This manual describes all System 200V components that are available
from VIPA with the exception of the CPUs. In addition to the product
summary it contains detailed descriptions of the different modules. You are
provided with information on the connection and the utilization of the
different System 200V components. Every chapter is concluded with the
technical data of the respective module.
A separate set of manuals is available for the CPUs.
Chapter 1: Introduction
This introduction presents the VIPA System 200V as a centralized as well
as decentralized automation system.
The chapter also contains general information about the System 200V, i.e.
dimensions, installation and operating conditions.
Chapter 2: Profibus-DP
This chapter contains a description of Profibus applications for the System
200V. The text describes the configuration of the VIPA Profibus master and
slave modules as well as a number of different communication examples.
Chapter 3: Interbus
This chapter contains all the information that is required to provide a
connection between the System 200V peripherals and Interbus. It contains
descriptions of the construction, commissioning and the configuration of
the Interbus coupler.
Chapter 4: CAN bus CANopen
This chapter deals with the VIPA CANopen slave and related CAN bus
applications. The structure of the program and the configuration of CAN
slaves is explained by means of examples.
Chapter 5: DeviceNet
This chapter contains a description of the VIPA DeviceNet coupler. A
description of the module is followed by an example of the configuration of
the DeviceNet coupler and the configuration of the System 200V modules
in the DeviceNet manager of Allen - Bradley. The chapter is concluded with
an overview of diagnostic messages and Profibus interfacing options.
Chapter 6: SERCOS
Content of this chapter is the description of the SERCOS coupler from
VIPA. Another part of this chapter is the project engineering of the
SERCOS coupler and the parameterization of the System 200V modules.
Overview

Manual VIPA System 200V About this manual
Subject to change to cater for technical progress.
Chapter 7: Ethernet coupler
Content of this chapter is the description of the Ethernet coupler
IM 253NET from VIPA. It contains all information for installation and
commissioning of the Ethernet coupler.
Chapter 8: PC 288 - CPU
This chapter describes the PC-CPU PC 288 and applications in System
200V. The configuration of a PC-based system is described in detail.
The chapter ends with an overview of the BIOS setup and the registers.
Chapter 9: Communication processor CP 240
This chapter contains information on the construction, the interfacing and
the communication protocols of the communication processor CP 240. It
also contains an explanation of the standard handler blocks for the VIPA
CPU 21x and the CPU 24x.
Chapter 10: Counter modules
This chapter deals with VIPA counter modules. The chapter also contains
information on the SSI module as well as the construction, configuration
and the different counter modes along with the respective interfaces.
Chapter 11: MotionControl modules FM 253 und FM 254
The chapter describes the VIPA MotionControl stepper and the Motion-
Control servo module. It contains information on the assembly, operating
modes, data transfer and applications in conjunction with a shaft encoder
at FM 253 or FM 254.
Chapter 12: Power supplies
This chapter deals with external power supplies for the System 200V. Here
you find a comprehensive set of safety related hints and information as well
as details on the construction, the installation and commissioning of the
module.
Chapter 13-15: Digital input/output modules
These chapters describe the digital remote I/O that is available from VIPA.
It provides all the information that is required for applications using these
modules. Chapter 13 contains information on the input modules, chapter 14
the information on the output modules and chapter 15 provides details on
input/output modules.
Chapter 16-18: Analog input/output modules
These chapters contain a description of the analog remote I/O. The chapter
also provides all the information that is required for applications using each
module. Chapter 16 describes the input modules, chapter 17 the output
modules and chapter 18 the analog input/output modules that are available
from VIPA.

About this manual Manual VIPA System 200V
Subject to change to cater for technical progress.
Chapter 19: System expansion modules
This chapter deals with the system expansion modules that are available
for the System 200V. These include amongst others the bus expansion
modules IM 26x that provide for the expansion of a single bus row to cater
for several rows, the mini switch CM 240 and terminal modules required for
the expansion of the available number of connections.
Chapter 20: Installation and installation guidelines
This chapter provides all the information required for the installation and
the hook-up of a controller using the components of the System 200V.
