Villa Ordinary User manual

Product features may be varied with actual product, please contact us for detail.
User Manual of Villa Outdoor Camera
(Ordinary / Standard / Luxury)

2
Contents
1. Appearance..............................................................................................3
2、Features.................................................................................................4
3、Functions...............................................................................................5
4、Extended functions (optional installation function) .............................6
5、Performance index................................................................................6
6、Using method........................................................................................6
7、Function debugging ..............................................................................7
8、Installation method ...............................................................................8
9、Failure analysis and troubleshooting..................................................13
10、Packing list........................................................................................14

3
1. Appearance
1）ordinary type：
2）standard type:
①Microphone
②LED lights
③Camera
④Speaker
⑤Call button
①Microphone
②Camera
③LED lights
④IC/ID Reader
⑤Call button
⑥Speaker

4
3）luxury type：
2、Features
Aluminum shell (normal-type/ standard-type)/ black crystal panel
(luxury-type), has waterproof, dustproof, anti-tamper, and shockproof
functions.
metal drawing process (Normal / Standard type), high temperature resistant
(Luxury), highlight the luxurious high-end
one-button call, simple and convenient
one button call management center and indoor machine, simple and
convenient (luxury type)
Digital camera, with stable and clear images
with light compensation function in the night or in strong light
All-digital design, support synchronously monitoring of multiple users.
Full-duplex voice intercom, has equal effect with the ordinary telephone
intercom.
ADI lower-power DSP design, which is energy-saving, reliable and has a long
①Microphone
②LED lights
③Camera
④management center call
button
⑤call button
⑥speaker
⑦IC/ID card sensing
area(optional feature)

5
services life

LINUX platform architecture, with simple and stable system
Standard Ethernet interface, suitable for the trend of digitalization and
networking;
with online upgrade services, the after-sale maintenance is simple and
convenient;
abundant interfaces, easy to expand;
Standard PCB board design，can quickly adapt to the different needs of
different customers.
3、Functions
Call household：provide quick service of one-button call household
Video intercom: has function of call indoor machine and video intercom with
indoor machine;

multi-mode unlocking: intercom unlocking, card (IC / ID card) unlocking
Pictures / Messages-leaving function: the gate unit has message and photograph
leaving function while calling
Call records query: all call records can be checked through the indoor
machine
Video surveillance: can be video monitored by the indoor unit and the
management center;
Video surveillance: can be video monitored by the indoor unit and the
management center;
System Settings: can set relevant parameters of the gate unit through indoor
machine or management center;
Remote control: the system has online upgrade function

6
4、Extended functions (optional installation function)
elevator linkage: with intelligent judgment and direct-to-floor elevator linkage
function;；
5、Performance index
Camera
CMOS digital color camera
Resolution
D1
Minimum
illumination
0.2Lux (with the luminous compensation light)
light
compensation
mode
white
Power supply
DC12V
power
consumption
static 2W; Max: 3W
networking
interface
RJ45
Transmission rate
10M / 100M
Operating
temperature and
humidity
-40 ℃~+ 70 ℃，10% ~ 95%
installation
wall-hung/ embedded
6、Using method
Press the call button to call the indoor machine directly, there will be three
icons of “unlock”, “answer”and “hang-up”presented on the indoor machine,
you can press the corresponding icon to realize desired function.
When the “owner message”of indoor machine is set to be “no message”，if
no one answered the call, it will automatically hang-up in 45 seconds.
When the indoor machine has been set “owner massage”, if no one answer
the call, system will play owner’s message in 35 seconds. It will issue “beep”

7
after finishing playing, and turn to message leaving state of the villa door
machine. System will automatically hang up in 30 seconds.
When “owner message”is set to be “default message”, if no one answered
the call, system will automatically turn to message leaving state of villa door
machine in 35 seconds. And automatically hang up in 30 seconds.
Press the management center button on the left of the panel to directly call
management center. You can intercom if someone answered the call.
Otherwise, it will automatically hang up if no one answers the call.（Luxury
type）
7、Function debugging
The factory default number of villa door machine is 0136101010.The factory
default room number of indoor machine is 01361010101，you can realize
intercom after networking.
Villa door machine setting：
In the initial networking state, change “Terminal Number”in “door machine
setting”(password:1111111111) of “system setting”of the indoor machine, click
“confirm”, system will prompt “room number changed successfully”. The villa
door machine will automatically restart, that means the setting is changed
successfully. Change the room number of indoor machine to the corresponding
room number (such as: 01020101), then you can intercom with villa machine.
Ringtone and volume setting：
When networking, set the ringtone and volume in “door machine setting”of
“system setting”(password: 1111111111) of indoor machine. Click “confirm”,
system will prompt “volume changed successfully”, that means setting is

