Viking VE-ARSW User manual

PRODUCT MANUAL
Designed, Manufactured and Supported in the USA
COMMUNICATION & SECURITY SOLUTIONS
Area of Refuge Surface Mount
Command Center Cabinet
Features
Each Area of Refuge is required to have a
central control point (Command Center)
where the emergency phones call for assis-
tance.
In low rise buildings (less than 60 ft. tall) the
Command Center can simply be a telephone
mounted in a cabinet located on the ground
floor of the elevator lobby. The VE-ARSW
cabinet is ideal for this application, allowing
you to mount a single line phone or PABX
Key phone.
The VE-ARSW is a 13” x 13.5” x 4” surface
mount metal cabinet with a hinged door,
roller catch, chrome handle, phone mounting
studs and optional lock. The lock is equipped
with a breakaway cam allowing emergency
personnel to force the door open if the key
cannot be found.
• 20 gauge galvanneal steel cabinet with
gloss white powder coat finish
• Optional roller catch to keep door closed
when not using the lock
• Lock with breakaway cam and two keys
• Heavy duty chrome plated cast handle
• Mounting studs on back panel for
mounting any standard wall phone
• Hinged door with clear acrylic window
• Wall mounting an Area of Refuge com-
mand center phone at the ground floor ele-
vator lobby in low rise buildings
Material: 20 gauge galvanneal steel
Finish: Gloss white powder paint
Dimensions: 13” x 13.5” x 4” (330.2mm x
342.9mm x 101.6mm)
Weight: 8.0 lbs (3.63 kg)
Mounting: Surface mount to wall via (4) mounting
holes
Included Hardware: (2) keys, handle with #8-32
x 3/4” mounting screws, roller latch with (2) #8 x
3/8” sheet metal mounting screws
VE-ARSW
Command Center
Cabinet
December 21, 2016
Applications
Specifications
www.vikingelectronics.com
Information: (715) 386-8861
VIKING
Shown with Panasonic 824 PABX key phone
model KX-T7731 (not included)
Installation and Specifications
2
A. Installing the Handle
13.5”
13.0”
4.0”
(2) key hole mounting holes
(2) mounting holes
(2) studs for mounting
a standard wall phone Access hole
for wiring
Front View Side View
B. Installing the Roller Catch
Step 1 Align the roller catch with the two holes centered on the inside of the door.
Step 2 Attach using two #8x3/8” sheet metal screws.
Step 3 Adjust the roller catch so that it catches the frame of the cabinet when opening and
closing.
Step 1 Align the handle with the two holes on the outside of the cabinet door.
Step 2 Attach using two 8-32x3/4” screws provided.
AREAOF REFUGE
Requirements for INSIDE
the Area of Refuge
Requirements for OUTSIDE
the Area of Refuge
Requirements for the
Area of Refuge
Lobby Command Center
Model
1600A Series Illuminated Signage
Directional Signage
Tactile
Signage
Two-Way
Communications
System
Instructional SignageTwo-Way
Communications
Area of Refuge Command Center
(phone in locked cabinet located
in the elevator lobby*)
Refuge Locking Command
Center Enclosure
Model VE-ARSW (surface mount)
VIKING
Persons able to use the exit
stairway do so as soon as
possible, unless they are
assisting others.
After activating
the Area of Refuge
communication system,
wait here for assistance.
LOC TION
Model ARS-IB100
AREA OF REFUGE
Model ARS-DLB100 (Left arrow)
Model ARS-DRB100 (Right arrow)
Model ARS-LR100
Model
ARS-TB100
EMERGENCY
PHONE
HELP
AREAOF REFUGE
* For buildings under 60 ft. For taller buildings, the
Refuge Command Center phone should be located
in the Fire Command Center.
As required by the
following codes:
IBC 1007, 1011
ICC 703
NFPA 22, 101
ADA 4.3.11
Recommendations for 6 or Less
Area of Refuge Emergency Phones
Recommendations for 7-23
Area of Refuge Emergency Phones
120V AC
6 Port Line Concentrator
Model LC-6
High Efficiency UPS
(Tripp-Lite model Internet55U
or equivalent)
Connect up to 6 Area of Refuge emergency phones (1600A Series)
to one command center phone and one C.O. line. UPS must have a
minimum of 90 minute backup.
120V AC
High Efficiency UPS
(Minuteman Entrust Series
ETR700 or equivalent)
Panasonic KX-TA824
Using a Panasonic KX-TA824 with optional expansion cards KX-TA82483 and
KX-TA82470, connect up to 23 Area of Refuge emergency phones (1600A Series)
to one command center phone and one C.O. line. UPS must have a minimum of
90 minute backup. Note: The Panasonic KX-TA824 can be expanded (in
increments of 6) up to 138 ports by adding a Viking LC-6 to each station port.
Application Examples
3
Printed in the U.S.A.
DOD# 237
ZF303510 Rev A
Due to the dynamic nature of the product design, the information contained in this document is subject to change without notice. Viking Electronics, and its affiliates
and/or subsidiaries assume no responsibility for errors and omissions contained in this information. Revisions of this document or new editions of it may be issued
to incorporate such changes.
