Viro Tech MINI User manual

Air/Surface Sanitiser
User Manual
TABLE OF CONTENTS
PRODUCT INTRODUCTION ........................................................................................................................................................ 2
FOUR TECHNOLOGIES .................................................................................................................................................................. 3
SPECIFICATIONS/WARNINGS ................................................................................................................................................... 3
DIAGRAMS ........................................................................................................................................................................................ 4
SETUP .................................................................................................................................................................................................. 5
CONTROLS ......................................................................................................................................................................................... 6
OPERATIONS .................................................................................................................................................................................... 7
DISASSEMBLY/ASSEMBLY .......................................................................................................................................................... 8
CLEANING ........................................................................................................................................................................................... 12
TROUBLESHOOTING ...................................................................................................................................................................... 13

22
VIRO TECH MINI - USER MANUAL
PRODUCT INTRODUCTION
BENEFITS
THE AIR PURIFIER SYSTEM BRINGS THE MOST ADVANCED AIR PURIFICATION TECHNOLOGY INTO THE
COMFORT OF YOUR SPACE
Unlike other air puriers, Viro Tech Mini does more than simply filter the air in your space. Incorporating technology like
photo catalytic oxidation, high level negative ionization, scalable purification and electrostatic filtration allows the air
purification system to provide tangible benefits to your home or workspace by:
• Destroying pollution from the air, embedded in walls, ceilings, oors, carpets, furniture, etc.
• Reducing or eliminating odours such as cigarette smoke, mildew, food, etc.
• Contributing to the sanitization of all surfaces.
The whisper quiet ve-speed fan disguises the power encapsulated in the advanced air purication system. Having the air purier
in your space will not only improve the quality of air but most importantly it will improve the quality of life.
EASE OF USE
THE AIR PURIFIER IS YOUR HASSLEFREE PROVIDER FOR CLEAN AIR AND HEALTHY LIVING
With proper care and maintenance (see “CLEANING” page 10), the air purier will operate with the same robust power and
eciency for several years beyond the date of purchase. With the push of a button the unit starts working to eliminate the
biological contaminates and dangerous pathogens in your home or oce. Enhancing your overall quality of life has never
been this easy.
FOUR TECHNOLOGIES
ELECTROSTATIC FILTRATION
An advanced electrostatic lter is included with air purier to help keep the purier clean while at the same time ltering out
particles. Unlike expensive HEPA lters, the electrostatic lter is washable and can be used over and over again.
NEEDLEPOINT IONIZATION
The air purier generates a continuous stream of millions of negative ions that circulate throughout the home. These ions
charge particles (such as dust, dander or bacteria) causing them to attract other particles and clump together. As more and
more particles come together, they become heavier, making them easier to pull into the home’s HVAC air lter or just fall to
the oor to be vacuumed up. Unlike HEPA lters that can only lter out particles of .5 microns or larger, the ionizer in the air
purier can reduce ultra-ne, even nano particles, that are much more dangerous than the larger particles you can actually
see.
SCALABLE PURIFICATION
The unit can be easily adjusted to the preferred purication setting for your living area Using these settings provides optimum
performance and comfort. In High Mode, the purication plate generates activated oxygen to assist in breaking down pollutants
which cause odours. For faster sanitization, the unit can be set to Away Mode which is equipped with an auto shut-o timer and
can be used for maximum output when the room or home is unoccupied.
ADVANCED PHOTO CATALYTIC
Both the Advanced Photo Catalytic Oxidation (PCO) and Scalable Oxidation work to destroy biological contaminates as well
as odours, mold, bacteria and viruses. PCO Cells have been proven to reduce dangerous pathogens by more than 99% in less
than 24 hours through a process called molecular disassociation which actually breaks down the molecules instead of simply

