Viking Designer EPIC User manual

User’s Guide
KEEPING THE WORLD SEWING™

This household sewing machine is designed to comply with IEC/EN 60335-2-28 and UL1594.
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety precautions should always be followed, including the
following:
Read all instructions before using this household sewing machine. Keep the instructions at a suitable
place close to the machine. Make sure to hand them over if the machine is given to a third party.
DANGER –TO REDUCE THE RISK OF ELECTRIC SHOCK:
• A sewing machine should never be left unattended when plugged in. Always unplug this sewing
machine from the electric outlet immediately after using and before cleaning, removing covers,
lubricating or when making any other user servicing adjustments mentioned in the instruction
manual.
WARNING –TO REDUCE THE RISK OF BURNS, FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSON:
• Do not allow to be used as a toy. Close attention is necessary when this sewing machine is used by
or near children.
• Use this sewing machine only for its intended use as described in this manual. Use only
attachments recommended by the manufacturer as contained in this manual.
• Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if
it has been dropped or damaged, or dropped into water. Return the sewing machine to the nearest
authorized dealer or service center for examination, repair, electrical or mechanical adjustment.
• Never operate the sewing machine with any air openings blocked. Keep ventilation openings of
the sewing machine and foot control free from the accumulation of lint, dust, and loose cloth.
• Keep fingers away from all moving parts. Special care is required around the sewing machine
needle.
• Always use the proper needle plate. The wrong plate can cause the needle to break.
• Do not use bent needles.
• Do not pull or push fabric while stitching. It may deflect the needle causing it to break.
• Wear safety glasses.
• Switch the sewing machine off (“0”) when making any adjustment in the needle area, such as
threading needle, changing needle, threading bobbin, or changing presser foot, etc.
• Never drop or insert any object into any opening.
• Do not use outdoors.
• Do not operate where aerosol (spray) products are being used or where oxygen is being
administrated.
• To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• The foot control is used to operate the machine. Avoid placing other objects on the foot control.
• Do not use the machine if it is wet.

• If the LED lamp is damaged or broken, it must be replaced by the manufacturer or its service
agent or a similarly qualified person, in order to avoid a hazard.
• If the cord connected with the foot control is damaged, it must be replaced by the manufacturer
or its service agent or a similarly qualified person, in order to avoid a hazard.
• This sewing machine is provided with double insulation. Use only identical replacement parts. See
instructions for Servicing of Double-Insulated Appliances.
SAVE THESE INSTRUCTIONS
FOR EUROPE ONLY:
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made
by children without supervision.
The noise level under normal operating conditions is less than 80dB(A).
The machine must only be used with foot control of type FR5 manufactured by Shanghai Binao
Precision Mould Co., Ltd.
FOR OUTSIDE EUROPE:
This sewing machine is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the sewing machine by a person responsible for their
safety. Children should be supervised to ensure that they do not play with the sewing machine.
The noise level under normal operating conditions is less than 80dB(A).
The machine must only be used with foot control of type FR5 manufactured by Shanghai Binao
Precision Mould Co., Ltd.
SERVICING OF DOUBLE INSULATED PRODUCTS
In a double-insulated product, two systems of insulation are provided instead of grounding. No
ground means is provided on a double-insulated product, nor should a means for grounding be
added to the product. Servicing of a double-insulated product requires extreme care and knowledge
of the system and should be done only by qualified service personnel. Replacement parts for a
double-insulated product must be identical to those parts in the product. A double-insulated product
is marked with the words ‘DOUBLE INSULATION’ or ‘DOUBLE INSULATED’.

Federal Communication Commission Interference Statement
For the USA and Canada
Responsible party: VSM Group AB (wholly owned subsidiary of SVP Worldwide)
Drottninggatan 2, 56184 Huskvarna, SWEDEN
Product name: HUSQVARNA VIKING® DESIGNER EPIC™ sewing and
embroidery machine
Model number: SFV1
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the authorized HUSQVARNA VIKING® retailer or an experienced radio/TV technician
for help.
The included interface cable should be used in order to ensure compliance with the limits for a Class
B digital device.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate this equipment.
Declaration of Conformity
For Europe
Hereby, VSM Group AB (wholly owned subsidiary of SVP Worldwide), declares that this sewing and
embroidery machine is in compliance with the essential requirements and other relevant provisions of
Directive 2014/53/EU. To view a copy of the Declaration of Conformity, please seeRC-0234 EU
Declaration .

