Lincat OE8017 Owner's manual

IS 615 ECN 3862 Page 1 of 10
Installation, Operating and Servicing
Instructions
Opus 800 Electric Induction Range
OE8017
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________

IS 615 ECN 3862 Page 2 of 10
CONTENTS
Important Information
2
Warnings and Precautions
3
Technical Data
3
Checklist of Enclosures
4
Installation and Commissioning
4-5
Operating Instructions
5-7
Cleaning
8
Servicing, Maintenance and Component Replacement
9
Fault Finding
9
Spare Parts List
9
Service Information and Guarantee
10
IMPORTANT INFORMATION
Read these instructions carefully before using this product, paying particular
attention to all sections that carry warning symbols, caution symbols and notices.
Ensure that these are understood at all times.
WARNING!
This symbol is used whenever there is a risk of personal injury.
CAUTION!
This symbol is used whenever there is a risk of damaging your Lincat product.
NOTE:
This symbol is used to provide additional information, hints and tips.
KEEP THIS MANUAL FOR FUTURE REFERENCE

IS 615 ECN 3862 Page 3 of 10
WARNINGS AND PRECAUTIONS
This appliance must be installed, commissioned and serviced by a qualified person
in accordance with national and local regulations in force in the country of
installation.
Caution Symbol: Non-ionising electromagnetic radiation (magnetic field).
Warning Symbol: Dangerous voltage (live parts at a working voltage exceeding
250V).
If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified person.
Ensure that the plug/socket is accessible at all times.
Strip plastic coating and clean the appliance before use.
During operation parts may become hot - avoid accidental contact.
Disconnect this appliance before servicing, maintenance or cleaning.
If the ceramic glass surface is cracked, immediately disconnect the appliance
from the supply.
Do not stand on the unit.
The ceramic glass is very strong but do not slam pans down onto it and be careful
not to scrape pans along the surface.
TECHNICAL DATA
OE8017
OE8014
Height (mm)
900
Width (mm)
900
Depth (mm)
800
Weight (kg)
180
60
Hob zones
4
4
Hob surface
6mm thick ceramic glass
Electrical supply 3N~+E
400V 3ph 50Hz or 60 Hz
Total power rating (A)
35A per phase
30.7
Hob zone power (kW)
4 x 5
Oven power (kW)
4
Total power (kW)
24
20

IS 615 ECN 3862 Page 4 of 10
CHECK LIST OF ENCLOSURES
Warranty card
Instructions manual
INSTALLATION AND COMMISSIONING
This appliance must be earthed.
An equipotential bonding terminal is provided to allow cross bonding with other
equipment.
If replacing the plug connect the terminals as follows:
Green and Yellow wire Earth E
Blue wire Neutral N
Brown wire Live L1
Black wire Live L2
Grey wire Live L3
Means of isolation with at least 3mm contact separation in all poles must be
incorporated into the fixed wiring of this appliance.
The fixed wiring insulation must be protected by insulated sleeving having a
temperature rating of at least 60oC.
Supply cords shall be oil resistant, sheathed flexible cable not lighter than ordinary
polychloroprene or equivalent elastomer sheathed cord (code 60245 IEC 57)
If the supply cable is replaced, the live and neutral conductors must pass through
the ferrite ring for EMC compliance. Do not pass the earth wire through the ferrite
ring.
Install this appliance on a level surface ensuring all vents are unobstructed. Any
partitions, walls or furniture must be of non-combustible material. Minimum
distances, A 100mm, B 1000mm –see Fig 1.
Do not block or restrict the inlet filters on the appliance base. Restricted airflow will
result in reduced performance.
Keep means of electrical isolation accessible at all times.

IS 615 ECN 3862 Page 5 of 10
Fig 1
OPERATING INSTRUCTIONS
General Information
Only qualified or trained personnel should use this appliance.
The green neon illuminated indicates power to the appliance.
Hob
When the induction hob is initially switched on, there will be a momentary flashing
of the green indicators. Rotate the control knob to the required power level setting.
After use, switch the hob zone off by means of the control. Do not rely on the pan
detectors.

IS 615 ECN 3862 Page 6 of 10
Fans may continue to operate after controls are switched to zero. This is normal.
Do not place aluminium foil or plastic vessels on hot ceramic surfaces. Do not use
the surfaces for storage.
Metallic objects should not be placed within the cooking zones as they will get hot.
Take care when operating the appliance as rings, watches or similar objects could
get hot in close proximity to the hob surfaces.
Only use pans of the size and type recommended in the pan selection notes.
Users with heart pacemakers should consult with their doctor or the manufacturer of
the pacemaker.
Induction cooking and pan selection
Induction cooking produces heat directly in the base of the pan. The system
comprises a ceramic glass hob with an induction coil beneath it. The coil generates
an alternating magnetic field. When a pan with a magnetic base is placed on the
cooking zone, eddy currents are produced in the base of the pan leading to the
production of heat. The pan heats extremely quickly.
The quality of the cookware is essential to the efficiency of induction cooking. The
base of the pan needs to be flat with good heat distribution.
Suitable pans are made from cast iron, enamelled steel and stainless steel with a
magnetic base. Unsuitable pans are glass, earthenware, aluminium, copper and
non-magnetic stainless steel.
Operation of the pan detection system is dependent on the size of the pan and its
material. Power from the induction coil to the pan will vary and is dependent on
size and pan material.
It is normal for induction generators to make buzzing, whistling and clicking noises,
especially on lower power settings.
Locate the pan concentrically over the ceramic glass target ring. If the inner ring of
the ceramic glass is visible around the pan, the pan is too small.
Recommended pan base diameter –minimum of 120mm.
Nominal coil diameter –270mm.
Power level settings
Constantly variable power level settings are available via the rotary control knob,