3
VIRO TECH MINI - USER MANUAL
covering up the source. Scalable Oxidation ensures your air purier will perform at the maximum eciency specic to its
environment at the time of use. In High Mode, the purication plate generates activated oxygen to assist in breaking down
contaminates which cause odours. For faster cleanup, the unit can be set to Away Mode which has a programmable auto-
shuto timer feature. This allows the machine to generate maximum output when the room or home is unoccupied.
SPECIFICATIONS/WARNINGS
SPECIFICATIONS
UNIT
Size: H 305 mm x W 228 mm x D 273 mm
Weight: 4.7 kg
Coverage: from 23 m2to 279 m2(depending on variables such as the severity and frequency of pollution, ow of air in the
environment, humidity and temperature)
Input: 100-240 Vac - 50/60 Hz - 2.5 A
PCO CELL
“NORMAL” Mode Output: <0.02 ppm ozone (ambient room concentration)
PURIFICATION PLATE
“HIGH” Mode Output: 25-360 mg ozone per hour
IONIZATION
6 KV DC Needle Ion generator
24 - 30 KV, 20 - 30 KHIon generator pulsator
WARNINGS
Review this list before use and performing any maintenance or cleaning of your unit.
WARNING: Never operate unit near heat source, open ame or ammable/combustible uids.
WARNING: Do not operate unit unless all parts (including PCO Cell, Purication Plate, Rear Filter Assembly and
Rear Cover) are properly installed.
CAUTION: Directly viewing the lamp inside unit for an extended period (longer than 20 min.) may result in
eye damage.
CAUTION: Never adjust setting to exceed square metres of ventilated space being treated.
CAUTION: Do not use “AWAY” Mode in occupied spaces. Short term exposure to ozone levels exceeding 0.5
ppm can cause temporary adverse reactions.
CAUTION: Unit should be powered OFF and Power Cord should be disconnected when Cleaning/
Disassembling/Reassembling/Servicing.

44
VIRO TECH MINI - USER MANUAL
DIAGRAMS
FRONT OF UNIT REAR OF UNIT SIDE OF UNIT
1
2
3
2
1
3
1
23
1Ionization Needlepoint
2Front Grill
3Control Panel
1Rear Cover Screw
2Rear Cover Clasps
3Power Adapter Inlet
1Rear Cover
2Unit Rear
3Unit Front
REAR OF UNIT
(Rear Cover Removed)
REAR OF UNIT
(Filter Assembly Removed)
2
11
2
3
4
1
1Brass Thumbscrews
2Filter Assembly
1PCO Cell
2PCO Cell Nuts
3PCO Cell Connector
4Purification Plate

5
VIRO TECH MINI - USER MANUAL
SETUP
IDEAL PLACEMENT
There are several important factors to consider when selecting a location for your air purier:
• Make sure the location you choose is as far away from the HVAC air return duct as possible. This will ensure that the
purication produced by the air purier is optimally circulated.
• Place the unit on top of something tall such as a bookcase, a shelf or a mounting bracket, leaving only 30 to 60 cm
between the unit and the ceiling. Point the unit towards the centre of the room.
• To ensure the unit works properly, there should be as much space as possible in front of your air purier so that it can
eciently process the air in the area.
• Never place an operating unit on the oor.
• Nearest the source of the worst pollution.
INITIAL SETTING
Before using the unit you will need to nd the area (or square metres) of the environment. To do this accurately, take into
account all connected rooms with open doorways (the purication does not ow readily through closed doors).
The Air purier can purify up to 279 m2of space.
For example: Suppose you have a 232 m2house. The living room is attached to the kitchen, three bedrooms, the den and a
laundry room. The kitchen and three bedrooms’doors remain open the majority of the time but the laundry room and den
usually remain closed o from the rest of the house. Together, the laundry room and den have a combined area of 46 m2.
The area of the environment you would want to set your air purier and purify would be 186 m2.
Once you have determined an ideal location for your unit and calculated the area of the environment:
1. Connect the Power Cord into the unit.
2. Insert the Power Plug into the wall outlet.
3. Turn the unit on and set it to “NORMAL”mode (see “OPERATIONS”: page 7).
4. Leave the unit on “NORMAL” mode for at least 24 hours to begin with.
5. After 9 hours, set the unit to“HIGH”mode and set the square metres to 24 m2.
6. Gradually increase the square metres setting every 24 hours until you reach the accurate square metres of your area
which you calculated in the initial steps).
NOTE
Using the purier at a setting less than the m2of the area being treated is acceptable and may be desirable in an environment
relatively free of pollutants.
Register your product for 12 month warranty at:
https://f-tech-warranty.com

