VISA SN-9100 User manual

1
OPERATING INSTRUCTIONS
FOR PREPROGRAMMED REMOTE
CONTROLS BY BRAND
SN-9100
BRANDS OFTHE SONY - PANASONIC - SAMSUNG GROUP
DESCRIPTION
1. LED indicator.
2. Access to “secondary functions”.
3. Access to Teletext functions
(only on some models).
4. Switch key to access additional
memory for copying functions
by the learning procedure.
5. Main functions and code entry keys.
6. TV: On/Off or access to the
automatic Device-Code search.
7. VCR: Play or access to the
automatic Device-Code search.
8. Internal RESET key
(to be used only in the specified cases).
9. Key to initialize programming,
search or code visualising
procedures.
Fig. 1
RAPID SET-UP
HOW TO MAKE YOUR REMOTE CONTROL FUNCTION IMMEDIATELY
OPEN THE BATTERY COVER AND INSERT 2 NEW ALKALINE BATTERIES, TYPE AAA/LR03 1,5V AND
CLOSE THE BATTERY COVER.
• SWITCH THE TELEVISION SET ON.
• OPEN THE FRONT COVER OF THE REMOTE CONTROL, PRESS AND RELEASE THE «CODE» KEY AND ENTER
• POINT THE REMOTE CONTROL TOWARDS THE TV SET.
• PRESS AND KEEP PRESSED THE ON/OFF KEY.
• RELEASE IMMEDIATELY THE ON/OFF KEY ONCE THE TV SWITCHES OFF.
•
CHECK THAT THE REMOTE CONTROL OPERATES THE MAIN FUNCTIONS.
• IN THIS CASE
• THE UNIT IS READY.
• OTHERWISE REPEAT AGAIN PROCEDURE.
TO KNOW MORE…
TO MAKE THE BEST USE OF YOUR NEW REMOTE CONTROL WE RECOMMEND THAT YOU READ IN FULL AND
RETAIN THESE INSTRUCTIONS
N.E. SN 9100 (GB) 13-07-2000 12:29 Pagina 1

MAIN FEATURES:
The new remote control you are about to use
is preprogrammed to replace almost all of the
original TV remote controls of this brand (or
group of brands) and, in their basic functions,
most brands ofVCR remote controls.
- It fully replaces the original TV remote con-
trol,including the teletext/fastext (if available
on the original).
- It operates simultaneously aTV and aVCR
with no additional operation required once
the respective codes have been inserted.
- The buttons are identified by the symbols of
the original remote control
- It can learn up to 19 additional functions from
another remote control (TV,VCR,SAT,etc.)
- Its use is further facilitated by the LED
indicator (➀Fig.1) which emits a short flash,
every time a button is pressed to transmit a
command,or a series of flashes,when perfor-
ming operations as described below.
PRELIMINARY OPERATIONS
To set the remote control to operate yourTV
and/orVCR it is necessary to perform the
simple operations as described in the attached
instructions,which we recommend you read
in full and keep for future reference.
Open the battery cover and insert two 1.5V
mini batteries of the type LR03 (AAA) obser-
ving the polarity as indicated.
Close the battery cover and proceed on setting
up your remote control.
N.B.: Open the front cover of your remote
control to access other functions.
1) HOW TO PROGRAM
THE REMOTE
CONTROL FOR TVs
If you know the model of the original remote
control, please read paragraph “1.1” here
below:TV, manual programming; if not, go
to paragraph “1.2”:TV, automatic search
and programming.
1.1)TV, MANUAL
PROGRAMMING
1.1.A) Look for the brand and the model of the
original remote control in table B, page
4-5, and make a note of the code that
corresponds to it.(If you do not find this
match,go to paragraph“1.2”:
TV,automatic search and program-
ming).
1.1.B) Press and release the « » but-
ton (➈Fig.1) and immediately watch the
LED, which will signal a short flash.
1.1.C) Enter the code using the numeric but-
tons (see group ➄Fig. 1) and immedia-
tely watch the LED.
