VISIO BW-108P AW User manual

NO.011
Building Wash
BW-108P AW
User Guide
Advanced LED Technology

BW-108P AW
1-
TABLE OF CONTENTS
1. Safety Instruction
2. Technical Specification
3. Main Function
4. How To Control The Unit
5. Troubleshooting
6. Fixture Cleaning

EC Declaration of Conformity
We declare that our products (lighting equipments) comply with the
following specification and bears CE mark in accordance with the
provision of the Electromagnetic Compatibility (EMC) Directive
89/336/EEC.
EN55014-2: 1997A1: 2001, EN61000-4-2: 1995; EN61000-4-3: 2002;
EN61000-4-4: 1995; EN61000-4-5: 1995, EN61000-4-6: 1996,
EN61000-4-11: 1994.
&
Harmonized Standard
EN60598-1: 2000+ALL: 2000+A12: 2002
Safety of household and similar electrical appliances
Part 1: General requirements
BW-108P AW
2-
Accessories:
Signal cable 2pcs
)0.36m Male water proof connector + female XLR connector cable x
1pc
)0.36m Female water proof connector + male XLR connector cable x
1pc
Power cable 1pc
)1.5m Water proof connector + plug x 1pc
Option (sold separately):
)10m Power cable (water proof connector male/female)
)Signal cables for linking fixtures, available length: 1m (CCT-1), 2m
(CCT-2), 5m (CCT-5) or 10m (CCT-10)
1. Safety Instruction
WARNING
yPlease keep this User Guide for future consultation. If you sell the unit to another
user, be sure that they also receive this instruction booklet.
yUnpack and check carefully there is no transportation damage before using the
unit.
yBefore operating, ensure that the voltage and frequency of power supply match
the power requirements of the unit.
yIt’s important to ground the yellow/green conductor to earth in order to avoid
electric shock.
ySuitable for both indoor & outdoor use.
yThe unit must be installed in a location with adequate ventilation, at least 50cm
from adjacent surfaces.
yDisconnect mains power before replacement or servicing.
yMake sure there is no flammable materials close to the unit while operating as it is
fire hazard.
Please read carefully the instruction which includes important
information about the installation, usage and maintenance.

BW-108P AW
3-
yUse safety cable when fixes this unit under ceiling or on the truss.
yMaximum ambient temperature is ta: 40 . Don’t operate it where the temperature℃
is higher than this.
yUnit surface temperature may reach up to 60 . Don’t touch the housing℃
bare-hand during its operation. Turn off the power and allow about 15 minutes for
the unit to cool down before replacing or serving.
yIn the event of serious operating problem, stop using the unit immediately. Never
try to repair the unit by yourself. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical
assistance center. Always use the same type spare parts.
yDo not touch any wire during operation as high voltage might be causing electric
shock.
Warning
yDo not open the unit within five minutes after switching off.
yMake sure that the housing is firmly closed and all screws are tightly fastened
when operate.
yDo not connect in series much more than 4 units.
Caution
There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repair yourself. In the unlikely event your unit may require service,
please contact your nearest dealer.
Installation
The unit should be mounted via its screw holes on the bracket. Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating. Always
ensure that the structure to which you are attaching the unit is secure and is able
to support a weight of 20 times of the unit.
For power supply, do not connect in series much more than 4 units, use
another mains supply for next 4 units.
BW-108P AW
12-
5. Troubleshooting
Following are a few common problems that may occur during operation. Here
are some suggestions for easy troubleshooting:
A. The unit does not work, no light output
1. Check the connection of power.
2. Measure the mains voltage on the main connector.
B. Not responding to DMX controller
1. Check DMX connectors, cables to see if link properly.
2. Check the address settings.
3. If you have intermittent DMX signal problems, check the pins on connectors of
the unit or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that
may cause damage or interference to DMX interface circuit.
7. Fixture Cleaning
The cleaning of and external optical lenses must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the
fixture operates: damp, smoky or particularly dirty surrounding can cause greater
accumulation of dirt on the unit’s optics.
yClean with soft cloth using normal glass cleaning fluid.
yAlways dry the parts carefully.
yClean the external optics at least every 20 days.

BW-108P AW
11-
4.4 DMX512 Connection
1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin
adapter-cable.
2. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120
ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug
and plug it in the DMX-output of the last unit.
3. Connect the unit together in a `daisy chain` by XLR plug from the output of the
unit to the input of the next unit. The cable can not branched or split to a `Y`
cable. DMX 512 is a very high-speed signal. Inadequate or damaged cables,
soldered joints or corroded connectors can easily distort the signal and shut
down the system.
4. The DMX output and input connectors are pass-through to maintain the DMX
circuit, when one of the units’ power is disconnected.
5. Each lighting unit needs to have an address set to receive the data sent by the
controller. The address number is between 0-511 (usually 0 & 1 are equal to 1).
6. The end of the DMX 512 system should be terminated to reduce signal errors.
7. 3 pin XLR connectors are more popular than 5 pin XLR.
3 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+)
5 pin XLR: Pin 1: GND, Pin 2: Negative signal (-), Pin 3: Positive signal (+),
Pin 4/5: Not used
BW-108P AW
4-
2. Technical Specification
yDMX 2/2 channels selectable
yLED display with password protection at the rear panel
yCome with great built-in programs (16 chases) and 3 editable chases
yUsing the latest LED technology makes important energy (cost) savings compared
to traditional halogen fixtures.
yCompletely silent, the projector is cooled by natural air convection without fan
yThermal sensor in LED PCB to protect LEDs from over heated.
yWith waterproof IP66 housing, it perfect to illuminate all kinds buildings like: hotels,
shops, discotheques, stage, amusement parks, fairground, museum, etc.
yVoltage:100-240V~50/60Hz
yPower consumption: 150W
yLight source: 108×1W LEDs (Amber:36pcs, Cool White: 72psc)
50,000hrsrated
yBeam Angle: as indicated on the product label (10°/25°/30° x 65° are available)
yDimension: 582×188×251 mm
yWeight: 18.4 kgs

