PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
All models include
• Both ov ns
o Ov rall capacity—4.7 cu. ft.
(25-5/16”W. x 16-1⁄2”H. x 19-1/2”D.)
o AHAM Standard ov n capacity—
4.1 cu. ft. (25-5/16”W. x 16-1⁄2”H. x
16-13⁄16”D.)
o Exclusiv pat nt-p nding Vari-Sp d
Dual Flow™ conv ction syst m has
th larg st conv ction fan in th
industry; th 8 1/2" fan works bi-
dir ctionally for maximum airflow
and xc ll nt cooking r sults
o Conc al d 10-pass dual bak l m nt
provid s pr cis t mp ratur control
o Extra larg Gourm t Glo™ glass
nclos d infrar d broil r provid s
sup rior broiling p rformanc
o Rapid R ady™ Pr h at provid s on
of th fast st pr h at tim s – so your
ov n is r ady to b gin cooking wh n
you ar
o Ov n has six porc lain coat d rack
supports and com s standard with
on TruGlid ™ full xt nsion ov n
rack and two standard ov n racks
o Thr strat gically locat d ov n
lights provid maximum visibility
o H avy-duty broil r pan and tray with
rack provid mor roasting and
broiling options
o High p rformanc cooking mod s
includ Bak , Conv ction Bak ,
TruConv c™ conv ction cooking,
Conv ction Roast, Hi, M dium, and
Low Broil, and Conv ction Broil
•Exclusive VSH™ Pro S al d Burn r
Syst m (VariSimm r™ to High)—
combination of pat nt d burn r and top
d sign provid cl anability plus sup rior
p rformanc at simm r and high
•Exclusive VariSimm r™ s tting for all
burn rs
•Exclusive on -pi c tool d and
porc lainiz d cooking surfac contains
spills for asy cl aning
• Standard kickspac h ight
6G models include
•Exclusive – on TruPow r Plus™
18,500 BTU burn r (front right burn r)
• Fiv 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 24”W. th rmostatically controll d st l
griddl /simm r plat (s parat
burn rs/controls for l ft and right sid )
6GQ models include
•Exclusive – on TruPow r Plus™
18,500 BTU burn r (front right burn r)
• Fiv 15,000 BTU stainl ss st l burn rs
with porc lain/cast iron caps and
automatic ignition/r -ignition
• 12”W. th rmostatically controll d st l
griddl /simm r plat
• 12”W. grill with flavor g n rator plat s
and automatic ignition/r -ignition
• Shipp d standard with h avy-duty
m tal knobs with stainl ss st l finish
• Shipp d standard with stainl ss st l
island trim attach d
Standard Features & Accessories
COOKING
Professional Custom Series Freestanding Dual Fuel
Self-Clean 60”W. Sealed Burner Range
*Shown throughout with island trim. See Installation Notes & Accessories or details.
ORDERING INSTRUCTIONS
First sp cify mod l numb r, and th n color cod (VDSC560-6GSS). If ord ring optional brass acc nt, sp cify cod at nd
(VDSC560-6GSSBR). If ord ring optional LP conv rsion, sp cify cod at nd (VDSC560-6GSSBRLP).
VDSC560-6G*
Six-Burner/Griddle Range
• All finish s hav stainl ss st l
handl /chrom -plat d brack ts and
stainl ss st l drip tray pull, control
pan l, and landing l dg .
• Brass Acc nt Option (BR)—nam plat ,
handl , nd caps, and knob b z ls.
Brass compon nts hav a durabl
prot ctiv coating for maint nanc -
fr normal us .
front pan l, and sid pan ls.
o Has black porc lain grat s, black
porc lain burn r caps, black
porc lain grat supports, and black
knobs/switch s.
• Whit (WH)
o Finish d signat s door front, low r
front pan l, sid pan ls, porc lain
grat supports, and knobs/switch s.
o Has black porc lain grat s and black
porc lain burn r caps.
FINISH DETAILS FOR ALL MODELS
• Stainl ss St l (SS), Black (BK), Whit
(WH), M tallic Silv r (MS), Graphit Gray
(GG), Ston Gray (SG), Taup (TP), Biscuit
(BT), Cotton Whit (CW), Oyst r Gray
(OG), Gold n Mist (GM), L monad (LE),
Sag (SA), Mint Jul p (MJ), S a Glass
(SE), Irid sc nt Blu (IB), Viking Blu (VB),
Pumpkin (PM), Racing R d (RR), Appl
R d (AR), Burgundy (BU), Plum (PL),
Chocolat (CH), and Cobalt Blu (CB).
o Finish d signat s door front, low r
VDSC560-6GQ*
Six-Burner/Grill/Griddle Range
Model Options