TABLE OF CONTENTS
1 Introduction .................................................. 9
Machine Overview ........................................10
Front .......................................................... 10
Needle Area ................................................. 11
Right Side .................................................... 11
Rear............................................................ 11
Accessory Tray ............................................. 12
Storing a Needle Plate.................................... 12
Embroidery Unit........................................... 12
Function Buttons............................................13
Automatic Needle Threader ............................ 13
Stitch Re-Start .............................................. 13
Speed – and + .............................................. 13
Needle Stop Up/Down.................................. 13
Cut Function................................................ 13
Reverse ....................................................... 14
Start/Stop.................................................... 14
FIX function ................................................ 14
STOP function ............................................. 14
Presser Foot Down and Pivot.......................... 14
Presser Foot Up and Extra Lift........................ 14
Basic Gestures for the Multi-Touch Screen ....15
Accessories....................................................16
Included Accessories ..................................... 16
Included Hoops............................................ 16
Presser Feet...................................................17
Stitch Overview.............................................19
Utility Stitches .............................................. 19
Stitch Menu Overview ................................... 22
Alphabets .................................................... 22
2 Preparations................................................ 23
Unpacking Machine and Embroidery Unit......24
Connect the Power Cord and Foot
Control..........................................................24
Pack Away After Sewing ................................25
USB Ports......................................................25
Using a USB device ....................................... 25
Getting Started with WiFi and
mySewnet ™ Cloud .......................................26
LED Lights .....................................................26
Free Arm.......................................................26
Manual Thread Cutter ...................................26
Thread Sensor ...............................................27
Telescopic Thread Guide ...............................27
Spool Pins......................................................28
Spool Caps ....................................................28
Threads .........................................................29
Needles .........................................................30
Important Needle Information ........................ 30
Changing the Needle.....................................31
Threading ......................................................32
Threading the Upper Thread........................... 32
Automatic Needle Threader ............................ 34
Threading Tips and Hints ............................... 36
Threading for Twin Needle............................. 37
Bobbin Winding.............................................39
Winding Through the Needle.......................... 41
Inserting the Bobbin.......................................43
Changing the Presser Foot.............................43
Attaching the Sensor One-Step
Buttonhole Foot ............................................44
Attaching the Sensor Q-Foot.........................44
Dual Feed With Changeable Presser Feet......45
Changing to Straight Stitch Plate ....................46
3 Embroidery Preparations .......................... 47
Embroidery Unit............................................48
Embroidery Hoop Overview.........................48
Sensor Q-Foot...............................................48
Straight Stitch Plate........................................49
Designs..........................................................49
DESIGNER EPIC™ Sampler Book ................ 49
Connect the Embroidery Unit .......................50
Remove the Embroidery Unit........................50
To Hoop the Fabric .......................................51
Slide on/off the Hoop ....................................51
4 The Multi-Touch Screen ............................ 53
Multi-Touch Screen........................................54
Gestures ...................................................... 54
Smart Toolbox...............................................55
Common Functions .......................................56
OK............................................................. 56
Cancel......................................................... 56
Embroidery Edit........................................... 56
Embroidery Stitch Out................................... 56
Touch & Hold .............................................. 56
Topbar ...........................................................57
WiFi ........................................................... 57
mySewnet™ ................................................... 57
Wireless Firmware Update.............................. 58
JoyOS advisor™ feature.................................... 58
Quick Help .................................................. 58
Settings ....................................................... 59
Sewing/Embroidery Mode Toggle ................... 59
5 WiFi & mySewnet™ Services..................... 61
WiFi Introduction ..........................................62
Getting Started With WiFi .............................. 62
Hidden Network........................................... 62
Firmware Update Using WiFi.........................62
Firmware Update Using a USB Device...........63
Complimentary Software (PC) ......................64
mySewnet ™ Services ....................................65
mySewnet™ Account....................................... 65