Warranty
Product Support: (715) 386-8666
8
IF YOU HAVE A PROBLEM WITH A VIKING PRODUCT, CONTACT: VIKING TECHNICAL SUPPORT AT (715) 386-8666
Our Technical Support Department is available for assistance Monday 8am - 4pm and Tuesday through Friday 8am - 5pm central time. So
that we can give you better service, before you call please:
1. Know the model number, the serial number and what software version you have (see serial label).
2. Have your Product Manual in front of you.
3. It is best if you are on site.
RETURNING PRODUCT FOR REPAIR
The following procedure is for equipment that needs repair:
1. Customer must contact Viking's Technical Support Department at 715-386-8666 to obtain a Return Authorization (RA) number. The cus-
tomer MUST have a complete description of the problem, with all pertinent information regarding the defect, such as options set, condi-
tions, symptoms, methods to duplicate problem, frequency of failure, etc.
2. Packing: Return equipment in original box or in proper packing so that damage will not occur while in transit. Static sensitive equipment
such as a circuit board should be in an anti-static bag, sandwiched between foam and individually boxed. All equipment should be
wrapped to avoid packing material lodging in or sticking to the equipment. Include ALL parts of the equipment. C.O.D. or freight collect
shipments cannot be accepted. Ship cartons prepaid to: Viking Electronics, 1531 Industrial Street, Hudson, WI 54016
3. Return shipping address: Be sure to include your return shipping address inside the box. We cannot ship to a PO Box.
4. RA number on carton: In large printing, write the R.A. number on the outside of each carton being returned.
RETURNING PRODUCT FOR EXCHANGE
The following procedure is for equipment that has failed out-of-box (within 10 days of purchase):
1. Customer must contact Viking’s Technical Support at 715-386-8666 to determine possible causes for the problem. The customer MUST
be able to step through recommended tests for diagnosis.
2. If the Technical Support Product Specialist determines that the equipment is defective based on the customer's input and troubleshooting,
a Return Authorization (R.A.) number will be issued. This number is valid for fourteen (14) calendar days from the date of issue.
3. After obtaining the R.A. number, return the approved equipment to your distributor, referencing the R.A. number. Your distributor will then
replace the Viking product using the same R.A. number.
4. The distributor will NOT exchange this product without first obtaining the R.A. number from you. If you haven't followed the
steps listed in 1, 2 and 3, be aware that you will have to pay a restocking charge.
TWO YEAR LIMITED WARRANTY
Viking warrants its products to be free from defects in the workmanship or materials, under normal use and service, for a period of two years
from the date of purchase from any authorized Viking distributor. If at any time during the warranty period, the product is deemed defective or
malfunctions, return the product to Viking Electronics, Inc., 1531 Industrial Street, Hudson, WI., 54016. Customer must contact Viking's Technical
Support Department at 715-386-8666 to obtain a Return Authorization (R.A.) number.
This warranty does not cover any damage to the product due to lightning, over voltage, under voltage, accident, misuse, abuse, negligence
or any damage caused by use of the product by the purchaser or others. This warranty does not cover non-EWP products that have been
exposed to wet or corrosive environments. This warranty does not cover stainless steel surfaces that have not been properly maintained.
NO OTHER WARRANTIES. VIKING MAKES NO WARRANTIES RELATING TO ITS PRODUCTS OTHER THAN AS DESCRIBED ABOVE
AND DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE.
EXCLUSION OF CONSEQUENTIAL DAMAGES. VIKING SHALL NOT, UNDER ANY CIRCUMSTANCES, BE LIABLE TO PURCHASER,
OR ANY OTHER PARTY, FOR CONSEQUENTIAL, INCIDENTAL, SPECIAL OR EXEMPLARY DAMAGES ARISING OUT OF OR RELATED
TO THE SALE OR USE OF THE PRODUCT SOLD HEREUNDER.
EXCLUSIVE REMEDY AND LIMITATION OF LIABILITY. WHETHER IN AN ACTION BASED ON CONTRACT, TORT (INCLUDING NEGLI-
GENCE OR STRICT LIABILITY) OR ANY OTHER LEGAL THEORY, ANY LIABILITY OF VIKING SHALL BE LIMITED TO REPAIR OR RE-
PLACEMENT OF THE PRODUCT, OR AT VIKING'S OPTION, REFUND OF THE PURCHASE PRICE AS THE EXCLUSIVE REMEDY AND
ANY LIABILITY OF VIKING SHALL BE SO LIMITED.
IT IS EXPRESSLY UNDERSTOOD AND AGREED THAT EACH AND EVERY PROVISION OF THIS AGREEMENT WHICH PROVIDES
FOR DISCLAIMER OF WARRANTIES, EXCLUSION OF CONSEQUENTIAL DAMAGES, AND EXCLUSIVE REMEDY AND LIMITATION OF
LIABILITY, ARE SEVERABLE FROM ANY OTHER PROVISION AND EACH PROVISION IS A SEPARABLE AND INDEPENDENT ELEMENT
OF RISK ALLOCATION AND IS INTENDED TO BE ENFORCED AS SUCH.
