Vinten uVRC User manual

User Guide
Part No. V4063-0010
www.vinten.com
EN
μVRC Robotic Control System
μVRC Robotic Control System

Copyright © 2018
All rights reserved.
Original Instructions: English
All rights reserved throughout the world. No part of this publication may be stored in a retrieval system, transmitted, copied or reproduced in any
way, including, but not limited to, photocopy, photograph, magnetic or other record without the prior agreement and permission in writing of the Vitec
Group Plc.
Disclaimer
The information contained in this publication is believed to be correct at the time of printing. Vitec Production Solutions Ltd reserves the right to
make changes to the information or specications without obligation to notify any person of such revision or changes. Changes will be incorporated
in new versions of the publication.
We are making every e󰀨ort to ensure that our publications are updated on a regular basis to reect changes to product specications and features.
Should this publication not contain information on the core functionality of your product, please let us know. You may be able to access the latest
revision of this publication from our website.
Vitec Production Solutions Ltd reserves the right to make changes to product design and functionality without notication.
Trademarks
All product trademarks and registered trademarks are the property of The Vitec Group Plc.
All other trademarks and registered trademarks are the property of their respective companies.
Published by:
Vitec Production Solutions Ltd
Supports Technical Publications Department
Email: [email protected]

Contents
Safety..................................... 2
About this User Guide ...................... 3
Box Contents 4
μVRC Computer Components and Connections  5
Joystick Panel Controls and Connections....... 6
System and Power Connections ........... 7
Connecting the μVRC........................ 7
Starting and Using the μVRC  8
Powering Up ............................. 8
Launching the VRC System Application ........ 8
Using the μVRC........................... 8
Using the Joystick Panel ................. 8
Joystick Panel Keys ..................... 8
Using the μVRC  9
Joystick Camera Controls ............... 10
Maintenance  11
Technical Specications  12
General Notices  13

2
Safety
Important information on the safe installation and operation of
this product Read this information before operating the product
For your personal safety, read these instructions Do not operate
the product if you do not understand how to use it safely Save
these instructions for future reference
Warning Symbols Used in these Instructions
Safety cautions are included in these instructions. These safety
instructions must be followed to avoid possible personal injury and
avoid possible damage to the product.
!
WARNING!
Where there is a risk of personal injury or injury to others,
comments appear supported by the warning triangle
symbol.
Where there is a risk of damage to the product,
associated equipment, process or surroundings,
comments appear supported by the word ‘CAUTION’.
ELECTRIC SHOCK
Where there is a risk of electric shock, comments appear
supported by the hazardous voltage warning triangle.
WARNING! Risk of electric shock Always disconnect and
isolate the product from the power supply before attempting
any servicing or removing the covers. Always check cables
for signs of damage. Damaged cables can cause personal
injury and/or damage the equipment. It is the responsibility
of the local organisation to ensure that the product is
periodically checked for electrical safety in accordance with
local regulations.
!CAUTION! This product must be connected to a power
supply of the same voltage (V) and current (A) as indicated
on the product. Refer to the technical specications for the
product. Using alternative power sources will invalidate the
system EMC liability. All connections to other devices must
be made using shielded cables.
Intended Use
The μVRC robotic control system is designed to control compatible
robotic camera equipment and accessories. Camera operators can
remotely control movements of axes and other functions.
The μVRC is designed for use in TV studios and other applications
including houses of worship, conference facilities and auditoriums.
Electrical Connection
Operating Environment
!WARNING! Slots and openings are intended for ventilation
purposes to ensure reliable operation of the product and
protect it from overheating. Do not block or cover any slots
and openings. Protect the product from water, moisture
and dust. The presence of electricity near water can be
dangerous.
Important Safety Information
Mounting and Installation
!WARNING! Always ensure that all power and auxiliary
communications cables are routed so that they do not
present any danger to personnel. Take care when routing
cables in areas where robotic equipment is in use.
Cleaning
WARNING! Risk of electric shock Always disconnect and
isolate the product from the power supply before cleaning.
Do not use solvent or oil-based cleaners, abrasives or wire
brushes. Clean with a dry lint free cloth.

3
Safety and About this User Guide
Maintenance
!WARNING! The tting of non-approved parts or accessories,
or the carrying out of non-approved alterations or servicing
can be dangerous and could a󰀨ect the safety of the product.
It may also invalidate the terms and conditions of the product
warranty.
Safety when Working with Robotic Equipment
In normal operation remote-controlled equipment can move suddenly
and without warning. Since audible warnings are not suitable for use
within the studio environment, it is recommended that only trained
personnel be allowed to work in the active areas where remote
controlled robotic equipment is located.
The safe operating zone is a minimum of 1 m (3 ft).
Safety Notes for Operators
Operators must familiarise themselves with the working footprint of
the robotic equipment, including all installed payload items (lens,
zoom and focus controls, viewnder, prompter, etc.) to prevent
inadvertent collisions or injury to personnel.
If personnel are too close to robotic equipment that is about to move,
the operator should prevent the motion from starting or stop the
motion if it has started.
We strongly recommend that the operator veries visually that the
active area is clear of hazards and personnel, both before and during
remote operation.
This user guide covers the installation and basic operation of the
hardware components of the μVRC robotic control system.
For information on the conguration and operation of the VRC
software, refer to the VRC System User Guide, part no V4063-
4980.
About this User Guide