mySewnet™ Cloud .......................................... 65
Used Space in mySewnet™ Cloud ...................... 66
Installation of mySewnet™ Cloud Sync Tool
for PC......................................................... 66
mySewnet™ Portal .......................................... 67
mySewMonitor App ......................................68
6JoyOS advisor™............................................ 69
JoyOS advisor ™ Introduction ........................70
JoyOS advisor ™ Project Menu ......................70
JoyOS advisor ™ Project Viewer ....................70
JoyOS advisor™ Project Viewer – Overview ........ 70
Pictures in JoyOS advisor™ Project Viewer.......... 71
Animations in JoyOS advisor™ Project Viewer..... 71
Stitch in JoyOS advisor™ Project Viewer ............. 71
SEWING ADVISOR™ – Overview...............72
Fabric Selection .............................................73
Woven or Knit.............................................. 73
Woven Fabrics.............................................. 73
Stretch Fabrics.............................................. 73
Leather and Vinyl.......................................... 73
Sewing Technique Groups .............................74
Basic Sewing Techniques................................75
Seam........................................................... 75
Overcast...................................................... 75
Seam and Overcast ....................................... 75
Baste........................................................... 76
Blind Hem ................................................... 76
Hem ........................................................... 76
Buttonholes ................................................. 76
Programmable Button Sew On ........................ 77
Start New .....................................................77
Continue .......................................................77
Load Smart Save............................................78
EMBROIDERY ADVISOR™ – Overview.......79
Background Color..........................................80
Grid Options .................................................80
Embroidery Technique Groups......................80
Start New......................................................80
Continue .......................................................81
Load Smart Save............................................81
Knowledge Center – Overview .....................82
Stabilizer Guide..............................................83
Quick Start Guide..........................................83
Step-by-Step Workbook................................83
Sewing Instructions ........................................83
Continue .......................................................83
7 Sewing.......................................................... 85
Getting Started to Sew..................................86
Sewing Mode – Overview .............................87
What is a Stitch? ............................................88
Select a Stitch or Letter .................................88
Load a Stitch or Letter From Another
Location ...................................................... 88
Stitch Settings ................................................89
Stitch Width ................................................. 89
Stitch Positioning .......................................... 89
Stitch Length................................................ 89
Stitch Density............................................... 90
Button Size .................................................. 90
Sew On Button............................................. 90
Sensor Foot Pressure ..................................... 91
deLuxe™ Stitch System................................... 91
Mirroring..................................................... 92
Balance ....................................................... 93
Free Motion Options.....................................94
Sewing Recommendations.............................95
Save Stitch .....................................................96
Smart Save ....................................................96
Dimensional Stitches – Menu L......................97
Theme Stitches – Menu M.............................97
Embellished Stitches – Menu N .....................98
Tapering Stitches – Menu Q ..........................99
Taper Satin Stitch Exercise.............................. 99
4-Way Stitches – Menu S.............................100
8-Way Stitches – Menu T ............................101
Special Stitches For Optional Presser
Feet .............................................................102
Sewing Pop-up Messages .............................102
8 Embroidery................................................105
Getting Started to Embroider......................106
Embroidery Edit – Overview.......................107
Load a Design..............................................108
Load a Stitch................................................108
Load a Font .................................................108
File Manager ................................................108
How to Select Designs ................................109
Hoop Selection............................................110
Toolbox .......................................................110
Move to Hoop.............................................110
Delete ........................................................110
Duplicate....................................................111
Mirror Side to Side and End to End ................111
Stitch Out Design Earlier/Later......................111
Group/Ungroup..........................................111
Select All ....................................................112
Multi-Select.................................................112
Touch Functions...........................................113
Position......................................................113
Rotate ........................................................113
Scale ..........................................................114
Pan............................................................114
Zoom ..........................................................115
Zoom Options ............................................115
Undo/Redo..................................................115

