Viking Installation Guide
Side-By-Side &
Bottom Mount Refrigerator/Free er
UL
C
UL

IMPORTANT–Please Read and Follow!
3
2
Table of Contents
Make sure that incoming voltage is the same
as unit rating. An electric rating plate
specifying voltage, frequency, wattage,
amperage, and phase is attached to the
product.
To reduce the risk of fire, electric shock, or
injury to persons, installation work and
electrical wiring must be done by qualified
people in accordance with all applicable
codes and standards, including fire-rated
construction.
The installer should leave these instructions
with the consumer who should retain them
for local inspector’s use and for future
reference.
It is your responsibility to:
Comply with installation specifications and
dimensions
Properly install unit
Remove any moldings or decorative panels
that prevent the unit from being serviced
Make sure that you have these materials (not
provided with your unit), which are necessary
for proper installation:
1/4” (6 mm) copper tubing with shutoff
valve
6– #8 x 3” (7.6 cm) wood screws (longer
screws may be required)
1– saddle valve (do not use self-piercing
feature of the valve)
Assure that floor will support unit, door
panels and contents (approximately 1200
pounds [540 kg])
Provide a properly grounded electrical outlet
Assure that location will permit appliance
doors to open 90˚ minimum
WARNING
TIP OVER HAZARD
Appliance is top
heavy and tips easily
when not completely
installed. Keep doors
closed until appliance
is completely installed
and secured per installation instructions.
Use two or more people to move and
install appliance. Failure to do so can
result in death or serious injury.
WARNING
ELECTRICAL SHOCK
HAZARD
Disconnect power or turn
power disconnect switch to
OFF position before removing
top grille. Failure to do so can
result in death or electrical shock
Your safety and the safety of others is
very important.
We have provided many important safety
messages in this manual and on your
appliance. Always read and obey all
safety messages.
This is the safety alert symbol. This
symbol alerts you to hazards that
can kill or hurt you and others.
All safety messages will be preceded by the
safety alert symbol and the word“DANGER”
or “WARNING.” These words mean:
D A N G E R
You will be killed or seriously injured if
you don’t follow instructions.
WARNING
You can be killed or seriously injured if
you don’t follow instructions.
All safety messages will identify the
hazard, tell you how to reduce the chance
of injury, and tell you what can happen if
the instructions are not followed.
Most of the unit’s weight is at the top. Extra care is needed when moving the unit to prevent
tipping. Use cardboard shipping material or plywood under unit until it is installed in the
operating position to protect floor surface.
Warnings & Important Information_____________________________________________________ 3
Professional & Professional Integrated Side-by-Side
Dimensions & Specifications (Professional 42” & 48”) ________________________________ 4
Dimensions & Specifications (Professional Integrated 42” & 48”) _______________________6
Cutout Dimensions (42”) __________________________________________________________ 8
Anti-Tip Dimensions (42”) _________________________________________________________ 9
Cutout Dimensions (48”)_________________________________________________________ 10
Anti-Tip Dimensions (48”)________________________________________________________ 11
Professional & Professional Integrated Bottom-Mount
Dimensions & Specifications (36”)_________________________________________________ 12
Cutout Dimensions (36”)_________________________________________________________ 14
Anti-Tip Dimensions (36”)________________________________________________________ 15
Cabinet Information (Professional) ____________________________________________________ 16
Cabinet Information (Professional Integrated) __________________________________________ 18
Designer Side-by-Side
Dimensions & Specifications (42” & 48”)___________________________________________ 20
Cutout Dimensions (42”)_________________________________________________________ 22
Anti-Tip Dimensions (42”)________________________________________________________ 23
Cutout Dimensions (48”)_________________________________________________________ 24
Anti-Tip Dimensions (48”)________________________________________________________ 25
Designer Bottom-Mount
Dimensions & Specifications (36”)_________________________________________________ 26
Cutout Dimensions (36”)_________________________________________________________ 28
Anti-Tip Dimensions (36”)________________________________________________________ 29
Cabinet Information (Designer)_______________________________________________________ 30
Custom Side Panel Dimensions (Professional)__________________________________________ 32
Custom Side Panel Dimensions (Designer & Professional Integrated) _____________________ 33
General Information ________________________________________________________________ 34
Unpacking & Moving _______________________________________________________________ 36
Installation_________________________________________________________________________ 37
Hinge Adjustment ______________________________________________________________ 38
Kickplate Installation ____________________________________________________________ 40
Door Stop Adjustment __________________________________________________________ 41
Water Filter Installation __________________________________________________________ 42
System Specifications and Data___________________________________________________ 43
Final Installation ________________________________________________________________ 44
Performance Checklist ______________________________________________________________ 45
Control Panels _____________________________________________________________________ 46
Service & Registration_______________________________________________________________ 47