If the LED emits two short flashes (OK) the
remote control is ready. (See also paragraph
“1.3”: Secondary Functions). If the LED emits
one long flash (error) you will need to repeat
the procedure.
1.2)TV,AUTOMATIC SEARCH AND
PROGRAMMING
1.2.A) Switch the TV on, on any channel, and
point the remote control towards the
set.
1.2.B) Press and release the « » but-
ton (➈Fig. 1) then press and keep
pressed the OFF button « » (➅ Fig.
1), releasing it immediately the set
switches off.
(During the“search” phase,the LED will
emit a series of flashes).
1.2.C) Using the remote control,switch the set
on again (by pressing the OFF button
« » or one of the numeric buttons,
depending on the model).
1.2.D) Check that all other buttons are func-
tioning correctly. (See also paragraph
“1.3”:“Secondary functions”).
IF EVERYTHING IS OK!YOUR REMOTE CONTROL
IS READY.
We advise you make a note of the code fol-
lowing the instructions in paragraph “3”:
Displaying the code.
If the buttons do not perform correctly, repeat
the search procedure. If the set does not swit-
ch off within 5minutes from the start of the
search, go to paragraph “5”: “What to do
if…”
1.3) SECONDARY FUNCTIONS
For maximum simplicity,the number of buttons
on your remote control has been limited to
functions of most frequent use.
The commands less frequently used,are repre-
sented by the orange coloured symbols on the
face of the remote or pictured on the appro-
priate diagram in this manual (Fig. 2,
Fig.3pag.8).
N.B. Secondary functions are available only if
present in the original remote control.
1.3.A) To transmit the required command,
press and hold down the « » button
(➁Fig. 1) while simultaneously
pressing the button identified for
that function.
2) HOW TO PROGRAM
THE REMOTE
CONTROL FOR VIDEO
RECORDERS
2.1) IFYOU KNOWTHE BRAND
OFTHEVIDEO RECORDER…
N.B.The main functions of the video recorder,
once the remote control has been program-
med,are accessed by simply pressing the speci-
fic buttons.
2.1.A) Look at table C page 6-7 relating to
SHIFT
CODE
?
CODE
?
2
N.E. SN 9100 (GB) 13-07-2000 12:29 Pagina 2

3
brands and codes for video recorders.
Next to the required brand are listed
one or more codes that have to be
inserted, in the same way as described
for TVs from para. “1.1.B”, one at the
time,in turn,until the one that operates
your VCR correctly is found. (See also
Note 1at the end of para.“2.2”).
Should you not be able to find the correct code
for the required brand, or the brand is not
listed,go to the next paragraph.
2.2)VCRs,AUTOMATIC SEARCH
AND PROGRAMMING
2.2.A) Insert a video cassette, preferably blank,
and set the video recorder on STAND
BY.
2.2.B) Point the remote control towards your
VCR.
2.2.C) Press and release the « »,button
and then press and keep pressed the
« » (PLAY), button (➆ Fig. 1), Release
the button as soon as the tape starts
advancing. (During the search phase the
LED will emit a series of short flashes).
2.2.D) Stop the tape and check the workings of
the other buttons (See also Note 1).
IF EVERYTHING IS OK!THE REMOTE CONTROL
IS READY.
We advise you make a note of the code just
memorized following the instructions in para.
“3”:Displaying the code.
If some commands do not correspond, repeat
the search procedure.If the tape does not start
advancing within 5minutes of commencing the
search,see para.“5”:“What to do if…”.
NOTE 1: the RECORD function is accessed by
pressing simultaneously the «SHIFT» and «
● »
(orange symbol) buttons.
The OFF or STAND BY functions are accessed
by pressing simultaneously the «SHIFT» and
« » (orange symbol) buttons.
3) DISPLAYING THE
CURRENT CODE
Premise:
• Each code is composed of 4digits.
• The LED indicates each digit as the sum of a
series of short flashes, except for the zero
that is represented by one long flash.
• The LED pauses for approx. 2seconds in
between each digit.
3.1) Press and keep pressed the «SHIFT» button.