Design Stitch Out Order .............................115
Total Number of Stitches in Design
Combination................................................116
Save Design .................................................116
Smart Save ..................................................116
GO..............................................................117
Edit an Existing Design or Text.....................117
Thread Color Edit........................................119
Program Embroidery Text ...........................120
Create a Text ...............................................120
Add a Letter................................................120
Delete a Letter.............................................120
Text Shaping ...............................................120
Design Shaping ............................................123
Select Spacing..............................................124
Select Line Positioning ..................................125
Select Side Positioning ..................................125
Fixed Design Angle ......................................125
Set Number of Designs .................................126
Design Appliqué ..........................................127
Embroidery Edit Pop-up Messages...............129
9 Embroidery Stitch Out ............................131
Embroidery Stitch Out – Overview.............132
Welcome to Embroidery Stitch Out............133
Color Block List ...........................................135
Zoom ..........................................................135
Zoom Options ............................................136
Corner Check..............................................136
Hoop Position Options................................136
Current Stitch Position..................................136
Park Position ...............................................136
Trim Position ..............................................137
Center/Remove Hoop Position ......................137
Design Positioning........................................138
Design Positioning Wizard.............................139
Zoom to Cursor...........................................140
Set Cursor Point ..........................................140
deLuxe ™ Stitch System...............................140
Smart Save ..................................................140
Auto Smart Save .........................................141
Thread Color Spools ...................................141
Return to Embroidery Edit ..........................141
Step Stitch-by-Stitch/Go to Stitch ................142
Numbers of Stitches in Current Color
Block............................................................142
Number of Stitches in Embroidery
Combination................................................142
Color Options .............................................142
Color Block Sort ..........................................143
Color Block Merge .......................................143
Monochrome ..............................................143
Basting Options ...........................................144
Embroidery Stitch Out Pop-up Messages ....145
10 Program .....................................................149
Program – Overview...................................150
Create New Program..................................151
To Edit a Created Program ..........................152
Edit Stitch or Lettering Program...................152
Adjust the Entire Program.............................154
Stitch Program Commands..........................154
Save Program...............................................156
Sew or Embroider Your Stitch Program.......156
Program Pop-Up Messages..........................157
11 Settings.......................................................159
Temporary Sewing Settings..........................160
deLuxe™ Stitch System..................................160
Sensor Presser Foot Lift ................................160
Automatic Thread Cutter...............................160
Automatic FIX ............................................161
Stitch Limiting Options.................................161
Feed Teeth Options ......................................161
Temporary Embroidery Settings ..................162
deLuxe™ Stitch System..................................162
Embroidery Foot Type..................................162
Thread Cut Options .....................................163
Twin Needle Options....................................164
Default Sewing Settings ...............................165
deLuxe™ Stitch System – Default....................165
Sensor Presser Foot Lift – Default ..................165
Automatic Thread Cutter – Default.................165
Automatic FIX – Default ..............................165
Free Motion Options – Default ......................165
Default Embroidery Settings ........................166
deLuxe™ Stitch System – Default....................166
Thread Cut Options – Default........................166
Embroidery Pivot Height – Default.................166
My Hoops ..................................................166
Machine Settings..........................................167
Language ....................................................167
Audio Volume .............................................167
Audio Repeat ..............................................167
Lock Screen ................................................167
LED Work Light Brightness...........................167
WiFi Settings................................................168
mySewnet ™ Settings...................................168
Machine Information....................................168
12 File Manager ..............................................169
File Manager – Overview.............................170
File Formats .................................................171
Browse File Manager....................................171
Open a File or Folder....................................171
Move Up One Folder Level ...........................172
List/Thumbnail View ....................................172
mySewnet ™ Cloud Folder ..........................172

Built-in Designs ............................................172
USB Device .................................................173
Organize......................................................174
Create New Folder .......................................174
Rename a File or Folder ................................174
Move a File or Folder....................................174
Copy a File or Folder ....................................174
Delete a File or Folder ..................................174
Filter Files...................................................175
File Manager Pop-up Messages ....................176
13 Maintenance .............................................. 178
Cleaning the Machine Exterior.....................179
Removing the Needle Plate and Cleaning
the Bobbin Area ..........................................179
Cleaning Under the Bobbin Area.................179
Replacing the Needle Plate..........................180
Troubleshooting...........................................180
Troubleshooting Connectivity ........................184
Service .......................................................184
Non-Original Parts and Accessories ................184
Technical specification..................................184
14 IMPORTANT.............................................186
IMPORTANT SAFETY INSTRUCTIONS ....186
DANGER –TO REDUCE THE RISK OF
ELECTRIC SHOCK:...................................186
WARNING –TO REDUCE THE RISK OF
BURNS, FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSON: ................................186
SAVE THESE INSTRUCTIONS...................186
SERVICING OF DOUBLE INSULATED
PRODUCTS ..............................................187
Licenses .......................................................187
RC-0234 EU Declaration.............................187
Index ..........................................................189