8
changed successfully.
8、Installation method
1）ordinary type：
Install the embedded box on the wall or iron gate, the dimension of the embedded box
is (height 137mm ×width 113mm ×depth 36mm). The upper edge of embedded box
is flushed with the surface of wall or iron gate. Reserve the upper and lower screw
holes, put the host in the embedded box and fix up the screw, or press the "bayonet"
of rear cover to the embedded box to ensure the “bayonet”connected firmly. The
installation height of the villa door machine is about 1.3 meters from the ground to the
bottom of the machine. (Shown as below)
Installation steps:
1. Cut mounting hole on the wall according to the size of the embedded box
2. After opening outlet holes of the embedded box, put the
embedded box into the mounting hole and fix it.
3. Properly connect the cable of door machine and test its function.
4. Align the four iron ears on both sides of the embedded box, horizontally push into
the embedded box and fix the screws.

9
2）Standard type：Install the embedded box on the wall or iron gate, the
dimension of the embedded box is (height 147mm × width 79mm ×
depth 40mm). The installation method is basically the same with the
normal type. But you need to first remove one fixed screw on the lower
part of the panel, then put the host to the embedded box and tighten the
screw.
3）Luxury type：Reserve for appropriate installation location on the wall, the size
should be the same with the embedded bottom box, and install the
embedded box to the mounting slot, then install door machine to the
embedded box and fix it. Note: put inlet trunking upward, put water
outlet downward, the outer surface flush with the wall. The installation
height of the villa door machine is about 1.3 meters from the ground to
the bottom of the machine (shown below)
Installation steps:
1. Cut mounting hole on the wall according to the size of the embedded box

10
2. After opening outlet holes of the embedded box, put the
embedded box into the mounting hole and fix it.
3. Properly connect the cable of door machine and test its function.
4. Aligned iron ears on both sides of the embedded box, top- down hang up the gate
unit.
Luxury-type embedded box diagram：
Wiring diagram

11
1）Ordinary type：
2）Standard type：
interfaces
pin number
pin name
Application functions
1
(J18)
1
LOCK KEY
one-button call indoor machine
2
GND
2
(J15)
1
RXD
External RS485 interface
2
TXD
3
GND
3（J17）
1
A
I2C/485 interface
2
B
3
GND
4
5V
5
LOCK_IN
4
(J38)
1-14
100M network interface
5（J19）
1
DC12-15V
Power supply: DC 12-15V input，Current:2A
2
GND
6
(J6)
1
VDD3.3V
System debugging interface, users disable
2
RX
3
TX
4
GND
7
(J10)
1
NC
Unlock signal interface
2
COM
3
NO

12
interfaces
Pin
number
Pin name
Application functions
1（J9）
1
DC12-15V
Power supply: DC 12-18V input，
current: 2A
2
GND
2（J15）
1
VCC
2 external analog camera interface
2
CVBS IN2
3
CVBS IN3
4
GND
3（J38）
1-14
100M network interface
4（J6）
1
VCC3.3
System debugging interface, users
disable
2
RX
3
TX
4
GND
5（J10）
1
GND
electric-control lock Panel and
infrared alarm interface
2
IR
3
OFF
4
COM
5
ON
3）Luxury type：

13
、
9.Failure analysis and troubleshooting
If the system can not work properly, please check them one by one according to
the “troubleshooting table” after power-off. If you failed to identify the cause of
malfunction, please inform the sales agent or the manufacturer. Be sure not to repair
or replace the components by yourself lest cause damage to the system
1
(J10)
1
NC
Unlock signal interface
2
COM
3
NO
2
(J6)
1
VDD3.3V
System debugging interface, users
disable
2
RX
3
TX
4
GND
3（J19）
1
DC12-15V
Power supply: DC 12-15V input，
current: 2A
2
GND
4 (J38)
1-14
100M network interface
5（J17）
1
A
I2C/485 interface
2
B
3
GND
4
5V
5
LOCK_IN
6
(J15)
1
RXD
External RS485 interface
2
TXD
3
GND
7
(J18)
1
LOCK KEY
one-button call indoor machine
2
GND

14
NO.
Fault phenomenon
Reason analysis
Troubleshooting
1
No response after startup
The power socket is plugged
unsteadily or connected
incorrectly
Check the plug and
voltage of the power line.
2
Cannot call or no response to
the call
1、Network line is not well
connected or no network.
2、gate unit number is not
well set.
1、check the network links
2、reset the machine
number
3
The call without ringing
Ringing is closed
Adjust the ring volume
4
Can intercom, but without
video
The internet cable is not well
inserted or the camera is
obscured.
Re-check the internet cable
and the camera works
normal or not.
5
The user can not unlock
External unlock module is
wrong.
Check or replace the
unlocking module.
10、Packing list
Ordinary/Standard/Luxury:
No.
Accessories
Quantity
Remarks
1
Villa machine
1
2
embedded box
1
3
manual
1
4
certification
1
Note: the packing list may be increased or reduced according to customers’requirements