3.2) Press the « » button.
3.3) Release both buttons (« » and
«SHIFT»).
3.4) Press and release the « » (OFF) button
for TV or « » (PLAY) for video recor-
ders.
Watch the LED which,after a short flash when
pressing the button, will indicate the code as
described in the premise.
4) LEARNING
FUNCTION
General
SN-9100 can learn from the majority of remo-
te controls on the market (TV,VCR, SAT, etc.)
up to a maximum of 19 functions. The com-
mands can be memorized on two memory
banks, selected by using the «LEARN», button,
using all buttons except «SHIFT», « »,
«VT» and «LEARN».
NOTE: the «LEARN» button, to select the
second memory bank,is used when wanting to
learn functions that are additional to those
already in use and all the buttons are full. It is
not necessary to select the second memory
bank if you want to replace commands on but-
tons that are not in use.
A learned command automatically replaces any
pre-existing preprogrammed command. If you
make a mistake and forget to select the second
memory bank , the original pre-programmed
command can be restored by simply cancelling
the learned command.
In all cases, it is necessary to cancel a learned
command before it can be replaced.
When toggling between memory banks, by
pressing «LEARN», the LED flashes once or
twice, to indicate which one is active,or not at
all if the second is empty.
4.1) Learning procedure.
a) Place the two remote controls on a level
surface as shown in the figure below.
b) Press and realease the « » button
and enter the code «5555».Wait for the
LED to emit 5 short flashes and then…
c) If necessary, select the memory bank by
pressing the «LEARN» button (See Note
above).
d) Press the button of the SN-9100 on which
you wish to learn,watch the LED which ini-
tially will stay on and within 5seconds…
e) Press and keep pressed the button of the
original remote control to be learned,relea-
sing it when the LED goes off (two short fla-
shes shortly after will confirm memoriza-
tion).
f) To memorize more commands repeat the
procedure from d).
N.B.:
• If the LED emits two long flashes there has
been a problem and you have to repeat the
procedure from d).
• Exit from the learning function is automatic
after approx.8seconds of the last operation
(or its interruption) and is signaled by a long
flash of the LED. To enter the learning func-
CODE
?
CODE
?
CODE
?
CODE
?
CODE
?
Visa SN-9100 Original
3~ 5cm.
N.E. SN 9100 (GB) 13-07-2000 12:30 Pagina 3

tion again repeat from b).
•To learn a new command on a button that has
already been memorized it is necessary to
first clear the memory (4.2)
4.2) Cancellation procedures.
Cancellation procedures are used when wan-
ting to replace a learned command with
another learned command or restore a pre-
programmed command (See NOTE above).
4.2.A) Cancellation of only one button.
a) Press and release the « » button.
b) Enter the code «6 6 6 6».
c) Press the button to be cleared and watch the
LED that will confirm cancellation with 2
short flashes.
d)To cancel more commands repeat from a).
N.B.: Exit from cancellation mode is automatic
after approx. 8seconds of the last operation.
4.2.B)Total cancellation (on all buttons of both
memory banks).
a) Press and release the « » button.
b) Enter the code «7 7 7 7» and watch the LED
that will confirm cancellation with two
short flashes.
5) “WHAT TO DO IF…”
- After the batteries have been inserted, the
LED will not flash when pressing the
« » button?
Check that the batteries have been inserted with
correct polarity.
-The automatic search was unsuccessful?
Repeat the operation and observe the LED
After a while you will notice that the LED emits 5
short flashes indicating the end of a search cycle.
Keep the search button pressed…if your
machine still does not respond and the LED
again emits 5 short flashes, abandon this proce-
dure and try inserting manually, one by
one, following the procedures in the pre-
vious chapters, all the codes listed in the
tables (Tab.A forTVs,Tab. C. forVCRs).
- You have some difficulties with the learning
function?
Try repositioning the two remote controls chan-
ging the distance and/or alignment.
- After a while the operation of the remote
control becomes erratic?
Make a note of the codes memorized (see also
para.
