VINNOVA 703230 User manual

Page 1 Model: 703230
Modèle:703230
*INSTALLING VANITY WITH TWO PEOPLE IS HIGHLY RECOMMENDED*
*L'INSTALLATION DE LA VANITÉ AVEC DEUX PERSONNES EST FORTEMENT RECOMMANDÉE*
Box Contents/Contenu de la boîte
Ceramic Basin/Countertop
Bassin/comptoir en céramique
Vanity Base/Cabinet
Base de vanité/Cabinet
Vanity Mirror/LED Mirror
Miroir de courtoisie/Miroir à DEL
Installation Tips/Conseils d'installation
Add silicone to attach frame/
Ajouter du silicone pour fixer le cadre
Secure the countertop to the main cabinet/
Fixez le comptoir à l'armoire principale
Please check your product packaging to make
sure the included accessories etc.
Main Body Parts/La partie principale du corps
Main Cabinet Installation Instructions/
Instructions d'installation de l'armoire principale
Ceramic basin
Cuves en céramique/1
Main cabinet
Armoires principal/1
Vanity Mirror
Miroir de courtoisie/1
Recommended tools/Outils recommandés
Tape measure/
mètre à ruban
Pencil/
Crayon
Screwdriver (Manual/Mechanical)/
Tournevis (manuel/mécanique)
Level/Niveau
Calking & Calking Gun/
Pistolet à calfeutrer et à calfeutrer
Installation tool/Outil d'installation
0
1
234
Tape measure Pencil Level Calking Gun
Screwdriver
Mechanical
Screwdriver
Installation Instruction/Instructions d’installation
The drawer is adjusted
Le tiroir est réglé
Diamètre de l’axe du
vis standard: 0,24"
Standard screwdriver
shaft diameter: 0.24"
±0.06" ±0.08"
Heightening rod installation, adjustment and removal
Installation, réglage et retrait de la tige de surélévation
Installation and adjustment
mise en place et réglage
disassemble
démonter
heightening
plus haut
±0.08"
Adjust the length
Longueur ajustée
These two connectors
are needed only for
heightening the rod
Les deux connecteurs
ne sont utilisés que
pour augmenter la
hauteur de la tige
3
3
21
2
2
2
1
1
1
1.Measure A-distance
between 2 hangers
2.Fix 2 wall rails with
screwhoos, B＜A
3.Paste the countertop 4.Hang the mirror
1.Mesurer la distance
A entre 2 cintres
2.Fixer 2 rails muraux
avec passe-vis, B＜A
3.Coller le comptoir 4.Accrocher le miroir
A
A
B

Diagram Specifications
Page 2
Vanity Care Guide
Vanity Care
Countertop Care
Cleaning and maintenance
WARNING WARNING WARNING
Avoid direct contact of sharp objects as they can cause exterior damage.
Do not expose directly to the sun as it can cause aging and cosmetic damage.
Avoid placing hot objects onto the vanity surface.
Avoid using cleaning products that contain Bleach or Ammonia.
Please use wood-friendly products on wooden base vanities.
To adequately clean exterior surfaces, use natural cleaning solutions or soap
This product can expose
you to chemicals including
Nickel compounds,which
is known to the State of
California to cause cancer.
For more information visit
www.P65Warning.ca.gov
This product can expose
you to to Glass wool fibers
(inhalable and biopersistent),
which is known to the State
Of California to cause cancer.
For more information,go
towww.P65Warnings.ca.gov
Serious or fatal crushing
can occur from furniture
tip over . To prevent tip
over this furniture must be
used with the wall attachment
device(s)provided.
Screw(s)and plug(s)for the wall
are not included.Use screw(s)
And plug(s)suitable for your walls.
If you are uncertain,seek professional
Advice. Read and follow each step
of the instruction carefully.
Kindly note that all our tops are sealed before shipping but may stain, scratch, or chip because they are porous by nature.
Do not place hot items directly on the countertop as it can damage it.
To prevent ring marks or staining, dry immediately.
Place table mats beneath objects that can potentially scratch the surface.
Use a clean, soft fabric to dust the vanity.
Occasionally wash with a cloth dampened in warm water. If needed, apply a small amount of mild dishwashing
liquid or stone soap to clean. Dry with a soft cloth.
Refrain from using chemical cleaners,sprays,abrasive cleaners, or products that contain lemon, vinegar, or other acids.
We advise to reseal top annually or when necessary.
24.0W×1.5D 32.0H inches×
24.0"
32.0"
IN20.9"
OUT19.7"
3.3"
5.9"
3.1"
19.7"
18.7"
8.3"
13.4"
21.8"
1.6"
30.1"
26.9"
27.1"
12.2"
26.9"
1.4" 1.4"
21.9"
1.5"
30.1W×21.9D 21.3H inches×
30.1W×21.9D 1.6H inches
×
17.1"
18.0"
20.5"
11.8"
12.7"
15.2"
21.9"
11.1"
30.1" 1.6"
2.3"
15.0"
φ1.4"
20.5W×15.2D 7.3H inches×