Specifications (Professional Side-By-Side)
5
24–11/16”
(62.7cm)
41”
(104.1cm)
75–15/16”
(192.9 cm)
3–19/32”
(9.1cm)
42”
(106.7 cm)
9–5/32”
(23.3 cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
22–3/16”
(56.4 cm)
24–11/16”
(62.7 cm)
47”
(119.4cm)
75–15/16”
(192.9cm)
3–19/32”
(9.1 cm)
48”
(121.9 cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
1–1/2”
(3.8cm)
22–3/16”
(56.4 cm)
27–1/4”
(69.2 cm)
1–1/2”
(3.8cm)
27–1/4”
(69.2 cm)
Dimensions (Professional Side-By-Side)
4
42” Professio al Side-By-Side
Descriptio VCSB423 VCSB423D
Overall width 42” (106.7 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm)
To front of top grille: 24-11/16” (62.7 cm)
To front of handle endcap: 27-1/4” (69.2 cm)
Cutout width 41-1/2” (105.4 cm) min. to 41-3/4” (106 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 15.0 cu. ft. (425 liters) 15.0 cu. ft. (425 liters)
Freezer 9.0 cu. ft. (255 liters) 8.6 cu. ft. (243 liters)
Total capacity 24.0 cu. ft. (680 liters) 23.6 cu. ft. (668 liters)
Approximate shipping weight 652 lbs. (293.4 kg) 676 lbs. (304.2 kg)
48” Professio al Side-By-Side
Descriptio VCSB483 VCSB483D
Overall width 48” (121.9 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm)
To front of top grille: 24-11/16” (62.7 cm)
To front of handle endcap: 27-1/4” (69.2 cm)
Cutout width 47-1/2” (120.7 cm) min. to 47-3/4” (121.3 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 18.5 cu. ft. (524 liters) 18.5 cu. ft. (524 liters)
Freezer 8.9 cu. ft. (252 liters) 8.6 cu. ft. (243 liters)
Total capacity 27.4 cu. ft. (776 liters) 27.1 cu. ft. (767 liters)
Approximate shipping weight 715 lbs. (321.8 kg) 735 lbs. (330.8 kg)
42” Professional
48” Professional

Specifications (Professional Side-By-Side)
7
24”
(61.0cm)
41”
(104.1cm)
75–15/16”
(192.9 cm)
3–19/32”
(9.1cm)
42”
(106.7 cm)
9–5/32”
(23.3 cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
23–3/8”
(59.4 cm)
24”
(61.0 cm)
47”
(119.4cm)
75–15/16”
(192.9cm)
3–19/32”
(9.1 cm)
48”
(121.9 cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
1–1/2”
(3.8cm)
23–3/8”
(59.4 cm)
26–1/2”
(67.3 cm)
1–1/2”
(3.8cm)
26–1/2”
(67.3 cm)
Dimensions (Professional Side-By-Side)
6
42” Professional Integrated
48” Professional Integrated
42” Professio al I tegrated Side-By-Side
Descriptio VISB423 VISB423D
Overall width 42” (106.7 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle endcap: 26-1/2” (67.3 cm)
Cutout width 42” (106.7 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 15.0 cu. ft. (425 liters) 15.0 cu. ft. (411 liters)
Freezer 9.0 cu. ft. (255 liters) 8.6 cu. ft. (244 liters)
Total capacity 24.0 cu. ft. (680 liters) 23.6 cu. ft. (668 liters)
Approximate shipping weight 625 lbs. (293.4 kg) 676 lbs. (304.2 kg)
48” Professio al I tegrated Side-By-Side
Descriptio VISB483 VISB483D
Overall width 48” (121.9 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle endcap: 26-1/2” (67.3 cm)
Cutout width 48” (121.9 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 18.5 cu. ft. (524 liters) 18.5 cu. ft. (507 liters)
Freezer 8.9 cu. ft. (252 liters) 8.6 cu. ft. (243 liters)
Total capacity 27.4 cu. ft. (776 liters) 27.1 cu. ft. (767 liters)
Approximate shipping weight 715 lbs. (321.8 kg) 735 lbs. (330.8 kg)