4
Box Contents
1μVRC computer
2Joystick panel
3μVRC power supply
NI USB connecting cable
NI Power cable (x3)
NI User guide
1
2
3
NI - Not Illustrated

5
μVRC Computer Components and Connections
4
1
3
2
5
6 6
7
8
1Touch-screen interface
2Adjustable stand
3Power button
4Power socket
5Network port
6USB3 ports
7VESA mounting holes (X4)*
8USB 2 ports
* For more information on the VESA mount,
see Technical Specications on page 12.

6
Joystick Panel Controls and Connections
1
2
3
4
5
6
7
1Main joystick control
2Shot control keys
3Focus controls
4Shift function keys
5Hand rest pad
6Camera selection keys
7USB port

7
Connecting the μVRC
Ethernet
USB
Connections
µVRC Computer
Ethernet Switch
PTZ Heads
Vantage Heads
Joystick Panel
µVRC Power Supply
19 VDC Power
System and Power Connections
The μVRC system is easily connected together.
Robotic cameras are connected using standard
Ethernet connections. Use a powered Ethernet
switch to expand the number of connections
available to suit your system requirements. The
control panel is connected and powered with the
supplied USB lead.
The μVRC computer connections are located on
the rear of the product. See the section μVRC
Computer Components and Connections on
page 5
For more information on connecting up
robotic cameras and components, refer to the
documentation supplied with the products.
* To connect PTZ heads, an additional license is
required. For more information refer to the VRC
System User Guide, part no V4063-4980

8
Starting and Using the μVRC
Powering Up
When all connections in the μVRC system have been made, the
μVRC computer can be powered up.
To power up, depress the power button recessed on the rear edge of
the case.
Using the μVRC
The μVRC user interface consists of a joystick panel and a PC work-
station with integral touch-screen display, through which all functions
and operations can be utilised.
Using the Joystick Panel
The joystick panel enables you to select and control connected
robotic cameras. Additional keys are available to select cameras and
other useful functions.
Joystick Panel Keys
The joystick panel has a selection of useful short cut keys which
duplicate features and functions available on the touch-screen
display. The keys provide quick access to functions when the operator
is using the joystick to control cameras.
Launching the VRC System Application
When the μVRC computer has booted up, the VRC system
application must be installed, congured and launched before robotic
cameras can be controlled.
For more information on the VRC system
application, refer to the VRC System User
Guide, part no V4063-4980

9
Using the μVRC
1Camera shot control keys (fade/stop/cut)
2Function keys
3Numeric keypad (not currently used)
4Camera selection keys*
5X4 key (zoom proportional)
6Camera selection shift key* (provides
access to cameras 9 to 16)
*The number of cameras available for selection
is dependent on the system license. For more
information refer to the VRC System User Guide,
part no V4063-4980

10
Using the μVRC
Joystick Camera Controls
The joystick panel provides the best way
to smoothly control camera movement and
adjustments.
Control functions can be reversed in the
VRC application conguration to suit a users
preferences.
Pan axis control
Tilt axis control
Zoom control
Course focus control
Fine focus control
Height control (optional)*
*An optional height drive is controlled by pressing
and holding down the F1 key and twisting the
joystick knob (normally zoom control).

11
Maintenance
The μVRC computer and panel require minimal routine maintenance,
apart from regular cleaning and routine checks.
Routine checks
During use, check the following daily:
• Check cables for signs of wear or damage. Replace as necessary.
• Check that all cables are connected properly.
Cleaning
WARNING! Risk of electric shock Disconnect and
isolate the product from the power supply before
cleaning.
During normal use the only cleaning required should be a regular
wipe over with a dry, lint-free cloth. Dirt accumulated during storage or
periods of disuse may be removed with a vacuum cleaner. Particular
attention should be paid to all connection ports on the μVRC
computer.

12
Technical Specications
Electrical Data
Power Supply
19V 135W AC Power Adapter
Technical specications are subject to change without notice.
Joystick Panel
Physical Data
Height
369 mm (145 in)
Length
539 mm (212 in)
Width
83 mm (33 in)
Touch-screen Display Panel
Specication
215inch TFT-LCD, LED Backlight, 16:9, 1920 x 1080
(FHD)
Illumination
250nits, Viewing Angle: 170° (Horizontal), 160°
(Vertical)
Physical Data
Height
111 mm (44 in)
Length
279 mm (11 in)
Width
228 mm (9 in)
Electrical Data
Power
Via USB interface (5V DC) consumption 1A
USB Interface
Type A male cable length: 2m (6ft 68in)
VESA Mount
Mounting Hole Spacings
100 x 100 mm (39 x 39 in)
μVRC PC Controller

www.vinten.com
Publication No. V063-4981/1