25-3/4” (65.4 cm)
19-3/8”
(49.2 cm)
8-1/8” (20.6 cm)
26-7/16” (67.2 cm)
1-5/8” (4.1 cm)
24-5/16” (61.8 cm)
28-1/16” (71.2 cm)
1” (2.5 cm)
35-7/8”
(20.3 cm) min.
to
37”
(94 cm) max.
45-1/8” (114.6 cm)
60”
(152.4cm)
35-7/8”
(91.1cm)min.
to
37”
(94.0cm)max.
1”(2.5cm)
COOKING
Professional Custom Series Freestanding Dual Fuel
Self-Clean 60”W. Sealed Burner Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E

Pl as s
Installation Notes &
Accessories
for important
installation
information
including
backguard, high-
sh lf, island trim,
and curb bas front.
Star-K Kosher
Certi ication or
use on the Jewish
Sabbath or Jewish
holidays
Dimensions & Specifications
PRODUCT DIMENSIONS & DOOR SWING
ALL MODELS
All models
Overall width 60” (152.4 cm)
Overall height
Base height
To top of side trim 35-7/ ” (91.1 cm) min. to 37” (94.0 cm) max.
Legs adjust (with “spindles” fully extended) 1-1/ ” (2.9 cm)
Additions to base height
To top of island trim Add 1” (2.5 cm)
To top of 8” bac guard Add ” (20.3 cm)
To top of high-shelf Add 23-1/2” (59.7 cm)
Overall depth (from rear)
To end of side panel 24-5/16” (61. cm)
To front of door 25-3/4” (65.4 cm)
To end of landing edge 2 -1/16” (71.2 cm)
To end of door handle 2 -11/16” (72.9 cm)
Oven
Interior width 25-5/16” (64.6 cm)
Interior height 16-1/2” (41.9 cm)
Interior depth Overall – 19-1/2” (49.5 cm)/AHAM – 16-13/16” (42.7 cm)
Overall interior size Overall – 4.7 cu. ft./AHAM – 4.1 cu. ft.
VDSC560-6G
Six-Burner/Griddle
Range
VDSC560-6GQ
Six-Burner/Grill
Range

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
Professional Custom Series Freestanding Dual Fuel
Self-Clean 60”W. Sealed Burner Range
42”min.
(106.7cm)
13”max.
(
33.0cm)
6”min.
(15.2cm)
60”
(152.4cm)
18”min.
(45.7cm)
3/8”
(0.95cm)
36”
(91.4cm)
Minimum clearances rom adjacent
combustible construction
• Cooking surfac and b low, i. .,
36” (91.4 cm) and b low
o Sid s—0”
o R ar—0” with backguard or high-
sh lf; 0” with island trim and
non-combustibl r ar wall; 6”
(15.2 cm) with island trim and
combustibl r ar wall
o Top grat support—36” (91.4 cm)
• Abov cooking surfac , i. ., abov
36” (91.4 cm)
o Sid s—6” (15.2 cm)
o Within 6” (15.2 cm) sid cl aranc ,
wall cabin ts no d p r than 13”
(33.0 cm) must b minimum 18”
(45.7 cm) abov cooking surfac
o Wall cabin ts dir ctly abov product
must b minimum 42” (106.7 cm) for
s al d top burn rs abov cooking
surfac
• Us rang only with factory suppli d
l gs
1.This rang may b install d dir ctly
adjac nt to xisting 36” (91.4 cm) high
bas cabin ts. Important: Th top
grat support must b 3/8” (0.95 cm)
abov th adjac nt bas cabin t
count rtop. This may b accomplish d
by raising th unit using th
adjustm nt spindl s on th l gs.
2.Th rang cannot b install d dir ctly
adjac nt to sid walls, tall cabin ts, tall
applianc s, or oth r sid v rtical
surfac s abov 36” (91.4 cm) high.
Th r must b a minimum of
6” (15.2 cm) sid cl aranc from th
rang to such combustibl surfac s
abov th 36” (91.4 cm) count r h ight.
3.Within th 6” (15.2 cm) sid cl aranc
to combustibl v rtical surfac s abov
36” (91.4 cm), th maximum wall
cabin t d pth must b 13” (33.0 cm)
and wall cabin ts within this 6” (15.2
cm) sid cl aranc must b 18” (45.7
cm) abov th 36” (91.4 cm) high
count rtop.
4.Wall cabin ts abov th rang must b
a minimum of 42” (106.7 cm) abov
th rang cooking surfac for th full
width of th rang . This minimum
h ight r quir m nt do s not apply if a
rang hood is install d ov r th
cooking surfac .
Dimensions & Specifications
CLEARANCE DIMENSIONS