Two 2”x 4” Mounting Boards
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm),then shim behind the mounting
boardby the difference.
One 2”x 4” Mounting Board
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boardby the difference.
Bottom of anti-tip board is3–7/8” (9.8 cm) below opening height.
NOTE: Top of unit must be placedfirmly under anti-tip board.
Professional Anti-Tip Location
Professional Integrated Anti-Tip Location
79–3/8”
(201.6 cm) min.
tobottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
tobottomof
anti-tipboard
35”
(88.9cm)
3–1/2”
(8.9cm)
3”
(7.6 cm)
35”
(88.9 cm)
3–1/2”
(8.9 cm)
1.5”
(3.8 cm)
Anti-Tip Dimensions (Professional Side-By-Side)
9
9”
(22.9cm)
73-3/8”
(186.4cm)
82–7/8”
(210.5cm) min.
anti-tip board &
opening height
84–1/16”
(213.5cm)min.
anti-tipboard &
openingheight
41–1/2”
(105.4 cm) min.
to
41–3/4”
(106.0 cm) min.
42”
(106.7 cm)
Professional Integrated
models only
24”
(61.0cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.5 cm)
5/8”
(1.5 cm)
10–1/2”
(26.7cm)
5/8”
(1.5 cm)
10–3/4”
(27.3 cm)
1”
(2.5 cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
42”
(106.7cm)
ProfessionalIntegrated
models only
41–1/2”
(105.4cm)
SeeAnti-Tipboardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Professional Side-By-Side)
8
42” Professional & Professional Integrated 42” Professional

Two 2”x 4” Mounting Boards
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boardby the difference.
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boardby the difference.
One 2”x 4” Mounting Board
3” (7.6 cm) x 3-1/2” (8.9 cm)
Bottom of anti-tip board is3–7/8” (9.8 cm) below opening height.
NOTE: Top of unit must be placedfirmly under anti-tip board.
Professional Anti-Tip Location
Professional Integrated Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
41”
(104.1cm)
3–1/2”
(8.9cm)
3”
(7.6cm)
41”
(104.1 cm)
3–1/2”
(8.9cm)
1-1/2”
(3.8 cm)
Anti-Tip Dimensions (Professional Side-By-Side)
11
9”
(22.9cm)
73-3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board&
opening height
84–1/16”
(213.5cm) min.
anti-tip board&
openingheight
47–1/2”
(120.7 cm) min.
to
47–3/4”
(121.2 cm)max.
48”
(121.9 cm)
Professional Integrated
models only
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.5 cm)
5/8”
(1.5 cm)
10–1/2”
(26.7 cm)
5/8”
(1.5 cm)
10–3/4”
(27.3 cm)
1”
(2.5cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
47–1/2”
(120.7cm)
48”
(121.9cm)
ProfessionalIntegrated
models only
SeeAnti-Tip boardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Professional Side-By-Side)
10
48” Professional & Professional Integrated 48” Professional & Professional Integrated

Specifications (Professional Bottom-Mount)
13
24–11/16”
(62.7cm)
35”
(88.9 cm)
51–1/2”
(130.8 cm)
23–1/16”
(58.5 cm)
3–19/32”
(9.1 cm)
36”
(91.5cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7cm)
22–3/16”
(56.4cm)
1–1/2”
(3.8 cm)
27–1/4”
(69.2 cm)
24”
(61.0 cm)
35”
(88.9 cm)
51–1/2”
(130.8 cm)
23–1/16”
(58.5 cm)
3–19/32”
(9.1 cm)
36”
(91.5 cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
23–3/8”
(59.4 cm)
1–1/2”
(3.8cm)
26–1/2”
(67.3 cm)
Dimensions (Professional Bottom-Mount)
12
36” Professional
36” Professional Integrated
36” Professio al Bottom-Mou t
Descriptio VCBB363
Overall width 36” (91.5 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm)
To front of top grille: 24-11/16” (62.7 cm)
To front of handle endcap: 27-1/4” (69.2 cm)
Cutout wdth 35-1/2” (90.2 cm) min. to 35-3/4” (90.8 cm) max.
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; minimum 20 psi;
requirements maximum 120 psi
Overall interior dimensions
Refrigerator 15.2 cu. ft. (431 Liters)
Freezer 5.1 cu. ft. (145 Liters)
Total capacity 20.3 cu. ft. (576 Liters)
Approximate shipping weight 565 lbs. (254.3 kg)
36” Professio al I tegrated Bottom-Mou t
Descriptio VIBB363
Overall width 36” (91.5 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle endcap: 26-1/2” (67.3 cm)
Cutout wdth 36” (91.4 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; minimum 20 psi;
requirements maximum 120 psi
Overall interior dimensions
Refrigerator 15.2 cu. ft. (431 Liters)
Freezer 5.1 cu. ft. (145 Liters)
Total capacity 20.3 cu. ft. (576 Liters)
Approximate shipping weight 565 lbs. (254.3 kg)