3 ) and quickly change the batteries. If no
change,press (for example with the tip of a pen-
cil or non sharp object) the internal reset button.
Take notice: after pressing the RESET but-
ton it is necessary to enter again all the requi-
red codes.
CODE
?
CODE
?
CODE
?
4
SONY
1001 - 1002 - 1003 - 1004
1005 - 1006 - 1007 - 1008
PANASONIC
1009 - 1010 - 1011 - 1012
1013
SAMSUNG
1014 - 1015 - 1016 - 1017
1018 - 1019 - 1020 - 1021
1022 - 1023 - 1023 - 1024
1025 - 1026 - 1027 - 1028
TAB. A: CODES OF TV
TAB. B
ORIGINAL SONY MODELS CODE
1 465 487 11 - 1 465 488 11 - A 1009801 A - A 1009840 A - A 1009866 A - A 1009875 A - A 1470708 A - A 1470716 A - 1001
A 1470726 A - A 1470735 A - A 1470738 A - A 1470742 A - A 1470744 A - A 1470745 A - A 1470747 A - A 1470760 A -
A 1470779 A - A 1470791 A - A 1470794 A - A 1470806 A - A 1470808 A - A 1470811 A - A 1470813 A - A 1470816 A -
A 1470818 A - A 1470839 A - A 1470844 A - A 1470858 A - A 1470876 A - RM (VIDEO 8) - RM 640 - RM 641 A -
RM 642 A - RM 644 - RM 646 - RM 649 - RM 650 - RM 651 - RM 652 - RM 653 - RM 654 - RM 655 - RM 657 -
RM 658 - RM 661 - RM 661 A - RM 662 - RM 663 - RM 664 - RM 665 - RM 668 - RM 670 - RM 671 - RM 672 -
RM 673 - RM 674 -RM 676 - RM 677 A - RM 687 - RM 687 B - RM 827 B - RM 849 T
1465 13411 - 1465 136311 - 1465 79611 - 1465 79621 - 1465 79711 - 1693 14122 - 9196 345 0 - A 1470681 A - 1002
A 1470704 A - A 1470712 A - A 1470727 A - A 1470728 A - A 1470741 A - A 1470802 A - A 1470847 A - A 1470859 A -
A 1470881 A - RM 669 - RM 677 C - RM 688 - RM 689 - RM 694 - RM 698 - RM 717 A - RM 724 - RM 816 - RM 817 -
RM 818 - RM 821 - RM 826 - RM 827 S - RM 828 - RM 845 T - RM 849 S - RMK 1T
RM 637 C - RM 830 - RM 831 - RM 832 - RM 833 - RM 834 - RM 836 - RM 838 - RM 839 - RM 842 - RM 846 - 1003
RM 860 - RM 862 - RM 863 - RMV 242
A 1009093 A - A 1009094 A - A 1009098 A - A 1009194 A - A 1009604 A - A 1009614 A - A 1009756 A - A 1009765 A - 1004
A 1470562 A - A 1470588 A - A 1470591 A - A 1470594 A - A 1470615 A - A 1470625 A - A 1470631 A - A 1470634 A -
A 1470640 A - A 1470648 A - A 1470672 A - A 1470759 A - RM 105 - RM 610 -
RM 611 - RM 613 - RM 613 S -
RM 613 ST - RM 614 - RM 615 P - RM 620 - RM 621 - RM 622 - RM 623 - RM 624 - RM 625 - RM 630 - RM 631 -
RM 632 - RM 633 - RM 634 - RM 635 - RM 636 - RM 637 - RMT 211 - X 43578551 - X 43716151