66
VIRO TECH MINI - USER MANUAL
CONTROLS
CONTROL PANEL REMOTE CONTROL PANEL
1Power Control 5Mode/ Coverage Setting
2LCD Screen 6“AWAY” Mode - Not for use in occupied room
3Fan Speed Setting 7“AWAY” Mode Timer Indicator - Not for use in occupied room
4Maintenance Reset
CONTROL PANEL SCREEN MODE SPECIFIC DISPLAY
1Fan Speed Indicator 5“AWAY” Mode Timer Indicator
Not for use in occupied room
2Photocatalytic-Oxidation
Mode Indicator 6“AWAY”Mode Warning Indicator
3Mode/Coverage Indicator 7REPLACE PLATE
REPLACE PCO CELL
Replacement Notification
Indicator
4Mode/Coverage Warning
Indicator 8PERFORM CLEANING Maintenance Notification Indicator
NOTE
It is recommended to leave the room vacant for 2 hours after running the unit in away mode.
This will allow time for the ozone to dissipate. It is also advisable to open windows/doors to ventilate the room.

7
VIRO TECH MINI - USER MANUAL
OPERATING THE UNIT
TURNING THE UNIT ON/OFF
Press the Power Button on the Control Panel or Remote to turn the unit on. The unit will initially be set to “NORMAL”
Mode. Press the Power Button once more to turn the power o.
USING “NORMAL” MODE
Press button until “NORMAL”is shown in the lower right of the display.
• Square metres not available in“NORMAL” mode (see“Initial Settings”: page 5).
• To control the fan speed: Use or buttons in menu.
USING “HIGH” MODE
Press the button and verify that “HIGH” is shown in the lower right of the display.
• To set the square metres on the Display: Use or buttons (see “Initial Settings”: page 6).
• To control the fan speed: Use or buttons.
CAUTION: Never adjust setting to exceed square metres of ventilated space being treated.
USING “AWAY” MODE
Press the button and verify that “AWAY” is shown in the lower right of the display.
• To set the “AWAY” Mode Timer: press . Each press of the button increases the running time of the Away Mode.
Select 0:30, 1:00, or 2:00 hours.
• Press once more to switch the unit back to “NORMAL” Mode.
LCD REMINDERS
REPLACE PLATE
When “REPLACE PLATE” appears, the Purication Plate has reached the end of its useful life and must be replaced. To order
a replacement, contact your distributor. Once a replacement has been obtained, follow the instructions in “DISASSEMBLY/
ASSEMBLY” (page 8) to replace your old Purication Plate with your new one.
REPLACE PCO CELL
When “Replace PCO Cell” appears, the PCO Cell has reached the end of its useful life and must be replaced.
Contact your distributor to order a replacement.
Once a replacement has been obtained, follow the instructions in “DISASSEMBLY/ASSEMBLY” (page 8) to replace your old
PCO Cell with your new one.
PERFORM CLEANING
“PERFORM CLEANING” will display once the 30 day operation cycle between cleanings has passed and the unit requires a
complete cleaning. Follow the instructions in “CLEANING”(page 10).
After replacing the Purication Plate or the PCO Cell, the corresponding reminders will reset themselves. After performing a
cleaning of the unit you should reset the reminders by holding down the Reminder Reset button on the Control Panel
of the unit. The reminder has been reset when“PERFORM CLEANING” no longer appears.