Two 2”x 4” Mounting Boards
3” (7.6 cm) x 3-1/2” (8.9 cm)
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boards by the difference.
NOTE: If unit is installed deeper than
24” (61.0 cm), then shim behind the mounting
boards by the difference.
One 2”x 4” Mounting Board
3” (7.6 cm) x 3-1/2” (8.9 cm)
Bottom of anti-tip board is 3–7/8” (9.8 cm) below opening height.
NOTE: Top of unit must be placedfirmly under anti-tip board.
Professional Anti-Tip Location
Professional Integrated Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
29–1/2”
(74.9cm)
3–1/2”
(8.9cm)
3”
(7.6cm)
29–1/2”
(74.9 cm)
3–1/2”
(8.9cm)
1.5”
(3.8 cm)
Anti-Tip Dimensions (Professional Bottom-Mount)
15
9”
(22.9cm)
73-3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board&
opening height
84–1/16”
(213.5cm) min.
anti-tip board&
opening height
35–1/2”
(90.2 cm) min.
to
35–3/4”
(90.8 cm) max.
36”
(91.5 cm)
ProfessionalIntegrated
modelonly
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.5 cm)
5/8”
(1.5 cm)
10–1/2”
(26.7 cm)
5/8”
(1.5 cm)
10–3/4”
(27.3 cm)
1”
(2.5cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
35–1/2”
(90.2 cm)
36”
(91.5 cm)
ProfessionalIntegrated
model only
SeeAnti-Tip boardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Professional Bottom-Mount)
14
36” Professional & Professional Integrated 36” Professional & Professional Integrated

Top View
1–13/16”
(4.6 cm)
Space if 24”
standard
cabinet
depth is
used
Door
24”
(61.0 cm)
Standard
Cabinet
Depth
Wall
3/4”
(1.9 cm)
Full End
Panel
2–1/2”
(6.4 cm) Offset
Countertop
Overhang
Cabinet Information (Professional)
17
Top View
Top View
Door
Wall
1–13/16”
(4.6 cm)
Space if 24”
standard
cabinet
depth is
used
3/4”
(1.9 cm)
Full End
Panel
24”
(61.0 cm)
Standard
Cabinet
Depth
2–1/2”
(6.4 cm) Offset
5–16”
(0.8 cm)
1–13/16”
(4.6 cm)
Space if 24”
standard
cabinet
depth is
used
Door
24”
(61.0 cm)
Standard
Cabinet
Depth
Wall
3/4”
(1.9 cm)
Full End
Panel
2–1/2”
(6.4 cm) Offset
Partial Overlay
Cabinet Door
Cabinet Information (Professional)
16
Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door
face protrudes 2-1/2” (6.4 cm) from the cabinet face. The handle protrudes an additional
2-1/2” (6.4 cm) into the room.
Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door
face protrudes 2-1/2” (6.4 cm) from the cabinet face. The handles protrude an additional
2-1/2” (6.4 cm) into the room.

Top View
Top View
Door
24”
(61.0 cm)
Standard
Cabinet
Depth
25”
(63.5 cm)
Countertop
Depth
Wall
3/4”
(1.9 cm)
Full End
Panel
Door
Wall
1”
(2.5 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
3/4”
(1.9 cm)
Full End
Panel
25”
(63.5 cm)
Flush
1”
(2.5 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
Flush
Cabinet Information (Professional Integrated)
19
Top View
Overlapping cabinet doors
Top View
Flush mount cabinet doors
Door
24”
(61.0cm)
Standard
Cabinet
Depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
Full End
Panel
3/4”
(1.9 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
Flush
Cabinet
Door
Door
Wall
3/4”
(1.9 cm)
Full End
Panel
1”
(2.5 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
Flush
25”
(63.5 cm)
Cabinet
Depth
Cabinet
Door
Cabinet Information (Professional Integrated)
18
Professional Integrated models fit flush in standard 24” (61.0 cm) deep cabinet openings with no
protrusion into the room except the handle protrudes 2-1/2” (6.4 cm) into the room.
Professional Integrated models fit flush in standard 24” (61.0 cm) deep cabinet openings with no
protrusion into the room except the handle protrudes 2-1/2” (6.4 cm) into the room.