N.E. SN 9100 (GB) 13-07-2000 12:33 Pagina 4

5
TAB. B
ORIGINAL SONY MODELS CODE
RM 656 - RM 681 - RM 682 - RM 683 - RM 684 - RM 685 - RM 687 C - RM 694/I - 818/I - RM 826/I - RM 841 1005
A 1009005 A - A 1009009 A - A 1009014 A - A 1009022 A - A 1009027 A - A 1009029 A - A 1009041 A - A 1009043 A - 1006
A 1009044 A - A 1009057 A - A 1009060 A - A 1009313 A - A 1009379 A - A 1470405 A - RM 604 - RM 604/B -
RM 604/F - RM 605 - 604/F - RM 605 - RM 606 - RM 606/A - RM 606/F - RM 609
A 1009042 A - RM 603 B 1007
RM 702 1008
ORIGINAL PANASONIC MODELS
017040053 - 017040054 - 017040064 - 017040065 - 017040067 - 017040071 - 017040073 - ALPHA - EUR 16541 - 1009
EUR 37211 - EUR 50100 - EUR 50369 - EUR 50370 - EUR 50372 - EUR 50535 - EUR 50536 - EUR 50621 - EUR 51140 -
EUR 51142 - EUR 51143 - EUR 51169/II - EUR 51200 - EUR 51203 - EUR 51204 - EUR 51207 - EUR 51210 - EUR 51241 -
EUR 51253 - EUR 51920 - EUR 51940 - EUR 62531 - EUR 64028 - EUR 64102 B - EUR 64531 - EUR 64541 - EUR 64542 -
EUR 64542/31 - EUR 64546 A - EUR 64564 - EUR 64582 - EUR 64598 - THQ 70465 - TNP 107318 AA - TNQ 1408 -
TNQ 1410 - TNQ 1411 - TBQ 1412 - TNQ 1414 - TNQ 1416 - TNQ 1420 - TNQ 1442 - TNQ 1455 - TNQ 1482 -
TNQ 1487/1 - TNQ 1628 - TNQ 1E 2607 - TNQ 1E 2611 - TNQ 2403 - TNQ 2442 - TNQ 2443 - TNQ 2447 - TNQ 2448 -
TNQ 2459 - TNQ 2498 - TNQ 2607 - TNQ 2611 - TNQ 2637 - TNQ 611 - TNQ 696 - TNQ 8E 0401 - TNQ 8E 0402 -
TNQ 8E 0403 - TNQ 8E 0404 - TNQ 8E 0405 - TNQ 8E 0406 - TNQ 8E 0407 - TNQ 8E 0408 - TNQ 8E 0409 - TNQ 8E 0410 -
TNQ 8E 0411 - TNQ 8E 0412 - TNQ 8E 0413 - TNQ 8E 0414 - TNQ 8E 0415 - TNQ 8E 0417 - TNQ 8E 0418 - TNQ 8E 0419 -
TNQ 8E 0421 - TNQ 8E 0422 - TNQ 8E 0423 - TNQ 8E 0428.1 - TNQ 8E 0430 - TNQ 8E 0434 - TNQ 8E 0438 -
TNQ 8E 0439 - TNQ 8E 0440 - TNQ 8E 0432 - TNQ 8E 0441 - TNQ 8E 0442 - TNQ 8E 0835 - TZS 1EK 001 - VEQ 0528
EUR 501100 - EUR 501101 - EUR 501120 A - EUR 50623 - EUR 50624 - EUR 50700 - EUR 50752 - EUR 530754 - 1010
EUR 50755 - EUR 50756 - EUR 50757 - EUR 51144 - EUR 51805 - EUR 51921 - EUR 61550 - EUR 64150 - EUR 641550 -
EUR 64510 - EUR 645645 - TNQ 10464 4 D13 - TNQ 8E 70446 - TNQ 8E 0428 - TNQ 8E 0435 - TNQ 8E 0436 -
TNQ 8E 0443 - TNQ 8E 0445 - TNQ 8E 0446 - TNQ 8E 0448 - TNQ 8E 0449 - TNQ 8E 0453 - TNQ 8E 0454 -
TNQ 8E 0461 - TNQ 8E0499
017040017 - EUR 51169 - TNQ 1417 - TNQ 1426 - TNQ 1458 - TNQ 1621 - TNQ 1629 1 - TNQ 1633 - TNQ 1634 - 1011