IS 615 ECN 3862 Page 7 of 10
Error codes
There are numerous error codes identifying issues within the induction system.
These are primarily of use when reporting a fault to Lincat’s Service Department;
however some errors can be cleared by turning the control to the ‘Off’ position,
unplugging the appliance and then switching back on again.
An illuminated red LED indicates an error.
The generator error codes are displayed in a series of flashes of the green LED.
There is a long flash followed by a series of shorter flashes.
The number of these short flashes is the error number.
A reduction in performance during cooking may be attributed to a blocked or
restricted air filter, a confined location with insufficient airflow or a failed cooling fan.
Pan detection function
Each zone has pan detection which prevents the coil from turning on without a pan
being present. The coil also turns off when a pan is removed.
OVEN SETTING
Check the green ‘power on’ neon on the fascia panel is illuminated.
Set the control knob to the desired temperature in degrees Celsius. The
orange light will illuminate indicating that power is being supplied to the
elements.
The orange light will go out when the oven has achieved the set temperature.
Periodically the orange light will illuminate to indicate that the oven
temperature has fallen and the elements are turned on to top up the
temperature.
SHUT DOWN
To shut down the appliance rotate all control knobs clockwise to the OFF position.
After operation, some parts of the appliance will remain hot for a period of time;
care should be taken to avoid risk of burns.
OPENING OF THE OVEN DOOR
Care must be taken to avoid injury when opening the oven door when the oven is
in use, as hot air will rapidly escape.

IS 615 ECN 3862 Page 8 of 10
CLEANING
Your product has a manufacturer’s warranty. This requires you maintain and care
for your product and follow maintenance instructions. If you fail to maintain your unit
or damage components, Lincat may charge you for a warranty repair. Please check
the website for terms and conditions.
Isolate from the power supply and allow to cool.
Do not use a water jet or steam cleaner, and do not immerse this appliance.
Clean all panels with warm water and mild detergent do not use abrasive or chlorine
based cleaners. Do not wet electrical components. Dry with a soft cloth.
Clean the ceramic glass regularly, avoiding abrasive sponges or scouring agents
and harsh chemicals like oven sprays. Remove dirt and food with a scraper or
Vileda Ceran cleaning sponge.
If plastic, aluminium foil or sugary food has dropped onto hot ceramic glass,
scrape off immediately. If these substances melt they can damage the
surface.
Check the air filters regularly –they are washable if contaminated. Ensure they are
fully dry before refitting.

IS 615 ECN 3862 Page 9 of 10
SERVICING, MAINTENANCE AND
COMPONENT REPLACEMENT
Replacing an air filter
Removing and cleaning the air filter will ensure an adequate supply of cool air and
restore performance. Disconnect from the power supply and allow the appliance to
cool. The filters are located on the base of the unit.
Open the right hand door, the filter is located at the bottom and slides out. Remove
the filter and clean –the filter may be put in a dishwasher. Replace the clean filter
and re-fit.
Do not operate the appliance without a filter being fitted, otherwise dirt and grease
could be drawn into the electronics, impairing safe operation.
All other servicing, maintenance and component replacement on this appliance
should be carried out by one of our recommended service engineers.
Please refer to the Service Help Desk number on the final page of this manual.
Part Number
Description
FI41
Filter pad (2 per unit)
KN506
Hob control knob
KN505
Oven control knob
CA143
Front lockable swivel castor
CA144
Rear swivel castor
SE25
Oven door seal
FAULT FINDING
SPARE PARTS LIST

IS 615 ECN 3862 Page 10 of 10
For help with the installation, maintenance and use of your Lincat equipment,
please contact our service department:
UK: 01522 875520
For non-UK customers, please contact your local Lincat dealer
All service work, other than routine cleaning should be carried out by one of our
authorised service agents. We cannot accept responsibility for work carried out by
other persons.
To ensure your service enquiry is handled as efficiently as possible, please tell us:
Brief details of the problem
Product code
All available on serial plate
Type number
Serial number
Lincat reserve the right to carry out any work under warranty, given reasonable
access to the appliance, during normal working hours, Monday to Friday, 08:30 to
17:00.
GUARANTEE
This unit carries a comprehensive UK mainland 2 year warranty. The guarantee is
in addition to, and does not diminish your statutory or legal rights.
The guarantee does not cover:
Accidental damage, misuse or use not in accordance with the manufacturer’s
instructions
Consumable items (such as filters, glass, bulbs, slot toaster elements and door
seals.)
Damage due to incorrect installation, modification, unauthorised service work or
damage due to scale, food debris build-up, etc.
The manufacturer disclaims any liability for incidental, or consequential damages.
Attendance is based on reasonable access to the appliance to allow the authorised
technician to carry out the warranty work.
Service calls to equipment under warranty will be carried out in accordance with the
conditions of sale. Unless otherwise specified, a maximum of 15 minutes of
administrative time, not spent directly carrying out servicing work, is provided for
within the warranty. Any requirement for staff attending the call to spend greater time
than 15 minutes due to administrative requirements, such as on health and safety risk
assessments, will be chargeable at the prevailing rate.
SERVICE INFORMATION