2”
(5.1 cm)
Dia.
2-3/4”
(7.0 cm)
4-3/8”
(11.1 cm)
2-1/2”
(6.4 cm)
1-3/4”
(4.4 cm)
31-1/16”
(78.9 cm)
28-5/16”
(71.9 cm)
23-7/16”
(59.5 cm)
Gas or Electrical
connection in
this area
Gas connection
in this area
COOKING
Professional Custom Series Freestanding Dual Fuel
Self-Clean 60”W. Sealed Burner Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Installation Requirements
ACCESS REQUIREMENTS
UTILITY
REQUIREMENTS
GAS
•Shipp d natural or
LP/Propan gas; fi ld
conv rtibl with
conv rsion kit
(purchas d s parat ly)
• Acc pts standard
r sid ntial 1/2” (1.3
cm) ID gas s rvic lin
•Gas manifold pr ssur
o Natural gas 5.0”
W.C.P.
oLP/Propan 10.0”
W.C.P.
ELECTRICAL
•El ctrical conn ction
box on product for
hardwir dir ct;
conn ct with locally
suppli d 3-wir ,
fl xibl cord rat d or
“pigtail” rat d 40 amp
125-250 VAC min.;
must b ag ncy-
approv d for us with
hous hold l ctric
rang s.
• Ch ck your national
and local cod s
r garding this unit.
• Maximum amp
usag —240 – 208
VAC/60 Hz
o 6G
• 240V—40.0 amps
• 208V—34.7 amps
o 6GQ
• 240V—40.0 amps
• 208V—34.7 amps
PLUMBING
Not applicabl
VDSC560-6G VDSC560-6GQ
Surface burner rating
Grated burners (each) 15,000 BTU Nat. (4.4 kW)/12,500 BTU LP (3.7 kW)
TruPower Plus™ burner (front right) 1 ,500 BTU Nat. (5.4 kW)/16,600 BTU LP (4.9 kW)
Griddle (each) 15,000 BTU Nat. (4.4 kW)/12,500 BTU LP (3.7 kW)
Grill 1 ,000 BTU Nat. (5.3 kW)/16,000 BTU LP (4.7 kW)
Note: Ground plug and electrical wire toward the direction of the electrical outlet.
VDSC560-6G
Six-Burner/Griddle
Range
VDSC560-6GQ
Six-Burner/Grill
Range

Island Trim
• Stainl ss St l (SS)
•Coordinat s with all finish s
• For island/p ninsula installation
• Can r plac backguard if wall is non-combustibl
• Includ d and shipp d automatically with rang
”H. Backguard
• Stainl ss St l (SS)
• Coordinat s with all finish s
High-shelf
• Stainl ss St l (SS)
• Coordinat s with all finish s
• Sh lf com s attach d to a 24”H. backguard
Countertop Side Trim
• Stainl ss St l (SS)
• Coordinat s with all finish s
• On pair of trim
• Installs on sid of unit; ov rlaps count rtop
Countertop Rear Trim
• Stainl ss St l (SS)
• Coordinat s with all finish s
COOKING
Professional Custom Series Freestanding Dual Fuel
Self-Clean 60”W. Sealed Burner Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Installation Notes & Accessories
A backguard, high-sh lf, or island trim must b us d for all installations.
Model Description Approx. ship wt. lbs. (kg)
P60BG8 60”W. bac guard 24 (10.8)
Model Description Approx. ship wt. lbs. (kg)
B60HS24 60”W. high-shelf 60 (27.0)
Model Description Approx. ship wt. lbs. (kg)
P60TII 60”W. island trim 15 (6.8)
Model Description Approx. ship wt. lbs. (kg)
P24CST 24”D. side trim 2 (0.9)
Model Description Approx. ship wt. lbs. (kg)
P60CRT 60”W. countertop rear trim 2 (0.9)

COOKING
Professional Custom Series Freestanding Dual Fuel
Self-Clean 60”W. Sealed Burner Range
PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 3 / 2 9 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Curb Base Front Custom Curb Base Front
• Stainl ss St l (SS) • R mov stainl ss st l front and r cycl
• Coordinat s with all finish s •Conc als rang l gs
•Front only •Attach locally suppli d trim
• Conc als rang l gs • Compl t ly ass mbl d
•Compl t ly ass mbl d • Easily clips onto rang l gs aft r rang is install d
•Easily clips onto rang l gs aft r rang is install d •Provid s drop-in rang look
LP/Propane Conversion Kit
• Allows for fi ld conv rsion of rang from natural gas to LP
Compliance Information
WARRANTY INFORMATION*
• On -y ar full warranty—compl t product
• T n-y ar limit d warranty—porc lain ov n and porc lain inn r door pan l
• Fiv -y ar limit d warranty—surfac burn rs, griddl burn rs, grill burn rs, and ov n burn r
• Nin ty-day limit d warranty—cosm tic parts such as glass, paint d, and d corativ it ms
* For compl t warranty s Use & Care Guide. Warranty valid on Viking products shipp d within th Unit d Stat s and Canada.
Model Description Approx. ship wt. lbs. (kg)
LPKPDR Natural to LP/propane conversion it 2 (0.9)
Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
P60CBF4 60”W. curb base front 11 (5.0)