1
1 Introduction

Machine Overview
Front
1. Lid
2. Pre-tension thread guide
3. Threading slot
4. Thread tension discs
5. Thread take-up lever
6. Threading slots
7. Thread cutter
8. LED light
9. Needle plate
10. Bobbin cover
11. Bobbin cover release button
12. Button ruler and built-in tape measure
13. Base plate
14. Function buttons, see Function Buttons, page 13 for
detailed description
15. Telescopic thread guide
16. Main spool pin
17. Auxiliary spool pin
18. Bobbin winding thread guides
19. Thread tension disc for bobbin winding
20. Multi-touch screen
21. Speaker
10 1 Introduction

Needle Area
1. Automatic needle threader, see Using the Automatic
Needle Threader, page 35
2. Needle bar with needle clamp screw
3. Needle thread guide
4. Presser foot bar
5. Presser foot ankle
6. Presser foot
Right Side
1. Handwheel
2. Bobbin winder
3. Bobbin winding lever
4. Thread cutter for bobbin winding
5. Built-in USB ports
6. ON/OFF switch, sockets for power cord and foot
control. See Connect the Power Cord and Foot Control,
page 24.
Rear
1. Handle
2. Accessory socket
3. Free arm
4. Embroidery unit socket
1 Introduction 11

Accessory Tray
The accessory tray features special compartments for presser
feet and bobbins, plus space for needles and other
accessories. Store the accessories in the tray so they are easily
accessible.
1. Space for accessories
2. Hook for storing the Sensor One-Step Buttonhole Foot
3. Space for needle plate
4. Space with hole for Buttonhole Foot C
5. Removable bobbin holder
6. Spaces for presser feet
7. Slot for needle packs
8. Space for seam ripper and brush
9. Extra wide space for Side-Motion Foot S
Storing a Needle Plate
Store the needle plate not in use in the bottom of your
accessory tray.
1. Insert the back of the plate into the assigned holes as
illustrated and lay it down.
2. Push the plate down and to the left to fasten it.
3. To remove the plate, place a finger into the hole by the
top left of the plate, push right and then lift the plate.
Embroidery Unit
(type EU 22)
1. Embroidery unit release button (underside)
2. Embroidery arm
3. Embroidery hoop attachment
4. Level adjustment feet
5. Embroidery unit plug
12 1 Introduction

Function Buttons
1. Automatic needle threader
2. Stitch re-start
3. Speed – and +
4. Needle stop up/down
5. Cut function
6. Reverse
7. Start/stop
8. FIX function
9. STOP function
10. Reverse (same functions as #6)
11. Presser foot down and pivot
12. Presser foot up and extra lift
Automatic Needle Threader
See Using the Automatic Needle Threader, page 35 to learn
how to place the thread for automatic needle threading. When
the thread is in place, touch this button to thread the needle
automatically.
To prevent damage to the automatic needle threader, needle,
presser foot or other attached accessories, read the instructions
carefully on how to use the automatic needle threader before
using it.
Stitch Re-Start
When you stop sewing in the middle of a stitch, touch stitch
re-start to begin sewing at the beginning of the stitch. The
stitch or stitch program will remember any special settings
you made.
Speed – and +
All stitches and embroideries in your machine have a pre-set,
maximum allowed sewing speed to provide a good stitch
result.
Touch speed – to decrease the maximum allowed sewing
speed. Touch speed + to increase the maximum allowed
speed again. The machine will never sew faster than the
maximum allowed sewing speed for the selected stitch/
embroidery. Touch speed – or + when the machine is not
running and a pop-up on the screen will indicate the speed
setting. You can set the speed by touching the slider in the
pop-up or by touching the speed – or + buttons. If you
change the speed setting while sewing no pop-up will appear.
Needle Stop Up/Down
Touch needle stop up/down to set the position of the needle
when you stop sewing. The needle will move up or down
when you touch the button. The indicator light is on when
needle stop down is set.
Tip: You can also tap the foot control to raise or lower the needle once
you stop sewing. Tapping the foot control does not change the set stop
position.
Cut Function
Touch the cut function button and your machine cuts the
upper and bobbin threads, raises the presser foot and needle,
and activates the FIX function for the next start.
To cut threads at the end of a stitch or stitch program, touch
the cut function button while sewing. The indicator light will
flash, alerting you that a cut is requested. When the stitch or
stitch program is completed, your machine cuts the upper and
bobbin threads, raises the presser foot and needle, and
activates the FIX function for the next start.
Note: If automatic FIX and selective presser foot lift has been deselected
in temporary sewing settings, FIX function will not be activated and
presser foot will not be raised when using the cut function.
Touch the cut function button when embroidering and your
machine cuts the upper and bobbin threads instantly.
Some optional accessories are attached in the two small
circular holes in the needle plate just above the bobbin cover.
Do not use the cut function when an accessory is attached in
these holes as that may interfere with the automatic thread
cutter located under the needle plate.
1 Introduction 13

