PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
CUSTOM PANEL–REFRIGERATION
Built In 36”W. Bottom Mount Refrigerator/Freezer—DFBB536
35-1/4”
(89.5cm)
23-1/16”
(58.6cm)
3/4”
(1.9cm)
35-1/4”
(89.5cm)
32-1/4”tonotch
(81.9cm)
3”
(7.6cm)
5/8”
(1.6cm)
51-7/8”
(131.8cm)
51-1/4”
(130.2cm)
3/4”
(1.9cm)
Note:Cornernotchisforleft
hingedoor.(Reverseforrighthinge)
Seecutoutinstructionsininstallation
manual
Note: Inset shown
upside down
1-13/16”
(4.60cm)
5/8”
5/8”
(1.6cm)
(1.6 cm)
3”
(7.62cm)
3/32”
(.24cm)
5/8”
5/8”
(1.6cm)
Note: Panel overlays must be dry, solid, straight one piece panels. The use of multiple panel pieces to achieve the dimensions is not
recommended.
Dimensions & Specifications
DFBB536
Overall panel width 35 1/4” (89.5 cm)
Overall panel height
Refrigerator front 51 7/8” (131.8 cm)
Freezer front 23 1/16” (58.6 cm)
Overall panel depth 3/4” (1.9 cm)*
Maximum panel weight
Refrigerator front 45 lbs. (20.4 kg)
Freezer front 20 lbs. (9.0 kg)
*Panel thickne mu t not exceed 1” (2.5 cm) on hinge ide. Thicker panel will interfere with door wing and clearance.
CUSTOM PANEL DIMENSIONS
DFBB536

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
CUSTOM PANEL–REFRIGERATION
Built In 36”W. Bottom Mount Refrigerator/Freezer—DFBB536
Dimensions & Specifications
CUSTOM SIDE PANEL DIMENSIONS
Note: Adding a 3/4” 1.9 cm) side panel adds an additional 3/4” 1.9 cm) to the overall width of the product for each side panel.
Requires side panel hardware kit Kit model number – SPHKDS)
DFBB536
Overall panel width 3/4” (1.9 cm)
Overall panel height 82 7/8” (210.5 cm) min. to 84 1/16” (213.5 cm) max.*
Overall panel depth 24” (61.0 cm)
*Depending on how high leveling feet are rai ed and cabinet enclo ure height.
DFBB536
3/4”
(1.9 cm)
End panel
1”
(2.5 cm) 1/4”
(0.6 cm)
Z-Bracket
21-3/4”
(55.2 cm)
21-3/4”
(55.2 cm)
24”
(61.0cm)
Optional kickplate notch
Dimensions determined by cabinets
24”
(61.0cm)
82-7/8”
(210.5cm)min.
to
84-1/16”
(213.5cm)max.*
82-7/8”
(210.5cm)min.
to
84-1/16”
(213.5cm)max.*

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
CUSTOM PANEL–REFRIGERATION
Built In 36”W. Bottom Mount Refrigerator/Freezer—DFBB536
Dimensions & Specifications
DFBB536
Overall grille width 35 1/2” (90.1 cm)
Overall grille height 3” (7.6 cm)
Overall grille depth 3 3/4” (9.5 cm)
Reverse dimensions
for other end.
1/2”
(1.27cm)
1-1/2”
(3.81cm)
1/4” Radius
(.64cm)
2-3/4”
(6.98cm)
1/2”
(1.27 cm)
3/4”
(1.90cm)
1/2”
(1.27 cm)
1/8”
(.31 cm)
1/2”
(1.27cm)
1/4” Radius
1/4” Radius
(1.2 cm) (1.2 cm)
1/4” Radius
(.64cm)
7/8”
(2.22 cm)
1/2”
(1.27cm)
34”
(86.36cm)
34”
(86.36cm)
3/4”
(1.90 cm)
2-1/8”
(5.4cm)
1/2”
(1.27 cm)
3/4”
(1.90 cm)
3-3/4”
(9.52 cm)
3-3/4”
(9.52cm)
3-5/8”
(9.20 cm)
33-15/16”
(86.20cm)
3”
(7.62 cm)
3”
(7.62 cm)
3/4”
(1.90cm)
35-1/2”
(90.17cm)
1/2”
(1.27 cm)
3-1/8”
(7.93 cm)
Optional hinge cover
32-3/16”
(81.75cm)
5-17/32”
(14.10cm)
4-11/64”
(10.59cm)
30-27/32”
(78.34cm)
325/32”
(9.60cm)
27/32”
(.84 cm)
9/16”
(1.42cm)
1/4”
(.635cm)
16.5˚
20.0˚
CUSTOM GRILLE DIMENSIONS
DFBB536

PLANNING AND DESIGN GUIDE
VIKINGRANGE.COM • 1-888-VIKING1
R E V I S E D 7 / 1 5 / 1
© 2 1 V R C — INFORMATION SUBJECT TO CHANGE
CUSTOM PANEL–REFRIGERATION
Built In 36”W. Bottom Mount Refrigerator/Freezer—DFBB536
DFBB536/DFBB536
Overall grille width 71 1/2” (181.6 cm)
Overall grille height 3” (7.6 cm)
Overall grille depth 3 3/4” (9.5 cm)
325/32”
(9.60cm)
27/32”
(.84 cm)
9/16”
(1.42cm)
1/4”
(.635cm)
16.5˚
20.0˚
Note: This part should be
located at the center of the
grille. If desired, twoper grille
can be used by dividing the
length of the grille into thirds.
1/2”
(1.27cm)
1-1/2”
(3.81cm)
1/4”Radius
(.64cm)
2-3/4”
(6.98cm)
1/2”
(1.27cm)
3/4”
(1.90cm)
3/8”
(0.38 cm)
1/2”
(1.27 cm)
R3/32”
(0.09 cm)
3/4”
(1.90 cm)
3/4”
(1.90 cm)
3/4”
(1.90 cm)
13/32”
(1.03 cm)
9/16”
(1.43 cm)
1/8”
(.32 cm)
Grille support
2-7/8”
(7.30cm)
1”
(2.54cm)
1/2”
(1.27 cm)
1/8”
(.31 cm)
1/2”
(1.27cm)
1/4” Radius1/4” Radius
(1.2 cm)
(1.2 cm)
1/4” Radius
(.64cm)
Reverse dimensions
for other end.
7/8”
(2.22cm)
1/2”
(1.27 cm)
1/2”
(1.27 cm)
3-1/8”
(7.93 cm)
Optional hinge cover
1/2”
(1.27cm)
3-5/8”
(9.20 cm)
3/4”
(1.90cm)
3/4”
(1.90 cm)
3-3/4”
(9.52cm)
3-3/4”
(9.52 cm)
3”
(7.62 cm)
3”
(7.62cm)
3/4”
(1.90cm)
71-1/2”
(181.61 cm)
70”
(177.80 cm
69-15/16”
(177.64 cm)
70”
(177.80 cm)
68-3/64”
(172.83cm)
66-27/32”
(169.78cm)
4-11/64”
(11.27cm)
5-17/32”
(14.04cm)
30-27/32”
(78.34cm)
32-3/16”
(81.75cm)
40-11/64”
(102.03cm)
41-25/64”
(105.13cm)
2-1/8”
(5.4cm)
DFBB536
Dimensions & Specifications
CUSTOM GRILLE DIMENSIONS – DUAL BOTTOM-MOUNT INSTALLATION
Dual 36”W. Grille
Note: Dual units can only be made in a left and right hand configuration. To use a custom 72”W. grille, you must purchase the center
trim kit FCTKSS.
