Viking PB-1 User manual

PRODUCT MANUAL
Designed, Manufactured and Supported in the USA
COMMUNICATION & SECURITY SOLUTIONS
Emergency Phone Panic Button Kit
(for use with Viking Emergency Phones)
Features
• LED to indicate call connected
• One-way talk path for listening
without audible indication
• Unobtrusive - mount anywhere at any
angle with supplied foam tape
• Provides security and peace of mind
• Switch can be used to trigger inputs
on K-2000-DVA, K-202-DVA, SLP-1,
SLP-4, etc.
• Courtrooms
• Bank tellers
• Gas stations
• Motel reception desks
• All night restaurants
• Convenience stores
PB-1
Panic Button Kit
August 3, 2017
Applications
Specifications
www.vikingelectronics.com
Information: [phone]
VIKING
The PB-1 Panic Button Kit connects to
a Viking 1600A or 1600-IP Series
Emergency Phone to provide a one-way
talk path to the pre-programmed
number when used.
The PB-1 will activate the 1600A or
1600-IP Series Emergency Phone and
allows the called party to light a red LED
to indicate that the call is connected.
The called party will be able to hear the
installation site, but the site will not be
able to hear the called party. This makes
Dimensions: 65mm x 35mm x 20mm
(2.56” x 1.38” x 0.79”)
Shipping Weight: 0.05kg (0.1 lbs)
Environmental: 0°C to 32°C (32°F to
90°F) with 5% to 95% noncondensing
humidity
Cord Length: 7 ft
Connections: (1) RJ11 jack, (1) 10-
position JST connector, (6) gel-filled butt
connectors
it a very effective security measure, as
there is no other indication that the site
is being monitored.

Installation
A. Connecting to a Viking 1600A Series Analog Emergency Phone
Step 1. Mount the PB-1 using the supplied foam tape.
Step 2. Connect the RJ11 plug on the supplied cable to the PB-1.
Step 3. Disconnect the installed white connector from the 1600A Series
Emergency Phone board.
Step 4. Remove the 1600A Series Emergency Phone board and then remove the
installed mic by carefully pulling it out of the black plastic mic mount.
Step 5. Place the mic from the PB-1 cable into the mic mount and replace the
1600A Series Emergency Phone board.
Step 6. Connect the white connector on the PB-1 cable to the 1600A Series
phone board.
Step 7. Connect the phone line to the red and green wires from the 1600A Series
Emergency Phone board.
Red
Green
Connect to
phone line
Mic
to PB-1
PB-1
1600A Series Circuit Board
White
Connector
2

3
B. Connecting to a Viking 1600A-EWP Series Analog Emergency Phone
Step 1. Mount the PB-1 using the supplied foam tape.
Step 2. Connect the RJ11 plug on the supplied cable to the PB-1.
Step 3. Cut the PB-1 cable at the white connector, discard the connector and
mic.
Step 4. Cut the black and red wires leading to the LED from the 1600A Series
board, leaving at least 1 inch of wire at the connector.
Step 5. Attach the black wire from the board to the black wire from the PB-1
using a gel-filled butt connector (do not strip prior to inserting).
Step 6. Attach the red wire from the board to the yellow wire from the PB-1.
Step 7. Cut the two black wires leading to the switch from the 1600A Series
board, leaving at least 1 inch of wire at the connector.
Step 8.
Attach one black wire to the red wire, and one to the green wire from the
PB-1 (non-polarity sensitive).
Step 9. Cut the two white wires leading to the speaker from the 1600A board.
Step 10. Connect the phone line to the red and green wires from the PCB.
Red
Green
- Black
+ Yellow
to PB-1
Red
Green
OR
C.O. Line
Analog
PABX/KSU
Station
1600A-EWP
Series
Circuit Board
Cut
Speaker
PB-1
Black
Yellow
Black
Black
- Black
+ Red
White
White
Switch Wires
LED Wires