88
VIRO TECH MINI - USER MANUAL
DISASSEMBLY / ASSEMBLY
TOOLS REQUIRED: You will need a #2 Phillips screwdriver.
A countertop or at surface is ideal for disassembling/assembling your unit. You will need 2 ft. x 3ft. of clean, accessible
workspace. It is recommended to use a small bowl or cup to hold any screws so they are not lost during the disassembly /
assembly process.
1. TURN THE UNIT OFF.
2. REMOVE THE POWER CORD FROM THE WALL AND REAR OF THE UNIT.
3. CLEAN EXTERIOR OF UNIT IF NECESSARY (see “Cleaning unit - Exterior”: page 10).
DISASSEMBLY
REMOVING THE REAR COVER
1. Using your screw driver, remove the Rear Cover Screw from the Rear Cover (above the Power Cord Port). Place the Rear
Caver Screw where you will nd it easily during reassembly.
2. Squeeze the tabs on both sides of the Rear Cover (where the grooves are) until they release and tilt the Rear Cover
upwards until the top tab releases. Clean with compressed air or a damp cloth. Set the Rear Cover aside.
3. Clean exterior of unit if necessary (see “Cleaning Unit - Exterior”: page 10).
REMOVING THE FILTER ASSEMBLY
1. Remove brass thumbscrews from the top corners of the Filter Assembly. Place brass thumbscrews where you will nd
them easily during reassembly.
2. Grasp the top of the Filter Assembly and tilt away from the unit. Clean if necessary (see “Cleaning the Filter Assembly”:
page 10) and set the Filter Assembly aside.
REMOVING THE PURIFICATION PLATE
Grasp the Purication Plate on the ceramic and gently pull it out of the grooves on the sides. Clean (see “Cleaning the
Purication Plate”: page 10) and set the Purication Plate aside.
REMOVING THE PCO CELL
1. Locate the PCO Cell Power Connector on the right of the rear of the unit (beside the Purication Plate slot). Squeeze
the tabs on the top and bottom of the PCO Cell Power Connector and pull gently until free from the PCO Cell Power
Connector Outlet.
2. Remove the thumb nuts from the screw posts on the right and left below the PCO Cell. Place the thumb nuts where you
will nd them easily during reassembly.
3. Gently slide the PCO Cell out of the unit. Clean (see “Cleaning the PCO Cell“: page 10) and set the PCO Cell aside. Clean
the interior of the unit (see “Cleaning the Unit - Interior”: page 10).
ASSEMBLY
INSTALLING THE PCO CELL
1. Position the PCO Cell inside the unit so that the two tabs are on the bottom (and interior side) of the PCO Cell. Ensure the
holes in the two tabs t over the two screw posts. Screw the thumb nuts onto the screw posts until they are snug.
2. Align the PCO Cell Power Connector to the PCO Cell Power Connector Outlet and insert gently until the tabs at the top
and bottom of the PCO Cell Power Connector snap into piace, holding it in the PCO Cell Power Connector Outlet.

9
VIRO TECH MINI - USER MANUAL
INSTALLING THE PURIFICATION PLATE
Holding the Purication Plate by the ceramic, slowly insert it into the Purication Plate Slot, ensuring that the Purication
Plate is sliding into the grooves on either side.
NOTE: About halfway in, the Purication Plate Connectors are parted. Continue sliding the Purication Plate into the
Purication Plate Slot until there is approximately one inch of the Purication Plate remaining outside of the Purication
Plate Slot and signicant resistance is met. Be careful not to force the Purication Plate further into the Purication Plate Slot
as this could seriously damage your unit.
INSTALLING THE FILTER ASSEMBLY
1. Hold the Filter Assembly with the larger at side facing the interior of the unit. A sticker reading, “Caution: Reinstall Filter
After Cleaning,”is located on the opposite side of the Filter Assembly. This sticker should be visible when you install the
Filter Assembly.
2. Insert the bottom of the Filter Assembly into the tabs on the rear of the unit and then seat the Filter Assembly on the rear
of the unit.
CAUTION: If the user fails to insert the Filter Assembly into the tabs appropriately, disassembling the unit in the future
could be extremely dicult.
3. Screw the two brass thumbscrews into their holes at the top corners of the Filter Assembly.
INSTALLING THE REAR COVER
1. Place the tab at the top of the Rear Cover into the hole at the top of the Filter Assembly then lay the Rear Cover at
against the rear of the unit until the tabs on the sides of the Rear Cover click into place on the unit.
2. Carefully insert the Rear Cover screw into its hole on the Rear Cover (above the Power Cord Port) and tighten.
OPTIONAL PREFILTER

1010
VIRO TECH MINI - USER MANUAL
REMOVING THE REAR LINT SCREEN
REMOVING THE PURIFIER PLATE & ACTIVEPURE RCI CELL

11
VIRO TECH MINI - USER MANUAL
INSTALLING THE PURIFIER PLATE & ACTIVEPURE RCI CELL
INSTALLING THE REAR LINT SCREEN
INSTALLING THE POWER CORD
1. Insert the Power Adapter Plug into the rear of the unit.
2. Ensure the Power Cord is properly connected to the Power Adapter.
3. Insert the Power Plug into a wall outlet.
TURNING THE UNIT ON
Press the Power Button . Ensure that the unit’s settings are adjusted to suit the environment (see“OPERATING THE UNIT”:
page 7).