Specifications (Designer Side-By-Side)
21
24”
(61.0cm)
41”
(104.1cm)
75–15/16”
(192.9 cm)
3–1/2”
(8.9cm)
9–5/32”
(23.3 cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
1–1/2”
(3.8cm)
23–3/8”
(59.4 cm)
24”
(61.0 cm)
47”
(119.4cm)
75–15/16”
(192.9cm)
3–1/2”
(8.9 cm)
9–5/32”
(23.3cm)
82–3/4”
(210.2cm)
min.
to
84–1/16”
(213.5cm)
max.
20–3/4”
(52.7 cm)
1–1/2”
(3.8cm)
23–3/8”
(59.4cm)
26”
(66.0cm)
26”
(66.0cm)
42”
(106.7cm)
48”
(121.9cm)
Dimensions (Designer Side-By-Side)
20
Designer 42”
Designer 48”
42” Desig er Side-By-Side
Descriptio DDSB423 DDSB423D
Overall width 42” (106.7 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top gr:ille: 24” (61.0 cm)
To front of handle: 26” (66.0 cm)
Cutout width 42” (106.7 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 15.0 cu. ft. (425 liters) 15.0 cu. ft. (425 liters)
Freezer 9.0 cu. ft. (255 liters) 8.6 cu. ft. (243 liters)
Total capacity 24.0 cu. ft. (680 liters) 23.6 cu. ft. (668 liters)
Approximate shipping weight 642 lbs. (289 kg) 665 lbs. (299.3 kg)
48” Desig er Side-By-Side
Descriptio DDSB483 DDSB483D
Overall width 48” (121.9 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle: 26” (66.0 cm)
Cutout width 48” (121.9 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; 1/4” copper tubing inlet waterline;
Requirements minimum 20 psi; maximum 120 psi minimum 35 psi; maximum 120 psi
Overall interior dimensions
Refrigerator 18.5 cu. ft. (524 liters) 18.5 cu. ft. (524 liters)
Freezer 8.9 cu. ft. (252 liters) 8.6 cu. ft. (243 liters)
Total capacity 27.4 cu. ft. (776 liters) 27.1 cu. ft. (767 liters)
Approximate shipping weight 705 lbs. (317.3 kg) 730 lbs. (328.5 kg)

One 2”x 4” Mounting Board
1–1/2” (3.8 cm) x3–1/2” (8.9 cm)
NOTE: If unit is installed deeper than 24” (61.0 cm), thenshim
behind the mounting board by the difference.
Bottom of anti-tip board is 3–7/8” (9.8 cm) belowopening height.
NOTE: Top of unit must be placed firmly under anti-tip board.
Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
35”
(88.9 cm)
3–1/2”
(8.9 cm)
1–1/2”
(3.8 cm)
Anti-Tip Dimensions (Designer Side-By-Side)
23
9”
(22.9cm)
73–3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board&
opening height
84–1/16”
(213.5cm) min.
anti-tip board&
opening height
42”
(106.7 cm)
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
42”
(106.7cm)
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.5 cm)
5/8”
(1.5 cm)
10–1/2”
(26.7 cm)
5/8”
(1.5 cm)
10–3/4”
(27.3 cm)
1”
(2.5cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
SeeAnti-Tip boardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Designer Side-By-Side)
22
42” Designer 42” Designer

One 2”x 4” Mounting Board
1–1/2” (3.8 cm) x 3 1/2” (8.9 cm)
NOTE: If unit is installed deeper than 24” (61.0 cm), thenshim
behind the mounting board by the difference.
Bottom of anti-tip board is 3–7/8” (9.8 cm) belowopening height.
NOTE: Top of unit must be placed firmly under anti-tip board.
Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
41”
(104.1cm)
3–1/2”
(8.9 cm)
1–1/2”
(3.8 cm)
Anti-Tip Dimensions (Designer Side-By-Side)
25
9”
(22.9cm)
73–3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board&
opening height
84–1/16”
(213.5cm) min.
anti-tip board&
opening height
48”
(121.9 cm)
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
47–1/2”
(120.7cm)
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.5 cm)
5/8”
(1.5 cm)
10–1/2”
(26.7 cm)
5/8”
(1.5 cm)
10–3/4”
(27.3 cm)
1”
(2.5cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
SeeAnti-Tip boardinstallation
6”
(15.2cm)
9”
(22.9cm)
Cutout Dimensions (Designer Side-By-Side)
24
48” Designer 48” Designer