4
C. Connecting to a Viking 1600-IP Series VoIP Emergency Phone
Step 1. Mount the PB-1 using the supplied foam tape.
Step 2. Connect the RJ11 plug on the supplied cable to the PB-1.
Step 3. Disconnect the installed white connector from the 1600-IP Series
Emergency Phone board.
Step 4. Remove the 1600-IP Series Emergency Phone board and then remove
the installed mic by carefully pulling it out of the black plastic mic mount.
Step 5. Place the mic from the PB-1 cable into the mic mount and replace the
1600-IP Series Emergency Phone board.
Step 6. Connect the white connector on the PB-1 cable to the 1600-IP Series
phone board.
Step 7. Connect the LAN with PoE cable to the RJ-45 jack.
Mic
to PB-1
PB-1
1600-IP Series Circuit Board
White
Connector
MAC:
18E80FXXXXXX
asdesaxtff

5
D. Connecting to a Viking 1600-IP-EWP Series VoIP Emergency Phone
Step 1. Mount the PB-1 using the supplied foam tape.
Step 2. Connect the RJ11 plug on the supplied cable to the PB-1.
Step 3. Cut the PB-1 cable at the white connector, discard the connector and
mic.
Step 4. Cut the black and red wires leading to the LED from the 1600-IP Series
board, leaving at least 1 inch of wire at the connector.
Step 5. Attach the black wire from the board to the black wire from the PB-1
using a gel-filled butt connector (do not strip prior to inserting).
Step 6. Attach the red wire from the board to the yellow wire from the PB-1.
Step 7. Cut the two black wires leading to the switch from the 1600-IP Series
board, leaving at least 1 inch of wire at the connector.
Step 8.
Attach one black wire to the red wire, and one to the green wire from the
PB-1 (non-polarity sensitive).
Step 9. Turn speaker mode to Off/Silent Monitor in IP Programming. See the
1600-IP Series Product Manual, DOD# 255.
Step 10. Connect the LAN with PoE cable to the RJ-45 jack.
1600-IP-EWP Series Circuit Board
MAC:
18E80FXXXXXX
asdesaxtff
to PB-1
PB-1 Red
Green
- Black
+ Yellow
Black
Black
- Black
+ Red
Switch Wires
LED Wires

6
E. Switch Only Applications (K-2000-DVA, K-202-DVA, SLP-1 or SLP-4)
to PB-1
PB-1
Black
Yellow
Red
Green
Terminals on Product
Step 1. Mount the PB-1 using the supplied foam tape.
Step 2. Connect the RJ11 plug on the supplied cable to the PB-1.
Step 3. Cut the PB-1 cable at the white connector, discarding the connector and
mic.
Step 4. Connect the red and green wires to the contact terminals on the product
(non-polarity sensitive).
A. Recommended DIP Switch Settings
B. Accessing the Programming Mode
Programming the E-1600A Series Analog Emergency Phone
IMPORTANT: Use the information below in conjunction with the 1600A Series
Technical Practice (DOD# 215).
Switch Position Description
1 OFF Disable hang-up with the “Call” button*
2 ON Enable answering of incoming calls
3 ON Normal operation mode
Step 1. Move DIP switch 2 to the ON position (sets unit to answer incoming calls).
Step 2. Move DIP switch 3 to the OFF position (incoming calls enter
Programming without security code).
Step 3. From a touch tone phone call the line attached to the 1600A Series
phone.
Step 4. When the 1600A Series, a double beep will be heard and the unit will
enter the programming mode.
Step 5. When finished programming, move DIP switch 3 back to the ON position.

7
C. Touch Tone Programming
Make a recording (Q4) including the following details:
1. Location of the emergency phone
2. One way talk path (listen only)
3. Press Qto stop this message and indicate that the call is connected
Enter Digits
Enter
Programming
Location
Description
0-20 digits #00 - #05 Up to 5 emergency speed dial numbers.
000210 #17 Play message on answer, dial “Q” to stop
message and light LED on PB-1.
100321 #18
0.1 second VOX time, no call length or silence
time out, dial next number on ring-no-answer
(3 rings) and busy signal, 10pps pulse dialing
speed.
D. Recording a Message

8