BW-108P AW
5-
3. How To Control The Unit
3.1 Rear Panel
Display-water proof touch screen
Touch screen to choose and show menus
Power
Water proof connectors for power input/output
DMX input/output
Water proof connectors for DMX 512 operation, use 3-pin XLR plug cable to link the
unit together
3.2 Main Function
To select any of the given functions, press the MENU button up to when the required
one is showing on the display. Select the function by ENTER button and the display
will blink. Use DOWN and UP button to change the mode. Once the required mode
has been selected, press the ENTER button to setup or it will automatically return to
the main functions without any change after idling 8 seconds. To go back to the
functions without any change press the MENU button. The main functions are
showing below:
Once you set to , after running in show mode for 5
minutes without any change or restarting the unit, the key board
become locked. Press ENTER button to enable the menu, the display
will show , press UP and DOWN button until it shows ,
then
p
ress ENTER to unlock.
BW-108P AW
10-
4.3 DMX 512 Configuration

BW-108P AW
9-
ENTER button and the display will show the number of working hours of the unit. To
go back to the functions press the MENU button.
Software version
Press the MENU button up to when the is blinking on the display. Pressing
ENTER button and the display will show the version of software of the unit. To go
back to the functions press the MENU button.
4. How To Control The Unit
You can operate the unit in two ways:
1. By master/slave built-in preprogram function
2. By universal DMX controller
No need to turn the unit off when you change the DMX address, as new DMX
address setting will be effected at once. Every time you turn the unit on, it will show
on the display, after that the unit will be ready to receive DMX signal or run
the built in programs.
4.1 Master/Slave Built In Preprogrammed Function
By linking the units in master/slave connection, the first unit will control the other
units to give an automatic show. This function is good when you want an instant show.
You have to adjust the fade time and wait time for the first unit. Its DMX input jack will
have nothing plugged into. The other units will be slave mode automatic.
4.2 Universal DMX Controller
Use universal DMX controller to control the units, you have to set DMX address from
1 to 512 channel so that the units can receive DMX signal.
Press the MENU button up to when the is showing on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to change the
DMX512 address. Once the address has been selected, press and keep ENTER
button up to when the display stops blinking or storing automatically 8 seconds later.
To go back to the functions without any change press the MENU button again.
Please refer to the following diagram to address your DMX512 channel for the first 4
units：
BW-108P AW
6-
DMX 512 Address Setting
Press the MENU button up to when the is shown on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to change the
DMX 512 address. Once the address has been selected, press ENTER button to
setup or automatically return to the main functions without any change after 8
seconds. Back to the previous functions without any change press MENU button.
Channel Mode
Press the MENU button up to when the is shown on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to select the
(2 channels) or (2 Channels) mode. Once the mode has been
selected, press the ENTER button to setup or automatically return to the main
functions without any change after 8 seconds. To go back to the previous functions
without any change press the MENU button.

BW-108P AW
7-
ShowMode
Press the MENU button up to when the is showing on the display. Press the
ENTER button，will blinking on the display, use DOWN and UP button adjust
the fade time (0~255), press ENTER button to store and will blinking on the
display, use DOWN and UP button adjust the wait time (0~255), press ENTER button
to store or automatically return to the main functions without any change after 8
seconds. To go back to the previous functions without any change press the MENU
button.
Blackout Mode
Press the MENU button up to when the is showing on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to select the
(yes blackout) or (no blackout) mode. Once the mode has been
selected, press the ENTER button to setup or automatically return to the main
functions without any change after 8 seconds. To go back to the previous functions
without any change press the MENU button.
Manual Mode
Press the MENU button up to when the is showing on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to select the
(amber) or (white) or (dimmer) or (strobe). Once
the selected, press the ENTER button to confirm and use DOWN and UP button to
adjust the value or automatically return to the main functions without any change
after 8 seconds. To go back to the previous functions without any change press the
MENU button.
For strobe, the function corresponds to the value shown below:
value function value function
0-7 OFF 182-189 Open
8-15 Open 190-231 Slow close fast open
16-131 Strobe from slow to fast 232-239 Open
132-139 Open 240-247 Random strobe
140-181 Slow open fast close 248-255 Open
BW-108P AW
8-
Display Inversion
Press the MENU button up to when the is showing on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to select the
(normal) or (inversion) mode. Once the mode has been selected,
press the ENTER button to setup or automatically return to the main functions
without any change after 8 seconds. To go back to the previous functions without any
change press the MENU button.
Key Board Lock
Press the MENU button up to when the is showing on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to select the
(lock the key board) or (normal). Once the mode has been selected,
press the ENTER button to setup or automatically return to the main functions
without any change after 8 seconds. To go back to the previous functions without any
change press the MENU button.
Self-Test
Press the MENU button up to when the is blinking on the display. Pressing
ENTER button and the unit will run self-test by built-in program. To go back to the
previous functions press the MENU button.
LED
Press the MENU button up to when the is shown on the display. Pressing
ENTER button and the display will blink. Use DOWN and UP button to select the
(display on) or (display off) mode. Once the mode has been
selected, press ENTER button to setup or automatically return to the main functions
without any change after 8 seconds. To go back to the previous functions without any
change press the MENU button.
Temperature Test
Press the MENU button up to when the is blinking on the display. Pressing
ENTER button and the display will show the temperature of the unit. To go back to
the functions press the MENU button again.
Fixture Hours
Press the MENU button up to when the is blinking on the display. Pressing