Specifications (Designer Bottom-Mount)
27
24”
(61.0 cm)
35”
(88.9cm)
51–1/2”
(130.8cm)
23–1/16”
(58.5cm)
3–1/2”
(8.9cm)
9–5/32”
(23.3 cm)
82–7/8”
(210.5 cm)
min.
to
84–1/16”
(213.5 cm)
max.
20–3/4”
(52.7 cm)
23–3/8”
(59.4 cm)
1–1/2”
(3.8cm)
26”
(66.0 cm)
36”
(91.5 cm)
Dimensions (Designer Bottom-Mount)
26
Designer 36” 36” Desig er Bottom-Mou t
Descriptio DDBB363
Overall width 36” (91.5 cm)
Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
Overall depth from rear To front edge of side trim: 23-3/8” (59.4 cm)
To front of top grille: 24” (61.0 cm)
To front of handle: 26” (66.0 cm)
Cutout width 36” (91.5 cm)
Cutout height 82-7/8” (210.5 cm) min. to 84-1/16” (213.5 cm) max.
Cutout depth 24” (61.0 cm) min.
Electrical requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum amp usage 9.9 amps
Inlet water 1/4” copper tubing inlet waterline; minimum 20 psi;
Requirements maximum 120 psi
Overall interior dimensions
Refrigerator 15.2 cu. ft. (431 Liters)
Freezer 5.1 cu. ft. (145 Liters)
Total capacity 20.3 cu. ft. (576 Liters)
Approximate shipping weight 565 lbs. (254.3 kg)

One 2”x 4” Mounting Board
1–1/2” (3.8 cm) x3–1/2” (8.9 cm)
NOTE: If unit is installed deeper than 24” (61.0 cm), thenshim
behind the mounting board by the difference.
Bottom of anti-tip board is 3–7/8” (9.8 cm) belowopening height.
NOTE: Top of unit must be placed firmly under anti-tip board.
Anti-Tip Location
79–3/8”
(201.6 cm) min.
to bottomof
anti-tipboard
80–1/2”
(204.6 cm) max.
to bottomof
anti-tipboard
29”
(73.7 cm)
3–1/2”
(8.9 cm)
1–1/2”
(3.8 cm)
Anti-Tip Dimensions (Designer Bottom-Mount)
29
9”
(22.9cm)
73–3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min.
anti-tip board&
opening height
84–1/16”
(213.5cm) min.
anti-tip board&
opening height
36”
(91.5 cm)
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
36”
(91.5 cm)
6–3/4”
(17.1 cm)
7–5/8”
(19.4 cm)
3”
(7.6 cm)
5/8”
(1.5 cm)
5/8”
(1.5 cm)
10–1/2”
(26.7 cm)
5/8”
(1.5 cm)
10–3/4”
(27.3 cm)
1”
(2.5cm)
3–5/8”
(9.2 cm)
Optional floor
water line entry
SeeAnti-Tip boardinstallation
6”
(15.2cm)
Cutout Dimensions (Designer Bottom-Mount)
28
36” Designer 36” Designer

Top View
Top View
Door
24”
(61.0 cm)
Standard
Cabinet
Depth
25”
(63.5 cm)
Countertop
Depth
Wall
3/4”
(1.9 cm)
Full End
Panel
Door
Wall
1”
(2.5 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
3/4”
(1.9 cm)
Full End
Panel
25”
(63.5 cm)
Flush
1”
(2.5 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
Flush
Cabinet Information (Designer)
31
Top View
Overlapping cabinet doors
Top View
Flush mount cabinet doors
Door
24”
(61.0cm)
Standard
Cabinet
Depth
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
Full End
Panel
3/4”
(1.9 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
Flush
Cabinet
Door
Door
Wall
3/4”
(1.9 cm)
Full End
Panel
1”
(2.5 cm)
If standard
25” (63.5 cm)
standard
cabinet depth
is used
Flush
25”
(63.5 cm)
Cabinet
Depth
Cabinet
Door
Cabinet Information (Designer)
30
Designer models fit flush in standard 24” (61.0 cm) deep cabinet openings with no protrusion into the
room except 2”(5.1 cm) curved handle depth.
Designer models fit flush in standard 24” (61.0 cm) deep cabinet openings with no protrusion into the
room except 2”(5.1 cm) curved handle depth.