1212
VIRO TECH MINI - USER MANUAL
CLEANING THE UNIT
Your unit should be cleaned monthly to be kept running at peak performance, but depending upon the pollution or odour
levels present during initial setup, it is advisable to clean the unit more frequently (weekly or bi-weekly) until the environment
has been treated.
CLEANING THE UNIT EXTERIOR
Wipe down the exterior with a damp cloth or use compressed air or a vacuum cleaner to remove dust. Use an alcohol-based
cleaning product to clean the surfaces of your unit.
CLEANING THE FILTER ASSEMBLY
You may use clean water or compressed air to clean your Filter Assembly once it has been disassembled (see“Removing the
Filter Assembly”: page 8).
CLEANING THE IONIZATION NEEDLE
Use compressed air to blow o any dust that may accumulate near the ionization needle.
CLEANING THE PCO CELL
Using a compressed air or a vacuum cleaner, blow and/ or vacuum the dust out of the PCO Cell. Do not use any liquid to
clean the PCO Cell.
CLEANING THE PURIFICATION PLATE
Using a 50/50 mix of warm water and clear ammonia (100% white vinegar can be used in place of water and ammonia), soak
the Purication Plate for 8-10 hours but do not exceed 12 hours. Using a soft-bristle brush, scrub the wire mesh to remove
debris lodged inside the mesh. Rinse thoroughly. Allow the purication plate to dry completely before reinstalling. After
reinstalling, use a soft cloth and rubbing alcohol to clean the contacts on the interior of the unit that touch the Purication
Plate.
CLEANING THE UNIT INTERIOR
Using a damp cloth, a clear alcohol-based cleaner, compressed air or a vacuum cleaner, carefully clean the walls and
components inside of the unit only after completing the disassembly procedures.

13
VIRO TECH MINI - USER MANUAL
TROUBLESHOOTING
THE UNIT FAILS TO TURN ON
1. Verify that the Power Plug is plugged into an operational wall outlet.
2. Ensure that the Power Adapter Plug is fully seated in the receptacle on the back of the unit.
3. Verify the Power Button has been activated on the Control Panel.
4. If the Power Button on the Control Panel fails, use the Power Button on the Remote Control.
THE UNIT IS OPERATING IN “HIGH” MODE OR “AWAY” MODE, BUT NO NOTICEABLE PURIFICATION IS BEING
PRODUCED
1. Ensure that the Purication Plate is clean (see “Cleaning Purication Plate”: page 10).
2. The Purication Plate may not be working because it needs to be replaced. Try installing a new Purifìcation Plate.
3. Check the electrical contact arms which touch the plate to ensure that they are making proper contact with the metal
weave on the Purifìcation Plate.
4. Ensure the electrical contact arms which touch the plate are clean. Clean them with a soft cloth and rubbing alcohol.
5. Turn the lights o in the room and look through the Front Grille at the Purication Plate. If it is operating properly, it will
produce a dim purple glow.
THE PURIFICATION PLATE GENERATES AN ELECTRICAL ARC, AN ARCING NOISE OR A BURNING ODOUR
This means the Purication Plate is damaged and must be replaced. The unit may or may not display the “REPLACE PLATE”
LCD reminder. To order a replacement, contact your distributor.
THE PCO CELL IS NOT LIGHTING UP
1. Ensure the PCO Cell Power Connector is properly seated in the PCO Cell Power Connector Outlet (see “DISASSEMBLY/
ASSEMBLY”: pages 8-9).
2. If the PCO still fails to operate, it needs to be replaced. Contact your distributor.
THE IONIZATION NEEDLE CREATES AN ELECTRICAL ARC
The Ionization Needle needs to be cleaned (see“Cleaning Ionization Needle”: page 10). Be sure to complete all of the cleaning
procedures (see“CLEANING”: page 10) every 30 days of operation.
THE FAN DOES NOT OPERATE PROPERLY
Try adjusting the fan speed using the Control Panel or Remote Control.
THE UNIT MAKES A RATTLING NOISE WHEN TAKEN OUT OF PACKAGING
Remove the back panel of the unit (see “DISASSEMBLY/ASSEMBLY”: pages 8-9). Check to ensure the two brass Thumb
Screws holding the Filter Assembly are in their proper place. If they are properly installed, remove the Thumb Screws and
Filter Assembly (see “DISASSEMBLY/ASSEMBLY”: pages 8-9) and check the PCO Cell to ensure the two brass Thumb Screws
securing the PCO Cell are installed properly.

Wilkinson Star Limited
Shield Drive
Wardley Industrial Estate,
Worsley,
Manchester,
M28 2WD
wilkinsonstar247.com
[phone]
[e-mail]
©June 2020