TNQ 1672 -TNQ 1684
TC 150 E 1012
TNQ 1603 1013
CODE
ORIGINAL SAMSUNG MODELS
33004 540 031 - 3F14 00031 040 - 3F14 00031 170 - 3F14 00031 181 - 3F14 00032 140 - 3F14 00033060 - 1014
3F14 00033 071 - 3F14 00034 140 - 3F14 00034 141 - 3F14 00034 840 - 931234567890 - RM 109 - RM 113
32199 101 020 - 33004 430 241 - 3F14 0000 313 - 3F14 00003 330 - 3F14 00004 250 - 3F14 00007250 - 1015
3F14 00007 253 - 3F14 00007 311 - 3F14 00007 313 - 3F14 00007 330/II - 3F14 00009 103 - M 701 - REM 07 -
REM 101 - REM 23 - RF 1400009103 - RM 101 - TM 07
3F14 026 050 1016
3F14 00007 330 - 3F14 00024060 - 3F14 00034 790 - CB 528 Z - CH 116 - RM 103 1017
3F14 00007 010 - 3F14 00007410 - RM 097 - 1018
610 048 5891 1019
3F14 00016 040 - 3GB B600649 1020
39202 206 060 - 39202 206 160 1021
RM 100 1022
3F14 00022 112 1023
3F14 00038 091 - 3F14 00038092 - 3F14 00038 092/I - 3F14 00098091 - CF 5035 Z - CJ 044 1024
INFR.REM.CONTR./I 1025
3F14 00040 141 1026
ALCUNI MODELLI / SOME MODELS 1027
ALCUNI MODELLI / SOME MODELS 1028
CODE
N.E. SN 9100 (GB) 13-07-2000 12:33 Pagina 5

6
TAB. C - BRANDS AND CODES OF THE VIDEO RECORDERS
ACCENT 2027
ADMIRAL 2020
ADYSON 2021
AIM 2041
AIOSTAY 2054
AIWA 2031 2037 2054
AKAI 2009 2010 2013 2022
2029 2032 2033 2040
AKASHI 2027
ALBA 2021
AMSTRAD 2054
ANGLO 2054
ANITECH 2021 2080
APHEL SOUND 2054
ASA 2017 2054 2080
ASTRA 2054
ASUKA 2017
ATLANTIC 2017 2020
AUDIO DYNAMIC 2025
AUDIOSONIC 2017 2021 2027
AUTHENTIC 2013
AUTOVOX 2017 2080
AWA 2040
AWATRON 2054
BAIRD 2013
BANG & OLUFSEN 2013 2080
BAUER - BOSCH 2009 2012 2080
BEAULIEU 2080
BLAUPUNKT 2009 2010 2012 2053
2074
BLUESTAR 2021
BONDSTEC 2021 2027
BRANDT>>THOMSON
BRAUN 2053
BRIONVEGA 2004 2013 2020
BRUNS 2021 2027
BUSH 2021 2027
C G E 2013 2020 2054
CANON 2012 2053
CASIO 2054
CGM 2020
CIE 2028
CIMLINE 2027
CITIZEN 2017
CONDOR 2020
CONT. EDISON 2004 2013
CORVUS 2054
CROWN 2027 2054
DAEWOO 2016
DANSAI 2027
DE GRAAF 2020 2043 2054 2080
DECCA 2013 2054 2080
DEMA COLOR 2020
DOMOH 2017
DUAL 2013 2054 2080
DUMONT 2020 2054 2080
DYNATECH 2054
EDAN LINE 2020
EDISON 2027
ELBE 2017 2020 2025 2054
ELTA 2021 2027 2054
EMERSON 2017 2020 2054
ESSELTE 2027 2054
EUMIG 2020
EXCEL 2020
FAIR VIDEO 2017
FAIRCHILD 2043
FENNER 2027
FIDELITY 2005 2027 2054
FINLANDIA 2020 2080
FINLUX 2001 2017 2020 2043
2053 2054 2080
FIRST LINE 2017 2027 2054