Reverse
When reverse is active, the reverse indicator is lit. For
permanent reverse, touch the reverse button once before
starting to sew. The reverse indicator will be lit and the
machine sews in reverse until you touch the button again to
cancel. If you press the reverse button while sewing, the
machine will sew in reverse for as long as you keep the button
pressed.
Reverse is also used when sewing for example manual
buttonholes, darning stitches and tapering stitches to step
between the parts of the stitch.
Start/Stop
Touch the start/stop button to start and stop the machine
sewing or embroidering without using the foot control. Touch
start/stop to begin and touch again to stop.
FIX function
FIX is used to tie off a stitch. Touch the button to turn the
function on/off. The indicator next to the FIX function
button is lit when the FIX function is active. When beginning
to sew with FIX function active, your machine sews a few tie-
off stitches and continues with the selected stitch. Touch FIX
while sewing and your machine sews a few tie-off stitches and
stops automatically.
You can activate automatic FIX in settings, see Automatic
FIX.
STOP function
Touch STOP when sewing to conclude a stitch or stitch
program. Your machine fixes the thread and stops
automatically when the stitch or stitch program has been
completed. Touch STOP before starting to sew and your
machine sews only one repetition of the stitch. Only one
stitch is displayed on the screen. The indicator next to the
STOP button is lit when the STOP function is active. To
cancel the function, touch STOP again or select a new stitch.
The STOP function is cancelled when the stitch is completed.
The STOP function is also used to repeat a sewn length when
sewing tapering, (see Tapering Stitches – Menu Q) and when
sewing manual buttonholes.
Presser Foot Down and Pivot
The presser foot is lowered automatically when you start
sewing. To lower the presser foot before starting to sew,
touch the presser foot down and pivot button. The presser
foot will be completely lowered and the machine firmly holds
the fabric. Touch presser foot down again to go to pivot
position.
In embroidery mode touch presser foot down to lower the
presser foot to embroidery position.
Presser Foot Up and Extra Lift
Touch the presser foot up button once to raise the presser
foot. Touch again and the presser foot will raise to extra lift
position, and the feed teeth will be automatically lowered to
make it easier to get heavy fabric under the presser foot.
In embroidery mode, the extra lift makes it easier to insert or
remove the hoop.
14 1 Introduction

Basic Gestures for the Multi-Touch
Screen
Easily navigate on the multi-touch screen with the gestures
described below. For more detailed information, see Multi-
Touch Screen.
Touch
Touch once on a button or setting on the screen to select.
Touch & Hold
Touch once without releasing for a few seconds to touch &
hold. Used on some buttons and screen areas to access more
options.
Pinch/Stretch
Touch with two fingers at the same time and without
releasing increase/reduce the distance between the fingers to
stretch (zoom in) or pinch (zoom out).
Touch and Move
Touch once on a selected design and, without releasing,
move your finger to a different position on the screen. Used
e.g. for moving a design in the embroidery area.
Swipe
Touch, move and release your finger in a swift gesture to
swipe. Left-right/right-left swipe is used e.g. to scroll
between stitch menus. Top-bottom/bottom-top swipe is
used e.g. to scroll within a stitch menu.
1 Introduction 15

