommen e is 6”
(15 cm) on the larger burners. Pots or pans as small as 4” (10 cm)
shoul be use on the smaller burners.
Surface Heat Settings*
*Note: The above information is given as a guide only. You may need
to vary the heat settings to suit your personal requirements.
Heat Setting Use
Simmer
Melting small quantities
Steaming rice
Simmering sauces
Low
Melting large quantities
Me Low
Low-temperature frying (eggs, etc.)
Simmering large quantities
Heating milk, cream sauces, gravies,
an pu ings
Me
Sauteing an browning, braising, an
pan-frying
Maintaining slow boil on large quantities
Me High
High-temperature frying
Pan broiling
Maintaining fast boil on large quantities
High
Boiling water quickly
Deep-fat frying in large utensil
Burner Use
Front left ual stacke
18,000 BTU burner
A versatile burner which is goo for both
bringing large quantities of liqui to
temperature or for simmering larger amounts
of sauces, etc.
Rear left 8,000 BTU burner
Best for simmering elicate sauces, etc.
Center 9,000 BTU burner
Best for use with the reversible gri le/grill
accessory
Front right 17,000 BTU burner
Best for bringing large quantities of liqui to
temperature an when preparing large
quantities of foo
Rear Right 12,000 BTU burner
Best use for most stan ar surface cooking
nee s
Surface Operation
Operation