FISHER 2020
FORMENTI 2001 2017 2020 2080
FUJITSU 2054
FUNAI 2027 2054
GBC 2001 2027
GE 2013
GEC 2004 2027 2080
GELOSO 2001 2021 2027
GENERAL TECHNIC 2012 2021 2027 2054
GOLDHAND 2021 2027
GOLDMEDAL 2027 2054
GOLDSTAR 2017 2025 2054
GOODMANS 2027 2054
GR 15 2027
GRANADA 2004 2013 2020 2053
2080
GRANDIN 2017 2027
GRUNDING 2009 2010 2012
HANSEATIC 2009 2017 2025 2027
2080
HANTAREX 2017
HARMAN/KARDON 2025
HCM 2027
HINARI 2021 2027
HITACHI 2004 2013 2018 2019
2043 2054
HMV 2013
HYPER 2027
IMPERIAL 2020 2030 2054
INNO HIT 2027 2030
INTERBUY 2027
INTERVIDEO 2017 2054
INTERVISION 2021 2025 2027 2054
IRRADIO 2017 2020 2027 2080
ITT/NOKIA 2004 2005 2013 2020
2030 2040 2081
JASON 2017
JVC 2013 2067 2069 2070
2071 2072
K-MART 2017
KAISUI 2027
KAMBROOK 2054
KANSAI 2021 2027 2054
KENDO 2028
KENWOOD 2013 2020 2025
KIC 2054
KOENIG 2001 2030
KOERTING 2080
KRONNE 2025
KTV 2017
KUBA ELECTRONIC 2009 2013 2017 2020
2053 2054
KUNYA 2013
LAVIS 2027
LENCO 2027
LENOIR 2017 2020
LEYCO 2027 2055
LLOYD 2004 2054
LLOYD’S 2013
LOEWE OPTA 2012 2017 2080
LOGIK 2040
LUXON 2027 2054
LUXOR 2004 2014 2020
M ELECTRONIC 2017 2021 2025 2027
2054 2080
MAGNADYNE 2001 2004 2013 2017
2020
MAGNASONIC 2020
MANESTH 2027 2054
MARANTZ 2012 2017 2080
MARQUANT 2021
MARTA 2017
MATSUI 2004 2028
MAXAM 2027
MAXELL 2027
MAXIMAL 2020
MEMOREX 2017 2020 2054
MERCURY 2017
METZ 2009 2010 2011 2012
MINERVA>>GRUNDING
MINOLTA 2013 2018 2043
MITSUBISHI 2010 2014 2051
MONEXE 2054
MTC 2054
MULTITECH 2027 2027 2054 2080
MURPHY 2054
NAKAMURA 2054
NEC 2013 2013
NECKERMANN 2004 2012 2013 2020
2030 2043 2080
NECOLA 2017
NEI 2080
NESCO 2054
NIKKAI 2017
NOKIA >>ITT/NOKIA
NORDMENDE 2001 2004 2005 2013
2057 2058 2059 2060
2067
OCEANIC 2004 2006 2020 2022
2081
OKANO 2027
OLYMPUS 2053
OMEGA 2054
ORION 2028 2034 2035 2037
2054 2055 2081
OSAKI 2017 2027 2054
OSIO 2017
OTTO VERSAND 2001 2009 2010 2025
2080
PALLADIUM 2004 2012 2013 2020
2025 2043 2054 2080
PALSONIC 2017 2054
PANASONIC 2004 2052 2053 2057
2074
PANORAMA 2017
PATHE CINEMA 2012
PATHE MAR.>>THOMSON
PCM 2017
PENTAX 2043
PERDIO 2054
PHILCO 2013 2020 2025 2054
PHILIPS 2006 2012 2076 2077
2080 2083
PHONOLA>>PHILIPS
PILOT 2017
PIONEER 2013 2038 2039 2043
2080 2083
PLAYSONIC 2020
PORTLAND 2017
PROFEX 2021
PROLINE 2027 2054 2080
PROSCO 2017 2054
PYE>PHILIPS
QUELLE>UNIVERSUM
QUALCRAFT 2040 2054
QUARTZ 2020