Accessories
Included Accessories
1. Thread net (4)
2. Universal tool
3. Seam ripper
4. Brush
5. Edge/Quilting guides (used attached to presser foot
ankle or together with the Dual Feed Foot)
6. Bobbins (9)
7. Thread cone holder (2)
8. Hoop clips (16)
9. Spool cap, small (2)
10. Spool cap, medium (2)
11. Spool cap, large (2)
12. Large spool holder (2)
13. Multipurpose tool/Button reed
14. Straight Stitch Plate
Included Accessories Not in Picture
• Complimentary software (PC) to download, see
Complimentary Software (PC).
• Soft cover for machine
• Luggage style carrying bag with packing insert for
embroidery unit
• Foot control
• Power cord
• Needles
• DESIGNER EPIC™ sampler book
Included Hoops
1. DESIGNER™ Imperial Hoop (360x260)
2. DESIGNER™ Crown Hoop (260x200)
3. DESIGNER™ Splendid Square Hoop (120x120)
16 1 Introduction

Presser Feet
Note: For the best sewing results, use only presser feet designed for and
compatible with your DESIGNER EPIC™ machine.
Utility Foot A
Snapped onto the machine upon delivery. Used mainly for straight stitching and zigzag
stitching with a stitch length longer than 1.0mm.
Decorative Stitch Foot B
For sewing close zigzag stitches (satin stitches) with less than 1.0mm stitch length,
other utility stitches or decorative stitches, use this foot. The tunnel on the underside of
the foot is designed to feed smoothly over the stitches.
Buttonhole Foot C
For manual buttonholes. This foot has guidelines to determine buttonhole length. The
middle measures ⅝″ (15mm) from the fabric edge. The two tunnels on the underside
of the foot ensure smooth feeding over the buttonhole columns. The finger on the
back of the foot holds cording for corded buttonholes.
Blindhem Foot D
For blindhem stitches. The inner edge of this foot guides the fabric. The right toe of
the foot is designed to ride along the hem edge.
Zipper Foot E
This foot can be snapped on either to the right or to the left of the needle. This makes
it easy to sew both sides of the zipper. Move needle position to right or left to sew
closer to zipper teeth or for covering large cording.
Non-Stick Glide Foot H
This foot, with a non-stick coating underneath, is used when sewing foam, vinyl,
plastic, or leather to keep these materials from sticking to the foot.
Edging Foot J
Used for overcasting and seam/overcasting, with stitches that have a stitch width of 5.0
and 5.5mm. Stitches form over the pin which prevents puckering at the edge of the
fabric.
Quilter’s ¼″ Piecing Foot P
Used when piecing quilt blocks. The foot has distance guideline marks ¼″ (6mm) and
⅛″ (3mm) from the needle.
Sensor Q-Foot
The Sensor Q-Foot is recommended for hoop embroidery.
This foot is also used for free motion sewing, free motion quilting and free motion
embroidering. When using the Sensor Q-Foot for free motion, select free motion
spring action in the free motion options pop-up in sewing mode.
1 Introduction 17

Embroidery/Darning Foot R
Used for free motion embroidery, free motion quilting, free motion stitching and free
motion darning. When using this foot, select free motion floating in the free motion
options pop-up in sewing mode.
This foot can also be used for hoop embroidery.
Side-Motion Foot S
Used for side-motion/omnimotion stitches.
Sensor One-Step Buttonhole Foot
Plug into the machine then enter the desired buttonhole length to sew sensor one-step
buttonholes. The middle mark measures a ⅝″ (15mm) from fabric edge.
Self-Adhesive Glide Plates
If sewing on foam, vinyl, plastic, or leather, the material can stick to the foot and
prevent the sewing machine from feeding properly. When using any of the above
materials, sew on a piece of scrap fabric, to make sure the machine feeds smoothly. If
not, fasten the self-adhesive glide plate to the underside of the presser foot.
Interchangeable Dual Feed
The Dual Feed Foot with changeable presser feet is designed to feed layers of fabric
and/or batting evenly. It is perfect for quilting, sewing velvet, stretch fabrics, imitation
leathers and fabrics that need precise pattern matching. Snap on the Changeable
Straight Stitch Foot when using the straight stitch in the center needle position with a
stitch length up to 6mm. Snap on the Changeable Zigzag Foot when selecting stitches
up to 7mm wide and 6mm long.
18 1 Introduction

