ViM HUCF ECO PR User manual

NT00000737-HUCF-ECO-PR-KIT-MONTAGE-VFIK-AN-210609
INSTRUCTION MANUAL
INSTALLATION | WIRING | COMMISSIONING | MAINTENANCE |
AFNOR CERTIFICATION
ISO 14001
Environnement
AFNOR CERTIFICATION
ISO 9001
Qualité
ENGLISH
HUCF ECO PR
Replacing a VFTM PR frequency converter
by a VFIK frequency converter
HUCF ECO PR CODE DESIGNATION
025 Mono 240110 KITVFTM toVFIK HU 025 MONO
025 Tri 240111 KIT VFTM to VFIK HU 025 TRI
045 Mono 240112 KITVFTM toVFIK HU 045 MONO
045 Tri 240113 KIT VFTM to VFIK HU 045 TRI
055 Mono 240114 KITVFTM toVFIK HU 055 MONO
055 Tri 240115 KIT VFTM to VFIK HU 055 TRI
080 Mono 240116 KITVFTM toVFIK HU 080 MONO
080 Tri 240117 KIT VFTM to VFIK HU 080 TRI
110 Mono 240118 KITVFTM toVFIK HU 110 MONO
110 Tri 240119 KIT VFTM to VFIK HU 110 TRI
COMPOSITION OF THE KIT DELIVERED
VFIK frequency converter +VCHV-A
controller mounted on a support
1 template
of drilling 1 translucent plastic tube
6 sheet metal
screws head H
6.2x15
6 rivets Steel Steel
4,8x14,7
NT00000738-HUCF-ECO-PR-AN instruction manual
NECESSARY TOOLS
-A drill with Ø5 drill bit
-A riveting machine
-One 10 H-head nozzle
1DISCONNECT THE VFTM FREQUENCY CONVERTER
-Open the frequency converter
-Disconnect the power cable
-Disconnect the cable connected to the motor
-Disconnect the hose from the pressure tap.
P1 P2
PhN
S/L2 S/L1
W/T3 V/T2
U/T1
VFTM INTERIOR
Pressure pipe Power supply Motor cable
HUCF ECO with VFTM frequency converter HUCF ECO with VFIK frequency converter
GENERAL INFORMATION
When the originally ttedVFTM PR frequency converter is no
longer functional, it must be replaced by the KIT supplied. This
document describes the operations to be carried out.
Before carrying out any work, disconnect the general
power supply to the box.

NT00000737-HUCF-ECO-PR-KIT-MONTAGE-VFIK-AN-210609
VIM - Les prés de Mégy Sud - SOUDAN - CS 60120 - 79401 ST MAIXENT L’ECOLE CEDEX - FRANCE
Tél. : [phone] ou [phone] - Fax : [phone] - [email protected] - www.vim.fr
2REMOVE THE VFTM + SUPPORT ASSEMBLY
-Remove the rivets that secure the hinges
Hinges Rivets
3REMOVE THE LOCK
-Remove the rivets that secure the lock
Lock
4FIX THE LOCK IN ITS NEW POSITION
-Place the template on the 2 existing holes by positioning the
«square 10x10» mark on the left.
-Drill the 2 holes in Ø4
Marker : square 10x10 Template Existing holes
Holes to be drilled
-Secure the lock in this new position using the rivets or screws
provided.
New position
Refer to manual NT00000627-HUCF-ECO-PR supplied with the kit to set the desired pressure set point.
5FIXING THE NEW SET
-Attach the hinges to the suction side with the rivets preferably or
the screws provided.
6REWIRE
-Connect the pressure pipe to socket (-) of theVCHV-A.
-You can also replace the existing pipe with the new supplied.
Connect it also on the side of the box.
Pressure tap (-)
-Rewire themotor cablein theVFIK in accordancewith the following
instructions :
HUCF ECO PR
online HUCF ECO PR double suction
UGray thread Brown thread
VBlack thread Black thread
WBrown thread Gray thread
-Rewire the power cable in the VFIK
MONO power supply TRI power supply
W
V
U
L2/N L1/L
Câble alimentation
Power cable
Câble moteur
Motor cable
Power cable Motor cable
W
V
U
L2/N L1/L L3
Câble alimentation
Power cable
Câble moteur
Motor cable
Power cable Motor cable
8CHECK THE DIRECTION OF ROTATION OF THE ROTOR