QUASAR 2017
RADIALVA 2017
RADIONETTE 2004 2017
RANK ARENA 2013
REALISTIC 2017 2020 2053 2054
REX>SELECO
RFT 2021 2027
ROADSTAR 2017 2027 2054
ROYAL 2027
SABA 2004 2013 2057 2060
2062 2067 2069
SAISHO 2054
SALORA 2005 2014 2020 2051
2080
SAMBERS 2017 2054
SAMSUNG 2020 2030 2040 2042
SANSUI 2013 2027
SANYO 2006 2020 2026
SAVEMA 2017
SCHAUB L.(ITT) 2004 2017 2020
SCHNEIDER 2017 2027 2030 2043
2054 2080
SCOTT 2017 2020
SEG 2021 2027 2030 2054
SELECO 2004 2013 2080
SENTRA 2017 2027 2040
SETRON 2027
SHARP 2006 2007 2017 2054
SHINKO 2027 2054
SHINTOM 2027 2054
SIEMENS 2009 2010 2012 2020
N.E. SN 9100 (GB) 13-07-2000 12:34 Pagina 6

7
TAB. C - BRANDS AND CODES OF THE VIDEO RECORDERS
SILVA 2017
SILVER 2020
SIMKO 2054
SINGER 2020 2023 2030
SINUDYNE 2028 2037 2080
SONAMEC 2054
SONITRON 2017
SONOKO 2020
SONY 2015 2023 2044 2044
2045 2046
SPECIAL 2017
STARLITE 2017
STERN>SELECO
STRONG 2027 2054
STZ 2054
SUNSTAR 2054
SUPERTEC 2054
SUPRA 2017 2027 2040 2054
SYLVANIA 2054
SYMPHONIC 2054
TANDY 2017 2027 2054 2080
TATUNG 2013 2054 2080
TEAK 2013 2054
TEC 2020 2027 2054
TECHLINE 2027
TECHNICS 2052 2053 2074
TEDELEX 2025 2028
TEF 2013
TEKNIKA 2017 2054
TELEAVIA>>THOMSON
TELEFUNKEN 2013 2058 2059 2060
2062 2063 2067
TELERENT 2013 2053 2054
TELESTAR 2027 2040
TELETECH 2027
TELEVIDEON 2001 2020
TEMPEST 2040
TENOSAL 2027
TENSAI 2017 2021 2027 2054
THOMSON 2013 2058 2059 2060
2062 2063 2067
THORN 2004 2005 2010 2013
2056 2077
TOKAI 2017 2027
TOSHIBA 2013 2023 2024 2036
TOTEVISION 2017
TOWADA 2021 2027
TRANSONIC 2032
TTR 2013
UHER 2013 2030 2043
ULTRAVOX 2001 2004 2020
UNIC RADIO 2027 2054
UNIVERSUM 2004 2009 2010 2012
2013 2017 2020 2027
2030 2043 2053 2054
2080
URANYA 2004 2017 2020
VECTOR RESEARCH 2025
VICTOR 2013
VIDAR 2020
VIDEO E.CLUB 2020
VIDEO TECHNIK 2027 2054
VIDION 2020
VIDITAL 2004
WELTBLICK 2017
WHITE WESTING 2004 2017 2020
YAMAHA 2013 2025
YOKO 2017 2021 2027 2030
2054
ZANELA 2027 2054
N.E. SN 9100 (GB) 13-07-2000 12:37 Pagina 7

8
GUARANTEE:
We guarantee that this product will be free from defects for a period of one year from the date of purchase.
DATE OF PURCHASE
VISA Electronics S.r.L. - Via S. Cornelia, 11 - 00060 Formello (ROMA)
Varigrafica ALTO LAZIO - Cod. 771383
SONY
SECONDE FUNZIONI
PANASONIC
SECONDE FUNZIONI
Fig. 4
Fig. 2 Fig. 3
SAMSUNG
SECONDE FUNZIONI
N.E. SN 9100 (GB) 13-07-2000 12:40 Pagina 8