3/4”
(1.9 cm)
End panel
1”
(2.5 cm) 1/4”
(0.6 cm)
Z-Bracket
21-3/4”
(55.2cm)
21-3/4”
(55.2cm)
24”
(61.0 cm)
Optional kickplate
Notch, dimensions
determined by cabinets
24”
(61.0 cm)
82-7/8”
(210.5cm)min.
to
84-1/16”
(213.5cm)max.*
82-7/8”
(210.5cm)min.
to
84-1/16”
(213.5cm)max.*
Custom Side Panel Dimensions
(Designer & Professional Integrated)
33
3/4”
(1.9 cm)
End panel
5/32”
(0.4 cm)
3/16”
(0.5 cm)
Back filler
panel
22-7/16”
(57.0cm)
22-7/16”
(57.0cm)
22-1/4”
(61.0cm)
6”
(15.2cm)
Optional kickplate
Notch, dimensions
determined by cabinets
82-7/8”
(210.5cm) min.
to
84-1/16”
(213.5cm) max.*
82-7/8”
(210.5cm)min.
to
84-1/16”
(213.5cm)max.*
6”
(15.2 cm)
22-1/4”
(61.0cm)
Custom Side Panel Dimensions
(Professional)
32
* Depending on how high leveling feet are raised, and cabinet enclosure height. * Depending on how high leveling feet are raised, and cabinet enclosure height.

General Information
Water Supply Requirements
Use only 1/ ” (6 mm) copper tubing for
water line. Do Not install copper tubing in
area where temperatures drop below
35˚ F (1.7˚ C). Before attaching copper
tubing to the unit, flush at least 2 quarts
(1.9 L) of water through the copper tubing
and into a bucket to remove any particles
in the water line.
• Viking Range Corporation is not
responsible for property damage due to
improper installation or water
connection.
Connect 1/4” (6 mm) flexible copper tubing
to household plumbing in compliance with
local codes and ordinances.
Length of copper tubing must reach from
water supply connection to the unit
connection with an additional length to
facilitate moving the unit out of enclosure
for cleaning or service. Tubing should be
soft instead of rigid and ends should be
free of burrs.
Copper tubing route must be above 35˚ F
(1.7˚ C) to prevent water line from freezing.
• Do not use plastic water lines from the
household plumbing to the water inlet
valve connection on the refrigeration
unit.
• Do not use the self-piercing feature of a
saddle valve. The hole made by the
piercing lance is too small for the water
flow rate required by the ice maker.
If saddle valve is not used, place a
separate shut-off valve in an easily
accessible location between water supply
and the unit. Do not locate shut-off valve
behind the unit.
The installation of Viking units with a
reverse osmosis system is acceptable
as long as the water pressure remains
within the allowable PSI as stated below.
It is important to note that with many
reverse osmosis systems, the pressure
starts off high, but then it decreases as the
water level of the reverse osmosis storage
area drops. This must be considered when
checking the water pressure coming into
the unit.
Connect a vertical or horizontal 1/2” (1.2 cm)
to 1-1/4” (3.2 cm) COLD water line near
water area.
Run water line through the floor, back, or
side wall. Tubing should lay flat on floor
underneath the unit. Clamp tubing to wall
or floor.
Water pressure must be greater than 20 psi
and less than 120 psi on non-dispensers
and greater than 35 psi and less than 120
psi on dispensers.
35
Area Requirements
Verify the following:
Unit can fit into residence and can be
moved around corners and through
doorways.
Floors can support unit’s weight plus food
weight (approximately 1200 pounds [540 kg]
total).
Rear wall is solid and is able to support
two horizontally mounted 2X4s (included)
bolted to two wall studs. The 2X4
board bolt heads must be flush with 2X4
to prevent obstruction.
Remove anything attached to rear or side
walls that can obstruct unit installation.
Cutout dimensions are accurate.
Electrical outlet is in correct location.
Water line is in correct location.
Do not install a refrigeration unit near a
heat source, nor in a location where the
surrounding temperature will fall below
60º F (16º C).
Electrical Requirements
It is the customer’s responsibility to:
Contact a qualified electrical installer.
Assure that the electrical installation is
adequate and in conformance with the
National Electrical Code, ANSI/NFPA 70-
latest edition or Canadian Electrical Code
C22.1-1998 and C22.2 No. 0-M91 (or
latest edition), and all local codes and
ordinances. A 115 volt, 60-Hz, 15 amp,
fused, electrical supply is required. It is
required that a separate circuit serving only
this appliance be provided. This appliance
is equipped with a power supply cord
having a 3-prong grounding plug. To
minimize possible shock hazard, the cord
must be plugged into a mating 3-prong,
grounding-type wall receptacle.
Do not use an extension cord.
If codes permit a separate grounding wire to
be used, it is recommended that a qualified
electrician determine that the grounding
path is adequate.
DO NOT ground to a gas pipe. Check with
a qualified electrician if you are not sure the
appliance is properly grounded. DO NOT
have a fuse in the neutral or grounding
circuit.
Anti-Tip Requirements
The anti-tip boards should be fastened
into position prior to moving the unit into
the opening.
NOTE: Additional mounting boards may
be required if the unit does not touch
the back all of the enclosure. To
prevent unit from tipping for ard, it
must be secured in place ith a solid
soffit or ood block.
34
General Information
C A U T I O N
Be sure to have a replacement cartridge available
when filter change is required.
If water filtration system has been allowed to
freeze, replace filter cartridge.
If system has not been used in several months, and
water has an unpleasant taste or odor, flush system
by dispensing 2-3 glasses of water. If unpleasant
taste or odor persists, change filter cartridge.
WARNING
To avoid serious illness or death, do not use unit
where water is microbiologically unsafe or of
unknown quality without adequate disinfection
before or after the system. Systems certified for cyst
reduction may be used on disinfected water that
may contain filterable cysts. The contaminants or
other substances removed or reduced by this water
treatment system are not necessarily in you water.