Stitch Overview
Utility Stitches
Stitch № Presser
foot
Name Description
A1 A Straight stitch, left needle
position
For all types of sewing.
A2 A Straight stitch, center
needle position
For all types of sewing.
A3 A Straight stitch with
reinforced tie-off
For all types of sewing. Begins and ends with forward and
reverse stitches.
A4 A Straight stitch, right
needle position
For all types of sewing.
A5, A6,
A7
A Stretch stitch, left, center
and right needle position
For seams in tricot and stretch fabrics.
A8, A9,
A10
A Zigzag, left, center and
right needle position
For sewing on lace, trims and appliqués.
A11,
A12,
A13
A Reinforced straight
stitch, left, center and
right needle position
Triple and elastic, for reinforced seams. For top stitch, increase
the stitch length.
A14 BReinforced zigzag stitch For joining fabric edge to edge or overlapping in leather. For
decorative sewing.
A15 A Three-step zigzag For overcasting, mending, sewing on patches and elastic.
Suitable for light and medium weight fabrics.
A16 JSeam/overcast stitch Seam and overcast in one step along the edge or trim later. For
light stretch and non-stretch fabrics.
A17 BStretch seam/overcast
stitch
Seam and overcast in one step along the edge or trim later. For
medium and heavy stretch fabrics.
A18 BDouble overlock stitch Seam and overcast in one step along the edge or trim later. For
heavy stretch and heavy woven fabrics.
A19 BOverlock stitch Seam and overcast in one step along the edge or trim later. For
medium stretch fabrics.
A20 BFlatlock stitch Decorative hems and overlapped seams, belts and bands. For
medium/heavy stretch fabrics.
A21 DStretch blind hem stitch Blind hems in medium and heavy stretch fabrics.
A22 DWoven blind hem stitch Blind hems in medium and heavy woven fabrics.
A23 A Shell edge stitch For edging, sewing over the edge on light woven fabrics. Sew
woven fabrics on bias.
A24 A Four-step zigzag For overcasting, mending, sewing on patches and elastics on
loosely woven fabrics.
1 Introduction 19

Stitch № Presser
foot
Name Description
A25 BElastic/casing stitch For overlapped seams in tricot. To sew casing over narrow
elastic.
A26 A Serpentine stitch For mending and elastic applications.
A27 BElastic or smocking
stitch
Sew over two rows of elastic thread for elastic shirring.
A28 BBridging stitch For joining two pieces of fabric with finished edges and for
elastic shirring.
A29 JThree-step zigzag For overcasting, mending, sewing on patches and elastic.
Suitable for light and medium weight fabrics.
A30 A Two-step zigzag For joining two pieces of lace, and for elastic shirring.
A31 BBartack stitch Reinforce pockets, shirt openings, belt loops as well as at lower
end of a zipper.
A32 BBartack, manual Reinforce pockets, shirt openings, belt loops as well as at lower
end of a zipper.
A33 A Darning stitch (forward
and backward)
Darn and mend small holes in work clothes, jeans, tablecloths
and linen towels. Stitch over hole, touch reverse for continuous
darning and auto stop.
A34 A Darning stitch (side to
side)
For mending small tears.
A35 A Reinforced darning stitch Darn and mend work clothes, jeans, tablecloths and linen
towels. Stitch over hole, touch reverse for continuous darning
and auto stop.
A36 BDarning stitch (four-
step)
A group of four stitches perfect for mending small tears. Stitch
#1 and #3 are sewn in a forward motion, stitch #2 and #4 are
sewn backwards. To change stitch and direction touch the
reverse button.
Tip: Press fusible interfacing on the wrong side before mending the tear.
A37 A Belt loop stitch For securing belt loops.
A38 A Basting stitch For temporary seams. The long stitches and reduced tension
make the seams easy to unravel.
A39 A Straight basting stitch To baste, press the foot control and the machine will make two
stitches, stop and raise the foot. When the presser foot lifts,
move the fabric to the next baste position and press the foot
control. Feed teeth lowered automatically.
A40 A Zigzag basting To baste, press the foot control and the machine will make two
stitches, stop and raise the foot. When the presser foot lifts,
move the fabric to the next baste position and press the foot
control. Feed teeth lowered automatically.
A41 A Gathering stitch No fix stitch in the beginning of the seam for easy gathering.
A42 Sensor
Buttonhole
foot/C
Wide bartack buttonhole For medium and heavy fabrics with extra cutting space.
20 1 Introduction