37
1
2a
Place unit in front of cutout. (Professional) Lift center grille louver up
and pull out.
2b
3
(Designer) Pull the center grille louver up
at an angle and pull out.
Using an 8” magnetic nut driver, remove
the two 1/4” screws.
4
Remove grille assembly.
Most of the unit’s weight is at the top.
Extra care is needed when moving the unit
to prevent tipping.
Do not remove protective film until unit is
in operating position.
All four leveling legs must contact the floor
to support and stabilize the full weight.
Do not drop unit.
Remove exterior shipping materials prior
to moving unit into home, except door
latching device.
Use two or more people to move and
install unit. Failure to follow this instruction
can result in back or other injury.
To avoid personal injury, wear gloves when
performing any installation procedure and
wear eye protection when cutting metal
straps.
TIP OVER HAZARD
Appliance is top heavy and tips easily
when not completely installed. Keep
doors closed until appliance is
completely installed and secured per
installation instructions. Use two or
more people to move and install
appliance. Failure to do so can result
in death or serious injury.
Unpacking Unit
1. Remove top and bottom strap.
2. Remove top cap.
3. Cut carton rear approximately 1/4”
(0.6 cm) to 1” (2.5 cm) from right corner
with a utility knife extended 1/4” (0.6 cm).
4. Remove carton and exterior packaging.
Save cardboard shipping material to
protect floor surface when installing unit.
Remove anti-tip board, kickplate and door
trim pieces (DF models) from rear of unit.
36
Moving Unit
Remove shipping brackets from skid by removing four
bolts (two on each side) with a 1/2” deep-well socket
wench and a pair of pliers.
NOTE: Tilting unit is not required to remove
shipping brackets
Slip appliance dolly between unit and skid. Remove
unit from skid.
NOTE: Use excess packaging to protect decorative
trim; also, verify that leveling legs are up (0”
adjustment)
General Information
Installation

39
9
3”
3”3”
10a
Plug in power cord to verify operation.
NOTE: Make sure power switch is in the “On” Position
Place unit within 3” of being flush with cabinets.
NOTE: To avoid cabinet damage, place cardboard
between cabinets and unit When moving unit, do not
crimp, kink or crush water supply line
10b
11
Carefully move unit until semi flush with cabinet
(depending on unit).
Pull supply tubing forward under unit.
NOTE: DO NOT use plastic water lines
12
13
Flush water line by running two quarts of water
into a bucket. Turn water off.
Connect supply tube to water valve using
a 1/2” wrench. NOTE: DO NOT overtighten
38
Remove four side screws and remove unit top. Loosen the four hinge screws. Adjust door.
Retighten four hinge screws.
Replace unit top. Replace four side screws.
Attach one 2x4 to wall stud (refer to dimensions page
for exact location).
If needed, depending on cabinet and depth,
attach second 2x4 to first 2x4.
2
1
5
Front of unit
2
1 3
6
1
2
7
8a
Wall
2 x 4
Refrigerator
8b
Wall
2 x 4
Refrigerator
Hinge Adjustment
